CKD ESM Series User manual

CC-1259A 1

Transporting work pieces from machine to machine for processing
High speed transport is possible (straight section: Max. 2,000 mm/s; curve section: Max. 1,500 mm/s).
Work pieces can be stopped at multiple locations (repeatability ±0.5 mm).
Soft starting and soft stopping are possible.
The combination of straight sections and curve sections allows you to create the pathway you want.
Pathwaycanbemodiedaftersetup.
Maintaining the conventional pathways, work pieces can be transported from machine to
machine.
Makingefcientuseoftheavailablespace
Effective
example
Solution case study
For three-dimensional
transport
Air Shuttle
Mover
SM-25
The air driven three-dimensional P&P
sytem allows you to create a three-
dimensional layout you really want.
A technique to bend a cylinder tube without crushing
enables a curved transport system. The product
features three-dimensional transport which was
previously unachievable.
Conventional transport system
Transport system using ESM
Conveyor
Lifter
Parts feeder
Air piping possible at the ends
Hand-chuck can be used.
Supplying the same parts to different machines in a straight path
Collecting and transferring of jigs in an assembly line
Astheproductionlinebecomesmoreefcient,theproductivitywillbeincreased.
The staff workload will be reduced.
Sincetheassemblymachinescanbearrangedinastraightline,theplantspacecanbeutilizedmoreefciently.
The workload to transport the jig was eliminated.
Theentiresystemwasimprovedonlywithfewmodicationsofthedevicelayout.
Improvetheproductionefciency
Nosignicantcapitalinvestmentormodicationrequired
A single actuator can now deliver the same assembly parts to different machines
in the production line.
Jigs in an assembly line can be easily pick up after the last station and transferred back to
the 1st.
Effective
example
Effective
example
Assembly machine
Parts supply
Parts feeder
Picking jig after
the last station
"ESM" can provide solutions for transport challenges!!
Placing jig for the 1st
station

Motor driven shuttle mover
ESM Series
Motor driven two-dimensional transport P&P system
Specications
Note 1: Contact CKD if the stroke length exceeds 20 m.
Note 2: The vertical difference is the difference between the heights at the highest spot and the lowest
spot in the transporting path.
Note 3: Contact CKD if you want to use a motor other than the recommended motors.
Note 4: If you need to detect the origin and overruns on both ends, you need three of these.
(Place an order for the required quantity. Refer to page 2 for the model no. and page 10 for the
specications.)
Note 5: You need 0.5 second or longer for either acceleration or deceleration.
Note 6: The products do not come with a motor. Customers are required to prepare, install, adjust the
motor and driver.
Note 7: The products are sold as a unit. Customer are required to install and adjust them.
Note 8: If a curve unit is directly connected to the motor drive unit, the PP unit (air supply unit) cannot be
used.
Descriptions ESM
Motor power supply voltage Three-phase 200 V
Max. load capacity kg 4
Maximum speed mm/s Straight section: 2000 or lower
Curved section: 1500 or lower
Max. transfer distance (Note 1) m 20
Vertical differences (Note 2) m 3
Repeatability mm ±0.5
Lubrication Not available
Applicable motor (Note 3) AC servomotor 750 W
For recommended motors, refer to page 2
Detection sensor (Note 4) Proximity switch
OMRON E2E-X2D1-N
Working environment
Use inside general plant (room temperature 5 to 40˚C)
Weight
Note 1: The weight increases by 0.5 kg as the stroke length becomes longer by 100 mm.
Unit name Unit model no. Weight (kg)
Carrier unit ESM-CA 0.7
Motor drive unit ESM-HDU-M 4
Straight unit ESM-ST-100 (Note 1) 0.5
Tension unit ESM-TTU 2
Curve unit
ESM-VC-90-1 3.7
ESM-VC-90-2 3.9
ESM-VC-45-1 1.9
ESM-VC-45-2 2
1

