Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
First Published: 2018-08-14
Last Modified: 2018-11-07
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

©2018 Cisco Systems, Inc. All rights reserved.

CONTENTS
Product Overview 1
CHAPTER 1
Cisco UCS 6454 Fabric Interconnect Overview 1
Cisco UCS 6454 Fabric Interconnect 1
Ports on the Cisco UCS 6454 Fabric Interconnect 2
Port Numbering 4
Power Supplies 5
Fan Modules 6
HA Ports and LEDs 6
Management Port LEDs 7
System Environment LEDs 7
Port LEDs 8
L1 and L2 Port LEDs 8
Supported Transceivers 8
SFP 1-Gigabit Transceivers 9
SFP+ Transceivers and SFP+ Copper Cables 9
QSFP Transceivers and Cables 11
SFP Fibre Channel Transceivers 12
Installing the Cisco UCS Fabric Interconnect 15
CHAPTER 2
Preparing for Installation 15
Considerations and Warnings 15
Installation Options 16
Airflow Considerations 16
Fabric Interconnect Weight 16
Installation Guidelines 16
Required Equipment 17
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
iii

Cabinet and Rack Requirements 18
General Requirements for Cabinets and Racks 18
Requirements Specific to Perforated Cabinets 19
Requirements Specific to Standard Open Racks 19
Cable Management Guidelines 19
Unpacking and Inspecting the Cisco UCS Fabric Interconnect 19
Installing the Cisco UCS Chassis in a Cabinet or Rack 20
Establishing System Ground 24
Proper Grounding Practices 24
Preventing Electrostatic Discharge Damage 25
Grounding the Fabric Interconnect 27
Starting the System 28
Connecting the Cisco UCS Fabric Interconnect 31
CHAPTER 3
Preparing for Network Connections 31
Connecting to the Console Port 31
Connecting the Management Port 33
Connecting to an SFP28 Ethernet or Fibre Channel Port 33
Installing or Removing Cables into SFP Transceivers 33
Installing a Transceiver 33
Removing a Transceiver 34
Installing or Removing Cables into SFP28 Trancsceivers 35
Installing a Cable into an SFP28 Transceiver 35
Removing a Cable from a Transceiver 35
Maintaining SFP28 Transceivers and Fiber-Optic Cables 36
Replacing Components 37
CHAPTER 4
Preparing a Fabric Interconnect for Removal 37
Removing a Cisco UCS Fabric Interconnect 38
Replacing a Fabric Interconnect 38
Repacking the Cisco UCS Fabric Interconnect for Return Shipment 42
Technical Specifications 43
CHAPTER 5
System Specifications 43
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
iv
Contents

Power Specifications 43
Transceiver Specifications 45
Environmental Conditions and Power Requirements Specification for SFP Transceivers 45
General Specifications for Cisco Fibre Channel SFP Transceivers 45
Cable and Port Specifications 47
CHAPTER 6
Accessory Kit for the Cisco UCS Fabric Interconnect 47
Console Cable 48
Console Port 48
Supported AC Power Cords and Plugs 49
Argentina 49
Australia and New Zealand 50
Peoples Republic of China 50
Europe 51
India, South Africa, and United Arab Emirates 51
Israel 52
Italy 52
North America 53
Switzerland 54
Taiwan 54
United Kingdom 55
Cabinet Jumper Power Cords 55
Site Planning and Maintenance Records 57
CHAPTER 7
Site Preparation Checklist 57
Contact and Site Information 59
Chassis and Module Information 60
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
v
Contents

Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
vi
Contents

CHAPTER 1
Product Overview
•Cisco UCS 6454 Fabric Interconnect Overview, on page 1
•Cisco UCS 6454 Fabric Interconnect, on page 1
•Ports on the Cisco UCS 6454 Fabric Interconnect, on page 2
•Port Numbering, on page 4
•Power Supplies, on page 5
•Fan Modules, on page 6
•HA Ports and LEDs, on page 6
•Management Port LEDs, on page 7
•System Environment LEDs, on page 7
•Port LEDs, on page 8
•L1 and L2 Port LEDs, on page 8
•Supported Transceivers, on page 8
Cisco UCS 6454 Fabric Interconnect Overview
The Cisco UCS 6454 Fabric Interconnect provides both network connectivity and management capabilities
to the Cisco UCS system. The fabric interconnect provides Ethernet and Fibre Channel to the servers in the
system, the servers connect to the fabric interconnect, and then to the LAN or SAN.
Each Cisco UCS 6454 Fabric Interconnect runs Cisco UCS Manager to fully manage all Cisco UCS elements.
The fabric interconnect supports 10/25 Gigabit ports in the fabric with 40/100 Gigabit uplink ports. High
availability can be achieved when a Cisco UCS 6454 Fabric Interconnect is connected to another Cisco UCS
6454 Fabric Interconnect through the L1 or L2 port on each device.
Cisco UCS 6454 Fabric Interconnect
The Cisco UCS 6454 Fabric Interconnect is a 1 RU top-of-rack switch with 48 10/25-Gigabit SFP28 ports (8
unified ports) and six 40/100-Gigabit QSFP28 ports. The eight unified ports support 10/25 GbE or 8/16/32G
Fibre Channel speeds. The switch also has one network management port, a console port for setting the initial
configuration, and a USB port for saving or loading configurations. The switch also includes L1/L2 ports for
connecting two fabric interconnects to provide high availability. The switch mounts in a standard 19-inch
rack, such as the Cisco R Series rack. The Cisco UCS 6454 Fabric Interconnect also contains a CPU board
which consists of:
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
1

• Intel Xeon D-1528 v4 Processor, 1.6 GHz
• 64 GB of RAM
• 8 MB of NVRAM (4 x NVRAM chips)
• 128 GB SSD (bootflash)
Figure 1: Cisco UCS 6454 Fabric Interconnect Rear View
Ports 9-44 (10/25 Gbps Ethernet or FCoE)2Ports 1-8 (Unified Ports 10/25 Gbps
Ethernet or FCoE or 8/16/32 Gbps Fibre
Channel)
1
Uplink Ports 49-54 (40/100 Gbps Ethernet
or FCoE)
4Ports 45-48 (1/10/25 Gbps Ethernet or
FCoE)
3
For additional information about the port groups, see Port Numbering, on page 4.
The Cisco UCS 6454 Fabric Interconnect chassis has two power supplies and four fans. Two of the fans
provide front to rear airflow.
Figure 2: Cisco UCS 6454 Fabric Interconnect Front View
Fans 1 through 4, numbered left to right, when
facing the front of the chassis
2Power supply and power cord connector1
L1 port, L2 port, RJ45, console, USB port,
and LEDs
3
Ports on the Cisco UCS 6454 Fabric Interconnect
The ports on the Cisco UCS 6454 Fabric Interconnect can be configured to carry either Ethernet or Fibre
Channel traffic. You can configure only the first eight ports to carry Fibre Channel traffic. The ports cannot
be used by a Cisco UCS domain until you configure them.
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
2
Product Overview
Ports on the Cisco UCS 6454 Fabric Interconnect

When you configure a port on a fabric interconnect, the administrative state is automatically set to enabled.
If the port is connected to another device, this may cause traffic disruption. The port can be disabled and
enabled after it has been configured.
Note
The following table summarizes the second, third and fourth generation ports for the Cisco UCS fabric
interconnects.
Fourth
Generation
Third GenerationSecond Generation
Cisco UCS
6454
Cisco UCS
6332-16UP
Cisco UCS
6332
Cisco UCS
6296 UP
Cisco UCS
6248 UP
Item
54-Port Fabric
Interconnect
40-Port Fabric
Interconnect
32-Port Fabric
Interconnect
96-Port Fabric
Interconnect
48-Port Fabric
Interconnect
Description
1 RU1 RU1 RU2 RU1 RUForm factor
48 10/25G
interfaces
88 (40G to 4 x 10G
breakout cables)
96 (40G to 4 x
10G breakout
cables), QSA,
Port 13 and 14
do not support
40G to 10G
breakout
4832Number of
fixed 10 GB
Interfaces
816—4832Number of
Unified Ports
10/25 Gbps or
8/16/32-Gbps
FC
1/10 Gbps or
4/8/16-Gbps FC
—1/10 Gbps or
1/2/4/8-Gbps
FC
1/10 Gbps or
1/2/4/8-Gbps
FC
Unified Port
Speeds
Six 40/100
Gigabit ports
2432——Number of
40-Gbps ports
Ports 1-8Ports 1-16NonePorts 1-48Ports 1-32Unified Port
Range
UCS 2204,
UCS 2208
UCS 2204, UCS
2208, UCS 2304
UCS 2204,
UCS 2208,
UCS 2304
UCS 2204,
UCS 2208
UCS 2204,
UCS 2208
Compatibility
with the IOM
Cisco Nexus
2232PP
Cisco Nexus
2232TM-E
Cisco Nexus
2232PP
Cisco Nexus
2232TM-E
Cisco Nexus
2348UPQ
Cisco Nexus
2232PP
Cisco Nexus
2232TM-E
Cisco Nexus
2348UPQ
Cisco Nexus
2232PP
Cisco Nexus
2232TM-E
Cisco Nexus
2232PP
Cisco Nexus
2232TM-E
Compatibility
with the FEX
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
3
Product Overview
Ports on the Cisco UCS 6454 Fabric Interconnect

