Set up CIMC for UCS C−Series Server
Document ID: 111455
Contents
Introduction
Prerequisites
Requirements
Components Used
Network Diagram
Conventions
Background Information
Getting CIMC Started
Initial Setup
KVM Features
Cable Connections
Power Up the KVM
Power UP KVM View
F8 to configure/view CIMC IP
Access CIMC
Verify
Troubleshoot
Related Information
Introduction
This support document provides an overview for the steps required to set up CIMC network connectivity for
the UCS C−Series server.
Prerequisites
Requirements
Cisco recommends that you:
Have a working knowledge of the Cisco UCS C−Series Server Blade hardware and software
administration.
•
Be familiar with UCS C−Series Servers Cisco Integrated Management Controller• Understand the impact and implications of the different commands described in this document.• Be familiar with the UCS C−Series components and topology.•
Components Used
The information in this document is based on Cisco UCS C−Series Servers.
The information in this document was created from the devices in a specific lab environment. All of the
devices used in this document started with a default configuration. If your network is live, make sure that you
understand the potential impact of any command.

Network Diagram
There is currently no specific network diagram available.
Conventions
Refer to the Cisco Technical Tips Conventions for more information on document conventions.
Background Information
There is currently no specific background information available.
Getting CIMC Started
Initial Setup
This is an overview of how to setup CIMC network connectivity for UCS C−Series servers.
KVM Features
Overview of KVM features:
Cisco C−Series Rack Servers provides a physical local video and two usb connections for a usb
keyboard, video monitor, and usb mouse connection through the front panel of the Rack Server using
the Cisco provided dongle connector.
1.
All Rack Servers can have up to 4 active KVM over IP sessions in addition to the local connection at
front or rear panels. All active sessions have full control of the console
2.
KVM over IP supports text and graphics modes of the graphics controller and needs no manual setting
to view data
3.
Graphics modes supported are up to the video chips maximum capabilities of 1600 x 1200 with 16 bit
color.
4.
KVM sessions over Linux may, depending on Linux distribution, require mouse configuration5. If KVM responsiveness seems slow; many factors such as network bandwidth latency can effect this.
Reducing the color depth and resolution can improves the responsiveness.
6.
Remote KVM shows exactly what is on the video. This is not a serial terminal view but rather a
pixel by pixel rendition
7.
If recording the session is desired you can use utilities on the local client such as webex or other
screen capture applications.
8.
If text logging of keystrokes is desired use SOL (Serial Over Lan) features and a terminal program to
capture the text.
9.
Cable Connections
Cable connections for C−Series servers:
C200 Front Panel:1.

C200 Rear Panel:
Connection for C200 Server:
C210 Front Panel:
C210 Rear Panel:
Connection for C210 Server:
2.

C250 Front Panel:
C250 Rear Panel:
Connection for C250 Server:
3.

Power Up the KVM
Complete these steps in order to power up the server:
Plug the power cord into the chassis.
Note:
CIMC initializes system standby (Power Off mode).♦ CIMC is active and can be controlled through GUI or CLI, if you know the IP address.♦
1.
Depress Front Panel Power:
The Fans begins to spin up.♦ Then POST sequence begins.♦ At this point you can either boot up or begin the installation process.♦ Note that for large memory, models can display a blank screen for several minutes.♦
For C−250If you immediately depress the power switch, you interrupt the CIMC
initialization.
♦
2.

It is possible that the Fans spin down and the indicator turns yellow.♦ If this happens, wait and then press the power button again.♦
Power UP KVM View
While the server boots up, you can access BIOS, Cisco Splash Screen in Quiet mode:
Press ESC in order to watch POST.• Once the system begins to boot, press F2 in order to access the BIOS configuration screen. These
steps require a physical KVM, either directly attached monitor and keyboard, or a local/remote KVM.
Once the chassis boots, press F2 in order to get to this screen.
•
Press F6 in order to manually choose the boot device.• Press F12 for the network boot.•
F8 to configure/view CIMC IP
While in BIOS you can press F8 for the CIMC IP address configuration and password reset.
Choose either DHCP or Static config.1. Enter the VLAN tag if needed.2. Enter the CIMC password.3. After you make a change to IP or enable DHCP, you can press F5 in order to display the configured
IP.
4.
Press F10 in order to save the configuration.5.
Access CIMC
Complete these steps:
The POST and the option ROM config is displayed during the boot up process.1. These are the Option ROM config screens, which are displayed:
LSI♦
2.

HBA/CNA if installed♦ Additional NICs♦ LOM♦
Then point a Web browser to the configured CIMC IP address.
Default username: admin♦ Default password: password♦
3.
Choose Admin > Network Settings and check Settings.4.

In order to revert to DHCP, from the Admin tab in the GUI, choose Network and in IPv4 properties,
check the Use DHCP box. Reboot the chassis.
5.

Monitor your DHCP server to see when the IP is assigned to your MAC. Then point to the new IP
server.
Once you logged into the CIMC, you can check the network setting:
6.

Verify
Refer to the previous sub−sections for verifications.
Troubleshoot
There is currently no specific troubleshooting information available for this configuration.
