Cisco Nexus 93180LC-EX Manual

Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
First Published: 2017-05-17
Last Modified: 2018-10-19
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS REFERENCED IN THIS DOCUMENTATION ARE SUBJECT TO CHANGE WITHOUT NOTICE.
EXCEPT AS MAY OTHERWISE BE AGREED BY CISCO IN WRITING, ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS DOCUMENTATION ARE
PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED.
The Cisco End User License Agreement and any supplemental license terms govern your use of any Cisco software, including this product documentation, and are located at:
http://www.cisco.com/go/softwareterms.Cisco product warranty information is available at http://www.cisco.com/go/warranty. US Federal Communications Commission Notices are found
here http://www.cisco.com/c/en/us/products/us-fcc-notice.html.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS
HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Any products and features described herein as in development or available at a future date remain in varying stages of development and will be offered on a when-and if-available basis. Any
such product or feature roadmaps are subject to change at the sole discretion of Cisco and Cisco will have no liability for delay in the delivery or failure to deliver any products or feature
roadmap items that may be set forth in this document.
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network
topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional
and coincidental.
The documentation set for this product strives to use bias-free language. For the purposes of this documentation set, bias-free is defined as language that does not imply discrimination based
on age, disability, gender, racial identity, ethnic identity, sexual orientation, socioeconomic status, and intersectionality. Exceptions may be present in the documentation due to language
that is hardcoded in the user interfaces of the product software, language used based on RFP documentation, or language that is used by a referenced third-party product.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com
go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1721R)
©2017 Cisco Systems, Inc. All rights reserved.

CONTENTS
Trademarks ?
Preface vii
PREFACE
Audience vii
Documentation Conventions vii
Related Documentation for Cisco Nexus 9000 Series NX-OS Software viii
Documentation Feedback x
Obtaining Documentation and Submitting a Service Request x
Overview 1
CHAPTER 1
Overview 1
Preparing the Site 5
CHAPTER 2
Temperature Requirements 5
Humidity Requirements 5
Altitude Requirements 5
Dust and Particulate Requirements 6
Minimizing Electromagnetic and Radio Frequency Interference 6
Shock and Vibration Requirements 7
Grounding Requirements 7
Planning for Power Requirements 7
Airflow Requirements 9
Rack and Cabinet Requirements 9
Clearance Requirements 10
Installing the Switch Chassis 13
CHAPTER 3
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
iii

Safety 13
Installation Options with Rack-Mount Kits 14
Airflow Considerations 14
Installation Guidelines 14
Unpacking and Inspecting the Switch 16
Installing the Switch Using the NXK-ACC-KIT-1RU Rack-Mount Kit 17
Installing the Switch Using the N3K-C3064-ACC-KIT Rack-Mount Kit 20
Grounding the Chassis 24
Starting the Switch 26
Connecting the Switch to the Network 29
CHAPTER 4
Connecting to the Network 29
Preparing for Network Connections 29
Connecting to a Console 30
Connecting the Management Interface 31
Connecting Interface Ports to Other Devices 31
Installing QSFP+ Transceivers 32
Managing the Switch 35
CHAPTER 5
Configuring Ports 35
Replacing Components 37
CHAPTER 6
Replacing a Fan Module 37
Removing a Fan Module 37
Installing a Fan Module 38
Replacing a Power Supply Module 38
Replacing an AC Power Supply 38
Replacing a High Voltage (HVAC/HVDC) Power Supply 40
Replacing a DC Power Supply 41
Rack Specifications 43
APPENDIX A
Overview of Racks 43
General Requirements for Cabinets and Racks 43
Requirements Specific to Standard Open Racks 44
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
iv
Contents