ESM Series
How to order
How to order
(1) Motor drive unit
AMotor installation specications
M
Select the most suitable motor specications from the table below.
* Contact CKD for the manufactures and models not mentioned in the table.
Y
ESM HDU M
(4) Straight unit
ESM ST 100
AStraight unit length
100
to
2000
100 mm to 2000 mm
Note: We accept special orders for the length between 100 mm to
2000 mm by 1 mm increment.
(5) Curve unit
ESM 90-1VC
AAngle
90-1 90 degrees inside
90-2 90 degrees outside
45-1 45 degrees inside
45-2 45 degrees outside
Note : The total of 180 degrees can be used for 1 set.
Example: Two 90-degree units or four 45-degree units.
(2) Tension unit
ESM TTU
(3) Carrier unit
ESM CA
Other units
ESM PP1
A
Model no. Descriptions
PP1 (Note ) PP unit (air supply unit)
SE
Detection sensor (For details, refer to page 10.)
(6) Belt
ABelt length
01370
to
40570
1370 mm to 40570 mm
ESM 01370
B
Manufacturer Symbol Motor (without brake) Motor (with brake)
MITSUBISHI M HF-KP73 HF-KP73B
Yaskawa Electric Corporation Y SGMJV-08ADA21 SGMJV-08ADA2C
Keyence Corporation Y SV-M075** SV-B075**
Motor installation specications and recommended motor model no. (rated output 750 W)
* Those other than "Other units" are required to create a set.
Unit example
Note: This is an air supply unit installed on the carrier to supply air to the terminal end.
If a curve unit is directly connected to the motor drive unit, the PP unit (air supply unit)
cannot be used.
Note: Refer to "Selection guide" on pages 7 and 8 to select the
belt length.
(5) Curve
unit
(5)
(4) (3) Carrier unit
(4) Straight
unit
(1) Motor
drive
unit
(4)
(6) Belt
(2)
Tension
unit
2

Unit combination examples
Belt length selection and examples
Unit model no. Stroke length Belt length (mm)
1 ESM-CA - -
2 ESM-HDU-M 150 HDU + TTU = 1170
3 ESM-ST-500 500 1000
4 ESM-VC-90-2 550 910
5 ESM-ST-1000 1000 2000
6 ESM-VC-90-2 550 910
7 ESM-ST-300 300 600
8 ESM-TTU 150 -
• Transporting distance: 3200 mm
• Belt length: 6590 mm
Calculate the belt length based on the unit combination given above. (Refer to page 8 for details.)
1. The belt length for the motor drive unit and the tension unit is 1170 mm (xed length).
2. Double the stroke length of the straight section.
(stroke length of [ESM-ST-500] + stroke length of [ESM-ST-1000] + stroke length of [ESM-ST-300]) × 2
= (500 + 1000 + 300) × 2
= 3600 mm
3. Belt length for the 90-degree curve unit is 910 mm.
Since there are two of them, the total will be: 910 × 2 = 1820 mm
4. "Add the belt lengths obtained in steps 1, 2, and 3."
"Belt length for the motor drive unit and the tension unit" + "Double the belt length for stroke length of straight section" +
"Belt length for the curve section × quantity"
= 1170 mm + 3600 mm + 1820 mm
= 6590 mm
Hence, the belt length is 6590 mm
Belt model no.: ESM-B-06590
ESM Series
ESM-HDU-M
ESM-ST-500
ESM-VC-90-2
ESM-ST-1000
ESM-VC-90-2
ESM-ST-300
ESM-TTU
3

ESM Series
Dimensions
Dimensions
Motor drive unit (ESM-HDU-*)
Motor installation specications A B C
M M6 φ 90 φ 19
Y M6 φ 90 φ 19
Tension unit (ESM-TTU)
192
413
(150)
55
143
78
80
4-A (threaded hole)
(Motor mount)
φ C
P.C.D B
100
(127)
100
300 78
4

Dimensions
Carrier unit (ESM-CA)
Straight unit (ESM-ST-*)
ESM Series
80
117
40 86
4-M6
42
(27)
60
L = 100 to 2000
4-6.3 T groove for M6
9 60
100
78
22
5

