CBM-290/291 Service Manual
- 2- CITIZEN
INTRODUCTION
This manual describes the disassembly, reassembly, and maintenance procedures of the dot
matrix printer CBM-290/291. It is intended for field maintenance men.
FEATURES
The CBM-290/291 is a thermal line dot type small printer equipped with a line thermal head.
This printer, developed for various data communication terminals, POS terminals, kitchen
printers, is widely available for a variety of applications.
(1) Rack built-in type small line thermal printer
(2) High speed and low noise
(3) High reliability due to long-life printing head and simple mechanism
(4) Serial and parallel interfaces selectable by a DIP switch
(5) Built-in input buffer
(6) Capable of printing bar codes (By a special command)
(7) Equipped with an auto cutter (CBM-291 only)
(8) Capable of dealing with the JIS 1st- and 2nd-level Kanji
(9) External character registration function (94 characters)

CBM-290/291 Service Manual
- 3- CITIZEN
CONTENTS
1. HANDLING AND MAINTENANCE OF PRINTER ..........................................................................4
2. SPECIFICATIONS...............................................................................................................................4
2.1 Basic Specifications……………………………………………………………………………………………..4
2.2 Paper Specifications…………………………………………………………………………………………… 5
3. DISASSEMBLY AND REASSEMBLY ................................................................................................6
3.1 Disassembly Procedure..........................................................................................................................6
3.2 Reassembly Procedure.........................................................................................................................10
4. TROUBLESHOOTING ......................................................................................................................11
4.1 Troubleshooting Procedure..................................................................................................................11
4.2 Troubleshooting Guide.........................................................................................................................11
5. SERVICE PARTS LIST......................................................................................................................13
5.1 Pats List for Mechanism......................................................................................................................14
5.2 Disassembly Drawing ..........................................................................................................................16
5.3 Packing Drawing..................................................................................................................................17
5.4 Parts List for Control Board ...............................................................................................................18
5.5 Parts Layout Drawing..........................................................................................................................20
5.5.1 PCB Assy(Parts Side) ..............................................................................................................
20
5.5.2 PCB Assy(Solder Side)............................................................................................................. 21
6. DRAWINGS.........................................................................................................................................22
6.1 Block Diagram......................................................................................................................................23
6.2.1 CBM-290(Without Auto Cutter)..............................................................................................
23
6.2.2 CBM-291(With Auto Cutter) ................................................................................................... 24
6.2 Circuit Diagram....................................................................................................................................25
6.2.1 CBM-290/291............................................................................................................................
25
7. OUTER DIMENTION........................................................................................................................26

CBM-290/291 Service Manual
- 4- CITIZEN
1
11
1.
..
.H
HH
HA
AA
AN
NN
ND
DD
DL
LL
LI
II
IN
NN
NG
GG
G A
AA
AN
NN
ND
DD
D M
MM
MA
AA
AI
II
IN
NN
NT
TT
TE
EE
EN
NN
NA
AA
AN
NN
NC
CC
CE
EE
E O
OO
OF P
F PF P
F PR
RR
RI
II
IN
NN
NT
TT
TE
EE
ER
RR
R
See the User’s Manual coming with the printer body.
2
22
2.
..
. S
SS
SP
PP
PEC
ECEC
ECI
II
IF
FF
FI
II
IC
CC
CA
AA
AT
TT
TI
II
IO
OO
ON
NN
NS
SS
S
2
22
2.
..
.1
11
1 B
BB
Ba
aa
as
ss
si
ii
ic
cc
c S
SS
Sp
pp
pe
ee
ec
cc
ci
ii
if
ff
fi
ii
ic
cc
ca
aa
at
tt
ti
ii
io
oo
on
nn
ns
ss
s
Item Description
Printing method Line thermal dot printing system
Printing speed 50 mm/sec. at maximum
Dot density 8 dots/mm (Horizontal and vertical)
Printing digits Font A: 34 digits, Font B: 46 digits
Character size Font A: 1.25 mm x 3.00 mm (10 x 24 + 2 dot space),
Font B: 0.88 mm x 2.13 mm (7 x 17 + 2 dot space),
Kanji: 3.00 mm x 3.00 mm (24 x 24)
Character types Alphenumerals, international characters, JIS 1st- and 2nd-level
Kanji (Kanji for the domestic specifications)
Bar code types UPC-A/E, JAN(EAN) 13 digits/8 digits, ITF, CODE 39, CODE
128, CODE BAR
Line spacing 4.23 mm(1/6 inch), settable by a command
Paper Rolled thermal paper: 58 mm wide x f50 mm or less
Interface Parallel(CENTRONICS) or serial(RS-232C) (Selectable by a DIP
switch)
Input buffer 4 KB
Paper end detection Stops printing when the paper runs out.
Auto loading If new paper is set into the paper inlet, it will be fed
automatically.
Auto cutter (CBM-291 only) Cuts the paper automatically by a command. Either full cut or
partial cut is selectable.
International character set Capable of setting the following 10 countries for specific
character codes by a command.(U.S., French, German, Danish 1
and 2, Swedish, Italian, Spanish, Japanese, Norwegian)
Supply voltage and power
consumption 5 V +/- 5 %, approx. 0.2A at standby and printout; 24 V +/- 5 %, approx. 10 mAat standby and approx. 1.8A at print
(Approx. 6 Aat peak)
Operating temperature 5 to 40 °C, 35 to 85 % RH (No dew condensation)
Storage temperature -20 to 60 °C, 10 to 90 % RH (No dew condensation)
Outer dimensions 106 (W) x 109 (H) x 99 (D) mm
Weight CBM-290: Approx. 460 g (Main body only), CBM-291: Approx.
600 g (Main body only), Fitting: Approx. 50 g
Applicable standards UL, CUL, TUV
EMI VCCI: Class A applicable, FCC: ClassA applicable
Reliability
Printing head life: Pulse resistance --- 50,000,000 pulses (Print
ratio: 12.5 %), Wear resistance --- 30 km (With specified
paper at normal temperature and humidity)
Auto cutter life: 300,000 cuts (CBM-291)
