Cisco D9800 Instruction Manual

Installing the D9800 Network Transport Receiver
This section contains the information for technicians installing the Cisco D9800 Network Transport Receiver.
Allow only authorized and qualified service personnel to install, operate, maintain, and service this product.
Otherwise, personal injury or equipment damage may occur.
Warning
•Safety Guidelines, page 1
•Mounting a D9800 Receiver to a Rack, page 2
•Rear Connector Panels, page 3
•Connecting AC Power to the D9800 Receiver, page 5
•Connecting to the Satellite Input, page 6
•Connecting the Input/Output Signals, page 6
•External Alarm System Connector, page 9
•Connecting the Ethernet Management Interface, page 11
•Viewing the Hardware Information, page 11
Safety Guidelines
This section describes general safety guidelines prior to installing and connecting the D9800 receiver.
Cooling
The unit is cooled by the use of internal fans. The air intake is from the front and the air outlet is on the rear.
The inlet air temperature must not exceed 50°C/122°F at any time.Caution
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
1

Grounding or Earthing
You must ensure that the unit is properly connected to ground to meet safety and EMC requirements. Before
any other connection is made, the unit must be connected to protective Ground or Earth via the three wire
power cord of the AC power supply. This connection is mandatory.
Equipotential Bonding
If this equipment is equipped with an external chassis terminal marked with the IEC 5018 chassis icon ( ),
the installer should refer to CENELEC standard EN 50083-1 or IEC standard IEC 60728-11 for correct
equipotential bonding connection instructions.
Elevated Operating Ambient Temperature
Only install this equipment in a humidity- and temperature-controlled environment that meets the requirements
given in this equipment's technical specifications.
If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment may be greater than room ambient temperature. Therefore, install this equipment in an
environment compatible with the manufacturer's maximum rated ambient temperature.
Caution
Mounting a D9800 Receiver to a Rack
The D9800 receiver is a 1U unit with connector access at the rear panel. The receiver is intended for mounting
in a standard 19" rack.
The D9800 receiver is vented from front to back. Multiple units can be stacked in a rack, provided that adequate
cooling is available.
Make sure that the rack is placed on a stable surface. If the rack has stabilizing devices, install these stabilizing
devices before mounting any equipment in the rack.
Avoid personal injury and damage to this equipment. Mounting this equipment in the rack should be such
that a hazardous condition is not caused due to uneven mechanical loading.
Caution
Step 1 Mount L-brackets or equivalent shelving in the rack to support each unit to be installed.
Step 2 Place the receiver in its position in the rack.
Step 3 Mount the receiver securely to the rack by securing the mounting flanges to the rack using four screws.
Step 4 Ensure that the air outlet holes on the back of the receiver are not obstructed to allow air flow from the front to the back
of the chassis.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
2
Installing the D9800 Network Transport Receiver
Grounding or Earthing

Rear Connector Panels
The diagram below shows the rear connector panel of the D9800 base chassis with ASI and MPEGoIP
Input/Output (D9800-SS-MPEGOIP), with SDI (D9800-3G-SDI) and four port satellite input card
(D9800-SAT-GEN1) options installed.
Figure 1: D9800-SS-MPEGOIP Rear Connector Panel, with D9800-3G-SDI and D9800-SAT-GEN1 Options
The diagram below shows the rear connector panel of the D9800 Multi-Stream chassis with ASI and MPEGoIP
(D9800-MS-MPEGOIP), with D9800-SAT-GEN1 option.
Figure 2: D9800-MS-MPEGOIP Rear Connector Panel, with D9800-SAT-GEN1 Option
The table below describes the function and type of the various connectors.
TypeDescriptionConnector
FEach input accepts an LNB signal input. RF1 provides
LNB power for use when no external LNB power source
is available. RF2 to RF4 require an external LNB power
source.
RF1 to RF4
BNCThese are AES-3id outputs. One output for each stereo
channel.
This is only available on single-stream units with
the SDI option installed (D9800-3G-SDI).
Note
AES1 and AES2
Terminal BlocksAudio 1&2 and Audio 3&4 provide two stereo pairs or
four mono channels.
The AUD 3&4 outputs are only available on
single-stream units with the SDI option installed
(D9800-3G-SDI).
Note
AUD 1&2 and AUD 3&4
(Balanced Audio Outputs)
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
3
Installing the D9800 Network Transport Receiver
Rear Connector Panels