ESM Series
Dimensions
Curve unit: outside (ESM-VC-90-2)
Curve unit: inside (ESM-VC-45-1)
Dimensions
Curve unit: inside (ESM-VC-90-1)
Curve unit: outside (ESM-VC-45-2)
48
609
100
R350
R250
52
78
R228
R328
48
52
60
78
100
R228
R328
48 161
60
100 67
48
247
52
78
100
R350
R250
60
9
52
78
6

ESM Series
Dimensions
PP unit (ESM-PP1, air supply unit)
PP unit installation structure diagram (reference)
Carrier unit side nozzle Motor drive unit, tension unit side nozzle
Note: If a curve unit is directly connected to the motor drive unit, the PP unit (air supply unit) cannot be used.
149
20
(20)
24
258
M5 × 0.8 (OUT port)
Nozzle insertion
distance (90)
Rc1/8 (IN port)
15 15
124
15 15
10 20
149
73.5
124
M5 × 0.8 (OUT port)
Rc1/8 (IN port)
7

(
ESM Series
Unit selection
STEP-1 Checking the stroke and belt length for each unit
Unit name Model no. Stroke length (mm) Belt length (mm)
Motor drive unit ESM-HDU 150 1170 (including the tension unit)
(Fixed length)
Straight unit
Example ESM-ST-100
ESM-ST-200
ESM-ST-1200
ESM-ST-2000
100
200
1200
2000
200
400
2400
4000
Stroke length
× 2
Tension unit ESM-TTU 150 -
(Refer to the motor drive unit)
Inside 90-degree curve unit ESM-VC-90-1 360 910 (xed length)
Outside 90-degree curve unit ESM-VC-90-2 550 910 (xed length)
Inside 45-degree curve unit ESM-VC-45-1 180 455 (xed length)
Outside 45-degree curve unit ESM-VC-45-2 275 455 (xed length)
STEP-2 Min. dimensions of combinations with a curve unit
90-degree outside &
90-degree outside
45-degree outside &
90-degree outside
45-degree outside &
45-degree outside
90-degree outside &
90-degree inside
90-degree outside &
45-degree inside
45-degree outside &
45-degree inside
90-degree inside &
90-degree inside
90-degree inside &
45-degree outside
45-degree inside &
45-degree inside
90-degree inside &
45-degree inside
Unit selection
* The total of 180 degrees can be used for 1 set.
)
(700)
350 350
350 228
(656)
328
328
328
(578)
350
R350
R350
R228
R228
578
328
100
(597)
(494)
247 247
247 (322)
161 161
(170)
103
100
67
103
417 575
328 328
161
489
103
331
350
511
R350
R350
R228
R228
R228
247 350
350
R350
R350
R350
R228
R228
100
8

