Cisco Surge-Gap Multimedia Tap Operating instructions

4013399Rev C
Surge-Gap Multimedia Tap
Installation and Operation Guide

For Your Safety
Explanation of Warning and Caution Icons
Avoid personal injury and product damage! Do not proceed beyond any symbol
until you fully understand the indicated conditions.
The following warning and caution icons alert you to important information about
the safe operation of this product:
You may find this symbol in the document that accompanies this product.
This symbol indicates important operating or maintenance instructions.
You may find this symbol affixed to the product. This symbol indicates a live
terminal where a dangerous voltage may be present; the tip of the flash points
to the terminal device.
You may find this symbol affixed to the product. This symbol indicates a
protective ground terminal.
You may find this symbol affixed to the product. This symbol indicates a
chassis terminal (normally used for equipotential bonding).
You may find this symbol affixed to the product. This symbol warns of a
potentially hot surface.
You may find this symbol affixed to the product and in this document. This
symbol indicates an infrared laser that transmits intensity-modulated light
and emits invisible laser radiation or an LED that transmits intensity-
modulated light.
Important
Please read this entire guide. If this guide provides installation or operation
instructions, give particular attention to all safety statements included in this guide.

Notices
Trademark Acknowledgments
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its
affiliates in the U.S. and other countries. A listing of Cisco's trademarks can be found
at www.cisco.com/go/trademarks.
Third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between
Cisco and any other company. (1009R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Copyright
© 2006,2008, 2012 Cisco and/or its affiliates. All rights reserved. Printed in the United
States of America.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.

4013399 Rev C iii
Contents
Important Safety Instructions v
Chapter 1 Introducing the Surge-Gap Multimedia Tap System with
PDU 1
Description of the Surge-Gap Multimedia Tap System ..................................................... 3
Surge-Gap Multimedia Tap System Diagrams....................................................... 3
Features of the Surge-Gap Multimedia Tap............................................................ 4
2/4-way Surge-Gap Multimedia Tap Standard Housing .................................................. 5
2/4/8-way Surge-Gap Multimedia Tap Full Profile Housing .......................................... 6
2/4-way Surge-Gap Multimedia Tap Standard Faceplate................................................. 7
2/4/8-way Surge-Gap Multimedia Tap Full Profile Faceplate......................................... 8
2/4-way Surge-Gap Multimedia Standard Tap with Coax PDU...................................... 9
2/4-way Surge-Gap Multimedia Standard Tap with Twisted Pair PDU ...................... 10
2/4/8-way Surge-Gap Multimedia Full Profile Tap with Coax PDU............................ 11
2/4/8-way Surge-Gap Multimedia Full Profile Tap with Twisted Pair PDU .............. 12
Power Distribution Unit ....................................................................................................... 13
Types of PDUs........................................................................................................... 13
Features of the PDU.................................................................................................. 13
2/4-way Coax PDU .................................................................................................. 14
2/4-way Twisted Pair PDU ..................................................................................... 14
Chapter 2 Installing the Tap 15
Tools and Torque Specifications .......................................................................................... 16
Tools Required .......................................................................................................... 16
Torque Specifications ............................................................................................... 16
Torque Sequence....................................................................................................... 17
Preparing for Installation...................................................................................................... 18
To Prepare the Connectors ...................................................................................... 18
Removing the Faceplate........................................................................................................ 20
To Remove the Faceplate ......................................................................................... 20
To Remove a Faceplate with Feeder Cables Connected (Hot Install) ............... 21
Installing the Tap Housing on a Strand.............................................................................. 23
To Install the Tap Housing on a Strand................................................................. 23
Installing the Tap Housing in a Pedestal............................................................................ 25
To Install the Tap Housing in a Pedestal............................................................... 25
Mounting the Faceplate ........................................................................................................ 27
To Mount the Faceplate ........................................................................................... 27
Installing the PDU ................................................................................................................. 30
Strand Mounting Configuration ............................................................................. 30

