Installing a Network Module
•Network Modules Overview, on page 1
•Installing a Network Module in the Switch, on page 2
•Removing a Network Module, on page 9
•Installing and Removing Cisco Transceiver Modules, on page 10
•Finding the Network Module Serial Number, on page 12
Network Modules Overview
The Cisco Catalyst 9300 Series Switches supports the following optional network modules for uplink ports.
DescriptionNetwork Module
This module has four 1G SFP module slots. Any combination of standard SFP
modules are supported.
Supported only on Cisco Catalyst 9300 Series Switches.
Note
C9300-NM-4G
This module has eight 10G SFP+ module slots.
Supported only on Cisco Catalyst 9300 Series Switches.
Note
C9300-NM-8X
This module has two 40G QSFP+ module slots.
Supported only on Cisco Catalyst 9300 Series Switches.
Note
C9300-NM-2Q
This module has four Multigigabit Ethernet (mGig) module slots.
Supported only on Cisco Catalyst 9300 Series Switches.
Note
C9300-NM-4M
This module has two 25G SFP28 module slots.
Supported only on Cisco Catalyst 9300 Series Switches.
Note
C9300-NM-2Y
This module has four 1G SFP module slots. Any combination of standard SFP
modules are supported. SFP+ modules are not supported.
If you insert an SFP+ module in the 1G network module, the SFP+ module does
not operate, and the switch logs an error message.
C3850-NM-4-1G
Installing a Network Module
1

DescriptionNetwork Module
This module has four slots. Two slots (left side) support only 1G SFP modules and
two slots (right side) support either 1G SFP or 10G SFP modules.
C3850-NM-2-10G
This module has four 10G slots or four 1G slots.C3850-NM-4-10G
This module has eight 10G slots with an SFP+ port in each slot. Each port supports
a 1G or 10G connection
C3850-NM-8-10G
This module has two 40G slots with a QSFP+ connector in each slot.C3850-NM-2-40G
Insert this blank module when the switch has no uplink ports (this is required for
sufficient air flow).
Blank Network Module
Installing a Network Module in the Switch
Safety Warnings
This section includes the installation cautions and warnings. Translations of the safety warnings are available
in the Regulatory Compliance and Safety Information for Cisco Catalyst 9300 Series Switches.
Read this section before you install a network module.
Proper ESD protection is required whenever you handle equipment. Installation and maintenance personnel
should be properly grounded by grounding straps to eliminate the risk of ESD damage to the equipment.
Equipment is subject to ESD damage whenever you remove it.
Caution
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Do not reach into a vacant slot or chassis while you install or remove a module. Exposed circuitry could
constitute an energy hazard. Statement 206
Warning
Installing a Network Module
The switch can operate without a network module, but a blank module (with no ports or SFP slots) is available
and should be installed when uplink ports are not required.
Note
Installing a Network Module
2
Installing a Network Module
Installing a Network Module in the Switch

The switch generates logs when you insert or remove a network module with SFP/SFP+/SFP28/QSFP+ slots.
Note
Use only supported network modules and Cisco pluggable transceivers. Each module has an internal serial
EEPROM that is encoded with security information.
The network module is hot-swappable. If you remove a module, replace it with another network module or
a blank module.
The switch complies with EMC, safety, and thermal specifications when a network module is present. If no
uplink ports are required, install a blank network module.
Note
Before you begin
When installing network modules, observe these precautions:
• Do not remove the blank module from the slot unless you are installing a network module. A module
must be in the uplink slot at all times.
• Do not remove the dust plugs from the pluggable transceivers or the rubber caps from the fiber-optic
cable until you connect the cable. The plugs and caps protect the module ports and cables from
contamination and ambient light.
•Removing and installing a network module can shorten its useful life. Do not remove and insert a network
module more often than is necessary.
•To prevent ESD damage, follow your normal board and component handling procedures when connecting
cables to the switch and other devices.
Unlike other network modules, the C9300-NM-8X cannot be fully inserted and secured until the jackscrew
is properly tightened.
1. Push the module into the uplink slot until the jackscrew connects with the rightmost tab.
2. You will feel some light resistance, because a spring-loaded tab inside the slot will push back against the
C9300-NM-8X module
3. Continue to tighten the jackscrew while gently pushing the front panel of the network module into the
slot.
Note
Procedure
Step 1 Attach an ESD-preventive wrist strap to your wrist and to an earth ground surface.
Step 2 Remove the module from the protective packaging.
Step 3 Remove the blank module from the switch and save it. To remove the blank module, loosen the captive screw
on the module using a screwdriver until it completely disengages from the chassis.
Installing a Network Module
3
Installing a Network Module
Installing a Network Module

