Clarke CFF18B Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS1112
18 INCH HIGH VELOCITY FLOOR FAN
MODEL NO: CFF18B
PART NO: 3231520

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE 18 inch High Velocity Floor Fan.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
MODEL CFF18B
Part No: 3231520
Voltage: 230 V AC (50Hz)
Wattage: 140 W
Fan Speeds 3
Setting 1 950 RPM
Setting 2 1080 RPM
Setting 3 1250 RPM
Dimensions (L x W x H): 620 x 240 x 570 mm
Weight: 6.2 kg

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECTRICAL CONNECTIONS
Before switching the product on, make sure that the voltage of your electricity supply is
the same as that indicated on the rating plate. This product is designed to operate on
230VAC 50Hz. Connecting it to any other power source may cause damage.
This product may be fitted with a non-rewireable plug. If it is necessary to change the
fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or
damaged, the plug must not be used until a suitable replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or due to
damage, it should be cut off and a replacement fitted, following the wiring instructions
shown below. The old plug must be disposed of safely, as insertion into a mains socket
could cause an electrical hazard.
If the colours of the wires in the power cable of this product do not correspond with the
markings on the terminals of your plug, proceed as follows.
• The wire which is coloured Blue must be connected to the terminal which is
marked Nor coloured Black.
• The wire which is coloured Brown must be connected to the terminal which is
marked Lor coloured Red.
• The wire which is coloured Yellow and Green must be connected to the
terminal which is marked E or or coloured Green.
We strongly recommend that this machine is connected to the mains supply via a Residual
Current Device (RCD)
If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.
WARNING! Read these electrical safety instructions thoroughly
before connecting the product to the mains supply.
WARNING! The wires in the power cable of this product are
coloured in accordance with the following code:
Blue = Neutral Brown = Live Yellow and Green = Earth
Plug must be BS1363/A approved.
Always fit a 3 Amp fuse.
Ensure that the outer sheath of the cable is firmly held by the clamp
Neutral
(Blue)
Live
(Brown)
Earth
(Green and Yellow)

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY PRECAUTIONS
•DO NOT use in dusty environments.
• Indoor use only.
•DO NOT use in environments with high fumes from chemicals etc.
•DO NOT use as an extractor fan.
•DO NOT use in areas of high humidity/water vapour, i.e. bathrooms
etc.
•DO NOT connect fan to ducting system.
•DO NOT cover the fan with clothing or any material that will restrict
free airflow throught the fan
• Never touch the blades with your hand or any object.
OPERATION
TILTING THE FAN
You can adjust the angle of the fan
by holding the base and grill and
tilting the fan to the required angle.
• Tighten the nuts on the side of
the fan slightly if the fan will not
stay in position
ADJUSTING THE SPEED
Press the relevant button to select the
fan speed required
• Button 0 - Off
• Button 1 - 950 rpm
• Button 2 - 1080 rpm
• Button 3 - 1250 rpm

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
MAINTENANCE
• The motor bearings are permanently sealed and do not require any
additional lubrication.
• Have any repairs carried out by a suitably qualified person.
CLEANING
1. Disconnect the power cord from the mains.
2. Lift the guard clips and remove
the single bolt and nut at the
bottom of the guard.
3. Remove the guard carefully.
4. Wipe the fan blades with dry
cloth.
• Never use polish or any
corrosive liquid that will
damage the paint, metal or
plastic.
• Do not bend the blades!
5. Replace the guard so that the bolt holes in the front and rear guard line up
and lock the guard securely before use.
• Make sure that the guard clips are returned to the locked position.
WARNING: NEVER OPERATE THE FAN WITH THE FRONT GRILL
REMOVED.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PART LIST AND DIAGRAM
NODESCRIPTION PART NUMBER NODESCRIPTION PART NUMBER
1 Screw KWCFF18B01 11 Plastic Bearer KWCFF18B11
2 Front Guard KWCFF18B02 12 Locknut KWCFF18B12
3 Guard Clips KWCFF18B03 13 Screw KWCFF18B13
4. Blade KWCFF18B04 14 Tube Base KWCFF18B14
5 Set Screw KWCFF18B05 15 Power Cord KWCFF18B15
6 Nut KWCFF18B06 16 Control Box KWCFF18B16
7 Square Bolt KWCFF18B07 17 Washer KWCFF18B17
8 Rear Guard KWCFF18B08 18 Nuts KWCFF18B18
9 Motor KWCFF18B09 19 Carry Handle KWCFF18B19
10 Screw KWCFF18B10 20 Screw KWCFF18B20

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY
