PARTS MANUAL
MAN C100578 Rev. B 09-2013
HYDRO-DRIVE SOD CUTTER
OPERATORS MANUAL C100579
MODELS:
SCHV-18/5.5E
SCHV-18/8.0E

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its
constituents are known to the State of
California to cause cancer, birth defects
and other reproductive harm.
WARNING
The engine exhaust from this product
containschemicalsknowntotheState
of California to cause cancer, birth
defects or other reproductive harm.
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, wiring
insulation, and related accessories
contain lead and lead compounds,
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
WASH HANDS AFTER HANDLING.

1
HYDRO
SOD CUTTER
IMPORTANT MESSAGE
Thank you for purchasing this Classen product. You have purchased a world class product, one of the best
designed and built anywhere.
This product comes with Parts and Operator's Manuals. The useful life and good service you receive from this
product depends to a large extent on how well you read and understand this manual. Treat this product properly
and adjust it as instructed, and it will give you many years of reliable service.
See a Classen dealer for any service or parts needed. Classen service ensures that you continue to receive
the best results possible from Classen products. You can trust Classen replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Classen designs and builds its equipment to serve many years in a safe and productive manner. Forlongest life,
use this product only as directed in the manual, keep it in good repair and follow safety warnings and instruc-
tions. You'll always be glad you did.
Classen
1028 Street Road
Southampton, PA 18966
8-2012
TABLE OF CONTENTS FIGURES PAGE
SAFETY........................................................................................................................................................2, 3
SET-UP, MAINTENANCE.................................................................................................................................4
STORAGE........................................................................................................................................................5
SPECIFICATIONS............................................................................................................................................6
PARTS SECTION.............................................................................................................................................7
MAIN FRAME ASSEMBLY..................................FIGURE 1.......................................................................8, 9
HANDLE ASSEMBLY..........................................FIGURE 2...................................................................10, 11
CUTTER ASSEMBLY..........................................FIGURE 3...................................................................12, 13
POWER TRAIN ASSEMBLY...............................FIGURE 4...................................................................14, 15
CE KITS..........................................................................................................................................................16

2
HYDRO
SOD CUTTER
NOTICE !!!
Unauthorized modications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Classenstronglywarnsagainst,rejectsanddisclaims
any modications, add-on accessories or product
alterationsthat arenotdesigned,developed, tested
andapprovedbyClassenEngineeringDepartment.
Any Classen product that is altered, modied or
changed in any manner not specically authorized
after original manufacture–including the addition of
“after-market” accessories or component parts not
specically approved by Classen–will result in the
Classen Warranty being voided.
Anyandallliabilityforpersonalinjuryand/orproperty
damage caused by any unauthorized modications,
add-on accessories or products not approved by
Classen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Classen will vigorously
pursue full indemnication and costs from any party
responsibleforsuchunauthorizedpost-manufacture
modications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word denitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manualandonthesafetylabelsattachedtoClassen
machines. For your safety and the safety of others,
read and follow the information given with these
signal words and/or the symbol shown above.
DANGER indicates an imminently hazardous
situationwhich, ifnot avoided,WILLresult indeath
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTIONindicatesapotentiallyhazardoussituation
which,ifnotavoided,MAY resultinminorormoderate
injury. It may also be used to alert against unsafe
practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage
MODEL NUMBER: This number appears on
sales literature, technical manuals and price lists.
SERIAL NUMBER: This number appears only
on your machine. It contains the model number
followed consecutively by the serial number.
Use this number when ordering parts or seeking
warranty information.
SAFETY