Calculate the tact time for the selected products following the example below, and conrm it will meet the specications.
Select the rotational speed and rotational acceleration and deceleration for the motor you have selected from the
specications table for each model (pages 1 & 2).
STEP-3 Checking the tact time
Descriptions Symbol Unit Remarks
Set
value
Speed setting V mm/s
Acceleration setting a mm/s2
Deceleration setting d mm/s2
Movement distance Smm
Calculated
value
Reached speed Vmax mm/s = (2 × a × d × S/(a+d))1/2
Effective speed Vb mm/s Smaller one between V and Vmax
Acceleration time Ta s = Vb/a <0.5 sec and over>
Deceleration time Td s= Vb/d <0.5 sec and over>
Constant speed time Tc s = Sc/Vb
Acceleration distance Sa mm = (a × Ta2)/2
Deceleration distance Sd mm = (d × Td2)/2
Constant speed distance Sc mm = S - (Sa + Sd)
Positioning time T s = Ta + Tc + Td
• Do not use the products above the specication speed.
• Acceleration/Deceleration settings based on acceleration/
deceleration time vary depending on the speed setting and the
stroke length.
• Depending on the acceleration/deceleration settings and the stroke
length, the trapezoidal speed waveform may not be able to be
formed (speed does not reach the set speed).
Compare Vmax and the speed setting.
• Acceleration/Deceleration time should be 0.5 second or longer.
Speed
mm/s
Time
sec
Position
mm
Acceleration
range
Constant speed
range
Deceleration
range
Effective speed: Vb
Reached speed: Vmax
Acceleration
a
Deceleration
d
Acceleration
time
Ta
Deceleration
time
Td
Constant
speed time
Tc
Positioning time T
Acceleration
distance
Sa
Deceleration
distance
Sd
Constant speed
distance
Sc
Movement distance S
The maximum allowable load may vary depending on the overhang of the center of gravity of the load.
STEP-4 Conrming the maximum allowable load
Selection guide
Example of selection
* The allowable load weight may vary depending on the overhang.
Use this product within the range of the following graph.
* Refer to the examples of selection when calculating the overhang L.
For the displacement of the center of gravity of the load,
L = 55 mm is allowed as it remains inside the range of
the graph if W = 1 kg.
ESM Series
Unit selection
10 G
W = 1 kg
30
G15
Ly
Lx
Lz
Carrier
Center of
installation
surface
G
200
150
100
L (mm)
W (kg)
50
0 1 2 3 4
W = 1 kg
Lx = 15 mm
Ly = 10 mm
Lz = 30 mm
L = 15 + 10 + 30 = 55 mm
W: Load weight
G: Center of gravity of load
Lx:
Displacement of G in the X direction
Ly: Displacement of G in the Y direction
Lz: Displacement of G in the Z direction
L: Amount of overhang
L = Lx + Ly + Lz
9

ESM Series
Detection sensors and repair parts
Detection sensor
Type Manufacturer Model
Proximity sensor OMRON E2E-X2D1-N
Performance
Descriptions Specications
Cylindrical type detection head size
M8
Type Shield type
Detection method Induction type
Detection range 2 mm ±10%
Distance setting 0 to 1.6 mm
Hysteresis 15% or less of the detection range
Detectable materials Magnetic metals (Detection range decreases for non-magnetic metals)
Standard object for detection Iron 8 × 8 × 1 mm
Response frequency DC: 1.5 kHz (average)
Power supply voltage 12 to 24 VDC ripple (P-P) 10% or less
Working voltage range 10 to 30 VDC
Leakage current 0.8 mA or less
Control output (output type) Two-wire DC
Control output (switching capacity)
3 to 100 mA
Indicator light Power indicator (red) and setting indicator (green)
Ambient temperature range During operation: -25 to 70˚C. In storage: -40 to 85˚C (no freezing and no
condensation)
Ambient humidity range During operation: 35 to 95% RH. In storage: 35 to 95% RH (no condensation)
Thermal effect Detection range varies within ±15% in the temperature range of -25 to +70˚C.
(detection range at 23˚C as the standard)
Output circuit Wiring diagram
Color Arrangement
Brown +V
Blue 0V
Terminal arrangement
Load
Proximity
Sensor
Main circuit
Brown +V
OV
Blue
Set name Set no. Set descriptions
Roller set ESM-RO Rollers, shafts, and bearing assemblies (for 1 unit)
Joint set ESM-JO Drive block, joint plate, and screws
Carrier side belt Belt for ESM-B-**** For specially modied belts and model no., refer to page 2
Motor side belt ESM-B-K For the motor pulley
* Specify the set no. when you place an order.
* Avoid sunlight, oil, water, and ozone for rubber and urethane parts in the set. Store them in a cool and low-humidity place.
Repair parts
10

