Citizen PPU-231II Installation manual

LINE THERMAL PRINTER
MODEL PPU-231II
Rev. 1.01 Newly issued on December 19, 2002
Command Reference

Rev.No. Date Comment
Rev. 1.00 Jun. 10, 2002 Newly issued
Rev. 1.01 Dec. 19, 2002 Revised P. 12, P. 78, P. 79, P. 90
REVISION

— 1 —
1 HT Horizontal tab S.P. <09>H 5
2 LF Printing and paper feed S.P. <0A>H 6
3 CR Back to printing S.P. <0D>H 7
4FF
Printing in PAGE MODE and returning to P
<0C>H 8
STANDARD MODE
Printing and paper feeding to the top of
the Black mark position S
5 CAN Canceling print data in PAGE MODE P <18>H 9
6 DLE EOT Sending status in real-time S.P. <10>H<04>H<n> 10
7 DLE ENQ Real-time request to printer S.P. <10>H<05>H<n> 13
8 ESC FF Printing data in PAGE MODE P <1B>H<0C>H 14
9
10 ESC SP Setting the right spacing of the character S.P.* <1B>H<20>H<n> 15
11 ESC ! Collectively specifying the printing mode S.P. <1B>H<21>H<n> 17
12 ESC $ Specifying the absolute positions S.P.*
<1B>H<24>H<n1> 19
<n2>
13 ESC % Specifying/Canceling download character set S.P. <1B>H<25>H<n> 21
<1B>H<26>H<s>H
14 ESC & Defining the download characters S.P.
<n><m>[<a><p1>
22
<p2> ⋅ ⋅ <ps×a>]
m-n+1
15 ESC *Specifying the bit image mode S.P.
<1B>H<2A>H<m>
24
<n1><n2>[<d>]k
16 ESC - Specifying/Canceling underline S.P. <1B>H<2D>H<n> 26
17 ESC 2 Specifying 1/6-inch line feed rate S.P. <1B>H<32>H 27
18 ESC 3 Setting line feed rate of minimum pitch S.P.* <1B>H<33>H<n> 28
19 ESC = Data input control S.P. <1B>H<3D>H<n> 29
20 ESC ? Deleting download characters S.P. <1B>H<3F>H<n> 30
21 ESC @ Initializing the printer S.P. <1B>H<40>H 31
22 ESC D Setting horizontal tab position S.P. <1B>H<44>H [<n>]k<00> 32
23 ESC E Specifying/Canceling Emphasis Printing S.P. <1B>H<45>H<n> 33
24 ESC G Specifying/Canceling Double strike printing S.P. <1B>H<47>H<n> 34
25 ESC J Printing and feeding paper in minimum pitch S.P.* <1B>H<4A>H<n> 35
26 ESC L Selecting PAGE MODE S <1B>H<4C>H 36
27 ESC M Selection of character fonts S.P. <1B>H<4D>H<n> 37
28 ESC R Selecting the international character set S.P. <1B>H<52>H<n> 38
29 ESC S Selecting STANDARD MODE P <1B>H<53>H 39
30 ESC T Selecting the character printing direction P
<1B>H<54>H<n> 40
in PAGE MODE
No. Command Function Mode Code Page
1. PRINT CONTROL FUNCTIONS
1.1 Command List