Fourth
Generation
Third GenerationSecond Generation
NoneNoneNone3 (16 port)1 (16 port)Expansion Slots
44442Fan Modules
2 (AC/DC)2 (AC/DC)2 (AC/DC)2 (AC/DC
available)
2 (AC/DC
available)
Power Supplies
Port Numbering
Ports on the Cisco UCS 6454 Fabric Interconnect are numbered and grouped according to their function. The
ports are numbered top to bottom and left to right. The following figure shows the port numbering.
Figure 3: Rear View of Cisco UCS 6454 Fabric Interconnect Port Numbers
Ports 9–44. Each port can operate as either
a 10 Gbps or 25 Gbps SFP28 port.
2Ports 1–8. Unified Ports can operate as
10/25 Gbps Ethernet or 8/16/32 Gbps
Fibre Channel. FC ports are converted
in groups of 4 ports by the first 4 ports
(port 1 to 4) or the first 8 ports (port 1
to 8). For more information on how to
configure the port modes, refer to
"Configuring Port Modes for a 6454
Fabric Interconnect" in the Cisco UCS
Network Management Guide, Release
4.0.
1
Uplink Ports 49–54. Each port can operate
as either a 40 Gbps or 100 Gbps Ethernet
or FCoE port. Ports 49-54 can only be used
to connect to network or FCoE uplink ports
and not UCS server ports. These ports do
not support breakout cables or QSA
module.
4Ports 45–48. Each port can operate as
a 1 Gbps, 10 Gbps, or 25 Gbps Ethernet
or FCoE port.
3
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
4
Product Overview
Port Numbering

Power Supplies
The fabric interconnect has two power supplies that are accessible from the front of the chassis. The two
power supplies support 1+1 redundancy. The Cisco UCS 6454 Fabric Interconnect and the UCS 6300 Series
Fabric Interconnect utilize the same power supplies.
Table 1: Power Supply Models
WattageSourceFabric InterconnectCisco PID
650 W110 to 240 VACCisco UCS 6454UCS-PSU-6332-AC
930 W-48 VDCCisco UCS 6454UCS-PSU-6332-DC
Figure 4: AC Power Supply for the Cisco UCS 6454 Fabric Interconnect Front View
Power supplies have two LEDs: one for power status and one for a failure condition.
Green power on LED2Amber fault or Error LED1
DescriptionStateLED
Power supply is on and functioning properlySolid greenPower on LED
3.3 V voltage standby (VSB) is on but the power supply is not
powering up the Fabric Interconnect
Blinking green
There is no AC power to the power supplyOff
Power supply failure that indicates an over voltage, over current,
or over temperature
Solid amberFault/error LED
AC power is present, 3.3 VSB is on, and the power supply is
off
Blinking amber
Normal operationOff
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
5
Product Overview
Power Supplies