Specications
Model no. Standard type High load type
Descriptions
Working uid Compressed air
Max. working pressure MPa 0.6
Min. working pressure MPa 0.3
Ambient temperature °C 5 to 40
Bore size mm φ 25
Port size Rc3/8
Magnet holding force N 120 240
Max. allowable load weight kg 2 (total load weight to be mounted) 4 (total load weight to be mounted)
Max. transfer distance m 20
Stroke limit adjustment length mm ±10
Cushion Piston Rubber cushion
Carrier Shock absorber
Lubrication Not required (use turbine oil class 1 ISO VG32 if necessary)
Shuttle mover standard type / high load type
SM-25 Series
The conguration which enables free layout.
Air driven three-dimensional transport P&P system
"Air drive type which allows three-dimensional transporting is available!"
The air driven three-dimensional
transport P&P system shuttle
mover (SM-25) employs a rodless
cylinder that combines air with a
magnetic force. The product
features three-dimensional
transport which was previously
unachievable. Use of a sleeve
and O-ring in the connecting
portion of the cylinder tube
eliminates leakage of air and also
enables easy assembly. This
conguration enables free layout.
Overview
* For details, refer to the shuttle mover SM series pages in "Pneumatic
Cylinders I" (catalog No. CB-029SA).
11

This product is designed and manufactured as a general industrial machine part.
It must be handled by an operator having sufficient knowledge and experience.
Use the product within specifications range.
This product must be used within its stated specifications. It must not be modified or machined additionally.
This product is intended for use as a device or part for general-purpose industrial machinery. It is not intended for use
outdoors (except for outdoor type) or for use under the following conditions or environment.
(Note that this product can be used when CKD is consulted prior to use and the customer consents to CKD product
specifications. The customer must provide safety measures to avoid risks in the event of problems.)
Use for special applications including nuclear energy, railway, aircraft, marine vessels, vehicles, medicinal devices,
devices or applications coming into contact with beverages or food, amusement devices, emergency circuits
(shutoff, release), press machines, brake circuits, and safety devices or applications.
Use for applications where life or property could be significantly affected, and special safety measures are required.
Be sure to observe the organization standards and regulations related to the safety of device design
and control, etc.
Do not remove the product until you can ensure safety.
Inspect and service the machine and devices after confirming safety of the entire system related to this product.
Note that there may be hot or charged sections even after operation is stopped.
When you inspect or service the equipment, be sure to turn off power to all of the devices. Take care to avoid
electrical shock
Be sure to observe all the warnings and precautions of the product to prevent accidents.
You may encounter an unexpected movement of the device during a teaching operation or test run. Do not touch
the actuator. When you operate the machine from a spot where you cannot see the shaft, make sure that any
movement of the actuator does not pose a danger.
Be sure to observe all the warnings and cautions to avoid electrical shock.
Do not touch the heat sink, the cement resistor inside the controller, and the motor.
Due to its high temperature, you may get burned. Take enough time to let them cool down before you start servicing.
Do not touch any electrical parts even if power is turned off, as high voltage may be applied until the charge in the
capacitor is fully released, which takes approximately three minutes.
Before you start maintenance or inspection, turn off power to the controller.
Otherwise you may get high voltage electrical shock.
Do not connect or disconnect the connectors while power is on. This may result in malfunction, failure, or electrical
shock.
Safety Precautions
Always read this section before use.
1
2
4
5
6
7
WARNING
When you design and manufacture a system using CKD actuators, you are required to confirm the safety of the
mechanical system as well as that of the electrical control system, to create a safe application.
It is important to select, use, handle and maintain the product appropriately to ensure that the CKD product is used
safely.
Observe warnings and precautions to ensure device safety.
Check that device safety is ensured and a safe device is manufactured.
3
The precautions are ranked as "DANGER", "WARNING", and "CAUTION" in this section.
DANGER :
WARNING :
CAUTION :
When a dangerous situation may occur if handling is mistaken leading to fatal or serious
injuries, and when there is a high degree of emergency to a warning.
When a dangerous situation may occur if handling is mistaken leading to fatal or serious
injuries.
When a dangerous situation may occur if handling is mistaken leading to minor injuries or
physical damage.
Note that some items described as "CAUTION" may lead to serious results depending on the situation.
Every item provides important information and must be observed.
The over current protection device should be installed.
The wiring to the controller should be equipped with the over current protection device (circuit breaker or circuit
protector) for the power line (power supply connector and power supply terminal block) and the primary power line of the
control line (I/O connector), as defined in "JIS B 9960-1:2008 Machine Safety - Electrical devices on machinery - Part 1:
General requirements."
(extract from JIS B 9960-1 7.2.1 General)
If there is any possibility of the circuit current of the machine (electrical device) exceeding either the rated value of a
component or the allowable current of an conductive part, whichever is smaller, an over current protection must be
provided. The rated values or the settings that should be selected are defined in Section 7.2.10.
Observe warnings and precautions below to prevent accidents.
8
●
1
●
1
●
1
●
1
●
2
●
3
●
2
●
3
●
2
12

