Clarke Filtra-Pac 02150A User manual

Form No. 70290A 1/05 Clarke®Printed in the USA
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your Clarke
machinecouldresultininjurytoyouortootherpersonnel;damagetothemachineortootherproperty
could occur as well. You must have training in the operation of this machine before using it. If your
operator(s) cannot read English, have this manual explained fully before attempting to operate this
machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente
antes de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
For new books write to: Clarke®, 2100 Highway 265, Springdale, Arkansas 72764.
FiltraPac
Operator's
Manual

Page2 Clarke® FiltraPac Operator's Manual
OperatorSafetyInstructions ............................................................................................................ 3
SafetyInformation ........................................................................................................................... 4
Introduction & Machine Specifications............................................................................................ 5
GroundingInstructions.................................................................................................................... 6
Maintenance .................................................................................................................................... 7
HowToChangeTheFilterBag ........................................................................................... 7
HowToCleanTheMotorFilter ............................................................................................ 8
SECTION II Parts and Service Manual
Main Body Assembly Drawing ......................................................................................................... 10
Main Body Assembly Parts List........................................................................................................ 11
Back Frame and Harness Assembly Drawing and Parts List............................................................ 12
Hose, Wand and Tools Assembly Drawing and Parts List ................................................................ 13
Electrical Schematic ........................................................................................................................ 14
Table of Contents
English Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.

Clarke® FiltraPac Operator's Manual Page 3
When using an electrical appliance, basic precautions should be followed including
the following: Read all instructions before using these appliances
IMPORTANT SAFETY INSTRUCTIONS
WARNING AVERTISSEMENT ADVERTENCIA
DANGER: Failure to read and observe all DANGER statements could result in severe
bodilyinjury ordeath. Readand observeallDANGER statementsfoundin
your Owner's Manual and on your machine.
WARNING: Failure to read and observe all WARNING statements could result in injury
to you or to other personnel; property damage could occur as well. Read
and observe all WARNING statements found in your Owner's Manual and on
yourmachine.
CAUTION: Failure to read and observe all CAUTION statements could result in damage
to the machine or to other property. Read and observe all CAUTION
statements found in your Owner's Manual and on your machine.
WARNING: To reduce the risk of fire, electric shock, or injury:
1. Donotleaveappliancewhenpluggedin. Unplug from outletwhennotinuseand before
servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not allow to be used as a toy. Close attention is necessary when used by or near
children.
4. Useonly as describedin the manual. Use only manufacturer'srecommended attach-
ments.
5. Do not use with damaged cord or plug. If appliance is not working as it should, has
beendropped,damaged,leftoutdoors, ordroppedintowater,returnitto aservice
center.
6. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
aroundsharpedges or corners. Do not runapplianceovercord. Keep cord away from
heatedsurfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plugor appliance with wethands.
9. Do not put any object into openings. Do not use with any opening blocked; keep free
of dust, lint, hair and anything that may reduce air flow.
10. Keep hair,looseclothing,fingers,and allparts ofbody awayfrom openingsand moving
parts.
11. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes.
12. Do not use without dust bag and/or filters in place.
13. Turnoffallcontrolsbeforeunplugging.
14. Use extra care when cleaning on stairs.
15. Do not use to pick up flammable or combustible liquids such as gasoline or use in
areaswhere they maybe present.
16. Connect toproperlygrounded outlet. See"GroundingInstructions".
SAVE THESE INSTRUCTIONS