TypeDescriptionConnector
BNCThe SDI outputs provide serial digital video with embedded
audio output for applications. The following lists the
supported SDI standards:
•HD-SDI (SMPTE-292M)
•SD-SDI (SMPTE ST 259)
•3G-SDI (SMPTE ST 424)
This is only available on the single-stream units
with the SDI option installed (D9800-3G-SDI).
Note
SDI 1 and SDI 2
BNCThe composite video output provides one SD composite
video output for monitoring applications and downstream
equipment.
This is available on the single-stream units
only.
Note
CVBS (Composite Video
Output)
HDMI Type A
receptacle (female)
The HDMI output is for monitoring purposes only.
This is available on the single-stream units
only.
Note
HDMI
BNCAsynchronous Serial Interface (ASI) input and/or output
ports. The single-stream units have one ASI input port and
one ASI output port. The multi-stream units have two ASI
input and/or output ports.
ASI IN and ASI OUT
(D9800-SS)
ASI I/O 1 and ASI I/O 2
(D9800-MS)
15-pin sub-D
female
Program relay provides programmed responses for alarms,
cue trigger states for ad-insertion equipment, or a cue tone
output for connection to ad-insertion equipment.
This is available on the single-stream units
only.
Note
Cue Tone/Cue Trigger
Relay Output
—
This is not supported in the current release.USB
RJ-45Supports the following network protocols: SSH, HTTPS,
SNMP, Syslog, and NTP.
Management
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
4
Installing the D9800 Network Transport Receiver
Rear Connector Panels

TypeDescriptionConnector
RJ-45This is for MPEGoIP and MPE outputs. The MPEGoIP
output transmits the transport stream encapsulated in IP
packets to a groomer for distribution. The MPEGoIP input
receives its streams from the terrestrial IP network.
The MPE output receives and outputs the IP data packets
from the incoming transport stream. This is only available
on single-stream units (D9800-SS).
D9800-SS: The DATA1 and DATA2 ports are for the
single-stream units with MPEGoIP input and output option
installed (D9800-SS-MPEGOIP). DATA1 and DATA2
are redundant data ports.
D9800-MS: The multi-stream units
(D9800-MS-MPEGOIP) have four IP data ports (DATA1,
DATA2, DATA3, and DATA4). DATA1 and DATA2,
and DATA3 and DATA4 are redundant ports.
DATA1 and DATA2
(D9800-SS)
DATA1 to DATA4
(D9800-MS)
Nut on StudA grounding/earthing point for the receiver for
equipotential bonding (not Safety).
Ground/Earth
Receptacle: IEC
60320 Sheet 14
Connects the receiver to an AC power source.Power
Connecting AC Power to the D9800 Receiver
To operate the receiver, you must connect it to an AC power source. The units are designed for continuous
operation and do not have a power switch. The mains cord and/or DC power supply cable serve(s) as the
mains disconnect device.
The unit is equipped with one power supply located in the rear of the chassis.
The power cord (consisting of appliance coupler, flexible cord, and plug) supplied with this product meets
the requirements for use in the country for which this product was purchased. In general, the power cord must
be approved by an acceptable, accredited agency responsible for evaluation in the country where the product
will be used.
Ensure that at least one end of the power cable(s) remains easily accessible for unplugging, if you need
to switch off the unit. For example: Ensure that the socket outlet is installed near the product.
Caution
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
5
Installing the D9800 Network Transport Receiver
Connecting AC Power to the D9800 Receiver

To avoid electrical shock, connect the three-prong plug on this product to an earth-grounded three-pin
socket outlet only.
Caution
Step 1 Connect the power cord (supplied with the unit) between the rear panel power receptacle and a 100 to 120/200 to 240
V AC, 50/60 Hz power outlet.
Step 2 Ensure that the power cable is connected to protective ground. See Grounding or Earthing, on page 2.
The Application Starting message appears on the front panel. The boot process, for a unit with a typical configuration,
may take up to two to three minutes to initialize. When ready, the front panel displays the startup screen.
Maintenance of EMC Compliance
For EMC protection, shielded cables must be used. Double-shielded (braid/foil or braid/braid) cables should
be used for all ASI I/O, CVBS, SDI, and RF inputs. Single-shield cables are acceptable for all other inputs
and outputs (AES audio, Ethernet). For Audio terminal block and Cue I/O, no shielding is required.
Connecting to the Satellite Input
Step 1 Set the 22 kHz signal and the output voltage, as required.
Step 2 Connect the ASI OUT port to an ASI device for digital tier applications.
Connecting the Input/Output Signals
This section describes how to connect the RF inputs, ASI input, ASI output, video outputs, and audio outputs.
Connecting the RF Inputs
Connect up to four LNB RF cables to the RF connectors labeled RF1 through RF4 on the rear of the unit.
Use 75-ohm (braid/foil or braid/braid), low insertion loss coaxial cable.
Each input accepts an LNB signal input. RF2 to RF4 require an external LNB power source.
Connecting the ASI Input
If desired, connect to the ASI IN port to an asynchronous serial interface for uplink monitoring.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
6
Installing the D9800 Network Transport Receiver
Maintenance of EMC Compliance

