Clarke CMC36 User manual

Thank you for purchasing this CLARKE Car Creeper.
To ensure the creeper is assembled and used correctly, please read this leaflet
and carefully follow all instructions. By doing so you can look forward to the seat
giving you long and satisfactory service.
Guarantee
This CLARKE product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product is found to have been abused or tampered
with in any way, or not used for the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be
returned to us without prior permission. This guarantee does not effect your
statutory rights.
CAR CREEPERS

CMC 40
For Spare Parts and Service, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
No. Description Qty Part No.
1. Head Rest 1 SNCMC4501
2. Rack Platet 1 SNCMC4502
3. Hinge 1 SNCMC4503
4. Bolt 4 SNCMC4504
5. Base frame 1 SNCMC4505
6. Barrel Nut 6 SNCMC4506
7. Spring Washer 6 SNCMC4507
8 Plastic Cap 4 SNCMC4508
9. Caster 6 SNCMC4509
10. Conn. Plate 1 SNCMC4510
11. Bolt 2 SNCMC4511
12. Cushion 1 SNCMC4512
13. Screw 2 SNCMC4513
No. Description Qty Part No.
1. Seat Cushion 1 SNCMC4001
2. Screw 2 SNCMC4002
3. Barrel Nut 6 SNCMC4003
4. Spring Washer 6 SNCMC4004
5. Base Frame 1 SNCMC4005
6. Caster 6 SNCMC4006
7. Plastic cap 4 SNCMC4007
Part No. 7630189
CMC 45
Part No. 7630188
Unpacking and Assembly
Unpack and lay out all components, checking for any damage which may have
occurred during transit, and ensuring that all parts are accounted for by checking
against the parts list. Should there be any deficiency or damage, please contact
your Clarke dealer immediately.
Assembly Ref: Parts diagram
It is only necessary to attach the castors to your creeper, by threading each one
through the hole in the base frame and securing with the hex socket head Barrel
Nuts with washers provided.
Do’s and Dont’ s
•DO NOT use on rough uneven surfaces and ensure that the floor surface is
hard enough so that the castors do not sink in.
•DO NOT use the seat to transport heavy objects.
•DO NOT use the seat as a stand.
•DO NOT leave the seat where it may be accidentally trodden on as this
could have serious consequences, particularly in a workshop environment.
• If a castor should fail or become damaged in some way, have it replaced
immediately. Should it be ignored, the additional strees placed on the other
three castors could quickly cause them to fail also.
•DO NOT exceed maximum load - 150kg
CMC36
Part No. 7630187
No. Description Qty Part No.
1. Seat Cushion 1 SNCMC3601
2. Base Frame 1 SNCMC3602
3. Barrel Nut 6 SNCMC3603
4. Spring Washer 6 SNCMC3604
5. Pladstic Cap 4 SNCMC3605
6. Caster 6 SNCMC3606
7. Screw 2 SNCMC3607
