Clas Ohlson VQ1420SWDC-UK User manual

ENGLISH
SVENSKANORSKSUOMI
DEUTSCH
Important!
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the equipment.
Keep the manual for future reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den innan
du använder utrustningen. Spara manualen
för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre deg
om at du forstår dem før du tar produktet i bruk.
Ta vare på anvisningene for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin alat
käyttää laitetta. Säilytä ohjeet myöhempää
tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung durchlesen und
aufbewahren.
Art.no Model
18-3157 VQ1420SWDC-UK
40-7938 VQ1420SWDC
Wet and Dry
Vacuum Cleaner
Torr- och våtsugare
Tørr og våtsuger
Kuiva- ja märkäimuri
Nass- und Trockensauger
Ver. 20131015
Original instructions
Bruksanvisning i original
Original bruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung

3
ENGLISH
Wet and Dry Vacuum Cleaner 1400 W
Art.no 18-3157 Model VQ1420SWDC-UK
40-7938 VQ1420SWDC
Please read theentire instruction manual before use and save it for future reference. Wereserve theright for any
errors in text or images and for making any necessary technical changes to this document. Ifyou should have
any questions concerning technical problems please contact our Customer Services.
1. Safety instructions
• Make sure that thepower supply is 230 VAC.
• Do not use thewet and dry vacuum for vacuuming flammable substances, hot coals, ashes or anything that
could cause thevacuum to catchfire.
• Do not use thevacuum for vacuuming large objects or metal objects as these could damage thevacuum.
• Do not run thewheels over themains lead or use thevacuum if themains lead is damaged.
• Do not let children play with thevacuum. Itis not atoy.
• Keep hair, fingers and loose clothing away from theair vents and moving parts of thevacuum.
• Never use themachine without afilter.
• Do not use thewet and dry vacuum if thenozzle is blocked or if any part is deformed.
• Do not use thewet and dry vacuum close to cookers, ovens or other sources ofheat.
• Carry thevacuum by its handle. Donot drag it around by its mainslead.
• Unplug thewet and dry vacuum when it is not inuse.
• Do not expose theelectrical components of thevacuum to rain or moisture.
• Store theproduct indoors in adry area when it is not inuse.
• If themains lead is damaged and needs changing it should be sent to themanufacturer, anauthorised
service facility or qualified person to be properly repaired.
• The product may be used by children of 8 years and above and by persons with reduced physical, sensory
or mental capability or lack of experience and knowledge provided they have been given supervision or
instruction concerning use of the product in a safe way and understand the hazards involved.
• Never let children play with the product.
• Cleaning and maintenance may be carried out by children but only under adult supervision.
Warning! Electrical appliances used close to water should be connected to thepower supply via aresidual
current device (tripping current 30 mA in not more than 30 ms).

4
ENGLISH
A B
C
D E F G H I
J K L M N O P Q
2. Package contents
A. Wet & Dry Vacuum Cleaner (1×)
B. Hose (1×)
C. Tubes (3×)
D. Universal nozzle for floors and carpets (1×)
E.
Crevice nozzle for corners and confined spaces (1×)
F. Foam filter for wet use (1×)
G. Dust bag (1×)
H. Adaptor (1×)
I. Filter cover (1×)
J. Cartridge filter (1×)
K. Wheel with mount (2×)
L. Castor with mount (2×)
M. Screws in plastic bag (1×)
N. Handle (1×)
O. Instruction manual (1×)
P. Brush nozzle (1×)
Q. Silencer (1×)

5
ENGLISH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Description
Wet & dry vacuum suitable for vacuuming up thefine dust from grinding and sanding as well as coarser
sawdust, wood chips, leaves, waste water from blocked drains, etc.
1. Castor
2. Castor mount
3. Wheel
4. Accessory holder
5. Over-centre catch
6. Blowing port/exhaust
7. Handle
8. Top section including motor
9. Power switch
10. Power tool socket
11. Vacuum port
12. Container
13. Accessory holder
14. Draincap

6
ENGLISH
1
6
11
2
7
12
3
8
13
4
9
14
5
10
15
3. Assembly
1. Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
2. Open theover-centre catch (5).
3. Lift up themotor unit/top (8) and remove theaccessories from thecontainer (12).
4. Check that all theparts are intact and that nothing is missing.
5. Turn thecontainer upside down and press in thecastors (L) securely on thebottom. Pressthem in securely
and fasten them with thescrews from theplastic bag (M).
6. Press thewheels (K) securely into thebottom. Thewheels are marked 1and 2and thebottom has
corresponding markings. Pressthewheel marked “1” securely into thebottom where it is marked 1and do
thesame for wheel “2”. Securethewheels with screws from theplastic bag.
7. Attach thehandle (N) and fasten it with thefastening screws (M), making sure not to over-tighten.
• Dry vacuuming (fig. 8 – 10):
8. The wet & dry vacuum is usually delivered ready for dry vacuuming with thecartridge filter (J) already
inserted. Ifit is not: Carefully press thefilter cartridge securely onto thefilter basket.
9. Fasten thefilter cover (I) by turning thelocking knob on thefilter cover to thelocked position.
10. Use thedust bag (G) when necessary to achieve thebest possible filtering results. Pressit securely onto
thevacuum port on thecontainer.
• Wet vacuuming (fig. 11):
11. Attach thefoam filter (F) before wet vacuuming. Slidethefoam filter onto thefilter basket making sure to
cover theentire filter basket.
12. Replace themotor unit/top (8) over thecontainer (12).
13. Secure thetop section onto thecontainer with theover-centre catch.
14. Attach thehose (B) to thevacuum port (11). Pressin and turn it clockwise until it is securely fastened.
15. Attach theaccessory of your choice to thehose.

