Cisco Prisma II Service manual

Prisma II 2.5G 2:1 bdr-I Receiver and
Prisma II Chassis Issue Technical
Bulletin
Overview
Customers using the Prisma® II 2.5G 2:1 bdr-I Receiver may experience
communication problems with the receiver when installed in a Prisma II Chassis
configured with an ID ending in 2 through 5.
Purpose
The purpose of this document is to inform users of the Prisma II 2.5G 2:1 bdr-I
Receiver, part numbers 4018935 and 4018938, of possible problems with the
receiver when used with chassis ID ending in 2 through 5. This technical bulletin
defines the issue and provides the corrective measures that should be taken by
qualified and skilled personnel.
Audience
This technical bulletin applies to system engineers, managers, and customers who
are responsible for operating or maintaining Prisma II equipment.
Qualified Personnel
Only appropriately qualified and skilled service personnel should attempt to
install, operate, maintain, and service this product.
WARNING:
Allow only qualified and skilled personnel to install, operate, maintain, and
service this product. Otherwise, personal injury or equipment damage may
occur.
Issue
It has been determined that the new Prisma II 2.5G 2:1 bdr-I Receiver has the two
chassis ID pins swapped on the main PCB resulting in the module not being able
to communicate with an ICIM or LCM when installed in a chassis configured with
an ID ending in 2 through 5. This issue was not observed with chassis IDs ending
in 0, 1 and 6-9.

2 78-4032387-01 Rev C
Overview
Resolution
For the units that exhibit this behavior, a software update has been made available
to correct this issue. Refer to the Software Upgrade Procedure (on page 3).
Safe Operation for Software Controlling Optical Transmission
Equipment
If this manual discusses software, the software described is used to monitor
and/or control ours and other vendors’ electrical and optical equipment designed
to transmit video, voice, or data signals. Certain safety precautions must be
observed when operating equipment of this nature.
For equipment specific safety requirements, refer to the appropriate section of the
equipment documentation.
For safe operation of this software, refer to the following warnings.
WARNING:
Ensure that all optical connections are complete or terminated before
using this equipment to remotely control a laser device. An optical or laser
device can pose a hazard to remotely located personnel when operated
without their knowledge.
Allow only personnel trained in laser safety to operate this software.
Otherwise, injuries to personnel may occur.
Restrict access of this software to authorized personnel only.
Install this software in equipment that is located in a restricted access area.
In This Document
Software Upgrade Procedure.................................................................................... 3
Pre-Work Procedure................................................................................................... 4
Upgrade Procedure .................................................................................................... 5
Setting Up An FTP Server........................................................................................ 11

For Information......................................................................................................... 18

78-4032387-01 Rev C 3
Software Upgrade Procedure
Software Upgrade Procedure
Scope
Upgrading a Prisma II module (CCB3-based or equivalent) involves using a
Windows application called the Prisma II Software Upgrade Program (SOUP) and
an FTP server that contains the current entire Prisma II software release.
SOUP is a user-friendly application that allows users to perform software upgrades
on Prisma II modules. The SOUP utility simplifies the software upgrade process by
providing a graphical user interface (GUI) that requires little training and eliminates
equipment downtime.
When connected to an ICIM2, the program shows the user the current versions of
software on all modules and allows the user to download and activate new versions
from system release files. The SOUP utility works with the ICIM2 to send the binary
image files and appropriate commands to the modules to upgrade their software.
As the modules are being upgraded, the SOUP utility displays relevant progress
information for the user.
Applicability
This procedure specifically applies to upgrading bdr-I modules from 1.01.10 to
1.01.11 to fix the chassis ID recognition problem.
Reference Documents
Prisma II XD Platform System Guide, System Release 2.03, part number 4025479
Prisma II Software Upgrade Program (SOUP, V2.00)
Cerberus or equivalent FTP Server software (if FTP server not available).
Equipment
Computer with Prisma II Software Upgrade Program (SOUP V2.00) installed
Access to an FTP server. Can be on same computer as above or a computer
where an FTP server can be installed and accessed
Prisma II ICIM (R013 or better) (optional)
Prisma II ICIM2