Connecting the Video Outputs
The video output connectors are of the BNC type. The interface type is SMPTE-292M and the connector type
is BNC female.
Connecting the Composite Video Output
Connect a video monitor to the CVBS connector. Use a 75-ohm double-braided coax cable.
Connecting the SDI Outputs
Connect rebroadcast equipment to the connectors labeled SDI1 and SDI2, and/or if required, connect them
to a video monitor.
Connecting the HDMI Output
Connect the video monitor to the HDMI connector. Use a HDMI Type A receptacle (female) connector.
Connecting the Audio Outputs
This section describes how to connect digital and balanced audio outputs.
Connecting the Digital Audio Outputs
The configuration of the D9800 receiver outputs two stereo channels. The receiver also supports encoding of
audio embedded in the SDI video signal.
The Interface type is AES-3id and the connector type is BNC female.
The digital audio output is always 75-ohm single-ended.Note
Connect digital audio output broadcast equipment to the AES-3id connectors. The two stereo channels are
useful for Dolby Digital 5.1 pass-through applications. Use a high-quality, double-shielded RG6 coaxial cable.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
7
Installing the D9800 Network Transport Receiver
Connecting the Video Outputs

Connecting the Balanced Audio Output
Step 1 Each row of the terminal blocks has a removable plug. Press down on the appropriate spring loaded terminal release
detent on the plugs and insert wire as required. Release the detent to secure wire.
Step 2 Connect the AUD1 and AUD 2 and AUD 3 and AUD 4 balanced audio outputs to monitoring equipment and/or downstream
equipment. Use a multi-conductor, pluggable cable from the audio 1, 2, 3, and 4 of the receiver (Left and Right) terminals
to your equipment, as shown below.
Figure 3: Balanced Audio Output Terminal Block Connector
Audio 3 and 4 requires the SDI option
(D9800-3G-SDI).
Note
Connecting the IP TS Input/Output
The RJ-45 interface DATA1 and DATA2, and DATA3 and DATA4 (on multi-stream units only) are
100/1000BASE-T Ethernet connectors. They are intended for the MPEGoIP input and output. The MPEGoIP
output of the transport stream is encapsulated in the IP packets to a groomer for distribution.
For reliable Ethernet operation; to run over a maximum segment length of 100 m and up to 100BASE-T,
the cable has to comply with the EIA/TIA Category 5 (or higher) wire specifications, and for 1000BASE-T,
Category 6 is required.
Note
Connect an RJ-45 cable between the Ethernet connector (DATA port only) on the D9800 receiver and the
Ethernet port of the equipment after the D9800 receiver. The equipment after the D9800 receiver could be an
IP router or a switch.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
8
Installing the D9800 Network Transport Receiver
Connecting the IP TS Input/Output

Connecting the ASI Output
Connect the output signal from the D9800 receiver ASI OUT connector.
Use a Belden “Brilliance”cable (or equivalent) with foil/braid construction. The shield must provide 99% or
better shielding effectiveness.
External Alarm System Connector
The Alarm output connector is a 15-pin sub-D female connector. The connector pin states depend on the
selected Relay Mode.
Changing the Relay Mode for Alarm Monitoring
The Alarm relay is a program relay that can be configured to provide programmed responses for alarms,
warnings, and cue trigger states for ad insertion equipment. As a default, the Alarm Relay is configured for
Alarm mode.
The cue tone or cue trigger interface is available on single-stream units only.Note
Step 1 From the Main Menu of the D9800 front panel, choose Setup >Outputs >Cueing >Relay Mode.
Step 2 Choose Alarm.
Step 3 Save your changes. The rear panel connector pin states will change to that shown in the table below for Alarm mode.
Relay ModeOpen in
Normal
Operation
Common PinClosed in
Normal
Operation
Connector
Trigger151011
Alarm (default)111015
A normally closed state implies the state when power is applied to the relay in a normal operating state, without
a trigger or alarm condition present.
Note
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
9
Installing the D9800 Network Transport Receiver
Connecting the ASI Output