Verify the correct orientation of your module before installing it. Incorrect installation can damage
the module.
Caution
Do not install the network module with connected cables or installed pluggable transceivers. Always
remove any cables and transceiver modules before you install the network module.
Caution
A module interface might become error-disabled when a network module with connected fiber-optic
cables is installed or removed. If an interface is error-disabled, you can reenable the interface by
using the shutdown and no shutdown interface configuration commands.
Caution
Step 4 Position the module face up to install it in the module slot. Slide the module into the slot until the screw makes
contact with the chassis. Fasten the captive screws to secure the network module in place.
Figure 1: Installing the Network Module in the Switch
Network Module Port Configurations
C9300-NM-2Q Module
If you use a 40G QSFP module, the ports default to 40G interfaces. In this case, the 10G interfaces are displayed
but not used.
Table 1: C9300-NM-2Q Module with 40G QSFP Module
ActionInterface
Configure this interfaceFortyGigabitEthernet1/1/1
Configure this interfaceFortyGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/1
Installing a Network Module
4
Installing a Network Module
Network Module Port Configurations

ActionInterface
DisregardTenGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/3
DisregardTenGigabitEthernet1/1/4
DisregardTenGigabitEthernet1/1/5
DisregardTenGigabitEthernet1/1/6
DisregardTenGigabitEthernet1/1/7
DisregardTenGigabitEthernet1/1/8
C9300-NM-4G Module
All ports in the C9300-NM-4G module are natively GigabitEthernet and are configured GigabitEthernet1/1/1
though GigabitEthernet1/1/4. There are only four interfaces that are valid, and the other four should not be
used even though they are available in the CLI.
Table 2: C9300-NM-4G Module
ActionInterface
Configure this interfaceGigabitEthernet1/1/1
Configure this interfaceGigabitEthernet1/1/2
Configure this interfaceGigabitEthernet1/1/3
Configure this interfaceGigabitEthernet1/1/4
DisregardTenGigabitEthernet1/1/1
DisregardTenGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/3
DisregardTenGigabitEthernet1/1/4
C9300-NM-4M Module
Table 3: C9300-NM-4M Module with 4 Multigigabit Ethernet (mGig) Module
ActionInterface
Configure this interfaceTenGigabitEthernet1/1/1
Configure this interfaceTenGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/3
Configure this interfaceTenGigabitEthernet1/1/4
Installing a Network Module
5
Installing a Network Module
C9300-NM-4G Module

C9300-NM-2Y Module
Table 4: C9300-NM-2Y Module with 25G SFP28 Module
ActionInterface
Configure this interfaceTwentyFiveGigabitEthernet1/1/1
Configure this interfaceTwentyFiveGigabitEthernet1/1/2
C9300-NM-8X Module
All ports in the C9300-NM-8X module default to 10 G and should be configured as TenGigabitEthernet1/1/1
through TenGigabitEthernet1/1/8, even when you are operating them as 1 G using SFP.
Table 5: C9300-NM-8-10X Module
ActionInterface
Configure this interfaceTenGigabitEthernet1/1/1
Configure this interfaceTenGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/3
Configure this interfaceTenGigabitEthernet1/1/4
Configure this interfaceTenGigabitEthernet1/1/5
Configure this interfaceTenGigabitEthernet1/1/6
Configure this interfaceTenGigabitEthernet1/1/7
Configure this interfaceTenGigabitEthernet1/1/8
C3850-NM-4-1G Module
All ports in the C3850-NM-4-1G module are natively GigabitEthernet and are configured GigabitEthernet1/1/1
though GigabitEthernet1/1/4. There are only four interfaces that are valid, and the other four should not be
used even though they still show up in the CLI.
Table 6: C3850-NM-4-1G Module
ActionInterface
Configure this interfaceGigabitEthernet1/1/1
Configure this interfaceGigabitEthernet1/1/2
Configure this interfaceGigabitEthernet1/1/3
Configure this interfaceGigabitEthernet1/1/4
DisregardTenGigabitEthernet1/1/1
Installing a Network Module
6
Installing a Network Module
C9300-NM-2Y Module