4 78-4032387-01 Rev C
Pre-Work Procedure
Pre-Work Procedure
If the bdr-I modules to be upgraded are in a chassis ID ending with 0, 1, 6, 7, 8 or 9
(e.g., 01, 16, etc), then skip ahead to Procedure; otherwise, the following steps must
be performed to make the bdr-I modules visible to the ICIM2.
Making the bdr-I Module Visible to ICIM2
There are several ways to make the bdr-I modules visible to the ICIM2.
1Set the chassis ID to a value that the bdr-I modules work with (e.g., 11) and cycle
power on the bdr-I module by removing or inserting the module.
Important: This will cause a temporary outage.
2Daisy-chain a second chassis (with fan tray and power supply) to the first chassis
and set its ID to the value the bdr-I module thinks it is (see table below). This will
not cause an outage, but may not be workable depending on the customer’s SMC
layout.
Physically installed in chassis
Thinks it is in chassis
02, 12, 22, 32, … 04, 14, 24, 34, …
03, 13, 23, 33, … 05, 15, 25, 35, …
04, 14, 24, 34, … 02, 12, 22, 32, …
05, 15, 25, 35, … 03, 13, 23, 33, …
3Set the ID bits to a legal unused value and use an ICIM (not ICIM2) to force the
bdr-I modules to read the new ID settings. This will not cause an outage, but may
impact the customer’s SMC layout.
4Install the ICIM (not ICIM2) in the domain. Only one ICIM type module can be
installed in a domain at any given time.
5Set the chassis ID switches to a legal value.
6Send the Update Address command via the ICIM.
a. Press the ICIM button.
b. Press the DOWN button three times to highlight “Update Adr”.
c. Press the SEL button (all module LEDs should blink). All modules will now
be at the new chassis ID.
d. Remove the ICIM.

78-4032387-01 Rev C 5
Upgrade Procedure
Upgrade Procedure
1Verify that Prisma II chassis contains an ICIM2, and that the ICIM2’s domain
contains the modules to be updated.
2Set up the RS-232 interface to the ICIM2.
Note: this interface will be used to change and/or read settings such as IP
address, gateway address, subnet mask, etc.
3Open a Hyperterm session and set up a COM port as follows:
Baud: 9600
No of data bits: 8
Parity: N
Stop bits: 1
Flow control: None
4Connect an RS-232 cable from a COM port on the PC to the RS-232 port of the
ICIM2.
5Press Enter and verify a response from the ICIM2. If no response, cycle power
on the ICIM2 and observe the Hyperterm display. The messages from the ICIM2
boot process should be visible.
6Set up an FTP server. If an FTP server not available, refer to Setting Up FTP
Server Software on Your Local Computer (on page 11) for information about
installing and setting up an FTP server using Cerberus.
7Add an account to the FTP server, specifying a username and a password.
Note: An account without a password will not work.
8Install SOUP. If SOUP is not present on PC, install it. For general information,
refer to Prisma II XD Platform System Guide, System Release 2.03, part number
4025479. The revision being used in this procedure is 2.01.
9Establish an IP connection with the ICIM2.
Obtain theICIM2IPaddress
1Using the RS-232 interface and Hyperterm, log into the ICIM2 with a valid
username and password.
2Type CLI and press Enter.
3Type ICIM and press Enter.
4Type SHOW IP and press Enter. The ICIM2 IP address will be shown.

6 78-4032387-01 Rev C
Upgrade Procedure
PingingtheICIM2
1From the PC containing SOUP, ping the ICIM2.
2On the Windows desktop, select: Start -> Run.
3Type cmd and press Enter.
4Type ping xxx.xxx.xxx.xxx and press Enter where xxx.xxx.xxx.xxx is the IP
address of the ICIM2.
5If the response is “Reply from xxx.xxx.xxx.xxx …”, then the connection is good.
If the response is “Request timed out.”, then the connection failed, and support
from the IT group is needed.
Changing the IP Settings
The IT group may need to change the IP settings on the ICIM2. The following are
the commands most likely needed to do this.
1Set IP xxx.xxx.xxx.xxx and press Enter. This will set the IP address of the ICIM2.
2Set gateway xxx.xxx.xxx.254 and press Enter. This will set the gateway address
of the ICIM2. It is usually the same as the IP address except for the last octet,
which is usually 254.
3Set subnet 255.255.255.0 and press Enter. This is the most common subnet mask
used. IT should know if a different mask is needed.
4Reboot the ICIM2 module by pulling it from the chassis far enough to remove
power, re-install module, and wait for the boot process to complete.
5Go back to Pinging the ICIM2 to re-attempt to ping the ICIM2.

