English
Steam Iron
Art.no 18-4708 Model ES-2339A-02
44-1919 ES-2339A-02
Please read theentire instruction manual before using theproduct and then save
it for future reference. Wereserve theright for any errors in text or images and any
necessary changes made to technicaldata. Intheevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
• Theproduct may be used by children of 8 years and above
and by persons with reduced physical, sensory or mental
capability or lack of experience and knowledge provided they
have been given supervision or instruction concerning use
of theproduct in asafe way and understand thehazards
involved.
• Never let children play with theproduct.
• Theproduct must never be left unattended when it is
pluggedin.
• Unplug theproduct before filling or emptying thewatertank.
• Unplug theproduct whenever it is not inuse.
• Only use theproduct on astable surface.
• Theproduct should only be placed on astable surface when
not inuse.
• Do not use theproduct if you have dropped it on thefloor, if it
is visibly damaged or if it is leaking.
• Only have themanufacturer, retailer or other qualified person
repair or replace adamaged mains lead in order to avoid any
possible danger.
• Caution: Theproduct will become very hot duringuse.
Lettheproduct cool completely before putting it away for
storage.

4
English
• Children should not be allowed to clean or maintain
theproduct unless they are older than 8 and under adult
supervision.
• Theproduct must only be used as described in this
instruction manual.
• Theproduct must not be immersed in water or other liquid.
Doingso could result in anelectricshock.
• Always set thetemperature to theMIN setting before
unplugging theproduct. Whenunplugging, always grasp
theplug and not themainslead.
• Keep themains lead away from hot or sharp objects.
Lettheproduct cool down completely before putting it away
for storage. Windthemains lead loosely around theproduct
before storingit.
• Never dismantle or modify theproduct in anyway.
• Be very careful if there are children close to where you are
ironing, there is arisk of them burning themselves or pulling
theiron down onto themselves.
• Hot water or steam can cause scalding injuries whenever
theproduct is tilted or turnedover.
• If theproduct emits smoke, anunusual odour or doesn’t
function normally, unplug it and have it checked by aqualified
electrician.
• This product is intended for indoor useonly.

5
English
1
2
3
4
5
678
9
10
Buttons and functions
1. Spray nozzle
2. Water tank refillport
3. Steam controlknob/
self-cleaning
4. Spray button
5. Steam shot button
6. Temperaturelight
7. Temperature settingknob
8. Handle
9. Watertank
10. Soleplate

6
English
Operating instructions
Before initialuse
Note: Remove theprotective plastic film from thesoleplate beforeuse.
Harmless smoke and odour may be emitted from theiron thefirst few times isused.
Thisis atemporary condition and is completely normal. Before using theiron, test it
on aspare piece of cotton cloth to check that both thesoleplate and thewater tank
areclean.
Refilling
1. Unplug theiron and let thesoleplate cooldown. Standtheiron upright.
2. Turn thesteam control knob (3) to the0position.
3. Flip open thewater tank’s refill port (2).
4. Use themeasuring cup and fill thetank (9) up to themaxmark.
5. Close thelid.
Note: Thewater tank’s filter prevents limescale deposits from forming in theiron.
Thefilter is permanently attached and does not need changing or cleaning. Use only
tap water. Thefilter will malfunction if distilled or demineralised water is used. Chemical
additives, fragrances or descaling agents added to thewater will also destroy thefilter.
Temperature settingknob
1. Always check thefabric care label on thepiece to be ironed.
2. Always use thelowest recommended temperature setting if thefabric consists of
mixed materials.
3. Plugin theiron and stand it upright.
4. Usethetemperature control knob (7) to set thedesired temperature
MIN – ○– ○○ – ○○○ – MAX.
- Thetemperature light (6) will be lit until theset temperature has been reached.
- Thetemperature light (6) will turn off once theset temperature has been reached.
Thegarment’s care label usually has therecommended ironing setting on it:
Symbol Material Thermostat setting
Synthetic ○Low temperature
Silk/wool ○○ Medium temperature
Cotton/linen ○○○ High temperature
Material not suitable for ironing.

7
English
Spray feature
This function can be used at any time and does not affect thetemperature setting.
Slowly press thespray button (4) for afull spray or press quickly for afinemist.
Donotuse thespray function on silk or synthetic fibres.
Steam ironing
This feature only works on thehigher temperature settings.
- ○○ mediumheat
- ○○○ maxheat
1. Fillthesteam iron with water if you have not already doneso.
2. Plugthemains lead into awall socket.
3. Setthetemperature to ○○ or ○○○.
4. Thetemperature light (6) will turn off once theset temperature has been reached.
5. Turnthesteam control knob (3) to the setting so that steam begins exiting from
thesoleplate’s steamports.
6. Holding theiron horizontally will allow steam to exit while holding it vertically will
prevent steam from exiting. Toiron vertically, such as on hanging garments, use
thesteam shot function.
Note: Watercan drip from thesoleplate if thetemperature setting is toolow. Ifthis
happens, set thetemperature to ○○ or ○○○. Steamwill return once thecorrect
temperature has beenset.
Steam shot feature
Thesteam shot feature can be used for both dry and steam ironing. However,
thetemperature must then be set tohigh. Pressthesteam shot button (5) afew times
to effectively smooth out wrinkles.
1. Holdtheiron over thepiece of clothing.
2. Pressthesteam shot button (max 2 seconds) until steam begins emitting from
thesoleplate.
3. Release thesteam shot button.
Dry ironing
1. Turnthesteam control knob (3) to the0position.
2. Plugthemains lead into awall socket.
3. Settheiron to thedesired temperature setting.
4. Thetemperature light (6) will turn off once theset temperature has been reached.

