Americas Headquarters:
© 2008 Cisco Systems, Inc. All rights reserved.
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Release Notes for the Cisco Catalyst
Blade Switch 3020 for HP,
Cisco IOS Release 12.2(44)SE
January 11, 2008
Cisco IOS Release 12.2(44)SE runs on the Cisco Catalyst Blade Switch 3020 for HP, referred to as the
switch. Unless otherwise noted, the term switch refers to a standalone switch.
Note If you wish to use Device Manager to upgrade the switch from Cisco IOS Release 12.2(35)SE through
Cisco IOS Release 12.2(40)SE1 (the LAN Base image) to Cisco IOS Release 12.2(44)SE or later (the IP
base image), you must first upgrade to Cisco IOS Release 12.2(40)SE2.
These release notes include important information about Cisco IOS Release 12.2(44)SE and any
limitations, restrictions, and caveats that apply to them. Verify that these release notes are correct for
your switch:
•If you are installing a new switch, see the Cisco IOS release label on the switch packaging.
•If your switch is on, use the show version privileged EXEC command. See the “Finding the
Software Version and Feature Set” section on page 3.
•If you are upgrading to a new release, see the software upgrade filename for the software version.
See the “Deciding Which Files to Use” section on page 3.
For the complete list of Cisco Catalyst Blade Switch 3020 for HP documentation, see the “Related
Documentation” section on page 20.
You can download the switch software from this site (registered Cisco.com users with a login password):
http://tools.cisco.com/support/downloads/go/MDFTree.x?butype=switches
This software release is part of a special release of Cisco IOS software that is not released on the same
8-week maintenance cycle that is used for other platforms. As maintenance releases and future software
releases become available, they will be posted to Cisco.com in the Cisco IOS software area.

2
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Contents
Contents
This information is in the release notes:
•“System Requirements” section on page 2
•“Upgrading the Switch Software” section on page 3
•“Installation Notes” section on page 6
•“New Software Features” section on page 6
•“Limitations and Restrictions” section on page 7
•“Important Notes” section on page 12
•“Open Caveats” section on page 14
•“Resolved Caveats” section on page 15
•“Documentation Updates” section on page 17
•“Obtaining Documentation, Obtaining Support, and Security Guidelines” section on page 20
System Requirements
The system requirements are described in these sections:
•“Hardware Supported” section on page 2
•“Device Manager System Requirements” section on page 2
Hardware Supported
The hardware supported on this release is the Cisco Catalyst Blade Switch 3020.
Device Manager System Requirements
These sections describes the hardware and software requirements for using the device manager:
•“Hardware Requirements” section on page 2
•“Software Requirements” section on page 3
Hardware Requirements
Table 1 lists the hardware supported on this release.
Table 1 Supported Hardware
Switch Description Supported by Minimum Cisco IOS Release
Cisco Catalyst Blade Switch 3020
for HP
24-Gigabit Ethernet ports and 4 SFP
module slots
Cisco IOS Release 12.2(35)SE
Small form factor pluggable (SFP)
modules
1000BASE-LX, -SX, and -T Cisco IOS Release 12.2(35)SE