78-4032387-01 Rev C 7
Upgrade Procedure
Downloading the New Firmware
1Double-click SOUPLauncher.
Result: The following screen appears.
ICIM IP: Enter the IP address of ICIM2 module.
User Name: Enter the username of valid account on the ICIM2.
Auth Level: 3
Setting Up the SNMP Connection
1Enter the appropriate SNMP read string. If it’s unknown, enter “prismaread”.
2Enter the appropriate SNMP write string. If it’s unknown, enter “prismawrite”.
3Verify IP connectivity and SNMP setup by clicking on “Test SNMP”. If the
message “SNMP Connection OK” is displayed, go to Setting Up the FTP
Connection (on page 8).
4Obtain the SNMP read and write string from the ICIM2.
a. Log into the ICIM2 using Hyperterm.
b. Type CLI and press Enter.
c. Type ICIM and press Enter.
d. Type SHOW COMMREAD and press Enter.
e. The SNMP read string should be displayed. Record it for later use.
f. Type SHOW COMMWRITE and press Enter.
g. The SNMP write string should be displayed. Record it for later use.
h. Re-attempt to set up the SNMP connection.

8 78-4032387-01 Rev C
Upgrade Procedure
Setting Up the FTP Connection
1Enter the IP address of the FTP server in the “FTP Host:” cell.
2Enter the FTP User and FTP Password for the account set up earlier.
3Enter the directory on the FTP server that contains the current Prisma II release
files.
4Verify the FTP connection by clicking on “Test FTP”. The message “FTP
Connection OK” should be displayed. If not, then troubleshoot the FTP
connection. The FTP server should be able to ping the ICIM2.
5Click OK.
6SOUP should display a list of the installed Prisma II modules.
Result: The following screen or one similar appears.
7SOUP should identify the modules in need of updating by placing a check in the
box in the first column. If any modules are identified for updating that the
operator does not wish to upgrade at this time, unselect these modules.

78-4032387-01 Rev C 9
Upgrade Procedure
8Click Download + Activate.
Result: The following screen or one similar appears.
9Click Start.
10 The new firmware should start downloading.
Result: The following screen or one similar appears.
11 When the download(s) are finished, the firmware will be activated, and the
module(s) will be rebooted.
Result: The following screen appears after successfully upgrading the modules.

10 78-4032387-01 Rev C
Upgrade Procedure
12 Click Close.
Result: The following screen appears after the modules have been successfully
upgraded, and should reflect the new versions of the firmware just downloaded.

78-4032387-01 Rev C 11
Setting Up An FTP Server
Setting Up An FTP Server
You may prefer to store and serve the firmware upgrade files on the same local
computer on which you run the Transport System firmware upgrade utility. This
can be done by installing FTP server software on the local computer and making the
firmware upgrade files available from there.
Setting Up FTP Server Software on Your Local Computer
FTP server software is available for download from various Internet sites. An
Internet search on the term “FTP server” will yield many results. The software used
in this example is Cerberus FTP Server software, which is available for download
from the Cerberus web site at www.cerberusftp.com.
Disclaimer: Cerberus is used as an example only. The version you download may
be different from the one shown below. This example is meant to be a general
guideline for setting up a local FTP server. Use the FTP server software that you are
familiar with. Consult your Information Technology department for support.
Complete the following steps to install and configure the Cerberus FTP Server
software.
1Download the Cerberus FTP Server software from www.cerberusftp.com and
follow the installation instructions to install the software on your computer.
2When installation is complete, start the Cerberus FTP Server program.
Result: The following Cerberus Getting Started Wizard – Licensing screen
appears.