If one power supply is installed in the chassis, but the other power supply slot is empty, a blank filler panel
should be used to cover the empty slot.
Fan Modules
The Cisco UCS 6454 Fabric Interconnect supports four fan modules. The fans support 3+1 redundancy. The
Cisco UCS 6454 Fabric Interconnect and the UCS 6300 Series Fabric Interconnect utilize the same model
fans. All fans are hot swappable but only one fan can be removed at a time.
DescriptionProduct ID (PID)
UCS 6332 and UCS 6454 Fabric Interconnect fan
modules. The UCS 6332 and UCS 6454 Fabric
Interconnect use the same model fans.
UCS-FAN-6332
HA Ports and LEDs
The Cisco UCS 6454 Fabric Interconnect has L1, L2 high availability ports, network management port, console
port, and a USB port that are shown in Figure 5. For L1 and L2 ports, the maximum length of Ethernet CAT5e
or CAT6 cable is 100 meters.
Figure 5: HA Ports and LEDs
L2 high availability port2L1 high availability port1
RJ45 console port4RJ45 Network Management Port3
Beacon LED6USB port
- The USB port can be used for booting or
downloading scripts.
5
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
6
Product Overview
Fan Modules

System Status LED7
The status of the beacon and system status LEDs are as follows:
DescriptionStateColorFunctionLocationLED
Chassis
selected
Solid OnBlueIndicate selected
chassis
Front and rearBeacon
LED
Chassis not
selected
Off
Normal
operation
Solid onGreenIndicate system
power/health at bootup
and run time
Front and rearSystem
Status LED
System
powered off
Off
System
fault
OnAmber
Power shut
down by
software
Solid onRed
Secure boot
validation
has failed
Blinking
Management Port LEDs
The status of the management ports is listed below.
DescriptionLED StateLED Position
No linkOffLeft
Physical linkSolid green
No activity
OffRight
ActivityBlinking green
System Environment LEDs
The system environment LED states are listed below.
DescriptionLED State
Minor fan alarm (a fan is missing or there is a failure)Solid amber
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
7
Product Overview
Management Port LEDs

DescriptionLED State
Major fan alarm (two or more fans are missing or have failed, or there is a fan direction
mismatch
Solid red
Port LEDs
The port LED states are listed below.
DescriptionLED State
Enabled, but SFP not inserted
Administrative down (software shutdown)
Yellow
Enabled and link is upGreen
Enabled, but link is not connectedOff
Power On Self Test (POST) failed
Port beacon enabled
Blinking yellow
L1 and L2 Port LEDs
The L1 and L2 port LED states are listed below.
DescriptionLED StateLED Position
No linkOffLeft
Physical linkSolid greenLeft
No activityOffRight
ActivityBlinking greenRight
Supported Transceivers
The Cisco UCS 6454 Fabric Interconnect support SFP28 Ethernet transceivers, SFP transceivers, SFP28
transceivers, SFP28 copper twinax cables with integrated transceivers, SFP Fibre Channel transceivers, QSFP
transceivers, QSFP28 transceivers, and QSFP cables. Except where noted, both the Cisco UCS 6454 Fabric
Interconnect support all the transceivers listed in this section. Ports 1–8 operate as unified ports that are capable
of 10/25-Gbps fixed Ethernet, 10/25-Gbps FCoE, or 8-, 16-, or 32 Gbps Fibre Channel ports.
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
8
Product Overview
Port LEDs

SFP 1-Gigabit Transceivers
The SFP 1-Gigabit Ethernet transceiver module is a bidirectional device with a transmitter and receiver in the
same physical package.
Table 2: Supported SFP Optical Transceivers
DescriptionModel
1000BASE-T standardGLC-TE
1000BASE-SX short wavelength with MDOMGLC-SX-MMD
1000BASE-T SFP (NEBS 3 ESD)SFP-GE-T
The maximum length of fiber optic runs is limited to 300 meters. This is imposed by our use of
802.3X/802.1Qbb Priority Pauses. SFP-10G-LR is supported between fabric interconnect and I/O Module,
but the 300 meter limit still applies. For copper wiring the maximum distance is 100 meters.
Note
SFP+ Transceivers and SFP+ Copper Cables
The enhanced SFP+ 10-Gigabit Ethernet transceiver module is a bidirectional device with a transmitter and
receiver in the same physical package. It has a 20-pin connector on the electrical interface and duplex LC
connector on the optical interface.
Table 3: Supported Transceivers
DescriptionProduct ID
10GBASE-SR SFP+ module (multimode fiber
[MMF])
SFP-10G-SR
10GBASE-SR SFP+ module (multimode fiber
[MMF], S-Class)
SFP-10G-SR -S
10GBASE-LR SFP+ module (single-mode fiber
[SMF])
SFP-10G-LR
10GBASE-LR SFP+ module (single-mode fiber
[SMF], S-Class)
SFP-10G-LR -S
Cisco 10G Line Extender for FEXFET-10G
Cisco 10GBASE-ER ModuleSFP-10G-ER
Cisco SFP-10G-ER-S module (S-Class)SFP-10G-ER-S
Cisco SFP-10G-ZR moduleSFP-10G-ZR
Cisco SFP-10G-ZR-S module (S-Class)SFP-10G-ZR-S
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
9
Product Overview
SFP 1-Gigabit Transceivers