3
HYDRO
SOD CUTTER
SAFETY
MAINTENANCE SAFETY
In general
• Maintain machine according to manufacturer's
schedule and instructions for maximum safety
and best results.
• Park machine on level ground.
• Never allow untrained personnel to service ma-
chine.
• Guards should only be removed by qualied
maintenance technician for maintenance/service.
Replace when work is complete.
• Adjust or repair only after the engine has been
stopped and the blade has stopped moving.
• Disconnect spark plug wire(s) before doing any
maintenance.
• Replace parts if worn, damaged or faulty. For best
results, always replace with parts recommended
by the manufacturer.
• Do not dismantle the machine without releasing or
restraining forces which may cause parts to move
suddenly.
• Provide adequate support, e.g. jack stands for
lifted machine or parts if working beneath.
• Do not put hands or feet near or under
rotating parts.
• Clean up spilled oil or fuel thoroughly.
• Replace faulty mufers.
• To reduce re hazards, keep the engine, mufer,
and fuel storage area free of grass, leaves, debris
buildup or grease.
Blades
The sod cutter blade is sharp
and can cut. Use extra caution
when handling. Remove ob-
structions with care. Wrap the
blade or wear gloves.
• Only replace blade. Never
straighten or weld.
• Keep other persons away from blades.
Fuel
• Petrol (gasoline) and diesel
fuels
are ammable; petrol
(gasoline) vapors are
explosive. Use extra care
when handling.
• Store only in containers specically designed for
fuel.
• When refueling or checking fuel level:
• Stop the engine and allow to cool;
• Do not smoke;
• Refuel outdoors only;
• Use a funnel;
• Do not overll;
• If fuel is spilled, do not attempt to start the
engine until the spill is cleaned up and vapors
have cleared.
• Replace caps on fuel containers and tanks
securely.
Sparks from static electricity can start res or cause
explosions. Flowing fuel can generate static electricity.
To prevent static electricity sparks:
• Keep fuel containers electrically grounded. Do not
ll containers in a vehicle or on a truck or trailer
bed with a plastic liner. Fill containers on the
ground away from the vehicle.
• When practical, remove petrol (gas) powered
equipment from the truck or trailer and refuel it on
the ground. If equipment must be refueled on the
truck or trailer, refuel from a portable container
rather than a dispenser nozzle.
• Keep the dispenser nozzle in contact with the rim
of the fuel tank or container opening until fueling is
complete. Do not use a nozzle lock-open device.
Storage Safety
• Stop the engine and allow to cool before storing.
• Drain the fuel tank outdoors only.
• Store fuel in an approved container in a cool, dry
place.
• Keep the machine and fuel containers in a locked
storage place to prevent tampering and to keep
children from playing with them.
• Do not store the machine or fuel container near
heating appliances with an open ame, such as a
water heater, or an appliance with a pilot light.
• Keep gasoline (petrol) storage area free of grass,
leaves and excessive grease to reduce re haz-
ard.
• Clean grass and debris from cutting units, drives,
mufers and engine to help prevent res.
!
WARNING
!
WARNING

4
HYDRO
SOD CUTTER
SET UP/ MAINTENANCE
SET UP INSTRUCTIONS
To prevent injury, wear appropriate eye protection and
stand clear when cutting banding. Banding is under
tension and may snap back when cut.
1. Remove box top, sleeve and unit.
Remove the banding attaching the sod cutter to
the pallet.
2. Roll the sod cutter off the pallet.
3. Dispose of pallet, box, and banding in a respon-
sible manner.
GENERAL MAINTENANCE
To keep the sod cutter in good operating condition,
perform the following:
• Keep blade sharp; a sharp blade cuts cleaner,
faster and more uniformly and places less load
on the machine. Sharpen cutting edge on bevel
or top side only.
• Keep drive belt at proper tension and free of oil
and dirt at all times.
• Check engine oil level and air lter element daily.
• Check for loose bolts and connections.
• All grease ttings are pressurized type. Use a
good grade Lithium Base Grease or equivalent.
Grease eccentric arms sparingly every 4 hours
of service, all others daily. Wipe off all grease
ttings before and after each greasing (there
are a total of 8 grease ttings).
• To make sure the chain on the front drive wheels
is tight, you will need to remove the chain
guard to check this. If tightening is required,
loosen nuts and bolts on the 3/4” pillow block
bearings and push the bearings toward the
back of the sod cutter until chain is tight. Make
sure both bearings go back evenly to keep
jackshaft running even with the frame. After do-
ing this, retighten nuts and bolts on the bearing
and replace the chain guard.
• Engine (refer to manufacturer's owner’s manual).
Engine Oil Level Check
1. BEFORE CHECKING OIL:
• make certain the engine is level
• the engine switch is in the OFF position
• the sod cutter blade is NOT engaged
• the drive wheels are disengaged.
2. Remove the ller cap/dipstick and wipe it clean.
3. Insert and remove the dipstick without screwing
it into the ller neck. Check the oil level shown on
the dipstick.
4. If the oil level is low, ll to the edge of the
oil ller hole with the recommended oil.
SAE 10W-30 is recommended for general use.
Refer to engine oil recommendations in engine
manual for other viscosities and information.
5. Screw in the ller cap/dipstick securely.
Transmission (Gearbox) Oil Level Check
(This unit is bolted to the engine)
1. Check the transmission oil level with the engine
stopped and in a level position.
2. Remove the ller cap/dipstick and wipe it clean.
3. Insert and remove the dipstick without screwing
it into the ller hole. Check the oil level shown on
the dipstick.
4. If the oil level is low, add oil to reach the upper
limit mark on the dipstick. Use the same oil that is
recommended for the engine, SAE 10W-30.
5. Screw in the ller cap/dipstick securely.
Hydro Drive Oil Level Check
1. Check the Hydro Drive oil level with the engine
stopped and in a level postion.
2. If the oil level is low, add oil to reach the upper
limit mark. Use SAE 20W50 oil.