ActionInterface
DisregardTenGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/3
DisregardTenGigabitEthernet1/1/4
C3850-NM-4-10G Module
All ports in the C3850-NM-4-10G module default to 10 G and should be configured as TenGigabitEthernet1/1/1
through TenGigabitEthernet1/1/4, even when you are operating them as 1 G using SFPs. Only four interfaces
are valid; the other four should not be used even though they still show up in the CLI.
Table 7: C3850-NM-4-10G Module
ActionInterface
DisregardGigabitEthernet1/1/1
DisregardGigabitEthernet1/1/2
DisregardGigabitEthernet1/1/3
DisregardGigabitEthernet1/1/4
Configure this interfaceTenGigabitEthernet1/1/1
Configure this interfaceTenGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/3
Configure this interfaceTenGigabitEthernet1/1/4
C3850-NM-2-10G Module
In the C3850-NM-2-10G module, the first two parts are natively 1-G ports and the last two ports are natively
10-G ports. So, you configure the 1-G posts as GigabitEthernet1/1/1 through GigabitEthernet1/1/2, and
configure the last two ports as TenGigabitEthernet1/1/3 through TenGigabitEthernet1/1/4, even when you
are operating the last two ports as 1-G. Only four interfaces are valid, and the other four should not be used
even though they still show up in the CLI.
Table 8: C3850-NM-2-10G Module
ActionInterface
Configure this interfaceGigabitEthernet1/1/1
Configure this interfaceGigabitEthernet1/1/2
DisregardGigabitEthernet1/1/3
DisregardGigabitEthernet1/1/4
DisregardTenGigabitEthernet1/1/1
Installing a Network Module
7
Installing a Network Module
C3850-NM-4-10G Module

ActionInterface
DisregardTenGigabitEthernet1/1/2
Configure this interface, even when operating as 1-GTenGigabitEthernet1/1/3
Configure this interface, even when operating as 1-GTenGigabitEthernet1/1/4
C3850-NM-8-10G Module
All ports in the C3850-NM-8-10G module default to 10 G and should be configured as TenGigabitEthernet1/1/1
through TenGigabitEthernet1/1/8, even when you are operating them as 1 G using SFP.
Table 9: C3850-NM-8-10G Module
ActionInterface
Configure this interfaceTenGigabitEthernet1/1/1
Configure this interfaceTenGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/3
Configure this interfaceTenGigabitEthernet1/1/4
Configure this interfaceTenGigabitEthernet1/1/5
Configure this interfaceTenGigabitEthernet1/1/6
Configure this interfaceTenGigabitEthernet1/1/7
Configure this interfaceTenGigabitEthernet1/1/8
C3850-NM-2-40G Module
The default port connections for the C3850-NM-2-40G module depends on whether you use a 40 G QSFP
module or a 4x10G breakout cable.
If you use a 40 G QSFP module, the ports default to 40 G interfaces. In this case, the 10 G interfaces are
displayed but not used.
Table 10: C3850-NM-2-40G Module with 40 G QSFP Module
ActionInterface
Configure this interfaceFortyGigabitEthernet1/1/1
Configure this interfaceFortyGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/1
DisregardTenGigabitEthernet1/1/2
DisregardTenGigabitEthernet1/1/3
DisregardTenGigabitEthernet1/1/4
Installing a Network Module
8
Installing a Network Module
C3850-NM-8-10G Module

ActionInterface
DisregardTenGigabitEthernet1/1/5
DisregardTenGigabitEthernet1/1/6
DisregardTenGigabitEthernet1/1/7
DisregardTenGigabitEthernet1/1/8
If you use a 4x10G breakout cable, the ports default to 10 G interfaces.
Table 11: C3850-NM-2-40G Module with 4x10G breakout cable
ActionInterface
DisregardFortyGigabitEthernet1/1/1
DisregardFortyGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/1
Configure this interfaceTenGigabitEthernet1/1/2
Configure this interfaceTenGigabitEthernet1/1/3
Configure this interfaceTenGigabitEthernet1/1/4
Configure this interfaceTenGigabitEthernet1/1/5
Configure this interfaceTenGigabitEthernet1/1/6
Configure this interfaceTenGigabitEthernet1/1/7
Configure this interfaceTenGigabitEthernet1/1/8
Removing a Network Module
The switch complies with EMC, safety, and thermal specifications when a network module is present. If no
uplink ports are required, install a blank network module.
Note
Procedure
Step 1 Attach an ESD-preventive wrist strap to your wrist and to an earth ground surface
Do not remove the network module with connected cables or installed pluggable transceiver modules.
Always remove any cables and modules before you remove the network module.
Caution
Installing a Network Module
9
Installing a Network Module
Removing a Network Module