3
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Upgrading the Switch Software
Software Requirements
Table 2 lists the supported operating systems and browsers for using the device manager, which does not
require a plug-in. The device manager verifies the browser version when starting a session to ensure that
the browser is supported.
Note Windows NT and Windows 98 are no longer supported.
Upgrading the Switch Software
These are the procedures for downloading software. Before downloading software, read this section for
important information:
•“Finding the Software Version and Feature Set” section on page 3
•“Deciding Which Files to Use” section on page 3
•“Upgrading a Switch by Using the Device Manager” section on page 5
•“Upgrading a Switch by Using the CLI” section on page 5
•“Recovering from a Software Failure” section on page 6
Finding the Software Version and Feature Set
The Cisco IOS image is stored as a bin file in a directory that is named with the Cisco IOS release.
A subdirectory contains the files needed for web management. The image is stored on the system board
flash device (flash:).
You can use the show version privileged EXEC command to see the software version that is running on
your switch. The second line of the display shows the version.
You can also use the dir filesystem:privileged EXEC command to see the directory names of other
software images that you might have stored in flash memory.
Deciding Which Files to Use
The upgrade procedures in these release notes describe how to perform the upgrade by using a combined
tar file. This file contains the Cisco IOS image file and the files needed for the embedded device
manager. You must use the combined tar file to upgrade the switch through the device manager. To
upgrade the switch through the command-line interface (CLI), use the tar file and the archive
download-sw privileged EXEC command.
Table 2 Supported Operating Systems and Browsers
Operating System Minimum Service Pack or Patch
Microsoft Internet
Explorer1
1. Service Pack 1 or higher is required for Internet Explorer 5.5.
Netscape
Navigator
Windows 2000 None 5.5 or 6.0 7.1
Windows XP None 5.5 or 6.0 7.1

4
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Upgrading the Switch Software
Note If you wish to use Device Manager to upgrade the switch from Cisco IOS Release 12.2(35)SE through
Cisco IOS Release 12.2(40)SE1 (the LAN Base image) to Cisco IOS Release 12.2(44)SE or later (the IP
base image), you must first upgrade to Cisco IOS Release 12.2(40)SE2.
Table 3 lists the filenames for this software release.
Archiving Software Images
Before upgrading your switch software, make sure that you have archived copies of the current Cisco
IOS release and the Cisco IOS release to which you are upgrading. You should keep these archived
images until you have upgraded all devices in the network to the new Cisco IOS image and until you
have verified that the new Cisco IOS image works properly in your network.
Cisco routinely removes old Cisco IOS versions from Cisco.com. See Product Bulletin 2863 for more
information:
http://www.cisco.com/en/US/products/sw/iosswrel/ps5187/prod_bulletin0900aecd80281c0e.html
You can copy the bin software image file on the flash memory to the appropriate TFTP directory on a
host by using the copy flash: tftp: privileged EXEC command.
Note Although you can copy any file on the flash memory to the TFTP server, it is time consuming to copy
all of the HTML files in the tar file. We recommend that you download the tar file from Cisco.com and
archive it on an internal host in your network.
You can also configure the switch as a TFTP server to copy files from one switch to another without
using an external TFTP server by using the tftp-server global configuration command. For more
information about the tftp-server command, see the “Basic File Transfer Services Commands” section
of the Cisco IOS Configuration Fundamentals Command Reference, Release 12.2 at this URL:
http://www.cisco.com/en/US/products/sw/iosswrel/ps1835/products_command_reference_book09186a
00800811e0.html
Table 3 Cisco IOS Software Image Files
Filename Description
cbs30x0-ipbase-tar.122-44.SE.tar Cisco Catalyst Blade Switch 3020 for HP image file and
device manager files.
This image has Layer 2+ features.
cbs30x0-ipbasek9-tar.122-44.SE.tar Cisco Catalyst Blade Switch 3020 for HP cryptographic
image file and device manager files.
This image has the Kerberos and SSH features.