5
HYDRO
SOD CUTTER
STORAGE
STORAGE INSTRUCTIONS
WARNING
!
To prevent possible explosion or ignition of vapor-
ized fuel, do not store equipment with fuel in tank or
carburetor in enclosure with open ame (for example,
a furnace or water heater pilot light).
Daily Storage
1. Check engine oil level and air lter element daily.
2. Check oil level in gear case. Hydro gear uses
20W50 oil.
3. Close fuel valve at bottom of fuel tank.
4. Clean cutting blade (grass, dirt, etc.).
Extended Storage
Before the equipment is put into storage for any
period exceeding 30 days:
1. Drain all fuel from fuel tank and lines (use a
hose or fuel line, routed from fuel tank shut-off to
proper container).
2. Start engine and run until all fuel is used from
the carburetor oat bowl.
3. While engine is warm, check the transmission
oil and rell with the proper weight of oil corre-
sponding to the season when the equipment will
next be used.
4. Remove the spark plug and squirt a small quan-
tity of engine oil into the cylinder. Turn the engine
over a few times to distribute the oil.
5. Lubricate all lubrication ttings.
6. Clean and oil cutting blade to prevent rust.
To put equipment into operation after an
extended storage:
1. Fill fuel tank with clean fresh fuel.
2. Check crankcase oil level, and start engine.
3. Check fuel system for fuel leaks.
WARNING
!
When replacement parts are required, use genuine
Classen parts or parts with equivalent characteris-
tics, including type, strength and material. Failure to
do so may result in product malfunction and possible
injury to the operator and/or bystanders.
Carbon monoxide present in the exhaust is an odor-
less and deadly gas. Never start or run the engine
inside where exhaust fumes can collect. Provide
enough fresh air to keep fumes from getting too
strong.
Replace any warning decal that becomes illegible
immediately.

HYDRO
SOD CUTTER
SPECIFICATIONS
SCHV-18/8.0E - S/N: SV188E000101 & UP
ENGINE
Model.....................................4cycle 8 H. P. Honda
..........................................................Model GX240
.................................................14.8 cu. in. (242 cc)
Starter......................................................Recoil
Governor..........3400 RPM ± 200 RPM, no load
Clutch .............spring loaded belt tightener type
REDUCTION
Engine to blade.....................................3.03 to1
Engine to drive wheels ........................57.2 to 1
WHEELS:
Drive.......................8” (203 mm) Dia. w/knobby
......................................tread vulcanized to hub
Rear8 x 1.75 (203 X 45mm) semi-pneumatic tires
CUTTING WIDTH:
SCHV-18E....................................................18”
GEAR CASE
Lubrication............................EP 140 Gear lube
Capacity.................................... 31/2Pints(1.7L)
Cutting depth................................up to 2-1/2”
BLADE PITCH
Hand lever adjustment.............variable 0° to 9°
Blade speed ..1122 RPM @ 3400 engine RPM
DIMENSIONS
Width ............................................................23”
Length...........................................................59”
Height...........................................................35”
Wheel Base..................................................22”
WEIGHT
Dry Weights
SCHV-18/8E........................................355* Ibs.
* Add 12 Ibs. to each above weight for CE Guards

7
HYDRO
SOD CUTTER
PARTS SECTION
PARTS SECTION

8
HYDRO
SOD CUTTER
MAIN FRAME ASSEMBLY
FIGURE 1
6
9
1
23
3
9
7
7
11
13
14
15
30
20
31
7
20 19
9
10
35 34 36
9
9
7
4
5
12
8
17
9
18
19
18 19
18
22
26
14
27
9
2
8
9
24
31
25
33
24
20
20
37
32
29
19
20
21
20
18
17
18
16
19
20
10
10
10
10
10
98
41
42
40