Contents
iv 4013399 Rev C
Pedestal Mounting Configuration.......................................................................... 31
Installing the Coax PDU ....................................................................................................... 32
To Install the Coax PDU on a Strand-Mounted Surge-Gap Multimedia
Tap ........................................................................................................................... 33
To Install the Coax PDU on a Pedestal-Mounted Surge-Gap
Multimedia Tap ..................................................................................................... 34
To Attach the Faceplate to the Housing ................................................................ 35
Installing the Twisted Pair PDU .......................................................................................... 37
To Install the Twisted Pair PDU on a Strand-Mounted Surge-Gap
Multimedia Tap ..................................................................................................... 38
To Install the Twisted Pair PDU on a Pedestal-Mounted Surge-Gap
Multimedia Tap ..................................................................................................... 39
To Attach the Faceplate to the Housing ................................................................ 41
To Attach the Twisted Pair Cable........................................................................... 42
Chapter 3 Customer Support Information 47
Appendix A Technical Information 49
Specifications .......................................................................................................................... 50
Dimensions ................................................................................................................ 50
Surge-Gap Multimedia Taps Electrical.................................................................. 50
PDU Electrical ........................................................................................................... 51
Mechanical ................................................................................................................. 51
Part Numbers ......................................................................................................................... 52
Surge-Gap Multimedia Taps................................................................................... 52
PDUs........................................................................................................................... 55
Index 57

Important Safety Instructions
4013399 Rev C v
Important Safety Instructions
Read and Retain Instructions
Carefully read all safety and operating instructions before operating this equipment,
and retain them for future reference.
Follow Instructions and Heed Warnings
Follow all operating and use instructions. Pay attention to all warnings and cautions
in the operating instructions, as well as those that are affixed to this equipment.
Terminology
The terms defined below are used in this document. The definitions given are based
on those found in safety standards.
Service Personnel - The term service personnel applies to trained and qualified
individuals who are allowed to install, replace, or service electrical equipment. The
service personnel are expected to use their experience and technical skills to avoid
possible injury to themselves and others due to hazards that exist in service and
restricted access areas.
User and Operator - The terms user and operator apply to persons other than service
personnel.
Ground(ing) and Earth(ing) - The terms ground(ing) and earth(ing) are synonymous.
This document uses ground(ing) for clarity, but it can be interpreted as having the
same meaning as earth(ing).
Electric Shock Hazard
This equipment meets applicable safety standards.
WARNING:
To reduce risk of electric shock, perform only the instructions that are
included in the operating instructions. Refer all servicing to qualified service
personnel only.
Electric shock can cause personal injury or even death. Avoid direct contact with
dangerous voltages at all times.
Know the following safety warnings and guidelines:
Only qualified service personnel are allowed to perform equipment installation
or replacement.

Important Safety Instructions
vi 4013399 Rev C
Only qualified service personnel are allowed to remove chassis covers and access
any of the components inside the chassis.
Equipment Placement
WARNING:
Avoid personal injury and damage to this equipment. An unstable mounting
surface may cause this equipment to fall.
To protect against equipment damage or injury to personnel, comply with the
following:
Install this equipment in a restricted access location (access restricted to service
personnel).
Make sure the mounting surface or rack is stable and can support the size and
weight of this equipment.
Strand (Aerial) Installation
CAUTION:
Be aware of the size and weight of strand-mounted equipment during the
installation operation.
Ensure that the strand can safely support the equipment’s weight.
Pedestal, Service Closet, Equipment Room or Underground Vault Installation
WARNING:
Avoid the possibility of personal injury. Ensure proper handling/lifting
techniques are employed when working in confined spaces with heavy
equipment.
Ensure this equipment is securely fastened to the mounting surface or rack
where necessary to protect against damage due to any disturbance and
subsequent fall.
Ensure the mounting surface or rack is appropriately anchored according to
manufacturer‟s specifications.
Ensure the installation site meets the ventilation requirements given in the
equipment‟s data sheet to avoid the possibility of equipment overheating.
Ensure the installation site and operating environment is compatible with the
equipment‟s International Protection (IP) rating specified in the equipment‟s data
sheet.