— 2 —
In the Mode column: S = STANDARD MODE, P = PAGE MODE
*shows the command affected by GS P.
31 ESC V Specifying/Canceling 90°-right-turned S <1B>H<56>H<n> 41
characters
<1B>H<57>H<xL><xH>
32 ESC W Defining the print area in PAGE MODE P* <yL><yH><dxL><dxH> 42
<dyL><dyH>
33 ESC \ Specifying the relative position S.P.* <1B>H<5C>H<nL><nH> 44
34 ESC a Aligning the characters S.P. <1B>H<61>H<n> 45
35 ESC c3 Selecting the Paper Sensor valid for S.P.
<1B>H<63>H<33>H
46
paper end signal output <n>
36 ESC c4 Selecting the Paper Near-end Sensor valid S.P.
<1B>H<63>H<34>H
47
for print stop <n>
37 ESC c5 Enabling/Disabling the panel switches S.P.
<1B>H<63>H<35>H
48
<n>
38 ESC d Printing and feeding the paper by “n” lines S.P. <1B>H<64>H<n> 49
39 ESC n Setting a remaining amount of printout S.P. <1B>H<6E>H<n> 50
40 ESC t Selecting the character code table S.P. <1B>H<74>H<n> 51
41 ESC { Specifying/Canceling the inverted characters S <1B>H<7B>H<n> 52
42 GS ! Specifying the character size S.P. <1D>H<21>H<n> 53
43 GS $ Specifying the absolute vertical position P*
<1D>H<24>H<nL>
55
of characters in PAGE MODE <nH>
44 GS *Defining the download bit image S.P.
<1D>H<2A>H<n1>
56
<n2>[<d>]n1×n2×8
45 GS ( A Execution of test printing S
<1D>H<28>H<41>H
58
<pL><pH><n><m>
46 GS / Printing the downloaded bit image S.P. <1D>H<2F>H<m> 59
47 GS : Starting/Ending macro definition S.P. <1D>H<3A>H 60
48 GS A Correcting the position of black mark S.P.
<1D>H<41>H<m>
61
top position <n>
49 GS B Specifying/Canceling the black/white S.P. <1D>H<42>H<n> 62
inverted printing
50 GS H Selecting of printing position of HRI S.P.
<1D>H<48>H<n> 63
characters
51 GS I Sending the printer ID S.P. <1D>H<49>H<n> 65
52 GS L Setting the left margin S*
<1D>H<4C>H<nL>
<nH>
66
53 GS P Specifying the basic calculation pitch S.P.
<1D>H<50>H<x>
<y>
68
54 GS R0 Collecting receipts S.P.
<1D>H<53>H<30>
H<n>H
69
55 GS R1 Setting receipt collection timer S.P.
<1D>H<53>H<31>
H<n>
70
56 GS S Detecting a black mark S.P. <1D>H<53>H 71
( 1)<1D>H<56>H<m>
57 GS V Cutting the paper S.P.* (2)<1D>H<56>H<m> 72
<n>
No. Command Function Mode Code Page

— 3 —
58 GS W Setting the print area width S.P.*
<1D>H<57>H<nL>
<nH>
73
59 GS \ Specifying the relative vertical position S.P.*
<1D>H<5C>H<nL>
75
of a character in PAGE MODE <nH>
60 GS ^ Executing the macro S.P.
<1D>H<5E>H<n1>
76
<n2><n3>
61 GS a Enabling/Disabling ASB (Automatic S.P. <1D>H<61>H<n> 77
Status Back)
62 GS f Selecting the font of HRI characters S.P. <1D>H<66>H<n> 80
63 GS h Specifying the height of the bar code S.P. <1D>H<68>H<n> 81
(1)<1D>H<6B>H<m>
64 GS k Printing the bar code S.P.
[d1...dk]NUL
82
(2)<1D>H<6B>H<m>
<n>[d1...dn]
65 GS r Sending status S.P. <1D>H<72>H<n> 90
66 GS v0
<1D>H<76>H<30>H
Printing of raster bit image S <m><xL><xH> 91
<yL><yH>[<d>]k
67 GS w Specifying the horizontal size S.P. <1D>H<77>H<n> 93
(magnification) of bar code
No. Command Function Mode Code Page
Command relative to NV memory
<1C>H<67>H<33>
<m>H<a1>H<a2>H
68 FS g3 Writing data into the download user NV memory S <a3>H<a4>H<nL>H 94
<nH>H[<d>]nL+
(nH×256)
<1C>H<67>H<34>H
69 FS g4 Reading data from the download user NV memory S.P.
<m>H<a1>H<a2>H
96
<a3>H<a4>H<nL>H
<nH>H
70 FS p Printing the download NV bit images S <1C>H<70>H<n><m> 98
71 FS q Defining the download NV bit image S
<1C>H<71>H<n>H 100
No. Command Function Mode Code Page
In the Mode column: S = STANDARD MODE, P = PAGE MODE
*shows the command affected by GS P.
Commands Nos. 48 and 56 are available only if the Black mark feature is specified.

— 4 —
1.2 Command Details
1.2.1 Descriptions of Each Item
XXXX
[Function] The name of a command.
[Code] The string of codes comprising the command is represented
by < >H for hexadecimal numbers, < >B for binary numbers,
and < > for decimal numbers, [ ] k denotes the number of
repetition of “k” times.
[Range] Indicates the values (setting range) of argumeuts of the
command.
Note: If values outside the defined domain specified with
control codes are used, malfunctions could possibly
occur, so be sure to use the values within the defined
domain.
[Outline] Describes the functions of the command.
[Caution] Describes important points and cautionary notes, as required.
[Default] Initial values for the command if it has arguments.
[Reference] Describes commands related to the command when it is used.
[Sample Program] Describes examples of coding on Quick-Basic.
Examples are only for reference. They may vary depending
onlanguageandversion.Fordetails,pleaserefertoamanual
in your language.
[Printing Result] Describes the print results obtained by executing the above
programs.However,theprintresultsshownaredifferentinscale
from actual print results.