9
HYDRO
SOD CUTTER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
MAIN FRAME ASSEMBLY
FIGURE 1
1 C400386 FRAME, SOD CUTTER 1
2 C400234 LARGE GUARD 1
3 C400267 INNER ENGINE GUARD, 5.5 HP 1
C400268 INNER ENGINE GUARD, 8.0 HP
4 C400387 TRANSMISION COVER, GEAR 1
5 C400248 CHAIN GUARD 1
6 C400247 SMALL GUARD 1
7 C500133 BOLT, 5/16-18 x 1 9
8 C500140 BOLT, 5/16-18 x 3/4 2
9 C500115 WASHER, 5/16 LOCK 16
10 C500083 WASHER, 5/16 FLAT 9
11 C500219 BOLT, 5-16-18 x 5 1
12 C500101 NUT, 5/16-18 1
13 C100017 TIRE & WHEELASSEMBLY, 9X350X4 1
14 C500016 PIN, 5/32” x 1-1/4” COTTER 2
15 C300002 PIN, AXLE 1
16 C500154 BOLT, 3/8-16 x 2-1/2 1
17 C500043 BOLT, 3/8-16 X 1 3
18 C500042 WASHER, 3/8” FLAT 10
19 C500130 WASHER, 3/8 LOCK 8
20 C500129 NUT, 3/8-16 8
21 C300004 CLIP, R.H. BELTADJUSTMENT 1
22 C400443 ARM, BLADE CLUTCH 1
23 C400237 BUMPER, 8.0 HP 1
24 C500134 BOLT, 3/8-16 x 1-1/4 3
25 C100021 BUSHING, BRASS 2
26 C500001 GREASE FITTING, 1/4 x 28 1
27 38010-2A IDLER PULLEY 1
28 64221-07 E-RING .375 1
29 C100501 VLIER PIN 1
30 C100010 PULLEY, IDLER 1
31 C500091 BOLT, 3/8-16 x 2 2
32 C400251 NUETRAL HANDLE 1
33 C500041 NUT, 3/8-16 LOCK 2
34 4170118 DECAL, CLASSEN 1
35 C100607 DECAL, 12º WARNING 1
36 C100096 DECAL, ALL GUARDS ETC. 1
37 C100556 DECAL, “SCHV-18” 2
38* C100504 SPRK ARRSTR DECAL 1
39* C100505 CARB APPROVAL DECAL 1
40 C100489 DECAL-HYDRO DRIVE 2
41 C100490 DECAL-HYDRO MAN ROLL 1
42 C100559 DECAL-LUBRICATE 1
43* C100506 DECAL-SERVICE BELTS CE 1
* NOT ILLUSTRATED

10
HYDRO
SOD CUTTER
HANDLE ASSEMBLY
FIGURE 2
23
29
27
26
17
20
25
6
18
7
5
12
21
8
11
14
10
9
1
2
22
35
3
30 14
15
15
6
10
10
10
15
6
13
15
12
13
33
23
1521
16
8
13
12
12
12
13
12
12
12
8
31
28 34
32
21
34
26
14
20
36
21
36 43
42
41
45
24
48
47
37
40
37
4
15
49
49
50
19
49
14
12
15
38
36 53