A module interface might become error-disabled when a network module with connected fiber-optic
cables is installed or removed. If an interface is error-disabled, you can reenable the interface by
using the shutdown and no shutdown interface configuration commands.
Caution
Step 2 Disconnect the cables from the pluggable transceiver module.
Step 3 Remove the pluggable transceiver module from the network module.
Step 4 Loosen the captive screws that hold the network module in place until it completely disengages from the
chassis.
The C3850-NM-8-10G module is held secure in the switch by only one jackscrew. This screw also
helps to eject the module from its connector interface. Before the module can be removed completely,
the screw must be unscrewed all the way out. When removing the screw, a spring pushes the module
out when the screw is completely disengaged. Ensure that you hold the module securely until it is
completely removed.
Note
Step 5 Carefully slide the network module out of the slot.
Step 6 Install a replacement network module or a blank module in the slot.
Step 7 Place the module that you removed in an antistatic bag or other protective environment.
Installing and Removing Cisco Transceiver Modules
Installing a Cisco Pluggable Transceiver Module
Before you begin
You must have an installed network module to use the transceiver modules. See the switch release notes on
Cisco.com for the list of supported pluggable transceiver modules. Use only supported pluggable transceivers
on the switch. For the latest information about supported transceiver modules, refer to the Cisco Transceiver
Modules Compatibility Information.
For information about installing, removing, cabling, and troubleshooting pluggable transceiver modules, see
the module documentation that shipped with your device.
Observe these precautions:
Class 1 laser product. Statement 1008
Warning
• Do not remove the dust plugs from the pluggable transceiver modules or the rubber caps from the
fiber-optic cable until you are ready to connect the cable. The plugs and caps protect the module ports
and cables from contamination and ambient light.
• Removing and installing a pluggable transceiver module can shorten its useful life. Do not remove and
insert any module more often than is necessary.
•To prevent ESD damage, follow your normal board and component handling procedures when connecting
cables to the switch and other devices.
Installing a Network Module
10
Installing a Network Module
Installing and Removing Cisco Transceiver Modules

• When you insert several pluggable transceiver modules in multiple switch ports, wait for 5 seconds
between inserting each module. This will prevent the ports from going into error disabled mode. Similarly,
when you remove a pluggable transceiver module from a port, wait for 5 seconds before reinserting it.
Procedure
Step 1 Attach an ESD-preventive wrist strap to your wrist and to an earth ground surface.
Step 2 Find the send (TX) and receive (RX) markings that identify the top of the transceiver module.
On some modules, the send and receive (TX and RX) markings might be shown by arrows that show the
direction of the connection.
Step 3 If the pluggable transceiver module has a bale-clasp latch, move it to the open, unlocked position.
Step 4 Align the module in front of the slot opening, and push until you feel the connector snap into place.
Figure 2: Installing a Pluggable Transceiver Module in the Network Module
Step 5 If the module has a bale-clasp latch, close it to lock the module in place.
Step 6 Remove the dust plugs and save.
Step 7 Connect the transceiver cables.
Installing a Network Module
11
Installing a Network Module
Installing a Cisco Pluggable Transceiver Module

Figure 3: Network Module with Pluggable Transceiver Modules Installed
Removing Cisco Pluggable Transceiver Modules
Procedure
Step 1 Attach an ESD-preventive wrist strap to your wrist and to an earth ground surface.
Step 2 Disconnect the cable from the transceiver module. For reattachment, note which cable connector plug is send
(TX) and which is receive (RX).
Step 3 Insert a dust plug into the optical ports of the transceiver module to keep the optical interfaces clean.
Step 4 If the transceiver module has a bale-clasp latch, pull the bale out and down to eject the module. If you cannot
use your finger to open the latch, use a small, flat-blade screwdriver or other long, narrow instrument to open
it.
Step 5 Grasp the transceiver module, and carefully remove it from the slot.
Step 6 Place the transceiver module in an antistatic bag or other protective environment.
Finding the Network Module Serial Number
If you contact Cisco Technical Assistance regarding a network module, you need to know its serial number.
Installing a Network Module
12
Installing a Network Module
Removing Cisco Pluggable Transceiver Modules

Figure 4: Network Module Serial Number Location
Installing a Network Module
13
Installing a Network Module
Finding the Network Module Serial Number

Installing a Network Module
14
Installing a Network Module
Finding the Network Module Serial Number