— 5 —
1.2.2 Command Details
HT
[Function] Horizontal tab
[Code] <09>H
[Outline] Shifts the printing position to the next horizontal tab position.
• Ignored when the next horizontal tab position has not been
set.
[Caution] • The horizontal tab position is set by ESC D.
• The initial setting of horizontal tab positions is at intervals of
8 characters for font A at 9th, 17th, 25th, 33rd, columns.
[See Also] ESC D
[Sample Program]
[Printing Result] 12345678901234567890
AAA BBB ← Initially set horizontal tab
AAA BBB CCC ← When set to the 4th, 8th, and 15th columns
LPRINT “0123456789012345678901”;
LPRINT CHR$(&HA);
LPRINT CHR$(&H9) + “AAA”;
LPRINT CHR$(&H9) + “BBB”;
LPRINT CHR$(&HA) ;
LPRINT CHR$(&H1B) + “D”;
LPRINT CHR$(3) + CHR$(7) + CHR$(14) + CHR$(0);
LPRINT CHR$(&H9) + “AAA”;
LPRINT CHR$(&H9) + “BBB”;
LPRINT CHR$(&H9) + “CCC” + CHR$(&HA) ;
END

— 6 —
LF
[Function] Printing and paper feed
[Code] <0A>H
[Outline] Prints data inside the print buffer and feeds paper based on the
line feed amount having been set.
[Caution] The head of the line becomes the next print starting position.
[See Also] ESC 2, ESC 3
[Sample Program]
[Print Results] AAA ← Print and line feed
BBB ← Print and line feed
← Line feed only
CCC ← Print and line feed
LPRINT “AAA” + CHR$(&HA) ;
LPRINT “BBB” + CHR$(&HA) ;
LPRINT CHR$(&HA) ;
LPRINT “CCC” + CHR$(&HA) ;
END

— 7 —
CR
[Function] Back to printing
[Code] <0D>H
[Outline] 1) When DSW1-5 is OFF:
This command is ignored.
2) When DSW1-5 is ON:
With data held inside the internal print buffer, printing and
line feed are performed.
Without data inside the internal print buffer, however, only
line feed is performed.
[See Also] LF
[Sample Program]
[Print Results] AAA ← Print and line feed
BBB ← Print and line feed
← Line feed only
CCC ← Print and line feed
LPRINT “AAA” + CHR$(&HD) ;
LPRINT “BBB” + CHR$(&HD) ;
LPRINT CHR$(&HD) ;
LPRINT “CCC” + CHR$(&HD) ;
END

— 8 —
FF (Page Mode)
[Function] Printing in PAGE MODE and returning to STANDARD MODE
[Code] <0C>H
[Outline] Executes a batch printout of the data mapped in the entire print
area, and then returns to STANDARD MODE.
[Caution] • All mapped data is erased after printout.
• The print area set up by ESC W is initialized.
• This command does not execute a paper cut.
• After this command is executed, the beginning of the line is
taken as the start position for the next print.
• This command is only effective when the PAGE MODE is
selected.
[See Also] ESC FF, ESC L, ESC S, GS FF
FF (Standard Mode)
[Function] Printing and paper feeding to the top of the Black mark position
[Code] <0C>H
[Outline] Thiscommand prints the datain the printer bufferand searches
for the head of the next label (Black mark position)
[Caution] This command is valid only when the label printer is selected
with DS2-7. It is ignored when the thermal paper is specified.
After sending one label worth of print data, be sure to send this
command or GS FF command. After the user intentionally
moved the label paper, this command cannnot search for the
head of the label properly.
[See Also] GS FF, GS <
[Sample Program]
LPRINT “ABC” ; CHR$ (&HA) ;
LPRINT “123” ; CHR$ (&HC) ;
LPRINT “HHHHH” ; CHR$ (&HA) ;
LPRINT “gggg” ; CHR$ (&HC) ;
END
[Print Result]
ABC
123
HHHHH
ggggg

— 9 —
CAN
[Function] Canceling print data in PAGE MODE
[Code] <18>H
[Outline] Erases all data contained in the currently effective print area in
PAGE MODE.
[Caution] • Thiscommand is only effectivewhen PAGE MODE is selected.
• If the previously established print area overlaps the currently
effective print area, the overlapped data in the previously
established area will be erased.
[See Also] ESC L, ESC W