7
ENGLISH
4. Power switch
The power switch (9) has three settings:
• IOn
• 0Off
• II Power tool socket – Thewet & dry vacuum starts and stops automatically when themachine connected
to themachine socket is turned on andoff.
5. Power tool socket
The product has apower tool socket (10) which is intended for starting thewet and dry vacuum cleaner automatically.
• Connect theplug of acircular saw or similar machine to thepower tool socket and then connect thesuction
hose of thevacuum to thedust extractor port of thecircular saw (or whatever power tool is connected).
Setthepower switch toII.
• The ON and OFF control of thewet and dry vacuum will now be controlled by theconnected power tool.
Thewet and dry vacuum will switch on as soon as theconnected power tool has started and switch off
about 5 seconds after theconnected power tool has been switched off.
N.B. Thepower tool socket must not be loaded with more than 1600W.

8
ENGLISH
1
6
2
7
3
8
4
9 10
5
6. Use
Warning! Readthewarning label before use.
Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
N.B. Thecartridge filter is for vacuuming dust. Thefoam filter must only be used for vacuuming water.
Whenvacuuming very fine-particled substances, both thedust filter and thedust bag must be used.
Theguarantee will be void if thewrong type of dust bag has beenused.
6.1 Dry vacuuming
1. Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
2. Remove themotor/top (8) and check that thecartridge filter (J) is attached, if not: Removethedust filter
from thefilter basket* being careful not to damage thefilter.
3. Fasten thefilter cover (I) by turning thelocking knob on thefilter cover to thelocked position.
4. Use thedust bag (G) when necessary to achieve thebest possible filtering results. Pressit securely onto
thevacuum port inside thecontainer.
5. Replace themotor/top (8) onto thecontainer (12) and fasten it with theover-centre catch (5).
6. Attach thesuction hose (B) to thevacuum port (11). Pressand turn it clockwise until thehose
is securely fastened.
7. Attach any desired accessory to thehose.
8. Connect theplug to awall socket.
9. Start themotor by setting thepower switch (9) to the1=ON position (or position II when using thepower
tool socket).
10. Turn off themotor by flipping thepower switch to the0=OFF position when you are done. Pulltheplugout.
*N.B. Thecartridge filter has two different sides. Theflat side should be facing themotor/top.

9
ENGLISH
1
6
2
7
3
8 9
4 5
1. Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
2. Remove themotor/top and check that thefoam filter is fitted, if not: Fitthefoam filter (F) onto thefilter
basket being careful not to damage thefilter.
3. Replace themotor/top (8) onto thecontainer (12) and fasten it with theover-centre catch (5).
4. Attach thehose (B) to thevacuum port (11). Pressin and turn it clockwise until thehose is securely
fastened.
5. Attach any desired accessory to thehose.
6. Connect theplug to awall socket.
7. Start themotor by setting thepower switch (9) to the1=ON position (or position II when using thepower
tool socket).
8. Open thedrain cap (14) and empty thecontainer’s contents when it becomes full. Remember to screw
thecap backon!
9. Turn off themotor by flipping thepower switch to the0=OFF position when you have finished.
Pulltheplugout.
Precautionary measures for wet vacuuming
• Only use thefoam filter when wet vacuuming.
• Make sure that thefoam filter is clean and dry and secure it onto thefilter basket before starting to vacuum
any liquid.
• The safety cut-out float switch stops thevacuum from sucking when thewater level in thecontainer reaches
acertain level, thus preventing water from entering themotor. Themotor will race when thesuction function
has been stopped by thefloat. Switchthemotor off and empty thecontainer.
• Empty thecontainer before it becomes totally full and clean it afteruse.
• Clean thefoam filter when it looks clogged. Removethefilter and wash it by hand in water with amild
detergent, let it air-dry.
• Do not submerge theentire nozzle under thesurface. Leavesome space so that air can also pass through
when vacuuming alarge amount of liquid.
• Remember to reattach thefilter before using thevacuum again. NEVER use thewet and dry vacuum
without afilter.
6.2 Wet Vacuuming
Warning: Donot use thewet & dry vacuum to vacuum toxic, hazardous or flammable substances/liquids.
N.B. DoNOT use thecartridge filter or dust bag when wet vacuuming.

10
ENGLISH
1
6
2
7
3 4 5
1 2 3 4
1. Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
2. Screw thesilencer (Q) loose from themotor exhaust/blowing port (6) and attach thesuction hose (B),
bypressing it in and turning it clockwise until thesuction hose sits securely.
3. Attach theaccessory of your choice to thehose.
4. Set thepower switch (9) to the0=OFF position.
5. Connect theplug to awall socket.
6. Hold thehose and point thenozzle in thedesired direction. Startthemotor by switching thepower
switch(9) to the1=ON position.
7. Turn off themotor by switching thepower switch to the0=OFF position when you are done.
Pulltheplugout.
7. Repair and maintenance
1. Warning! Alwaysmake sure theplug is disconnected before servicing or adjusting.
2. Remove thesuction hose.
3. Open theover-centre catch and remove themotor/top from thecontainer.
4. Clean thecontainer and hose and make sure that they are dry before putting thevacuum away for storage.
Replace or clean thefilters whenever needed. Makesure that thehose, filter, couplings and mains lead are
undamaged. Ifthemains lead is damaged, have it replaced by aprofessional.
6.3 Blow function
Warning! Useaface mask and safety glasses and keep onlookers and pets at asafe distance.