Requirements Specific to Perforated Cabinets 44
Cable Management Guidelines 44
System Specifications 45
APPENDIX B
Environmental Specifications 45
Switch Dimensions 45
Switch and Module Weights and Quantities 46
Transceiver and Cable Specifications 46
Switch Power Input Requirements 46
Power Specifications 47
500-W AC Power Supply Specifications 47
1200-W HVAC/HVDC Power Supply Specifications 47
930-W DC Power Supply Specifications 48
Power Cable Specifications 49
Power Cable Specifications for AC Power Supplies 49
HVAC/HVDC Power Cables Supported by ACI-Mode and NX-OS Mode Switches 50
DC Power Cable Specifications 51
Regulatory Standards Compliance Specifications 51
LEDs 53
APPENDIX C
Switch Chassis LEDs 53
Fan Module LEDs 54
Power Supply LEDs 54
Additional Kits 57
APPENDIX D
Rack Mount Kit NXK-ACC-KIT-1RU 57
Rack Mount Kit N3K-C3064-ACC-KIT 58
Site Preparation and Maintenance Records 59
APPENDIX E
Site Preparation Checklist 59
Contact and Site Information 60
Chassis and Module Information 61
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
v
Contents

Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
vi
Contents

Preface
•Audience, on page vii
•Documentation Conventions, on page vii
•Related Documentation for Cisco Nexus 9000 Series NX-OS Software, on page viii
•Documentation Feedback, on page x
•Obtaining Documentation and Submitting a Service Request , on page x
Audience
This publication is for hardware installers and network administrators who install, configure, and maintain
Cisco Nexus switches.
Documentation Conventions
Command descriptions use the following conventions:
DescriptionConvention
Bold text indicates the commands and keywords that you enter literally
as shown.
bold
Italic text indicates arguments for which the user supplies the values.Italic
Square brackets enclose an optional element (keyword or argument).[x]
Square brackets enclosing keywords or arguments separated by a vertical
bar indicate an optional choice.
[x | y]
Braces enclosing keywords or arguments separated by a vertical bar
indicate a required choice.
{x | y}
Nested set of square brackets or braces indicate optional or required
choices within optional or required elements. Braces and a vertical bar
within square brackets indicate a required choice within an optional
element.
[x {y | z}]
Indicates a variable for which you supply values, in context where italics
cannot be used.
variable
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
vii

DescriptionConvention
A nonquoted set of characters. Do not use quotation marks around the
string or the string will include the quotation marks.
string
Examples use the following conventions:
DescriptionConvention
Terminal sessions and information the switch displays are in screen font.screen font
Information you must enter is in boldface screen font.boldface screen font
Arguments for which you supply values are in italic screen font.italic screen font
Nonprinting characters, such as passwords, are in angle brackets.< >
Default responses to system prompts are in square brackets.[ ]
An exclamation point (!) or a pound sign (#) at the beginning of a line
of code indicates a comment line.
!, #
Related Documentation for Cisco Nexus 9000 Series NX-OS
Software
The entire Cisco NX-OS 9000 Series documentation set is available at the following URL:
https://www.cisco.com/en/US/products/ps13386/tsd_products_support_series_home.html
Release Notes
The release notes are available at the following URL:
https://www.cisco.com/en/US/products/ps13386/prod_release_notes_list.html
Configuration Guides
These guides are available at the following URL:
https://www.cisco.com/en/US/products/ps13386/products_installation_and_configuration_guides_list.html
The documents in this category include:
•Cisco Nexus 2000 Series NX-OS Fabric Extender Software Configuration Guide for Cisco Nexus 9000
Series Switches
•Cisco Nexus 9000 Series NX-OS Fundamentals Configuration Guide
•Cisco Nexus 9000 Series NX-OS High Availability and Redundancy Guide
•Cisco Nexus 9000 Series NX-OS Interfaces Configuration Guide
•Cisco Nexus 9000 Series NX-OS Layer 2 Switching Configuration Guide
•Cisco Nexus 9000 Series NX-OS Multicast Routing Configuration Guide
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
viii
Preface
Related Documentation for Cisco Nexus 9000 Series NX-OS Software