Important Safety Instructions
4013399 Rev C vii
Connecting to Utility AC Power
Important: If this equipment is a Class I equipment, it must be grounded.
If this equipment plugs into an outlet, the outlet must be near this equipment,
and must be easily accessible.
Connect this equipment only to the power sources that are identified on the
equipment-rating label, which is normally located close to the power inlet
connector(s).
This equipment may have two power sources. Be sure to disconnect all power
sources before working on this equipment.
If this equipment does not have a main power switch, the power cord connector
serves as the disconnect device.
Always pull on the plug or the connector to disconnect a cable. Never pull on the
cable itself.
Connection to Network Power Sources
Refer to this equipment‟s specific installation instructions in this manual or in
companion manuals in this series for connection to network ferro-resonant AC
power sources.
AC Power Shunts
AC power shunts may be provided with this equipment.
Important: The power shunts (where provided) must be removed before installing
modules into a powered housing. With the shunts removed, power surge to the
components and RF-connectors is reduced.
CAUTION:
RF connectors and housing seizure assemblies can be damaged if shunts are
not removed from the equipment before installing or removing modules from
the housing.
Grounding (Utility AC Powered Equipment in Pedestals, Service Closets, etc.)
This section provides instructions for verifying that the equipment is properly
grounded.
Safety Plugs (USA Only)
This equipment is equipped with either a 3-terminal (grounding-type) safety plug or
a 2-terminal (polarized) safety plug. The wide blade or the third terminal is provided
for safety. Do not defeat the safety purpose of the grounding-type or polarized
safety plug.

Important Safety Instructions
viii 4013399 Rev C
To properly ground this equipment, follow these safety guidelines:
Grounding-Type Plug - For a 3-terminal plug (one terminal on this plug is a
protective grounding pin), insert the plug into a grounded mains, 3-terminal
outlet.
Note: This plug fits only one way. If this plug cannot be fully inserted into the
outlet, contact an electrician to replace the obsolete 3-terminal outlet.
Polarized Plug - For a 2-terminal plug (a polarized plug with one wide blade
and one narrow blade), insert the plug into a polarized mains, 2-terminal outlet
in which one socket is wider than the other.
Note: If this plug cannot be fully inserted into the outlet, try reversing the plug.
If the plug still fails to fit, contact an electrician to replace the obsolete 2-terminal
outlet.
Grounding Terminal
If this equipment is equipped with an external grounding terminal, attach one end of
an 18-gauge wire (or larger) to the grounding terminal; then, attach the other end of
the wire to a ground, such as a grounded equipment rack.
Safety Plugs (European Union)
Class I Mains Powered Equipment –Provided with a 3-terminal AC inlet and
requires connection to a 3-terminal mains supply outlet via a 3-terminal power
cord for proper connection to the protective ground.
Note: The equipotential bonding terminal provided on some equipment is not
designed to function as a protective ground connection.
Class II Mains Powered Equipment –Provided with a 2-terminal AC inlet that
may be connected by a 2-terminal power cord to the mains supply outlet. No
connection to the protective ground is required as this class of equipment is
provided with double or reinforced and/or supplementary insulation in
addition to the basic insulation provided in Class I equipment.
Note: Class II equipment, which is subject to EN 50083-1, is provided with a
chassis mounted equipotential bonding terminal. See the section titled
Equipotential Bonding for connection instructions.
Equipotential Bonding
If this equipment is equipped with an external chassis terminal marked with the IEC
60417-5020 chassis icon ( ), the installer should refer to CENELEC standard EN
50083-1 or IEC standard IEC 60728-11 for correct equipotential bonding connection
instructions.