5
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Upgrading the Switch Software
Upgrading a Switch by Using the Device Manager
You can upgrade switch software by using the device manager. For detailed instructions, click Help.
Note When using the device manager to upgrade your switch, do not use or close your browser session after
the upgrade process begins. Wait until after the upgrade process completes.
Upgrading a Switch by Using the CLI
This procedure is for copying the combined tar file to the switch. You copy the file to the switch from a
TFTP server and extract the files. You can download an image file and replace or keep the current image.
To download software, follow these steps:
Step 1 Use Table 3 on page 4 to identify the file that you want to download.
Step 2 Download the software image file. If you have a SmartNet support contract, go to this URL, and log in
to download the appropriate files:
http://www.cisco.com/kobayashi/sw-center/sw-lan.shtml
Step 3 Copy the image to the appropriate TFTP directory on the workstation, and make sure that the TFTP
server is properly configured.
For more information, see Appendix B in the software configuration guide for this release.
Step 4 Log into the switch through the console port or a Telnet session.
Step 5 (Optional) Ensure that you have IP connectivity to the TFTP server by entering this privileged EXEC
command:
Switch# ping tftp-server-address
For more information about assigning an IP address and default gateway to the switch, see the software
configuration guide for this release.
Step 6 Download the image file from the TFTP server to the switch. If you are installing the same version of
software that is currently on the switch, overwrite the current image by entering this privileged EXEC
command:
Switch# archive download-sw /overwrite /reload
tftp:[[//location]/directory]/image-name.tar
The /overwrite option overwrites the software image in flash memory with the downloaded one.
The /reload option reloads the system after downloading the image unless the configuration has been
changed and not saved.
For //location, specify the IP address of the TFTP server.
For /directory/image-name.tar, specify the directory (optional) and the image to download. Directory
and image names are case sensitive.

6
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Installation Notes
This example shows how to download an image from a TFTP server at 198.30.20.19 and to overwrite
the image on the switch:
Switch# archive download-sw /overwrite
tftp://198.30.20.19/c3750-ipservices-tar.122-44.SE.tar
You can also download the image file from the TFTP server to the switch and keep the current image by
replacing the /overwrite option with the /leave-old-sw option.
Recovering from a Software Failure
For additional recovery procedures, see the “Troubleshooting” chapter in the software configuration
guide for this release.
Installation Notes
You can assign IP information to your switch by using these methods:
•The Express Setup program or the HP Onboard Administrator program described in the getting
started guide.
•The CLI-based setup program, as described in the hardware installation guide.
•The DHCP-based autoconfiguration, as described in the software configuration guide.
•Manually assigning an IP address, as described in the software configuration guide.
New Software Features
These are the new software features for this release:
•DHCP-based autoconfiguration and image update to download a specified configuration and image
to a large number of switches
•Configurable small-frame arrival threshold to prevent storm control when small frames (64 bytes or
less) arrive on an interface at a specified rate (the threshold)
•Support for the *, ip-address, interface interface-id, and vlan vlan-id keywords with the clear ip
dhcp snooping command
•HTTP and HTTP(s) support over IPv6, which eliminates the need to run dual stack on the switch
•Simple Network and Management Protocol (SNMP) can be configured over IPv6 transport so that
an IPv6 host can send SNMP queries and receive SNMP notifications from a device running IPv6
•IPv6 supports stateless autoconfiguration to manage link, subnet, and site addressing changes, such
as management of host and mobile IP addresses
•IEEE 802.1x readiness check to determine the readiness of connected end hosts before configuring
IEEE 802.1x on the switch
•The switch now ships with the IP base image installed, which provides Layer 2+ features, including
static routing, EIGRP and PIM stub routing, the Hot Standby Router Protocol (HSRP), the Routing
Information Protocol (RIP), IPv6 host management, and IPv6 MLD snooping

7
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Limitations and Restrictions
Limitations and Restrictions
You should review this section before you begin working with the switch. These are known limitations
that will not be fixed, and there is not always a workaround. Some features might not work as
documented, and some features could be affected by recent changes to the switch hardware or software.
This section contains these limitations:
•“Cisco IOS Limitations” section on page 7
•“Device Manager Limitations” section on page 11
Cisco IOS Limitations
These limitations apply to the switch:
•“Configuration” section on page 7
•“Dynamic ARP Inspection” section on page 8
•“Ethernet” section on page 8
•“IP” section on page 8
•“IP Telephony” section on page 9
•“MAC Addressing Multicasting” section on page 9
•“QoS” section on page 10
•“SPAN and RSPAN” section on page 10
•“Trunking” section on page 11
•“VLAN” section on page 11
Configuration
The workaround is to configure the burst interval to more than 1 second.
These are the configuration limitations:
•A static IP address might be removed when the previously acquired DHCP IP address lease expires.
This problem occurs under these conditions:
– When the switch is booted without a configuration (no config.text file in flash memory).
– When the switch is connected to a DHCP server that is configured to give an address to it (the
dynamic IP address is assigned to VLAN 1).
– When an IP address is configured on VLAN 1 before the dynamic address lease assigned to
VLAN 1 expires.
The workaround is to reconfigure the static IP address. (CSCea71176 and CSCdz11708)
•When connected to some third-party devices that send early preambles, a switch port operating at
100 Mp/s full duplex or 100 Mp/s half duplex might bounce the line protocol up and down. The
problem is observed only when the switch is receiving frames.
The workaround is to configure the port for 10 Mp/s and half duplex or to connect a hub or a
nonaffected device to the switch. (CSCed39091)

