Claridge calyx Mina Mobile User manual

Mina Mobile
ASSEMBLY INSTRUCTIONS
WARNING
Risk of injury to installers and users
Read the enre assembly direcons before
beginning assembly.
The following instrucons will guide you through the steps required to assemble your
new Mina Mobile.
Please read enre installaon guide before beginning installaon.
The appropriate hardware kits for each mobile will be packaged with each product.
• Binder Post (x6)
• Binder Screw (x6)
• Protecve Sleeve (x6)
• Casters (2 locking, 2 non-locking) Mina Mobile
• Steel legs (x4)

800-434-4610
Calyxbyclaridge.com
Mina Mobile
Assembly
Step 1
Place panel on a clean work bench or table.
We recommend you place a blanket or pro-
tecve cloth to prevent any scratching of
the wring surface. Overhang panel to one
side of table 3”, to allow for leg assembly.
Step 2
Posion legs as shown. Join front and back
leg to panel using the binder post (3),
sleeve (3) and binder Screw (3). Tighten
with Allen key (not provided). Do not fully
ghten at this point.
Repeat for other side.
Step 3
The caster stems have been factory install
on each leg. Simple press caster hub onto
each stem. Two non-braking on one side.
Two brake on the other side.
Step 4
With two people, stand mobile up on a at
level surface. Now ghten all 6 binder
screws.