•Cisco Nexus 9000 Series NX-OS Quality of Service Configuration Guide
•Cisco Nexus 9000 Series NX-OS Security Configuration Guide
•Cisco Nexus 9000 Series NX-OS System Management Configuration Guide
•Cisco Nexus 9000 Series NX-OS Unicast Routing Configuration Guide
•Cisco Nexus 9000 Series NX-OS Verified Scalability Guide
•Cisco Nexus 9000 Series NX-OS VXLAN Configuration Guide
Other Software Documents
•Cisco Nexus 7000 Series and 9000 Series NX-OS MIB Quick Reference
•Cisco Nexus 9000 Series NX-OS Programmability Guide
•Cisco Nexus 9000 Series NX-OS Software Upgrade and Downgrade Guide
•Cisco Nexus 9000 Series NX-OS System Messages Reference
•Cisco Nexus 9000 Series NX-OS Troubleshooting Guide
•Cisco NX-OS Licensing Guide
•Cisco NX-OS XML Interface User Guide
Hardware Documents
•Cisco Nexus 3000 Series Hardware Installation Guide
•Cisco Nexus 92160YC-X NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 92300YC NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 92304QC NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9236C NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9272Q NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 93108TC-EX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 93120TX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 93128TX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 93180LC-EX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 93180YC-EX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9332PQ NX-OS-Mode Switch Hardware Installation Guide
•Cisco Nexus 9364C NX-OS-Mode Switch Hardware Installation Guide
•Cisco Nexus 9372PX and 9372PX-E NX-OS Mode Switches Hardware Installation Guide
•Cisco Nexus 9372TX and 9372TX-E NX-OS Mode Switches Hardware Installation Guide
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
ix
Preface
Preface

•Cisco Nexus 9396PX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9396TX NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9504 NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
•Cisco Nexus 9516 NX-OS Mode Switch Hardware Installation Guide
•Regulatory, Compliance, and Safety Information for the Cisco Nexus 3000 and 9000 Series
Documentation Feedback
To provide technical feedback on this document, or to report an error or omission, please send your comments
to [email protected]. We appreciate your feedback.
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, using the Cisco Bug Search Tool (BST), submitting a service
request, and gathering additional information, see What's New in Cisco Product Documentation, at:
https://www.cisco.com/warp/public/687/Directory/DirTAC.shtml.
Subscribe to What's New in Cisco Product Documentation, which lists all new and revised Cisco technical
documentation as an RSS feed and delivers content directly to your desktop using a reader application. The
RSS feeds are a free service.
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
x
Preface
Documentation Feedback

CHAPTER 1
Overview
•Overview, on page 1
Overview
The Cisco Nexus 93180LC-EX switch (N9K-C93180LC-EX) is a 1-RU, fixed-port standalone switch with
28 40/50-Gigabit Ethernet QSFP+ downlink ports and 4 100-Gigabit Ethernet QSFP28 uplink ports. You can
change the ways that these ports are used and configured as explained in Configuring Ports, on page 35.
The 40/50-Gigabit ports are 50-Gigabit capable but that speed is not currently supported.
Note
• Fan modules (four) with the following airflow choices:
• Port-side intake airflow with burgundy coloring (NXA-FAN-30CFM-B)
• Port-side exhaust airflow with blue coloring (NXA-FAN-30CFM-F)
Table 1: Fan Speeds for this Switch
Port-Side Exhaust
Fan Speed %
Port-Side Intake
Fan Speed %
70%50%Typical/Minimum
100%100%Maximum
Note
• Power supply modules (two—one for operations and one for redundancy [1+1]) with the following
choices (do not mix AC and DC power sources and do not mix airflow directions):
• 500-W AC power supply with port-side intake airflow (burgundy coloring) (NXA-PAC-500W-PI)
• 500-W AC power supply with port-side exhaust airflow (blue coloring) (NXA-PAC-500W-PE)
• 930-W DC power supply with port-side exhaust airflow (blue coloring) (NXA-PDC-930W-PE)
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
1

• 930-W DC power supply with port-side intake airflow (burgundy coloring) (NXA-PDC-930W-PI)
• 1200-W HVAC/HVDC power supply with dual-direction airflow (white coloring)
(N9K-PUV-1200W)
If you use the 1200-W HVAC/HVDC power supply, the power supply
automatically uses the same airflow direction as used by the fan
modules installed in the same switch.
Note
The following figure shows the hardware features seen from the port side of the chassis.
Interface ports (32)
• Downlink ports (ports 1-28)
• Uplink ports (ports 29-32)
4Chassis LEDs (Beacon [BCN], Status [STS], and
Environment [ENV])
1
Screw holes (6) for attaching rack mounting
brackets
5Port lane LEDs2
Grounding pad6Port lane switch button3
To determine which transceivers, adapters, and cables this switch supports, see the Cisco Transceiver Modules
Compatibility Information document.
The following figure shows the hardware features seen from the power supply side of the chassis.
Management port (SFP+ port)6Two power supplies (one used for operations and
one used for redundancy) (AC power supplies
shown) with power supply slot 1 on the left and
slot 2 on the right
1
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
2
Overview
Overview