DescriptionProduct ID
Cisco SFP-10G-BXD-I for 10Km (single-fiber
bidirectional applications)
SFP-10G-BXD-I
Cisco SFP-10G-BXU-I for 10Km (single-fiber
bidirectional applications)
SFP-10G-BXU-I
Cisco SFP-10G-BX40D-I for 40Km (single-fiber
bidirectional applications)
SFP-10G-BX40D-I
Cisco SFP-10G-BX40U-I for 40Km (single-fiber
bidirectional applications)
SFP-10G-BX40U-I
Cisco SFP+ transceiver module - SONET/SDH, 10
GigE
SFP10G-USR
Cisco SFP-10G-LRM 10 Gigabit Interface ConverterSFP10G-LRM
25 GbE Tranceiver
Cisco 25GBASE-SR SFP28 Module for MMF
SFP-25G-SR-S
25GBASE-CR1 Copper Cable 5-meterSFP-H25G-CU5M
25GBASE-CR1 Copper Cable 1-meterSFP-H25G-AOC1M
25GBASE-CR1 Copper Cable 2-meterSFP-H25G-AOC2M
25GBASE-CR1 Copper Cable 3-meterSFP-H25G-AOC3M
Supported 6454 Fabric Interconnect 10 Gb Cables
10GBASE-CU SFP+ cable 1 meter, passive
SFP-H10GB-CU1M
10GBASE-CU SFP+ cable 2 meter, passiveSFP-H10GB-CU2M
10GBASE-CU SFP+ cable 3 meter, passiveSFP-H10GB-CU3M
10GBASE-CU SFP+ cable 5 meter, passiveSFP-H10GB-CU5M
10GBASE-CU SFP+ cable 7 meter, activeSFP-H10GB-ACU7M
10GBASE-CU SFP+ cable 10 meter, activeSFP-H10GB-ACU10M
10GBASE-AOC SFP+ cable 1 meterSFP-10G-AOC1M
10GBASE-AOC SFP+ cable 2 meterSFP-10G-AOC2M
10GBASE-AOC SFP+ cable 3 meterSFP-10G-AOC3M
10GBASE-AOC SFP+ cable 5 meterSFP-10G-AOC5M
10GBASE-AOC SFP+ cable 7 meterSFP-10G-AOC7M
10GBASE-AOC SFP+ cable 10 meterSFP-10G-AOC10M
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
10
Product Overview
SFP+ Transceivers and SFP+ Copper Cables