Important Safety Instructions
4013399 Rev C ix
General Servicing Precautions
WARNING:
Avoid electric shock! Opening or removing this equipment’s cover may
expose you to dangerous voltages.
CAUTION:
These servicing precautions are for the guidance of qualified service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you
are qualified to do so. Refer all servicing to qualified service personnel.
Be aware of the following general precautions and guidelines:
Servicing - Servicing is required when this equipment has been damaged in any
way, such as power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into this equipment, this equipment has been exposed to rain
or moisture, does not operate normally, or has been dropped.
Wristwatch and Jewelry - For personal safety and to avoid damage of this
equipment during service and repair, do not wear electrically conducting objects
such as a wristwatch or jewelry.
Lightning - Do not work on this equipment, or connect or disconnect cables,
during periods of lightning.
Labels - Do not remove any warning labels. Replace damaged or illegible
warning labels with new ones.
Covers - Do not open the cover of this equipment and attempt service unless
instructed to do so in the instructions. Refer all servicing to qualified service
personnel only.
Moisture - Do not allow moisture to enter this equipment.
Cleaning - Use a damp cloth for cleaning.
Safety Checks - After service, assemble this equipment and perform safety
checks to ensure it is safe to use before putting it back into operation.
Electrostatic Discharge
Electrostatic discharge (ESD) results from the static electricity buildup on the human
body and other objects. This static discharge can degrade components and cause
failures.
Take the following precautions against electrostatic discharge:
Use an anti-static bench mat and a wrist strap or ankle strap designed to safely
ground ESD potentials through a resistive element.
Keep components in their anti-static packaging until installed.

Important Safety Instructions
x 4013399 Rev C
Avoid touching electronic components when installing a module.
Fuse Replacement
To replace a fuse, comply with the following:
Disconnect the power before changing fuses.
Identify and clear the condition that caused the original fuse failure.
Always use a fuse of the correct type and rating. The correct type and rating are
indicated on this equipment.
Batteries
This product may contain batteries. Special instructions apply regarding the safe use
and disposal of batteries:
Safety
Insert batteries correctly. There may be a risk of explosion if the batteries are
incorrectly inserted.
Do not attempt to recharge „disposable‟ or „non-reusable‟ batteries.
Please follow instructions provided for charging „rechargeable‟ batteries.
Replace batteries with the same or equivalent type recommended by
manufacturer.
Do not expose batteries to temperatures above 100°C (212°F).
Disposal
The batteries may contain substances that could be harmful to the environment
Recycle or dispose of batteries in accordance with the battery manufacturer‟s
instructions and local/national disposal and recycling regulations.
The batteries may contain perchlorate, a known hazardous substance, so special
handling and disposal of this product might be necessary. For more information
about perchlorate and best management practices for perchlorate-containing
substance, see www.dtsc.ca.gov/hazardouswaste/perchlorate.

Important Safety Instructions
4013399 Rev C xi
Modifications
This equipment has been designed and tested to comply with applicable safety, laser
safety, and EMC regulations, codes, and standards to ensure safe operation in its
intended environment. Refer to this equipment's data sheet for details about
regulatory compliance approvals.
Do not make modifications to this equipment. Any changes or modifications could
void the user‟s authority to operate this equipment.
Modifications have the potential to degrade the level of protection built into this
equipment, putting people and property at risk of injury or damage. Those persons
making any modifications expose themselves to the penalties arising from proven
non-compliance with regulatory requirements and to civil litigation for
compensation in respect of consequential damages or injury.
Accessories
Use only attachments or accessories specified by the manufacturer.
Electromagnetic Compatibility Regulatory Requirements
This equipment meets applicable electromagnetic compatibility (EMC) regulatory
requirements. Refer to this equipment's data sheet for details about regulatory
compliance approvals. EMC performance is dependent upon the use of correctly
shielded cables of good quality for all external connections, except the power source,
when installing this equipment.
Ensure compliance with cable/connector specifications and associated
installation instructions where given elsewhere in this manual.
EMC Compliance Statements
Where this equipment is subject to USA FCC and/or Industry Canada rules, the
following statements apply:
FCC Statement for Class A Equipment
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when this equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case users will be required to
correct the interference at their own expense.

