Clarke CML5 Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS0713
HYDRAULIC MOTORCYCLE LIFT
MODEL NO: CML5
PART NO: 7610193

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE hydraulic motorcycle lift.
Before attempting to operate this product, it is essential that you read this
manual thoroughly and carefully follow all instructions given. In doing so you
can look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Model Number CML5
Maximum Load 680 kg
Minimum Table Height 135 mm
Maximum Table Height 430 mm
Overall Length (inc handle) 1200 mm
Overall Width 390 mm
Weight 37.5 kg

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
SAFETY PRECAUTIONS
1. ALWAYS work in accordance with the instruction handbook;
2. NEVER exceed the maximum safe working load of 680 kg, and only use the
motorcycle lift for its intended purpose.
3. NEVER use the lift if it has been subjected to an abnormal load or shock. It
should be removed from service immediately and fully inspected by
qualified personnel, and passed as serviceable, before being used again.
4. NEVER rely upon the hydraulic ram to support the saddle when loaded.
Always use the locking bar to hold the saddle in one of the positions
provided.
5. ALWAYS use the lift on a solid, flat, level surface.
6. ALWAYS screw down the stabilisers before putting the saddle under load.
NOTE: The castors are not designed to take the weight of the motorcycle,
but are used merely to move the lift quickly and easily around the
workshop. On no account must you raise a loaded platform
unless the stabilisers are screwed down, and NEVER use the lift to
transport a load.
7. ALWAYS use appropriate safety equipment, such as protective footwear,
when using this lift.
8. ALWAYS inspect the lift before use to ensure it is in good condition, and
replace any damaged or worn parts.
9. ALWAYS use spare parts supplied by Clarke International. Using non-
standard parts could be extremely dangerous.
10. ENSURE the operator is trained in both operational and safety aspects.
11. NEVER leave this lift unattended whilst there is a load on it.
12. NEVER allow children or bystanders anywhere near this lift whilst it is in use.
13. NEVER use this lift to lift people or animals.
UNPACKING
Check to ensure that no damage has occurred during transit. Any damage
should be reported to your Clarke dealer immediately.
The following should be included:
1 x Main frame assembly 1 x Lifting pedal
1 x T - Handle assembly and retaining pin 1 x Locking bar handle
1 x Hydraulic pump assy c/w lowering pedal 1 x Pair of rachet straps

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
OVERVIEW
ASSEMBLY
THE RAM ASSEMBLY
1. Secure the ram assembly to its
baseplate using the two M8x25
bolts and M8 Spring washers
supplied.
2. Tighten the bolts securely.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
THE LOCKING BAR
1. Locate the locking bar handle in
to the socket at each side of the
lift.
2. Place a M8 spring washer on to
the threads and screw on the M8
nut securely.
• Ensure the locking bar is free to
rotate under its own weight.
• The locking bar should hinge so
that the ends engage against
one of the ridges on the base.
THE RAM TO THE FRAME
1. Lift the saddle manually and hook
the ram frame over the ram as
shown.
2. Secure in place using the locking
screw.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
THE HANDLE AND OPERATING PEDAL
The handle is secured to the frame using the pin provided.
The operating pedal should be slid into place and secured using the M8x12
bolt supplied.
OPERATION
NOTE: The operator must be able to watch the lift and the load during all
movements.
RAISING THE LOAD
1. Position the saddle between the
wheels of the motorcycle, as near
to the centre of gravity as
possible.
2. Pump the operating pedal until
the saddle makes light contact
with the motorcycle frame, then
assess where packing may be
required to ensure the motorcycle
is well supported and stable.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
3. When the motorcycle is
satisfactorily supported and
completely stable, screw down
the two stabilisers,
• This reduces any load from the
castors,
4. Raise the load slowlyby pumping
the operating pedal.
5. At all times make sure that the
moter cycle is fully supported and
stable.
6. Once you have reached the
desired height, ensure the locking
bar is engaged with the notches
on the base,
7. Press the release pedal gently,
allowing the saddle to lower until
the load is taken by the locking
bar.
• Do not work under the raised
load until it is secured using the
locking bar.
8. Secure the load using the
supplied rachet straps before you
begin work.
WARNING: UNDER NO CIRCUMSTANCES MUST YOU RELY UPON THE RAM
TO SUPPORT THE LOAD.
WARNING: ENSURE THE MOTORCYCLE IS FULLY STABILISED BEFORE
COMMENCING WORK.

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
LOWERING THE LOAD
1. Pump the operating pedal to
raise the load slightly and release
the locking bar.
2. Push the locking bar against the
ram and into the locking bar
retaining clip
3. Press down on the release pedal
and allow the load to descend.
4. Remove the locking bar from the
locking bar retaining clip before
using the lift again.
MAINTENANCE
BEFORE EACH USE
Visually inspect the lift for distortion of parts, cracked welds, damaged wheels
or castors, oil leakage from the ram, or any other sign of damage. Should any
of these be found, do not use the lift, and have it inspected and repaired by a
qualified technician before putting back into use. If necessary, consult your
Clarke dealer.
If any Warning labels becomes illegible, have it replaced. Contact your Clarke
dealer.
REPAIR
Should any repairs be required they should be carried out by qualified service
engineers, cantact the Clarke Service department on 020 8988 7400.
WARNING: TAKE GREAT CARE WHEN LOWERING. YOU ONLY NEED TO
PRESS THE RELEASE PEDAL VERY LIGHTLY. TOO HEAVY A TOUCH WILL
RESULT IN THE LOAD DESCENDING TOO RAPIDLY WHICH COULD BE
HAZARDOUS

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
PARTS LIST
MAIN UNIT
HARDWARE BOX
ITEM
NO
DESCRIPTION
PART
NUMBER
ITEM
NO
DESCRIPTION
PART
NUMBER
A Base HTCML5A L Pump Spring HTCML5L
B Link HTCML5B M Lock Rear Castor Assembly HTCML5M
C Lift Saddle HTCML5C N Height Lock Bar HTCML5N
D Height Lock Release HTCML5D O Front Wheel Assembly HTCML5O
E Connecting Rod HTCML5E P Loops HTCML5P
F T - Handle HTCML5F Q Clip HTCML5Q
G Locking Screw HTCML5G R Height Lock Springs HTCML5R
H Return Spring HTCML5H S Lock Position Ridge HTCML5S
I Hydraulic Ram HTCML5I T Rubber Pads HTCML5T
J Foot Pedal HTCML5J U Oil Fill Plug HTCML5U
KReleasePedal HTCML5K
1SpringNut
Sold as 1 Kit
HTCML5KIT
2NutM8
3CotterPin
4BoltM8x12
5BoltM8x25
6Washer
7BoltM6x15
8RachetStraps

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PART DIAGRAM

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [email protected]
DECLARATION OF CONFORMITY