8
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Limitations and Restrictions
•When port security is enabled on an interface in restricted mode and the switchport block unicast
interface command has been entered on that interface, MAC addresses are incorrectly forwarded
when they should be blocked
The workaround is to enter the no switchport block unicast interface configuration command on
that specific interface. (CSCee93822)
•A traceback error occurs if a crypto key is generated after an SSL client session.
There is no workaround. This is a cosmetic error and does not affect the functionality of the switch.
(CSCef59331)
Dynamic ARP Inspection
This is the Dynamic Arp Inspection limitation:
When dynamic ARP inspection is configured on a VLAN, and the ARP traffic on a port in the VLAN is
within the configured rate limit, the port might go into an error-disabled state. (CSCse06827)
Ethernet
These are the Ethernet limitations:
•Traffic on EtherChannel ports is not perfectly load-balanced. Egress traffic on EtherChannel ports
are distributed to member ports on load balance configuration and traffic characteristics like MAC
or IP address. More than one traffic stream might map to same member ports, based on hashing
results calculated by the ASIC.
If this happens, traffic distribution is uneven on EtherChannel ports.
Changing the load balance distribution method or changing the number of ports in the EtherChannel
can resolve this problem. Use any of these workarounds to improve EtherChannel load balancing:
– for random source-ip and dest-ip traffic, configure load balance method as src-dst-ip
– for incrementing source-ip traffic, configure load balance method as src-ip
– for incrementing dest-ip traffic, configure load balance method as dst-ip
– Configure the number of ports in the EtherChannel so that the number is equal to a power of 2
(for example, 2, 4, or 8)
For example, with load balance configured as dst-ip with 150 distinct incrementing destination IP
addresses, and the number of ports in the EtherChannel set to either 2, 4, or 8, load distribution is
optimal. (CSCeh81991)
•If you enter the test cable-diagnostics tdr privileged EXEC command on the dual-media interfaces
Gi0/23 and Gi0/24, the Ethernet interface that is being tested shuts down and then comes back up.
There is no workaround.(CSCse04563)
IP
This is the IP limitation:
When the rate of received DHCP requests exceeds 2,000 packets per minute for a long time, the response
time might be slow when you are using the console. The workaround is to use rate limiting on DHCP
traffic to prevent a denial of service attack from occurring. (CSCeb59166)