— 10 —
DLE EOT n
[Function] Sending status in real-time
[Code] <10>H<04>H<n>
[Range] 1 n 4
[Outline] Sends in real-time the status specified by “n”.
[Caution] • Each status represents the current status. It is 1 byte data.
• The status is transferred without checking whether the host is
ready to receive or busy.
• Thiscommandis executed even iftheprinter is in offlinestate,
receive-buffer full state, or error state.
• This command is dealt with when it is received.
• If another data string of <10>H<04>H<n> (1 n 4) is
received,the printer acts thesame way as withthis command.
Therefore, the user should be reminded of this fact.
[Example 1]
Suppose a command “ESC * mnL nH [d1 ... dk]”, where d1 =
<10>H, d2 = <04>H, d3 = <01>H.
• The DLE EOT n command cannot be interleaved into the code
string of another command consisting of 2 bytes or more.
[Example 2]
If the printer sends DLE EOT 3 after the host has sent up to ESC
3 in its attempt to send ESC 3 n, the printer handles the ESC 3
as ESC 3 <10>H. Thus, the user should be cautious.
• If ASB (Automatic Status Back) is enabled by GS a, it is
necessary to discriminate between the status due to ASB and
the status due to this command.
n Status
1 Printer status
2 Status caused by an offline condition
3 Status caused by an error
4 Continuous paper detector status

— 11 —
(1) Printer status (When n = 1 is specified)
Bit Status Hex. Decimal
0 Unused 00 0
1 Unused 02 2
2 Undefined — —
3Online status 00 0
Offline status 08 8
4 Unused 10 16
5 Undefined — —
6 Undefined — —
7 Unused 00 0
(2) Statuscausedbyanoffline condition (When n =2isspecified)
Bit Status Hex. Decimal
0 Unused 00 0
1 Unused 02 2
2 Unused 00 0
Not in paper feed state triggered by 00 0
FEED switch
3In paper feed state triggered by FEED 08 8
switch
4 Unused 10 16
Printing is not stopped because of 00 0
“paper out” state
5Printing is stopped because of 20 32
“paper out” state
6Error not occurred 00 0
Error occurred 40 64
7 Unused 00 0
Bit 5: Printing is stopped if the paper end detector detects a
“paper out” state, or if the printer is out of paper when
the Paper Near-end Sensor is enabled by ESC c 4. At this
time, bit 5 = “1”.

— 12 —
(3) Status caused by an error (when n = 3 is specified)
Bit Status Hex. Decimal
0 Unused 00 0
1 Unused 02 2
2
No Black mark detection error occurred
(only when “Black mark” is selected). 00 0
A Black mark detection error occurred
(only when “Black mark” is selected). 04 4
3Auto cutter error not occurred 00 0
Auto cutter error occurred 08 8
4 Unused 10 16
5Unrecoverable error not occurred 00 0
Unrecoverable error occurred 20 32
6Auto recovery error not occurred 00 0
Auto recovery error occurred 40 64
7 Undefined 00 0
Bit 3: If this error occurred because of a paper jam, for example,
remove the cause of the error, and then DLE ENQ n (1
n 2) can be used to recover from the error. However, it
is not possible to recover from any error due to a circuit
problem (e.g., broken wire).
Bit 6: If a head overheat error is detected, the printing is stopped
until the head temperature falls. At this time, bit 6 = “1”.
(4) Continuous paper detector status (When n = 4 is specified)
Bit Status Hex. Decimal
0 Unused 00 0
1 Unused 02 02
2
Paper found by Paper Near-end Sensor 1 00 0
Paper not found by Paper Near-end Sensor 1 04 4
3
Paper found by Paper Near-end Sensor 2 00 0
Paper not found by Paper Near-end Sensor 2 08 8
4 Unused 10 16
5Paper found by Paper-end Sensor 00 0
Paper not found by Paper-end Sensor 20 32
6Paper found by Presenter Sensor 00 0
Paper not found by Presenter Sensor 40 64
7 Unused 00 0
[See Also] DLE ENQ, GS a, GS r

— 13 —
DLE ENQ n
[Function] Real-time request to printer
[Code] <10>H<05>H<n>
[Range] 1 n 2
[Outline] The printer responds in real-time to the request that the host
specifies with number “n”.
[Caution] • This command is only effective if an auto cutter error has
occurred.
• This command is dealt with when it is received.
• This command is also executed even if the printer is in a
receive-buffer full state.
• Ifanotherdatastringof<10>H<05>H<n>(1 n 2)isreceived,
the printer acts in the same way as with this command. The
user should, therefore, be reminded of this fact.
[Example 1]
If, for example, a command “ESC * m nL nH {d} k”, where d1 =
<10>H, d2=<05>H, d3=<01>H1, is given, the DLE ENQ n
command cannot be interleaved into the code string of another
command consisting of two bytes or more.
[Example 2]
• If the printer sends DLE ENQ 2 when the host has sent up to
ESC 3 in its attempt to send ESC 3 n, the printer treats the ESC
3 as ESC 3 <10>H. Thus, the user should be careful.
• Even if DLE ENQ 2 is executed, the settings made by, for
example,ESC! and ESC3retain the conditions whentheerror
occurred. A combined use of this command and ESC @ can
completely initialize the printer.
[See Also] DLE EOT
n Function
1After recovering from an error, the printer resumes
printing from the beginning of the line where the error
occurred.
2 The printer clears the receive buffer and the print buffer,
and then recovers from the error.