12 78-4032387-01 Rev C
Setting Up An FTP Server
3Select the appropriate use type and click Next to continue.
Result: The User Creation screen appears. When it appears, create a user with
the settings shown below.
Create initial user: Yes (box checked)
Anonymous: Yes (box checked)
User Name: Anonymous (this is the default)
Password: (leave this field blank)
Initial Root: ftproot (this is the default)
Allow Download: Yes (box checked)
Allow Upload: Yes (box checked).
Note: Uncheck this box if you do not want to allow uploads
4Click Next to continue with network configuration.
Result: The following WAN IP auto-detection warning message appears.

78-4032387-01 Rev C 13
Setting Up An FTP Server
5Click Yes to continue with WAN IP auto-detection.
Result: When auto-detection completes, the Network Configuration window
appears.
Review the checklist regarding router and firewall configuration requirements.
6Click Finish to complete the user setup and network configuration.
Result: The Cerberus FTP Server main screen appears.
7Click File - Shutdown and Exit to exit the Cerberus FTP Server program.
Result: The program closes.

14 78-4032387-01 Rev C
Setting Up An FTP Server
8Using Windows Explorer, examine the C drive, and check for the presence of a
folder named “ftproot”. If the ftproot folder exists, open it and check that it
contains a sub-folder named “dload”.
If these folders do not exist, create the following folder structure:
C:\ftproot\dload\
9Restart the Cerberus FTP Server program.
Result: The Cerberus FTP Server main screen appears.
10 Click Configuration from the main screen and then choose User Manager.
Result: The following screen appears (with user Anonymous selected).
Important: Make sure the Simple Directories check box is unchecked.
11 If the user “ftp” does not appear in the Cerberus User Accounts window as
shown above, click the New button and create a new user named “ftp”. If user
“ftp” does appear, go to step 12.
12 Proceed as follows:
a. Select the user named “ftp” in the Cerberus User Accounts window.
b. Double-click Password in the Properties window.
c. Enter the password “@ftp”, and re-type it to confirm.
d. Click OK.

78-4032387-01 Rev C 15
Setting Up An FTP Server
13 If the folder “ftproot” already exists in the folder list for the selected user, go to
step 15. Otherwise, continue with this step.
a. Click the browse button in the “Root Directory for:” dialog box.
Result: The Browse for Folder window appears.
b. Browse to My Computer, then to Local Disk (C:), and then select the folder
named ftproot.
c. Click OK.
14 Click the Assign Root button in the “Root Directory for:” dialog
box.
Result: The ftproot folder is added to the folder list as shown.

16 78-4032387-01 Rev C
Setting Up An FTP Server
15 Select the new ftproot folder and then click all of the check boxes in the
Properties window so that all of the values read TRUE as shown above.
Result: The ftproot folder is added to the root for the current user.
16 Proceed as follows:
a. Click the browse button in the “Virtual Root Directory for:” dialog box.
Result: The Browse for Folder window appears.
b. Browse to My Computer, then to Local Disk (C:), then to ftproot, and then
select the folder named dload.
c. Click OK.
17 Click the Add to Root button in the “Virtual Root Directory for:”
dialog box.
Result: The dload folder is added to the folder list.
18 Select the new dload folder and then click all of the check boxes in the Properties
window so that all of the values read TRUE.
Result: The dload folder is added to the root for the current user.

78-4032387-01 Rev C 17
Setting Up An FTP Server
19 Select the user named “Anonymous” in the Cerberus User Accounts window.
Important: Make sure that the Is Anonymous checkbox in the Properties
window is checked.
20 Repeat steps 13 through 18 to add the two folders to the root for user
“Anonymous”, and click Close.
Result: The ftproot and dload folders are added to the root for user
“Anonymous”.
21 Copy the Transport System firmware upgrade files into the upgrade folder on
your local computer’s hard drive. (In this example, the “C:\ftproot\dload”
folder.)

For Information
Support Telephone Numbers
If you have technical questions, call Cisco Services for assistance. Follow the menu
options to speak with a service engineer.
Cisco Systems, Inc.
5030 Sugarloaf Parkway, Box 465447
Lawrenceville, GA 30042
678 277-1120
800 722-2009
www.cisco.com
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates
in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL:
www.cisco.com/go/trademarks .
Third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1110R)
Product and service availability are subject to change without notice.
© 2009, 2013 Cisco and/or its affiliates. All rights reserved.
January 2013 Printed in USA
Part Number
78-4032387-01 Rev C