Page4 Clarke® FiltraPac Operator's Manual
SAFETY INFORMATION
Information for your safety and notes on disposal
Before using the FiltraPac, please read the information
below with care. This gives important guidance on the
safety use and maintenance of the FiltraPac. Keep this
bookletinasafeplace,andifappropriate,handitontothe
nextowner.
• ThisClarkevacuumcomplieswithrecognized
technological standards and the current safety
regulations for electrical appliances.
• Thisappliance fulfills therequirements ofEU
guidelines89/336/EEC(Electromagnetic
compatibility)and73/23/EEC(Lowvoltage
guideline). The appliance is marked with the CE
symbol on the rating plate for 230V models.
Clarkereserves the right to modifydesignsand
specifications without notice.
ImportantInformation
• Do not switch on the appliance if the housing
exhibits any evidence of damage (cracks/
fractures), if the connecting lead is defective, or
if an internal defect is suspected (e.g. if the
appliance has been dropped).
• Appliance only to be connected to voltage
indicated on the rating plate.
• Clarke will not accept any liability for damage or
injury if the appliance is used other than for its
intended purpose or is improperly operated or
inexpertlyrepaired and maintained.
• Before use, check to ensure that all the filters
are correctly installed. The appliance must not
beusedwithoutfilters.
• Useonly genuine Clarke filters andaccessories.
• When connecting accessories, cleaning,
repairing or servicing the unit, unplug the unit.
• Do not let children use electrical appliances
unsupervised.
• This appliance is not suitable to be used to pick
upsubstancesconstitutingahealthhazard.
• Repairsshouldbecarriedoutbyonauthorized
Clarkeservicecenter(seeOperator'sManualfor
list of addresses). Incorrect repairs may expose
the user to electrical danger.
• Any appliance used commercially is to be
operated only by persons properly instructed in
it's use and operation.
SafetyPrecautions
• Do not pull out the plug from power supply socket
by pulling on the connecting lead.
• Do not pull the connecting lead over sharp edges
orallowittobecomejammed.
• Donotusedamagedextensionleads.
• If required, the connecting lead has to be
replaced together with the cable rewind by a
specialist.
• Neverreplace the powersupply cable with
anything other than the same type of cable
specified by the maker (H 05 VVF 2 x 0.75).
• The supply cable has to be replaced by an
authorizedClarkeAfter-Sales-Serviceonly.
• Before any maintenance operation or replacing a
filter, and after use, switch off the appliance and
pulloutthemainsplug.
• Keep the nozzles and ends of tubes well away
from the eyes and ears.
• The appliance must only be used for dry vacuum
cleaning. It is not a dual purpose (wt/dry)
vacuumcleaner.
• Do not use the appliance to pick up hot or
glowingsubstances.
• Do not use the appliance to pick up coarse
sliversofglass.
• Don not use the appliance to pick up any
solvents,explosiveliquidsorgases.
• Do not store the appliance outdoors.
• Do not expose the machine to weather, humidity
norexcessiveheat.
• Clean the appliance only with a dry or slightly
moist cloth. Do not allow any of the electrical
components(switches, plug, socket,electronics,
etc.) to come into contact with water.

Clarke® FiltraPac Operator's Manual Page 5
PowerSupply 115V-60 Cycle
VacuumMotor 19,200rpm
PowerBrushMotor 11,000rpm
Cord 40 ft.
WandAttachment 1 3/8" x 20 1/2" (2)
Hose 1 1/4" x 64"
FilterBags 6 lt, 2-ply disposable
Weight 11.5 lbs.
Shipping Weight 17lbs
Warranty 1 year
Model Filtra-Pac 02150A
INTRODUCTION
The FiltraPac is a vacuum for cleaning carpet. This machine is used to remove dry material from carpet. This
machine is intended for commercial use.
MACHINESPECIFICATIONS
52393A Power Wand ¼ HP Perm. Magnet Mtr. 12"
50721B Paper Filter Bag Pkg of 5
54025A Micro-Staph Filter Pkg of 15
50747A Cloth Filter Bag FiltraPac
59203A CreviceTool
59204A UpholsteryTool
59206A SoftFloorTool
59978A Hard Floor Tool (rep. brush #52395A)
59818A Extension Wand (Plastic, 2 piece)
52838A Airline 400 Cycle Conversion Kit
54490 Extension Wand (Aluminum, 2 piece)
47109 TelescopingChrome Wand
5146 SwivelDustingBrush
14295 4.5"Nozzle (Plastic)
5145 6"Nozzle(Aluminum)
6086 Brush 9" Plastic for Upholstery & Furniture
5144 LouverBrushNozzle
8046 Combination Tool 11" Plastic (soft & hard floor)
5147 Metal Floor Tool 13.5" (rep. brush #5147)
54118 Turbine Brush - Vacuumed Powered Capet Tool
15348 Metal Floor Tool 18" (rep. brush #15351)
Part No. Description
OPTIONALACCESSORIES

GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunc-
tion or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of
electric shock. This appliance is equipped with a cord
havingan equipment-groundingconductor and ground-
ing plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accor-
dance with all local codes and ordinances.
WARNING: Improper connection of
theequipment-grounding conductor canresult
in risk of electric shock. Check with a qualified
electrician or service person if you are in doubt
as to whether the outlet is properly grounded.
Do not modify the plug provided with the
appliance - if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120-volt circuit
andhas a ground plug that looks likethe plug illustrated
in figure 1. Make sure that the appliance is connected
to an outlet having the same configuration as the plug.
No adapter should be used with this appliance.
Grounding
Pin
Grounded
Outlet
Grounded
Outlet
Box
Figure 1
Figure 2
Page6 Clarke FiltraPac Operator's Manual
HOW TO USE THE MACHINE
How to Put the FiltraPac on and Adjust for Comfort
Follow these steps to put on the FiltraPac and to make
adjustmentsforfittingcomfort:
1. Pick up and put on vacuum, sliding in one arm at a
time.
2. Bucklethewaistbelt.
3. Toproperly adjust theshoulder strap and belt
harness, pull down on shoulder straps so the
materialslips throughbuckleuntiltight.
4. Tightenthewaistbelt. Thewaist belt should be
very snug to transfer the weight to the hip and legs.
5. Practice the vacuuming technique using a side to
side sweeping motion. See figure 2.
6. Useatwistingmotiontoinstall andremovethe
friction fit tools.
7. Take the vacuum off by first loosening both straps
onthe shoulder harness, thenunbucklebelt
harness.
8. Removethepack.

Figure 3
Figure 4
Figure 5
MAINTENANCE
WARNING: To prevent injury, always remove
the electrical plug from the electrical outlet
before doing any maintenance or repairs to
the machine.
WARNING: Maintenance and repairs must be
done by authorized personnel only. Use only
genuine Clarke parts.
How To Change The Filter Bag
Themachineusesapaperfilterbagoraclothfilterbag. To
changethepaperfilterbag,followthisprocedure:
1. Make sure the ON/OFF switch in the "O"
position.
2. Open the front of the tank housing. To open the
tank housing, press the tank release bar. See
figure 3.
3. Hold the bag by the cardboard inlet.
4. Pull the bag out.
5. Install a new filter bag. To install a new filter bag,
followthisprocedure:
a. Unfoldthefilterbag.
b. Hold the bag by the cardboard inlet.
c. Put the opening in the cardboard inlet over the
bag adapter. See figure 4.
d. Close the tank housing.
To empty the cloth filter bag, follow this procedure:
1. Openthe front ofthe tank housing.
2. Removetheclothfilterbagfromthebagadapter.
3. Slide the clamp off the filter bag. See figure 5.
4. Removethedirtfromthebag.
5. Slide the clamp on the bottom of the filter bag.
6. Install the filter bag in the machine.
7. Close the tank housing.
Clarke FiltraPac Operator's Manual Page 7

Page8 Clarke® FiltraPac Operator's Manual
Figure 6
How To Clean The Motor Filter
Clean the motor filter whenever it is dirty. To clean the
motorfilter,followthisprocedure:
1. Open the tank assembly.
2. Removethefilterbag.
3. Pull the filter cover off the filter disc.
4. Removethefilter.
5. Wash the filter in water.
6. Put the filter in a cloth and apply pressure to dry
thefilter.
7. Put the filter in the filter cover.
NOTE: Install the filter cover with the opening
toward the back of the tank housing. See
figure 6.
CAUTION: Check the motor protection filter
while changing the paper bag. Please change
the motor protection filter after use of 6 paper
bags.
8. Installthe filter bag.
9. Close the tank assembly.
MAINTENANCE

Clarke® FiltraPac Operator's Manual Page 9
FiltraPac
Section II
Parts and Service Manual
(70290A)