Important Safety Instructions
xii 4013399 Rev C
Industry Canada - Industrie Canadiene Statement
This apparatus complies with Canadian ICES-003.
Cet appareil est confome à la norme NMB-003 du Canada.
CENELEC/CISPR Statement with Respect to Class A Information Technology Equipment
This is a Class A equipment. In a domestic environment this equipment may cause
radio interference in which case the user may be required to take adequate
measures.

4013399 Rev C 1
Introduction
This guide provides the procedures for installing a Surge-Gap™
Multimedia Tap with a Power Distribution Unit (PDU).
Who Should Use This Guide
This guide is intended for authorized personnel who have experience
working with similar equipment. The personnel should have
appropriate background and knowledge to complete the procedures
described in this guide. Cisco service engineers who help system
operators manage their systems will also find the contents of this
guide useful.
Qualified Personnel
Only appropriately qualified and skilled personnel should attempt to
install, operate, maintain, and service this product.
WARNING:
Allow only qualified and skilled personnel to install, operate,
maintain, and service this product. Otherwise, personal injury or
equipment damage may occur.
1Chapter 1
Introducing the Surge-Gap
Multimedia Tap System with
PDU

2 4013399 Rev C
In This Chapter
Description of the Surge-Gap Multimedia Tap System .................... 3
2/4-way Surge-Gap Multimedia Tap Standard Housing ................. 5
2/4/8-way Surge-Gap Multimedia Tap Full Profile Housing ......... 6
2/4-way Surge-Gap Multimedia Tap Standard Faceplate................ 7
2/4/8-way Surge-Gap Multimedia Tap Full Profile Faceplate........ 8
2/4-way Surge-Gap Multimedia Standard Tap with Coax
PDU........................................................................................................... 9
2/4-way Surge-Gap Multimedia Standard Tap with Twisted
Pair PDU ................................................................................................ 10
2/4/8-way Surge-Gap Multimedia Full Profile Tap with Coax
PDU......................................................................................................... 11
2/4/8-way Surge-Gap Multimedia Full Profile Tap with
Twisted Pair PDU ................................................................................. 12
Power Distribution Unit ...................................................................... 13

Description of the Surge-Gap Multimedia Tap System
4013399 Rev C 3
Description of the Surge-Gap Multimedia Tap
System
The Surge-Gap Multimedia Tap System provides the subscriber with drop powering
capability that is required to support broadband telephony in hybrid fiber/coax
(HFC) networks.
In addition, the Surge-Gap Multimedia Tap System provides enhanced reliability
features that are essential to successful video and telephony service delivery.
Surge-Gap Multimedia Tap System Diagrams
The Surge-Gap Multimedia Tap System consists of the Surge-Gap Multimedia Tap
(faceplate and housing) and the Power Distribution Unit (PDU). There are two types
of PDUs: coax power and twisted pair power. Refer to Power Distribution Unit (on
page 13) for a full description of the PDU. The complete Surge-Gap Multimedia Tap
System for each PDU is shown in the following illustrations.

Chapter 1 Introducing the Surge-Gap Multimedia Tap System with PDU
4 4013399 Rev C
Features of the Surge-Gap Multimedia Tap
The Surge-Gap Multimedia Tap faceplate and housing is similar in form, fit, and
function to traditional taps. However, the Surge-Gap Multimedia Tap offers a
variety of enhanced features essential to the successful delivery of telephony and
other advanced services.
The following are features of the Surge-Gap Multimedia Tap.
Connection Beam AC/RF bypass switch
12 amperes through current rating
Power injection posts
Economical two-step upgrade to customer drop power passing capability
AC blocking capacitors on each port

2/4-way Surge-Gap Multimedia Tap Standard Housing
4013399 Rev C 5
2/4-way Surge-Gap Multimedia Tap Standard
Housing
The following illustration shows the 2/4-way Surge-Gap Multimedia Tap standard
housing.

Chapter 1 Introducing the Surge-Gap Multimedia Tap System with PDU
6 4013399 Rev C
2/4/8-way Surge-Gap Multimedia Tap Full Profile
Housing
The following illustration shows the 2/4/8-way Surge-Gap Multimedia Tap full
profile housing.