Warranty period
This warranty shall be valid for one year after delivery to the customer's designated site.
Scope of warranty
If any faults, found to be the responsibility of CKD, occur during the above warranty term, the product shall be
replaced, the required replacement parts provided free of charge, or shall be repaired at the CKD factory free of
charge.
Note that the following faults are excluded from the warranty scope:
(1) When the product is used exceeding the conditions and environment described in the product specifications.
(2) When the product is incorrectly used due to carelessness or incorrect management.
(3) The malfunction resulting from factors other than the product.
(4) Faults caused by improper use of the product.
(5) Faults caused by a modification of structure, performance, or specifications, which CKD has no involvement
with or a repair conducted by an agent not specified by CKD.
(6) Faults which could be avoided if the customer's equipment has the performance and structure which are
expected as the industry standards at the time when CKD products are installed.
(7) Faults caused by matters that could not be predicted with the technologies applied when the product was
delivered.
(8) Faults caused by an external factor including but not limited to fire, earthquake, flooding, lightning, force
majeure, natural calamity, pollution, salty or gaseous atmosphere, and abnormal voltage.
The warranty covers the actually delivered product, and does not cover any damage resulting from losses induced by
faults in the delivered product.
Warranty of exported products
(1) We offer repair service to CKD products returned to our plant or a company or plant we specify. The work and
costs accompanying the returning of the product is not covered by the warranty.
(2) The repaired product shall be delivered to a location in Japan with packaging suitable for domestic transport.
The terms and conditions of the warranty define the basics. When the product-specific warranty differs from this
warranty, the specification drawing or the specification shall govern.
Compatibility confirmation
The customer is responsible for confirming the compatibility of CKD products with the customer's systems, machines
and equipment.
Scope of the service
The product price does not include service charge for sending technicians to the customer's site. The following shall
be added to the charges.
(1) Guidance for installation and adjusting and the presence at the test run
(2) Maintenance, inspection, adjustment, and repair
(3) Technical guidance and technical training (operation, program, wiring method, safety education, etc.)
1
3
4
5
2
limited warranty and disclaimer
13