— 14 —
ESC FF
[Function] Printing data in PAGE MODE
[Code] <1B>H<0C>H
[Outline] Executes a batch printout of the data mapped in the entire print
area in PAGE MODE.
[Caution] • Thiscommand is only effectivewhen PAGE MODE is selected.
• Mapped data, as well as the ESC T and ESC W settings, and
the character mapping position are held even after printing.
[See Also] FF, ESC L, ESC S

— 15 —
ESC SP n
[Function] Setting the right spacing of the character
[Code] <1B>H<20>H<n>
[Range] 0 n 255
[Outline] Setstherightspacingof character to [n ×basiccalculationpitch]
inches.
[Caution] • If the horizontal magnification of character is 2 or more, the
right spacing increases with the magnification.
• The right spacing can be set separately for the STANDARD
and PAGE MODES.
• The basic calculation pitch is set by GS P. Once defined, the
right spacing is not changed if the basic calculation pitch is
changed by GS P.
• Fractions resulting from calculation are corrected with the
minimum pitch of the mechanism, and the remainder is
omitted.
• InSTANDARDMODE, this command usesthe horizontal basic
calculation pitch (x).
• In PAGE MODE, the basic calculation pitch used by this
command depends on the start point:
(1) If the start point specified by ESC T is top left or bottom
right, the command uses the horizontal basic calculation
pitch (x).
(2) If the start point specified by ESC T is top right or bottom
left, the command uses the vertical basic calculation pitch
(y).
• Themaximum rightspacingiscapable of approximately31.906
mm (255/203 inches). A setting greater than this maximum is
trimmed to the maximum.
[Default] n = 0
[See Also] GS P

— 16 —
[Sample Program]
[Print Results] AAAAA ← 0-dot space
AAAAA ← 1-dot space
AAAAA← 12-dots space
LPRINT CHR$(&H1B) + “ ” + CHR$(0) ;
LPRINT “AAAAA” + CHR$(&HA) ;
LPRINT CHR$(&H1B) + “ ” + CHR$(1) ;
LPRINT “AAAAA” + CHR$(&HA) ;
LPRINT CHR$(&H1B) + “ ” + CHR$(12) ;
LPRINT “AAAAA” + CHR$(&HA) ;
END

— 17 —
ESC ! n
[Function] Collectively specifying the printing mode
[Code] <1B>H<21>H<n>
[Range] 0 n 255
[Outline] Printing mode is assigned.
Bit Function Value
01
0 Character Font Font A Font B
1 Undefined
2 Undefined
3 Emphasis Canceled Specified
4 Double height Canceled Specified
5 Double width Canceled Specified
6 Undefined
7 Underline Canceled Specified
[Caution] • With double height and double width being specified
simultaneously, quadruple characters are created.
• An underline is attached to the full character width, which,
however, is not attached to the part having been skipped by
the horizontal tab. Neither is it attached to 90 -right-turned
characters.
• The underline width is as specified by the <ESC –> command.
(The default setting is 1 dot width.)
• In case characters with different vertical magnification ratios
coexist on the same line, they are printed on the same base
line.
[Default] n = 0
[See Also] ESC E, ESC –, GS !

— 18 —
[Sample Program]
[Print Results] Font A
Font B
Font A + Emphasis
Font B + Emphasis + Quadruple + Underline
Font A + Underline
Font A + Double Width
Font A + Double Height
∨∨∨
LPRINT CHR$(&H1B) + “!” + CHR$(&H00) + “H” ;
LPRINT CHR$(&H1B) + “!” + CHR$(&H01) + “H” ;
LPRINT CHR$(&H1B) + “!” + CHR$(&H08) + “H” ;
LPRINT CHR$(&H1B) + “!” + CHR$(&H10) + “H” ;
LPRINT CHR$(&H1B) + “!” + CHR$(&H20) + “H” ;
LPRINT CHR$(&H1B) + “!” + CHR$(&HB9) + “H” ;
LPRINT CHR$(&HA) ;
END
∨∨ ∨∨