USB port7Four fan modules with fan slot 1 on the left and
fan slot 4 on the right
2
Screw holes (6) for attaching rack mounting
brackets
8Console port (RS-232 port)3
Grounding pad9Management port (RJ-45 port)4
Chassis LEDs (Beacon [BCN] and Status [STS])5
USB support is limited to USB 2.0 devices that use less than 2.5 W (less than 0.5 A inclusive of surge current).
Devices, such as external hard drives, that instantaneously draw more than 0.5 A are not supported.
Note
Depending on whether you plan to position the ports in a hot or cold aisle, you can order the fan and power
supply modules with port-side intake or port-side exhaust airflow. To determine the airflow direction of the
modules installed in your switch, see the following table.
Port-Side Exhaust Airflow ColoringPort-Side Intake Airflow ColoringReplaceable Modules
BlueBurgundyFans
BlueBurgundyAC power supplies
WhiteHVAC/HVDC power supplies
Blue
BurgundyDC power supplies
The fan and power supply modules are field replaceable. You can replace one fan module or one power supply
module during operations, so long as the other modules are installed and operating. If you have only one
power supply that is installed, you can install the replacement power supply in the open slot before removing
the original power supply.
All the fan and power supply modules must have the same direction of airflow. Otherwise, the switch can
overheat and shut down. If you are installing a dual-direction power supply, that module automatically uses
the same airflow direction as the other modules in the switch.
Note
If the switch has port-side intake airflow (burgundy coloring for fan modules), you must locate the ports in
the cold aisle. If the switch has port-side exhaust airflow (blue coloring for fan modules), you must locate the
ports in the hot aisle. If you locate the air intake in a hot aisle, the switch can overheat and shut down.
Caution
The switch supports the Fabric Extenders (FEXs) listed at
https://www.cisco.com/c/en/us/td/docs/switches/datacenter/nexus9000/hw/interoperability/fexmatrix/fextables.html.
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
3
Overview
Overview

Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
4
Overview
Overview

CHAPTER 2
Preparing the Site
•Temperature Requirements, on page 5
•Humidity Requirements, on page 5
•Altitude Requirements, on page 5
•Dust and Particulate Requirements, on page 6
•Minimizing Electromagnetic and Radio Frequency Interference, on page 6
•Shock and Vibration Requirements, on page 7
•Grounding Requirements, on page 7
•Planning for Power Requirements, on page 7
•Airflow Requirements, on page 9
•Rack and Cabinet Requirements, on page 9
•Clearance Requirements, on page 10
Temperature Requirements
The switch requires an operating temperature of 32 to 104 degrees Fahrenheit (0 to 40 degrees Celsius). If
the switch is not operating, the temperature must be between –40 to 158 degrees Fahrenheit (–40 to 70 degrees
Celsius).
Humidity Requirements
High humidity can cause moisture to enter the switch. Moisture can cause corrosion of internal components
and degradation of properties such as electrical resistance, thermal conductivity, physical strength, and size.
The switch is rated to withstand from 5- to 95-percent (noncondensing) relative humidity.
Buildings in which the climate is controlled by air-conditioning in the warmer months and by heat during the
colder months usually maintain an acceptable level of humidity for the switch equipment. However, if the
switch is located in an unusually humid location, use a dehumidifier to maintain the humidity within an
acceptable range.
Altitude Requirements
Altitude rating is based on power supply installed; see critical components list in the system CB report for
altitude rating.
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
5