Safety Precautions
Always read this section before use.
Design & selection
DANGER
Do not operate the product where there are
hazardous materials such as combustibles,
ammables, and explosives.
It may ignite, catch re, or explode.
Ensure that the product does not come into contact
with water drops and oil drops. They may cause a
re or failure.
Be sure to securely install the product so that a
workpiece can be securely held.
If the product falls, drops, or malfunctions, this may lead to
personal injuries.
WARNING
Install the product at a location free of direct sun,
dust, heat source, corrosive gases, explosive
gases, ammable gases, and ammables.
Chemical resistance is not taken into account for
this product.
It could fail, explode, or ignite.
Operate or store the product at a location free of
strong electromagnetic waves, ultraviolet rays, and
radiation.
It could malfunction or fail.
Take into consideration the possibility of power
supply failure.
Design the system so that a power supply failure does not
cause any personal injuries or damages on the machine.
Determine how the machine should be re-started
after an emergency stop or abnormal stop.
Design the system so that restarting does not cause any
personal injuries or damages on the machine.
If you should reset the electric driven actuator to the starting
position, provide the system with a safety device.
Take into consideration the possibility of motor failure.
Design the system so that a power supply failure does not
cause any personal injuries or damages on the machine.
Avoid using this product where vibration and
impact are present.
Do not apply a load to the product which is greater
than or equal to the allowable load listed in the
materials for selection.
The carrier unit should be operated within the
specied speed limit.
It is not possible to x the carrier unit and use the
rail portion as a mobile unit.
Avoid scratching the rail with a workpiece or a tool
dropped by an error during mounting or removal of
a workpiece.
Failure to observe this could result in operation
faults.
If a foreign object gets lodged between the carrier
unit and the rail, the product may malfunction.
Be sure to provide a safety cover along the path to
prevent an accident if a workpiece is dropped.
The product should be used in a normal plant
environment where people can work.
(The temperature should be between 5 to 40˚C.)
Do not use the product in water, in oil, in powder, or
where it will come into contact with cutting uid or
cutting chips, as these may lead to malfunction.
The product cannot be used in a corrosive
environment.
Use this product in accordance with the
specications range.
Provide a safety circuit or design the system so
that stopping the operation for emergency or during
outage does not cause any personal injuries or
damages on the machine.
Install the product indoors at a location where
humidity is low.
Avoid the location exposed to elements or of high humidity
(humidity 85% or higher with condensation). This may cause
an electrical leak or a re. Oil mist and oil drops are also
strictly prohibited.
Using the product in such an environment may lead to a
damage or malfunction.
Product-specic precautions: Motor driven shuttle mover ESM Series
CAUTION
The belt runs inside the rail. Ensure that foreign
objects such as cutting chips do not enter the unit
during assembly.
Use the product within a range so that the carrier
unit never collides the stroke end.
Indicate the maintenance conditions in the device's
instruction manual.
The product's performance may drop too low to keep an
appropriate safety level depending on use conditions, use
environment, and maintenance status. With correct
maintenance, the product functions can be used to the
fullest.
When installing, setting up, adjusting, and servicing
the product, read through the instruction manual
and follow the instructions carefully.
The product is manufactured in accordance with
various regulations and standards.
Never modify the product.
Read the instruction manuals for the motors and
the control devices installed on the product. Follow
the instructions when you design the wiring or wire
the product paying particular attention to safety.
The customer is responsible for conrming the
compatibility of CKD products with the customer's
systems, machines and equipment.
14

ESM Series
DANGER
Do not enter the operating range of the product
when it is ready to be operated. The product may
make a sudden move leading to injury.
Installation & adjustment
WARNING
For the standard installation, supporting pillars
should be placed for every 3 m. (Customers are
asked to provide supporting pillars by themselves.)
Ensure that no twisting, bending, or pulling force
applies to the rail when you attach supporting
pillars or beams.
Do not tap the product with a hammer to move it.
Do not lift it directly with wire.
Be sure to install a safety cover where the system
goes over/through aisles and work areas or where
a hand or body part may come into contact.
Ensure sufcient room around the stroke end as
below:
(1) Room to mount/remove workpieces.
(2) Room for the motor.
(3) Room to replace the belt at the tensioner.
After completing installation and before installing
the motor, move the carrier manually by hand to
ensure that nothing will interfere with the movement
of the carrier within the operating range.
Do not let foreign objects, such as cutting chips
from drilling, enter inside the frame and the belt.
The product has precision parts inside it. Never let
it fall or give vibration/impact to it during transport.
It may result in breakage of a part.
When you temporally place it on the ground, put it
horizontally.
Do not climb on the packaging or put an object on
it.
Maintain the ambient temperature between -10 to
50˚C with no freezing and the ambient humidity
between 35 to 80% with no condensation during
transport.
It may result in breakage of the product.
Install the product on incombustible material. If the
product is installed directly on combustible material
or placed close to combustible material, it may lead
to a re.
This may result in burning.
Do not step on the product or use it in place of a
step ladder. Do not put any object on it.
This may lead to personal injuries and damage to or
malfunction of the product.
Design the system so that no personal injuries or
product damage may occur if power supply failure
occurs.
This may lead to an unexpected accident.
When malfunctions occur, stop the operation
immediately and contact CKD's local sales ofce.
CAUTION
Do not place the product where signicant vibration
or impact may be inicted.
It may lead to malfunction.
Do not let an external force move the movable part
of product. Do not make abrupt deceleration.
This may lead to malfunction or damage due to regenerated
power.
When you return the carrier unit to the origin, do
not let it hit the mechanical stopper. You may let it
contact the stopper slowly.
This may damage the parts resulting in malfunction.
Durability may vary depending on the transport
load and the work environment. Design the system
with sufcient margin for the transport load. Use
the system so that no impact may be inicted upon
moving parts.
Do not let the excessive moment apply onto the
carrier unit. Refer to "Maximum allowable load" on
page 9 for details.
This may damage the product resulting in malfunction.
Do not move the carrier before you install the
motor. The belt inside the product may be bent
causing kinks and scratches of the belt leading to
its premature failure.
The atness of the installation surface should be
0.05 mm per 200 mm or less so that any twisting or
bending force may not be inicted on the product.
The atness of the work piece surface installed on
the carrier unit should be 0.02 mm or less so that
any twisting or bending force may be inicted on
the product.
This may damage the product resulting in malfunction.
Tighten the mounting bolts following the tightening
torque table below.
Thread size Tightening torque (N∙m)
M3 0.7
M4 1.5
M5 3
M6 5.2
M8 12.5
M10 24.5
15