9
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Limitations and Restrictions
IP Telephony
This is the IP telephony limitation:
After you change the access VLAN on a port that has IEEE 802.1x enabled, the IP phone address is
removed. Because learning is restricted on IEEE 802.1x-capable ports, it takes approximately 30
seconds before the address is relearned. No workaround is necessary. (CSCea85312)
logging event-spanning-tree Command
When the logging event-spanning-tree interface configuration command is configured and logging to
the console is enabled, a topology change might generate a large number of logging messages, causing
high CPU utilization. CPU utilization can increase with the number of spanning-tree instances and the
number of interfaces configured with the logging event-spanning-tree interface configuration
command. This condition adversely affects how the switch operates and could cause problems such as
STP convergence delay.
High CPU utilization can also occur with other conditions, such as when debug messages are logged at
a high rate to the console.
Use one of these workarounds:
•Disable logging to the console.
•Rate-limit logging messages to the console. (CSCsg91027)
Remove the logging event spanning-tree interface configuration command from the interfaces.
MAC Addressing Multicasting
These are the multicasting limitations:
•If the number of multicast routes and Internet Group Management Protocol (IGMP) groups are more
than the maximum number specified by the show sdm prefer global configuration command, the
traffic received on unknown groups is flooded in the received VLAN even though the show ip igmp
snooping multicast-table privileged EXEC command output shows otherwise. The workaround is
to reduce the number of multicast routes and IGMP snooping groups to less than the maximum
supported value. (CSCdy09008)
•IGMP filtering is applied to packets that are forwarded through hardware. It is not applied to packets
that are forwarded through software. Hence, with multicast routing enabled, the first few packets are
sent from a port even when IGMP filtering is set to deny those groups on that port. There is no
workaround. (CSCdy82818)
•If an IGMP report packet has two multicast group records, the switch removes or adds interfaces
depending on the order of the records in the packet:
– If the ALLOW_NEW_SOURCE record is before the BLOCK_OLD_SOURCE record, the
switch removes the port from the group.
– If the BLOCK_OLD_SOURCE record is before the ALLOW_NEW_SOURCE record, the
switch adds the port to the group.
There is no workaround. (CSCec20128)

10
Release Notes for the Cisco Catalyst Blade Switch 3020 for HP, Cisco IOS Release 12.2(44)SE
OL-14761-01
Limitations and Restrictions
•When IGMP snooping is disabled and you enter the switchport block multicast interface
configuration command, IP multicast traffic is not blocked.
The switchport block multicast interface configuration command is only applicable to non-IP
multicast traffic.
There is no workaround. (CSCee16865)
•Incomplete multicast traffic can be seen under either of these conditions:
– You disable IP multicast routing or re-enable it globally on an interface.
– A switch mroute table temporarily runs out of resources and recovers later.
The workaround is to enter the clear ip mroute privileged EXEC command on the interface.
(CSCef42436)
After you configure a switch to join a multicast group by entering the ip igmp join-group
group-address interface configuration command, the switch does not receive join packets from the
client, and the switch port connected to the client is removed from the IGMP snooping forwarding
table.
Use one of these workarounds:
– Cancel membership in the multicast group by using the no ip igmp join-group group-address
interface configuration command on an SVI.
– Disable IGMP snooping on the VLAN interface by using the no ip igmp snooping vlan vlan-id
global configuration command. (CSCeh90425)
QoS
These are the quality of service (QoS) limitations:
•Some switch queues are disabled if the buffer size or threshold level is set too low with the mls qos
queue-set output global configuration command. The ratio of buffer size to threshold level should
be greater than 10 to avoid disabling the queue. The workaround is to choose compatible buffer sizes
and threshold levels. (CSCea76893)
•When auto-QoS is enabled on the switch, priority queuing is not enabled. Instead, the switch uses
shaped round robin (SRR) as the queuing mechanism. The auto-QoS feature is designed on each
platform based on the feature set and hardware limitations, and the queuing mechanism supported
on each platform might be different. There is no workaround. (CSCee22591)
•A QoS service policy with a policy map containing more than 62 policers cannot be added to an
interface by using the service-policy interface configuration command.
The workaround is to use policy maps with 62 or fewer policers. (CSCsc59418)
SPAN and RSPAN
These are the SPAN and Remote SPAN (RSPAN) limitations:
•Egress SPAN routed packets (both unicast and multicast) show the incorrect source MAC address.
For remote SPAN packets, the source MAC address should be the MAC address of the egress VLAN,
but instead the packet shows the MAC address of the RSPAN VLAN. For local SPAN packets with
native encapsulation on the destination port, the packet shows the MAC address of VLAN 1. This
problem does not appear with local SPAN when the encapsulation replicate option is used. This
limitation does not apply to bridged packets. The workaround is to use the encapsulate replicate
keywords in the monitor session global configuration command. Otherwise, there is no
workaround. This is a hardware limitation. (CSCdy81521)