Dust and Particulate Requirements
Exhaust fans cool power supplies and system fans cool switches by drawing in air and exhausting air out
through various openings in the chassis. However, fans also ingest dust and other particles, causing contaminant
buildup in the switch and increased internal chassis temperature. Dust and particles can act as insulators and
interfere with the mechanical components in the switch. A clean operating environment can greatly reduce
the negative effects of dust and other particles.
In addition to keeping your environment free of dust and particles, follow these precautions to avoid
contamination of your switch:
• Do not permit smoking near the switch.
• Do not permit food or drink near the switch.
Minimizing Electromagnetic and Radio Frequency Interference
Electromagnetic interference (EMI) and radio frequency interference (RFI) from the switch can adversely
affect other devices, such as radio and television (TV) receivers. Radio frequencies that emanate from the
switch can also interfere with cordless and low-power telephones. Conversely, RFI from high-power telephones
can cause spurious characters to appear on the switch monitor.
RFI is defined as any EMI with a frequency above 10 kHz. This type of interference can travel from the switch
to other devices through the power cable and power source or through the air as transmitted radio waves. The
Federal Communications Commission (FCC) publishes specific regulations to limit the amount of EMI and
RFI that are emitted by computing equipment. Each switch meets these FCC regulations.
To reduce the possibility of EMI and RFI, follow these guidelines:
• Cover all open expansion slots with a blank filler plate.
• Always use shielded cables with metal connector shells for attaching peripherals to the switch.
When wires are run for any significant distance in an electromagnetic field, interference can occur to the
signals on the wires with the following implications:
• Bad wiring can result in radio interference emanating from the plant wiring.
• Strong EMI, especially when it is caused by lightning or radio transmitters, can destroy the signal drivers
and receivers in the chassis and even create an electrical hazard by conducting power surges through
lines into equipment.
To predict and prevent strong EMI, you need to consult experts in radio frequency interference (RFI).
Note
The wiring is unlikely to emit radio interference if you use a twisted-pair cable with a good distribution of
grounding conductors. If you exceed the recommended distances, use a high-quality twisted-pair cable with
one ground conductor for each data signal when applicable.
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
6
Preparing the Site
Dust and Particulate Requirements

If the wires exceed the recommended distances, or if wires pass between buildings, give special consideration
to the effect of a lightning strike in your vicinity. The electromagnetic pulse that is caused by lightning or
other high-energy phenomena can easily couple enough energy into unshielded conductors to destroy electronic
switches. You will want to consult experts in electrical surge suppression and shielding if you had similar
problems in the past.
Caution
Shock and Vibration Requirements
The switch has been shock- and vibration-tested for operating ranges, handling, and earthquake standards.
Grounding Requirements
The switch is sensitive to variations in voltage that is supplied by the power sources. Overvoltage, undervoltage,
and transients (or spikes) can erase data from memory or cause components to fail. To protect against these
types of problems, ensure that there is an earth-ground connection for the switch. You can connect the grounding
pad on the switch either directly to the earth-ground connection or to a fully bonded and grounded rack.
When you properly install the chassis in a grounded rack, the switch is grounded because it has a metal-to-metal
connection to the rack. Alternatively, you can ground the chassis by using a customer-supplied grounding
cable that meets your local and national installation requirements. For U.S. installations, we recommend
6-AWG wire. Connect your grounding cable to the chassis with a grounding lug (provided in the switch
accessory kit) and to the facility ground.
You automatically ground AC power supplies when you connect them to AC power sources. For DC power
supplies, you must connect a grounding wire when wiring the power supply to the DC power source.
Note
An electrical conducting path shall exist between the product chassis and the metal surface of the enclosure
or rack in which it is mounted or to a grounding conductor. Electrical continuity shall be provided by using
thread-forming type mounting screws that remove any paint or non-conductive coatings and establish a
metal-to-metal contact. Any paint or other non-conductive coatings shall be removed on the surfaces between
the mounting hardware and the enclosure or rack. The surfaces shall be cleaned and an antioxidant applied
before installation.
Note
Planning for Power Requirements
The switch includes two power supplies (1-to-1 redundancy with current sharing) in one of the following
combinations:
• Two 500-W AC power supplies
• Two 1200-W HVAC/HVDC power supplies
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
7
Preparing the Site
Shock and Vibration Requirements