Page10 Clarke® FiltraPac Operator's Manual
Clarke®
FiltraPac
Main Body
Assembly Drawing 7/01
1
2
3
4
5
6
7
8
6
9
10
11
12
25
26
27
21
28
29
30
38
37
6
36
35
34
33
32
31
24
23
21
14
13 15 16 17 6 18 19 20

Clarke® FiltraPac Operator's Manual Page 11
Ref. Part # Description Qty.
1 52370A PowerCordonly 1
2 52371A Switchonly 1
3 52372A Power Cord w/Switch 1
4 52373A Cover Washer 1
5 52374A StrainRelief 1
6 57951A Screw 4mm x 20 8
7 52375A Washer 8
8 964004 Screw, 5mm x .8 x 16mm 2
9 52376A AngleBracket 1
10 52377A Nut 4mm 2
11 52378A RearCanister 1
12 52379A FlatCable 1
13 80067A Screw 3mm x 12 2
14 52380A Socket,Receptacle 1
15 55658A Bar,Locking 1
16 58693A Spring,Spiral 1
17 52381A CoverPlate 1
18 53408A Spring 1
19 55715B Latch 1
20 52906B Cover, Canister 1
2150636A Terminal Block 1
22
23 50721B Bag, Paper 10 Pak 1
50447A Cloth Filter Bag (Optional) 1
24 54023A Filter Frame 1
25 54024A Filter,Motor 1
26 54734A InsulatingInsert 1
27 52382A OverheatCutout 1
28 52383A CarbonBrushw/Holder 2
29 43607A Insulation,Motor 1
30 52384A MotorBearingBlock 1
31 57862A MotorGasketSeal 1
32 54360A Gasket,CainsterFront 1
33 54025A Filter,MicroExhaust 1
34 52385A VacMotor120Volt 1
35 54026A FilterCassette 1
36 52386A MotorCover 1
37 54361A GasketStrip 1
38 53931A Foam Insulation 1
NI 53394A H.E.P.A. Filter (Optional) 1
NOTE: indicates a change has been made since the
last publication of this manual.
Clarke®
FiltraPac
Main Body
Assembly Drawing Parts List 1/05

Page12 Clarke® FiltraPac Operator's Manual
Ref. Part # Description Qty.
50 52387A CarryFrameComplete 1
51 52388A CarryFrame 1
52 52389A ShoulderStrap 1
53 52390A Rivet 4
54 980205 Washer 2
55 52391A Waist Belt 1
56 52394A RivetNut 4
50
51
52
53
54
55
56
Clarke®
FiltraPac
Back Frame and Harness
Assembly Drawing and Parts List 7/01

Clarke® FiltraPac Operator's Manual Page 13
Clarke®
FiltraPac
Hose, Wand and Tools
Assembly Drawing Parts List 1/05
Ref. Part # Description Qty.
60 59203A Crevice Tool 1
61 54490 Wand - 2 Piece 1
62 59204A Nozzle Upholstery 1
63 59206A Soft Floor Tool 1
59978A Hard Floor Tool 0
64 52395A Bristle Set 0
6552478A Regulating Slide 1
6661447A Hand Tube 1
6852479A Connecting Socket 1
6910372A Hose & Handle Asm. 1
70 53054A Swivel End, Hose 1
71 57405A Retainer, Spring 1
72 53075A Socket, Connecting 1
NOTE: indicates a change has been made since the
last publication of this manual.
69686665
60
61
62
63
64
70 71 72

Page14 Clarke® FiltraPac Operator's Manual
Clarke®
FiltraPac
Electrical Schematic 11/04