CAUTION
Be sure to turn off power when you conduct
inspection or maintenance.
Regular cleaning is required when you use the
product at a location where the rails tend to
become dirty easily.
Regularly inspect the product two or three times a
year to ensure its proper operation.
During use & maintenance
DANGER
Do not operate the product with wet hands.
Failure to observe may result in an electrical shock.
If you nd any abnormality of the belt such as wear
on cogs, damage on sides of the belt, cracks at
cogs, cracks or softening on the back side of the
belt, and partial clefts, stop the operation
immediately. Use environment or conditions may
not be correct for the product.
Properly maintain the tension of the belts. You
should pay attention to the initial stretching of the
belts. If the tension is incorrect, vibration or noise
may increase resulting in shortened service life, or
belt cogs may jump over pulley cogs.
Be sure to turn off power to the product when you
perform maintenance, inspection, or repair. Take
measures so that other people do not turn on
power or operate the system inadvertently while
you are working on the product.
When you dispose of the product, follow the laws
and regulations concerning the cleaning and
disposal of the product. Be sure to outsource to a
certied waste disposal specialist.
ESM Series
Individual precautions
16

ESM Series
Related products
Electric driven actuator motorless type
Ball thread drive ETS Series
8 motor sizes, 7 lead types, and 5 motor mounting
orientations.
The motor you are familiar with can be used.
Models with origin sensors and limit sensors are also
available.
Any stroke length between 100 to 1500 mm (50 mm
increment) can be chosen.
Maximum load capacity of 150 kg and maximum speed of
2,000 mm/s provide versatility.
Belt drive ETV Series
Belt driven type based on ETS Series.
Any stroke length between 100 to 3,500 mm (50 mm
increment) can be chosen. The maximum speed is 2,000
mm/s achieving long stroke length at high speed.
6 motor sizes and 6 motor mounting orientations.
The motor you are familiar with can be used.
Ball thread drive low particle generation
specications
ECS Series
 Based on ETS Series, the product features the full-cover
construction and the suction port to achieve low particle
generation.
7 motor sizes, 7 lead types, and 5 motor mounting
orientations.
The motor you are familiar with can be used.
Models with origin sensors and limit sensors are also
available.
Any stroke length between 100 to 1500 mm (50 mm
increment) can be chosen.
Maximum load capacity of 150 kg and maximum speed of
2,000 mm/s provide versatility.
Belt drive ECV Series
 Based on ETV Series, the product features the full-cover
construction and the suction port to achieve low particle
generation.
6 motor sizes and 6 motor mounting orientations.
The motor you are familiar with can be used.
Catalog No.CC-1165A, CC-1216A, CC-1217A, CC-1257A
17