The maximum length of fiber optic runs is limited to 300 meters. This is imposed by our use of
802.3X/802.1Qbb Priority Pauses. SFP-10G-LR is supported between fabric interconnect and FEX, but the
300 m limit still applies.
Note
QSFP Transceivers and Cables
The Cisco 6454 Fabric Interconnect supports Cisco 40GGBASE and 100GBASE Quad Small Form Factor
(QSFP) transceiver modules.
Table 4: Supported QSFP Transceivers and Cables
DescriptionModel
40 GbE Tranceivers
40GBASE-ER4, 1310 nm, SMF with OTU3 data-rate support
QSFP-40G-ER4
40GBASE-LR4, 1310 nm, SMF with OTU3 data-rate supportQSFP-40G-LR4
40GBASE-LR4-Lite, 1310 nm, SMFWSP-Q40GLR4L
40GBASE-SR4 QSFP module (multimode fiber [MMF]), 100 meterQSFP-40G-SR4
40GBASE-SR4 QSFP module (multimode fiber [MMF]), 100 meterQSFP-40G-SR4-S
Cisco 40GBASE-LR4 QSFP+ transceiver module for SMF, duplex LC
connector
QSFP-40G-LR4
Cisco 40GBASE-LR4 QSFP+ transceiver module for SMF, duplex LC
connector
QSFP-40G-LR4-S
Cisco 40GBASE-SR-BiDi, duplex MMF (LC)QSFP-40G-SR-BD
100 GbE Tranceivers
100GBASE SR4 QSFP Transceiver, MPO, 100m over OM4 MMF
QSFP-100G-SR4-S
100GBASE LR4 QSFP Transceiver, LC, 10km over SMFQSFP-100G-LR4-S
100GBASE CWDM4 QSFP Transceiver, 2km over SMFQSFP-100G-SM-SR
40 GbE QSFP Cables
Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 1-meter, passive
QSFP-H40G-CU1M
Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 3-meter, passiveQSFP-H40G-CU3M
Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 5-meter, passiveQSFP-H40G-CU5M
Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 7-meter, passiveQSFP-H40G-ACU7M
Cisco 40GBASE-CR4 QSFP direct-attach copper cable, 10-meter, passiveQSFP-H40G-ACU10M
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
11
Product Overview
QSFP Transceivers and Cables

Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meterQSFP-H40G-AOC1M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meterQSFP-H40G-AOC2M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meterQSFP-H40G-AOC3M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meterQSFP-H40G-AOC5M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meterQSFP-H40G-AOC7M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 10-meterQSFP-H40G-AOC10M
Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 15-meterQSFP-H40G-AOC15M
100 GbE QSFP Cables
Cisco 100GBASE SFP28 passive direct-attach copper cable, 1 meter
QSFP-100G-CU1M
Cisco 100GBASE SFP28 passive direct-attach copper cable, 3 meterQSFP-100G-CU2M
Cisco 100GBASE SFP28 passive direct-attach copper cable, 5 meterQSFP-100G-CU3M
Cisco 100GBASE SFP28 active direct-attach optical cable, 1 meterQSFP-100G-AOC1M
Cisco 100GBASE SFP28 active direct-attach optical cable, 2 meterQSFP-100G-AOC2M
Cisco 100GBASE SFP28 active direct-attach optical cable, 3 meterQSFP-100G-AOC3M
Cisco 100GBASE SFP28 active direct-attach optical cable, 5 meterQSFP-100G-AOC5M
Cisco 100GBASE SFP28 active direct-attach optical cable, 7 meterQSFP-100G-AOC7M
Cisco 100GBASE SFP28 active direct-attach optical cable, 10 meterQSFP-100G-AOC10M
Cisco 100GBASE SFP28 active direct-attach optical cable, 15 meterQSFP-100G-AOC15M
Cisco 100GBASE SFP28 active direct-attach optical cable, 20 meterQSFP-100G-AOC20M
Cisco 100GBASE SFP28 active direct-attach optical cable, 25 meterQSFP-100G-AOC25M
Cisco 100GBASE SFP28 active direct-attach optical cable, 30 meterQSFP-100G-AOC30M
SFP Fibre Channel Transceivers
The UCS 6454 Fabric Interconnect supports the SFP Fibre Channel transceivers listed below.
Table 5: SFP Fiber Channel Transceivers
DescriptionModel
8-Gbps Fibre Channel SW SFP+, LCDS-SFP-FC8G-SW
8-Gbps Fibre Channel LW SFP+, LCDS-SFP-FC8G-LW
16-Gbps Fibre Channel SW SFP+, LCDS-SFP-FC16G-SW
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
12
Product Overview
SFP Fibre Channel Transceivers

DescriptionModel
16-Gbps Fibre Channel LW SFP+, LCDS-SFP-FC16G-LW
32-Gbps Fibre Channel SW SFP+, LCDS-SFP-FC32G-SW
32-Gbps Fibre Channel LW SFP+, LCDS-SFP-FC32G-LW
The maximum length of fiber optic runs from the fabric interconnect to a chassis is limited to 300 meters.
This restriction is imposed by the use of 802.3X/802.1Qbb Priority Pauses.
Note
Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
13
Product Overview
SFP Fibre Channel Transceivers

Cisco UCS 6454 Fabric Interconnect Hardware Installation Guide
14
Product Overview
SFP Fibre Channel Transceivers