Clarke® FiltraPac Operator's Manual Page 15
CLARKE PRODUCT SUPPORT BRANCHES
PRODUCTION FACILITIES
ALTO Danmark A/S, Aalborg
Blytaekkervej 2
DK-9000 Aalborg
[phone]
ALTO Danmark A/S, Hadsund
Industrikvarteret
DK-9560 Hadsund
[phone]
SALES SUBSIDIARIES
ALTO US - Canada, Ontario (Canada)
4080 B Sladeview Crescent Unit 1
Mississauga, Ontario L5L 5Y5
[phone]
ALTO Overseas Inc., Sydney (Australia)
1B/8 Resolution Drive
Caringbah NSW 2229
[phone]
ALTO Cleaning Systems Asia Pte Ltd., Singapore
No. 17 Link Road
Singapore 619034
[phone]
ALTO Deutschland GmbH, Bellenberg (Germany)
Guido-Oberdorfer-Straße 2-8
89287 Bellenberg
[phone]
ALTO Cleaning Systems (UK) Ltd., Penrith
Gilwilly Industrial Estate
Penrith
Cumbria CA11 9BN
[phone]
ALTO France S.A. Strasbourg
B.P. 44, 4 Place d’Ostwald
F-67036 Strasbourg
Cedex 2
[phone]
ALTO Nederland B.V.
Postbus 65
3370 AB Hardinxveld-Giessendam
The Netherlands
[phone]
ALTO Sverige AB, Molndal (Sweden)
Aminogatan 18
Box 4029
S-431 04 Molndal
[phone]
ALTO Norge A/S, Oslo (Norway)
Bjornerudveien 24
N-1266
[phone]
U. S. A. Locations European Locations
CORPO
PRODUCTION FACILITIES
Clarke®, Springdale, Arkansas
2100 Highway 265
Springdale, Arkansas 72764
[phone]
Customer Service - 1-800-253-0367
Technical Service - 1-800-356-7274
American Lincoln®, Bowling Green, Ohio 43402
1100 Haskins Road
SERVICE FACILITIES
Clarke®, Elk Grove, Illinois 60007
2280 Elmhurst Road
[phone]
Clarke®, Denver, Colorado 80204
1955 West 13th Ave.
[phone]
Clarke®, Houston, Texas 77040
7215 North Gessner Road
713-937-7717
SERVICE AND SALES FACILITY
American Lincoln®/ Clarke, Madison Heights,
Michigan 48071-0158
29815 John R.
[phone]
American Lincoln®/ Clarke, Marietta, Georgia 30066
1455 Canton Road
[phone]
Clarke®
Clarke American Sanders
A.L. Cook
Customer Service Headquarters and Factory
2100 Highway 265
Springdale, Arkansas 72764
[phone]
Technical Service
1-800-356-7274

This Clarke Industrial/Commercial Product is warranted to be free from defects in materials and
workmanship under normal use and service for a period of one year from the date of purchase, when
operated and maintained in accordance with Clarke’s Maintenance and Operations Instructions.
This warranty is extended only to the original purchaser for use of the product. It does not cover
normal wear parts such as electrical cable, rubber parts, hoses and motor brushes.
If a difficulty develops with the product, you should:
(a).Contact the nearest authorized Clarke repair location or contact the Clarke Service Operations
Department, 2100 Highway 265, Springdale, Arkansas 72764, for the nearest authorized Clarke repair
location. Only these locations are authorized to make repairs to the product under this warranty.
(b).ReturntheproducttothenearestClarkerepairlocation. Transportationchargestoandfromtherepair
location must be prepaid by the purchaser.
(c).Clarke will repair the product and/or replace any defective parts without charge within a reasonable
time after receipt of the product.
Clarke’s liability under this warranty is limited to repair of the product, and/or replacement of parts and
is given to purchaser in lieu of all other remedies, including INCIDENTAL AND CONSEQUENTIAL
DAMAGES.
THEREARENOEXPRESSWARRANTIESOTHERTHANTHOSESPECIFIEDHEREIN. THEREARENO
WARRANTIESWHICHEXTENTBEYONDTHEDESCRIPTIONOFTHEFACEHEREOF. NOWARRANTIES,
INCLUDINGBUTNOTLIMITEDTOWARRANTYOFMERCHANTABILITY,SHALLBEIMPLIED. Awarranty
registration card is provided with your Clarke product. Return the card to assist Clarke in providing the
performance you expect from your new floor machine.
Clarke®, 2100 Highway 265, Springdale, Arkansas 72764.
Clarke®U.S. LIMITED WARRANTY
Clarke reserves the right to make changes or improvements to its machine without notice.
Always use genuine Clarke Parts for repair.
2100 Highway 265
Springdale, Arkansas, 72764