8
English
Ironingtips
• Garments with embroidery, sequins, lace,etc., should be ironed on thelowest
temperature setting.
• For textiles made of mixed fibres (e.g. 40% cotton/60% synthetic fibre), choose
thetemperature setting appropriate for thefibre with thelowest recommended
ironing temperature.
• If you are not sure what thematerial is made of, start by ironing aninconspicuous
part of thegarment on thelowest temperature setting and increase thetemperature
gradually.
• Never iron agarment which has sweat stains or other discolouration, theheat will
iron thestain into thefabric and it will be very difficult to remove.
• Ironing silk, wool and synthetic fibres can cause shiny patches to be formed.
Toprevent this, iron such fabrics on thereverseside.
• Velvet can also form shiny patches when ironed. Ironin thedirection of thepile/nap
to avoid such damage. Avoidpressing theiron down onto thefabric.
• Washing more clothes at thesame time causes more wrinkles toform.
• Higher speed spin cycles also causes more wrinkles toform.
• Many types of fabric are easier to iron before they are completelydry. Silk, for
example should always be steam-ironed.
Care advice
Cleaning thehousing
• Note: Unplug theiron from thewall socket before cleaning.
• Wipe theexterior with amoist, softcloth. Donot use abrasive cleaning agents
orsolvents.
• Note: Avoidscratching thesoleplate – do not slide it over metal items such as
buttons orzips.
Afteruse
Warning: Theiron becomes very hot directly afteruse. Remember to let it cool down
completely before putting it away for storage.
1. Unplug themains lead from thewall socket.
2. Empty thewater tank by turning theiron upside down whilst carefully using aback
and forth motion to allow any excess water to drip from thetank. Pressthespray
button afew times to ensure thetank is completelyempty.
3. Store theiron in adry, room temperature environment.

9
English
Self-cleaning
We recommend that you use theself-cleaning function at least once amonth or
possibly more often depending on thewater quality in yourarea. Theself-cleaning
function removes scale and dust particles from thewatertank.
1. Fillthewater tank up to themax levelmark.
2. Turnthesteam control knob (3) to the0position.
3. Standtheiron upright.
4. Plugthemains lead into awall socket.
5. Setthetemperature to MAX using thetemperature control knob (7).
6. Waituntil theiron becomes hot and thetemperature light (6) turnsoff.
7. Holdtheiron in thehorizontal position and turn thesteam
control knob to the position. Thebutton will pop up (see
illustration) and theself-cleaning feature will become active.
Continue holding theiron and let it run through theself-
cleaning procedure (approximately 1 min). Thiscan be done
over thebasin or other appropriate location.
8. Unplug theiron and set thesteam control knob to 0so that no water comesout.
9. Lettheiron cool down and then iron aspare piece of cotton fabric. Thiswill clean
theface of thesoleplate from any remaining scale and dirt deposits.
Responsible disposal
This symbol indicates that this product should not be disposed of with
general householdwaste. Thisapplies throughout theentire EU. Inorder
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner.
Whenrecycling your product, take it to your local collection facility or
contact theplace of purchase. Theywill ensure that theproduct is
disposed of in anenvironmentally sound manner.
Specifications
Voltage 220–240V AC, 50/60 Hz
Power 1830–2200 W
Tank capacity 180ml
Cable length 1.9m

10
Svenska
Ångstrykjärn
Art.nr 18-4708 Modell ES-2339A-02
44-1919 ES-2339A-02
Läs igenom hela bruksanvisningen före användning och spara den sedan
för framtidabruk. Vireserverar oss förev. text- och bildfel samt ändringar av
tekniskadata. Vidtekniska problem eller andra frågor, kontakta vår kundtjänst
(se adressuppgifter påbaksidan).
Säkerhet
• Produkten får användas av barn från 8 år och av personer
med någon form av funktionsnedsättning, brist på erfarenhet
eller kunskap som skulle kunna äventyra säkerheten, om
de har fått instruktioner om hur den på ettsäkert sätt ska
användas och förstår faror och risker som kan uppkomma.
• Låt aldrig barn leka med produkten.
• Produkten får inte lämnas utan uppsikt när stickkontakten är
ansluten till vägguttaget.
• Dra stickproppen ur vägguttaget innan du fyller på vatten eller
tömmer vattenbehållaren.
• Dra ur stickproppen när produkten inte används.
• Använd produkten endast på stadigt underlag.
• Ställ ifrån dig produkten endast på stadigt underlag.
• Produkten får inte användas om du har tappat den igolvet,
om det finns någon synlig skada på den eller om den läcker.
• Om nätsladden skadas får den endast bytas ut av tillverkaren,
återförsäljaren eller annan kvalificerad tekniker för att
undvikafara.
• Tänk på att produkten blir mycket varm vid användning.
Låtprodukten svalna ordentligt innan du stoppar undan
denför förvaring.
• Rengöring och skötsel får inte utföras av barn från 8 år utan
vuxens närvaro.