• Two 930-W DC power supplies
Both power supplies must be the same type. Do not mix AC, DC, and HVAC/HVDC power supplies in the
same chassis.
Note
For n+1 redundancy, you can use one or two power sources for the two power supplies. For n+nredundancy,
you must use two power sources and connect each power supply to a separate power source.
Note
Some of the power supply modules have rating capabilities that exceed the switch requirements. When
calculating your power requirements, use the switch requirements to determine the amount of power that is
required for the power supplies.
Note
To minimize the possibility of circuit failure, make sure that each power-source circuit that is used by the
switch is dedicated to the switch.
For AC input application, please refer to the following statement:
Note
Statement 1005—Circuit Breaker
This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the
protective devices are rated not greater than 20A (North America), 16A (Europe), and 13A (UK).
Warning
For DC input application, please refer to the following statement:
Note
Statement 1005—Circuit Breaker
This product relies on the building's installation for short-circuit (overcurrent) protection.
• Ensure that the protective devices are rated not greater than 30A when the switch is powered with regular
DC power supplies (rated 48-60VDC).
• Ensure that the protective devices are rated not greater than 10A when the switch is powered with HVDC
power supplies (rated 240-350VDC).
Warning
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
8
Preparing the Site
Planning for Power Requirements

Statement 1033
Connect the unit only to DC power source that complies with the Safety Extra-Low Voltage (SELV)
requirements in IEC 60950 based safety standards.
Warning
We recommend 8-AWG wire for DC installations in the U.S.
Note
For the power cables to use with the power supplies, see Power Cable Specifications, on page 49.
Note
Airflow Requirements
The switch is positioned with its ports in either the front or the rear of the rack depending on your cabling
and maintenance requirements. You must have fan and power supply modules that move the coolant air from
the cold aisle to the hot aisle in one of the following ways:
• Port-side exhaust airflow—Cool air enters the chassis through the fan and power supply modules in the
cold aisle and exhausts through the port end of the chassis in the hot aisle.
• Port-side intake airflow—Cool air enters the chassis through the port end in the cold aisle and exhausts
through the fan and power supply modules in the hot aisle.
• Dual-direction airflow—The direction of the installed fan modules determines the airflow.
You can identify the airflow direction of each fan and power supply module by its coloring as follows:
• Blue coloring indicates port-side exhaust airflow.
• Burgundy coloring indicates port-side intake airflow.
• White coloring on HVAC/HVDC power supplies indicates dual-direction airflow.
To prevent the switch from overheating and shutting down, you must position the air intake for the switch in
a cold aisle. The fan and power supply modules must have the same direction of airflow (even if their coloring
is different). If you must change the airflow direction for the switch, you must shutdown the switch before
changing the modules.
Note
Rack and Cabinet Requirements
You can install the following types of racks or cabinets for your switch:
• Standard perforated cabinets
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
9
Preparing the Site
Airflow Requirements

• Solid-walled cabinets with a roof fan tray (bottom-to-top cooling)
• Standard open four-post Telco racks
Work with your cabinet vendors to determine which of their cabinets meet the following requirements or see
the Cisco Technical Assistance Center (TAC) for recommendations:
• Use a standard 19-inch (48.3-cm), four-post Electronic Industries Alliance (EIA) cabinet or rack with
mounting rails that conform to English universal hole spacing per section 1 of the ANSI/EIA-310-D-1992
standard.
• The depth of a four-post rack must be 24 to 32 inches (61.0 to 81.3 cm) between the front and rear
mounting rails (for proper mounting of the bottom-support brackets or other mounting hardware).
• Required clearances between the chassis and the edges of its rack or the interior of its cabinet are as
follows:
• 4.5 inches (11.4 cm) between the front of the chassis and the interior of the cabinet (required for
cabling).
•3.0 inches (7.6 cm) between the rear of the chassis and the interior of the cabinet (required for airflow
in the cabinet if used).
• No clearance is required between the chassis and the sides of the rack or cabinet (no side airflow).
Also, you must have power receptacles that are located within reach of the power cords that are used with the
switch.
Statement 1048—Rack Stabilization
The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before installation
or servicing. Failure to stabilize the rack can cause bodily injury.
Warning
Clearance Requirements
Provide the chassis with adequate clearance between the chassis and any other rack, device, or structure so
that you can properly install the chassis. Provide the chassis with adequate clearance to route cables, provide
airflow, and maintain the switch. For the clearances required for an installation of this chassis in a four-post
rack, see the following figure.
Cisco Nexus 93180LC-EX NX-OS Mode Hardware Installation Guide
10
Preparing the Site
Clearance Requirements
