Clarke CTS4000B User manual

Assembly Instructions
AUTOMOTIVE SUPPORT STAND
Model No. CTS4000B
Part No. 7600200
0112

Parts List & Diagram
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
No. Description Part No. No. Description Part No.
Saddle HTCTS4000B01
Screw Rod HTCTS4000B02
Screw Nut HTCTS4000B03
Bearing HTCTS4000B04
Tube Insert HTCTS4000B05
Bolt M10x25 HTCTS4000B06
Support Post HTCTS4000B07
Leg HTCTS4000B08
Lower Strut HTCTS4000B09
Handle HTCTS4000B10
Locking Pin HTCTS4000B11
Bolt M10x20 HTCTS4000B12
Nut M10 HTCTS4000B13
Flat Washer HTCTS4000B14
Connect Plate HTCTS4000B15
Upper Strut HTCTS4000B16
Upper
Assembly
Specifications
Max. Height .............. 2360 mm
Min Height ................ 1255 mm
Base Dimensions ..... 650 x 563 mm
Weight ....................... 22 kg
Max Capacity .......... 750 kg
Thank you for purchasing this Clarke Automotive Support Stand. which is designed for
many support uses e.g. exhausts. Before use please read these instructions. This is for your
own safety and that of others around you, and to help you achieve long and trouble free
service from the stand.
Guarantee
This product is guaranteed against faults in manufacture for 12 months from purchase
date. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been abused or tampered with in any way, or
not used for the purpose for which it is intended. The reason for return must be clearly
stated.
This guarantee does not affect your statutory rights.
Safety Precautions
•DO NOT exceed the load for which this device was designed (750 kg).
•ENSURE the Stand is positioned on a solid level surface (concrete or similar).
•ALWAYS inspect before each use, to ensure the frame is not bent or twisted and that
there are no cracked welds etc. Should any damage be apparent, or if the stand has
been subjected to an abnormal shock, it should be removed from service and repaired
by a qualified technician.
•DO NOT use this tool as a jack.
•DO NOT use this stand to support a vehicle transmission.
Features
Little maintenance is required. The screw thread should be greased periodically with a
medium grease. In addition to the visual inspection before each use, as detailed above,
the stand should be inspected by a qualified technician annually to ensure it is completely
safe for use, with no distortion or damage of any kind.
The unit requires assembling according to the drawing opposite
Operation Ref: Parts List
1. Rotate the Screw Nut (3), anticlockwise, using the Handles (10), to lower the Saddle
(1), as far as possible
2. Grasp one of the handles (10), and taking the weight of the complete Upper Assembly
(Saddle, Screw Rod (2), Screw Nut, Handles and Tube Insert (5)), remove the Locking
Pin (11), which secures the Upper Assembly to the Support Post (7).
3. Raise the Upper Assembly as high as necessary so that the Saddle is as near as possible
to the load. Line up one of the holes in the Tube Insert (5) with the hole in the top of the
Support Post and locate using the Locking Pin.
4. Finally, screw the Screw Nut clockwise so that the Saddle contacts the load at a
suitible support point...careless positioning could result in damage to the load.
Continue to raise the saddle, but only so much as to take the weight of the load ONLY.