Cue Tone/Cue Trigger Interface
The D9800 receiver is equipped with a connector labeled Cue Tone/Relay for alarm relay outputs for remote
alarm signaling. This connector provides Cue Tone, Cue Trigger, and Alarm relay functionality. These outputs
are user-configurable via the Setup Menu on the front panel.
The connector is a 15-pin sub-D female connector, with the voltage and current of SV Vmax 30 mAmax. The
following table shows the connector and the pin allocation table for Cue Tone, Cue Trigger, and Alarm relay
connections.
Pin AllocationPinConnector
Cue Trig 11
Cue Trig 22
Cue Trig 33
Cue Trig 44
Cue Trig 55
Cue Trig 66
Cue Trig 77
Cue Trig 88
Not connected9
Alarm - Ground10
Alarm - Normally open11
Chassis ground12
Cue Tone-13
Cue Tone +14
Alarm - Normally closed15
Connecting the Cue Tone Interface
Connect the Cue Tone pins, 13 and 14 to a device to facilitate ad-insertion using DTMF Analog Cue Tones.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
10
Installing the D9800 Network Transport Receiver
Cue Tone/Cue Trigger Interface

Connecting the Cue Trigger Interface
Connect the Cue Trigger pins (1 to 8) to up to 8 serial control devices or a device to control ad-insertion.
These outputs are user-configurable on the front panel menu.
Configuring Open-collector Outputs
The D9800 supports decoding of SCTE-35 messages with DTMF descriptor. The D9800 outputs tones or sets
the open collector contacts according to the content of the DTMF descriptor in the Cisco D9036 Modular
Encoding Platform. For information on the open-collector output settings, see the Cisco D9036 Modular
Encoding Platform Installation and Configuration Guide.
Connecting the Ethernet Management Interface
The RJ-45 interface for 100/1000BASE-T Ethernet is currently intended for upgrading/downloading the
software application. The Ethernet Management port supports the following network protocols: SSH, HTTPS,
SNMP, Syslog, and NTP. You must set up the IP address, the default gateway and the subnet mask to match
the network connection. This is done through the front panel menu (Setup >IP >IP).
Proper cables are required for reliable Ethernet operation; to run up to a maximum segment length of 100
m and up to 100BASE-T, the cable has to comply with the EIA/TIA Category 5 (or higher) wire
specifications, and for 1000BASE-T, Category 6 is required. For EMC protection, shielded cables must
be used.
Note
Step 1 Connect an RJ-45 cable between the Ethernet connector on the D9800 receiver and the Ethernet port of your PC.
Step 2 Set up the IP address on the D9800 receiver via the front panel display (Setup >IP >IP).
Viewing the Hardware Information
From the D9800 web GUI, choose System Settings >Identification, or from the Main Menu of the D9800
front panel, choose About >General.
The Hostname field or front panel menu allows you to set the name of the current unit. It appears on the web
GUI title to identify the receiver.
The remaining fields or front panel menus display the unit information, such as serial number, model number,
and port addresses.
The following icons are displayed in the User Address field:
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
11
Installing the D9800 Network Transport Receiver
Configuring Open-collector Outputs

DescriptionIcon
Indicates that the blue UA (master UA) matches the EEPROM or repair
location in SPI Flash. Otherwise, it displays a red X.
Indicates that the UA was used to create the X.509 certificate, which
enables security features and establishes a secure session. If a certificate
symbol is not displayed, it indicates that the X.509-enabled features,
such as VideoGuard smart cards and license re-hosting, are not
available.
License re-hosting allows you to initiate license transfers.
This feature is coming soon to the SWIFT license portal.
Details will be provided in the coming months.
Note
The ISE block signature is validated.
The ISE block validation has failed or is missing.
Cisco D9800 Network Transport Receiver Version 3.11 Installation and Configuration Guide
12
Installing the D9800 Network Transport Receiver
Viewing the Hardware Information
