Clarke CAM24C Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS DL1122
24” DRUM FAN
MODEL NO: CAM24C
PART NO: 3230446

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE 24” Drum Fan.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ELECTRICAL CONNECTIONS
Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. This product is
designed to operate on 230VAC 50Hz. Connecting it to any other power
source may cause damage.
This product may be fitted with a non-rewireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or due
to damage, it should be cut off and a replacement fitted, following the wiring
instructions shown below. The old plug must be disposed of safely, as insertion
into a mains socket could cause an electrical hazard.
If the colours of the wires in the power cable of this product do not correspond
with the markings on the terminals of your plug, proceed as follows.
•TheBlue wire must be connected to the terminal which is marked N
or coloured Black.
•TheBrown wire must be connected to the terminal which is marked L
or coloured Red.
•TheYellow and Green wire must be connected to the terminal which
is marked E or or coloured Green.
We strongly recommend that this machine is connected to the mains supply
via a Residual Current Device (RCD)
If in any doubt, consult a qualified electrician. DO NOT attempt any repairs
yourself.
WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE
MAINS SUPPLY.
Plug must be BS1363/A approved.
Always fit a 3 Amp fuse.
Ensure that the outer sheath of the cable is firmly held by the clamp
Neutral
(Blue)
Live
(Brown)
Earth
(Green and Yellow)

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY PRECAUTIONS
1. ALWAYS read the manual before use.
2. ONLY suitable for indoor use.
3. DO NOT operate without the front and rear grilles in place.
4. AV O I D using in dusty environments.
5. DO NOT use in environments containing chemical fumes etc.
6. DO NOT use as an extractor fan.
7. DO NOT use in areas of high humidity/water vapour, i.e. bathrooms etc.
8. DO NOT connect the fan to duct system.
9. DO NOT cover the fan with clothing or any material that will restrict free
airflow through the fan.
10. NEVER touch the blades with your hand or any loose object.
11. ALWAYS unplug the fan before moving it or performing maintenance.
12. DO NOT touch the fan when your hands are wet.
13. ONLY qualified electricians should disassemble, repair or rebuild the fan.
14. ALWAYS unplug the fan when it is not in use.
15. NEVER unplug the fan by holding the cable. Unplug by holding the plug.
16. NEVER use the fan if the cable or plug are damaged.
17. NEVER use the fan close to fires.
18. DO NOT use this fan with any solid-state speed control device to reduce
the risk of fire or electric shock.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY
FAN CRADLE ASSEMBLY
WARNING: THERE IS ONE SMALL HOLE ON EACH SIDE OF THE TWO CRADLE BASES.
THE TWO SMALL HOLES SHOULD BE KEPT ON THE INNER SIDE AND AT TEH SAME
DIRECTION.
1. Align the cradle base with
the support brackets
attached to the fan body
sides.
NOTE: You may need to flex
the parts to make them
align correctly.
2. Insert the support bracket into the
opening of the cradle base. Press the
spring loaded button down to allow it
to insert into the cradle base.
3. Press the support bracket into the
cradle base until the spring button
protrudes out of the open holes in the
cradle base.
4. Repeat the above process for the
opposite side of the fan.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
FAN WHEEL ASSEMBLY
1. Insert axle clamps onto the two sides
of the axle, followed by the wheels, as
shown.
2. Insert the washer and nut onto the
ends of the axle and tighten.
3. Align the axle clamps with the indents
on the cradle base and push them on
to attach as shown.
FAN FEET ASSEMBLY
1. Slide the feet into each end
of the spacer tube as
shown.
2. Align the holes on the feet with the
holes on the cradle base and
screw them in, as shown.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OPERATION
FAN OPERATION
Always operate the fan with the supports in an upright position following all
instructions and recommendations listed in this manual.
FAN LOCATION
Place the fan in the area of the room that will provide proper fan cooling.
ADJUST FAN TILT
To adjust the tilt angle (3600 round the
horizontal axis) loosen the screw
knobs and adjust the fan’s position.
After adjustment, retighten the screw
knobs.
FAN CONNECTION
Plug the fan directly into a 230v AC, 50Hz wall outlet. Be sure the plug fits tightly
into the outlet. A loose connection may cause overheating and damage to
the plug or fan.
TURNING FAN ON
Place the fan on a stable level surface. Plug the fan into an electrical outlet.
To start the fan, turn the switch from
the OFF position to the desired fan
speed.
• Low: 950 rpm
• Medium: 1100 rpm
• High: 1200 rpm
TURNING FAN OFF
To turn the fan OFF, turn the switch from the current fan speed setting to the
OFF position. Remove the plug from the wall outlet.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
CLEANING & MAINTENANCE
WARNING: NEVER OPERATE THE FAN WITH THE FRONT OR REAR GUARD
REMOVED. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR BECOME
DAMAGED IN ANY WAY.
CLEANING
If the fan has been operating for long periods in a very dusty environment, the
blades and motor assembly may eventually require cleaning.
1. Disconnect the power cable from the power supply.
2. Unscrew the front grille and lift it away carefully.
3. Wipe the fan blades with dry cloth and remove any dust from the motor
assembly with a soft paintbrush, vacuum cleaner or jet of compressed air.
•NEVER use polish or any corrosive liquid that will damage the surface
finish.
4. Replace the grilles securely before use.
5. Periodic grille cleaning with a vacuum will prevent dust build up.
MAINTENANCE
Have any repairs carried out by a suitably qualified person.
The motor bearings are permanently sealed for life and do not require any
additional lubrication.
STORAGE
Keep the original carton for storage of the fan. Coil and tie the power cable to
avoid damage during storage.

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST AND DIAGRAM
NODESCRIPTION NODESCRIPTION
1 Front Grille 10 Capacitor
2 Blade 11 Power Cable
3 Drum 12 Support Bracket
4 Handle 13 Cradle Base
5 Rear Grille 14 Rubber Feet
6Motor 15SpacerTube
7 Switch Box 16 Wheel
8 Switch Knob 17 Axle
9 Switch 18 Axle Clamp

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATIONS
MODEL CAM24C
Part No: 3230446
Operating Voltage: 230 V AC (50Hz)
Rated Input Wattage: 230 W
Fan Speeds (Low): 950 rpm
Fan Speeds (Medium: 1100 rpm
Fan Speeds (High): 1200 rpm
Dimensions (W x D x H): 735 x 285 x 760 mm
Fan Blade Diameter: 610 mm
Weight: 11.5 kg
IP Rating: IPX0
ERP Ratings
Overall Efficiency: 30.2%
Measurement Category: A
Efficiency Category: Static
Efficiency Grade 40.05
Rated Motor Power Input @ Optimum
Energy Efficiency
230 W
Flow Rate @ Optimum Energy Efficiency 3448 m3/h
Pressure Rate @ Optimum Energy Efficiency 40 Pa
The Specific Ratio (EU 327/2011) 1

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DECLARATION OF CONFORMITY

12