11
HYDRO
SOD CUTTER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
HANDLE ASSEMBLY
FIGURE 2
1 C400008 HANDLE, ENGAGEMENT 1
2 C400007 ARM, CUTTING BLADE ADJUST 1
3 C100546 RUBBER BUSHING 4
4 C400380 SCHV MAIN HANDLE 1
5 C400253 3/8" LINKAGE ARM, SCH 1
6 C500026 YOKE, 3/8 CLEVIS 3
7 C500065 SPRING, COMPRESSION 1
8 C500043 BOLT, 3/8-16 X 1 6
9 C500154 BOLT, 3/8-16 X 3-1/2 1
10 C500134 BOLT, 3/8-16 x 1-1/4 7
11 C500146 BOLT, 3/8-16 x 1-1/2 1
12 C500129 NUT, 3/8-16 15
13 C500041 NUT, 3/8-16 LOCK 4
14 C500042 WASHER, 3/8" FLAT 11
15 C500130 WASHER, 3/8 LOCK 15
16 C500133 BOLT, 5/16-18 x 1 7
17 64123-311 BLT-HEX 1/4-20X3-3/4 FLTHRD 1
18 C500132 BOLT, 1/2-13 x 4 1
19 C500183 BOLT, 1/4-20 x 2 1
20 C500136 NUT, 1/4-20 LOCK 3
21 C500101 NUT, 5/16-18 5
22 C100488 HYDRO SPEED DECAL 1
23 C100018 GRIP, L.H. HANDLE 2
24 C100486 THUMB THRTTL CNTRL 1
25 C500019 SPRING, SMALL HANDLE 1
26 C100007 GRIP, RUBBER 2
27 C400381 CONTROL LEVER 1
28 C100635 RUBBER BUSHING, TAPERED 1
29 C400382 SCHV MAIN CONTROL MOUNT 1
30 C400383 RUBBER MOUNTING BRCKT 1
31 C400384 SCHV HANDLE BRACE 1
32 C400410 T-BOLT HANDLE, ENHANCED 1
33 C500131 NUT, 1/2-13 LOCK 1
34 C500106 NUT, 1/2-13 2
35 C100134 DECAL, WHEEL DRIVE 1
36 C500137 LOCK WASHER 12
37 4162977-007 FUEL HOSE CUT 1/4" 2
38 C500115 WASHER, 5/16 LOCK 2
39* C100133 DECAL, SLOW FAST 1
40 C500139 1/4” NUT LOCK 2
41 C400270 GUARD-HANDLE 1
42 C500147 5/16” X 1-1/2” BOLT 4
43 C500029 BOLT-1/4 X 3/4 4
44* C100488 DECAL, HYDRO SPEED 1
45 C500088 WASHER, 1/4" FLAT 4
46 C500273 NUT-COUPLER 1/4 2
47 C400271 BRACKET-THROTTLE FRCTION 1
48 C500254 BOLT, 1/4 x 2-1/4 1
49 C500025 NUT, 3/8-24 3
50 C100508 DECAL, CONTROL PANEL 1
51 C100183 BOLT, 1/4-20 x 2 1
52* C100132 DECAL, CUTTER BLADE 1
53 C500068 NUT 1/4-20 NYLOC 2
* NOT ILLUSTRATED

12
HYDRO
SOD CUTTER
10
24
21
22
32
14
25
23 15
1
4
9
7
30
28
29
21
31 18 3
520
6
19
16
2
17
7
11
13
10
11
6
15
6
11
15
67
5
7
20
2
8
27
26
8
12
13
33
34
35
28
CUTTER ASSEMBLY
FIGURE 3

13
HYDRO
SOD CUTTER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
1 C500133 BOLT, 5/16-18 x 1 6
2 C500001 GREASE FITTING, 1/4 x 28 6
3 C500101 NUT, 5/16-18 6
4 C500115 WASHER, 5/16 LOCK 6
5 C100003 BEARING 6
6 C100001 WASHER, 3/4 NYLON 12
7 C100002 SEAL 12
8 C100007 GRIP, RUBBER 2
9 C100016 BLADE, 18" CUTTING 1
10 C800002 ARM, BLADE 2
11 C500006 WASHER, 1/2 LCOK 4
12 C500007 NUT, 1/2 HANDLE 1
13 C500034 WASHER, 1/2 FLAT 5
14 C500088 WASHER, 1/4" FLAT 1
15 C500106 NUT, 1/2-13 4
16 C500131 NUT, 1/2-13 LOCK 2
17 C500241 BOLT, 1/2-13 x 1 2
18 C500249 BOLT, FINE THREADED 2
19 C500152 BOTL, 1/2-13 X 2-3/4 2
20 C600001 STEEL SLEEVE 4
21 C400411 ARM, ECCENTRIC ENHANCED 2
22 C400444 WING NUT, DEPTH GAUGE 1
23 C200004 BOLT ,PITCH ADJUSTMENT 1
24 C200005 BOLT, HEIGHT ADJUSTMENT 1
25 C300039 PLATE, DEPTH GAUGE 1
26 C400001 BAR, HIEGHTADJUSTMENT 1
27 C400238 PITCH ADJUSTMENT BAR 1
28 C100626 WASHER, PLASTIC 1/4" ENHCD 4
29 C100625 BEARING, ENHANCED 2
30 C400412 WASHER, STEEL ENHANCED 2
31 C500272 WASHER, 1/2" EXT. TOOTH LOCK 2
32 C500137 WASHER, 1/4 LOCK 1
33 C500296 BOLT, 1/4 x 2-1/2 CARRIAGE 1
34 C500068 NUT, 1/4-20 NYLOC 1
35 C100507 DECAL. EU 2
* NOT ILLUSTRATED
CUTTER ASSEMBLY
FIGURE 3

14
HYDRO
SOD CUTTER
POWER TRAIN ASSEMBLY
FIGURE 4
57
58
40
24
34 38 9
12
11
37
10
3
13
36
26
17
16
23
2
47
8
18
5
7
6
42
22
29
20
21
1
19
4
28
43
25
14
35
41 8
15
7
28
31
31
32
32
33
39 49
49
50
50
50
51
51
51
52 48
56
45
44
43
22
21
21
21
18
30
52
53
56
59
54
55

15
HYDRO
SOD CUTTER
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
POWER TRAIN ASSEMBLY
FIGURE 4
1 C100493 SPROCKET, #40x54 w/ HUB 1
2 C700024 S-WHEEL, 8-5/8 DRIVE 4
3 C100005 ENGINE HONDA 5.5HP 1
C100114 ENGINE-HONDA 8HP
4 C300204 SPACER, 3/4" JACK SHAFT 1
5 C200056 S-SPROCKET W/ SHAFT1
6 C100491 B55 V-BELT FOR 5.5HP 1
C100503 B58 V-BELT FOR 8 HP
7 C500004 KEY, 1/4 x 1 SQUARE 3
8 C500011 KEY, 3/16 SQUARE X 1 1
9 C100339 RESERVOIR, HYDROSTAT 1
10 C500259 SET SCREW, 5/16-24 x 3/8 1
11 C400249 CLUTCH ARM, SCH 1
12 C400250 SHIFTER ARM, SCH 1
13 C100028 PULLEY W/HUB & BOLTS 1
14 C300001 SPACER, DRIVE SHAFT 1
15 C500029 BOLT, 1/4-20 x 3/4 2
16 C200001 SPROCKET W/HUB, DRIVE SHAFT1
17 4171051 SHAFT, 12" DRIVE 1
18 C100013 BEARING W/ ECCENTRIC, 3/4" 2
19 C600003 SC-18 1" ECENTRIC SHAFT 1
20 C200002 PULLEY W/HUB & BOLTS, 6" 1
21 C100004 BEARING W/ECCENTRIC, 1" 4
22 C100025 LINK, #40 CONNECTING 2
23 C500158 BOLT, 1/2-13 x 3-1/2 8
24 C100043 SPROCKET, #40x17x1/2 IDLER 1
25 C100494 #40 X 76 ROLLER & CON LINK 1
26 C100513 B38 V-BELT 1
27 C500001 GREASE FITTING, 1/4 x 28 4
28 C500003 KEY, 1/4 x 7/8 HALF MOON 2
29 C500181 KEY, 1/4 x 1-1/2 SQUARE 1
30 C500147 BOLT-5/16-18 X 1-1/2 4
(FOR 8HP MODELS)
C500079 BOLT,3/8-16 x 1-3/4
(FOR 5.5HP MODELS)
31 C500115 WASHER, 5/16 LOCK 8
32 C500101 NUT, 5/16-18 8
33 C500083 WASHER, 5/16 FLAT 4
34 C500131 NUT, 1/2-13 LOCK 1
35 C100433 RING, 1/2" SNAP 1
36 C200054 S-SHEAVE, 2BK62H BUSHING 1
37 C100311 HYDROSTAT 1
38 C500168 BOLT, 5-16-18 x 4-1/2 2
39 C500074 BOLT, 5/16-18 X 1-3/4 2
40 C200044 SPROCKET, 13 TOOTH 1
41 C500135 BOLT, 1/2-13 x 21/2 1
42 C100495 #40 X 50 ROLLERS & CON LINK 1
43 C700035 HUB, ECCENTRIC 2
44 C500136 NUT,1/4-20 2
45 C500137 WASHER, 1/4 LOCK 2
46* B222522 DEFLECTOR, EXHAUST 1
47 C500147 BOLT, 5/16-18 x 1-1/2 4
48 C500034 WASHER, 1/2 FLAT 18
49 C500174 BOLT, 1/2-13 x 1-3/4 8
50 C500006 WASHER, 1/2 LOCK 16
51 C500106 NUT, 1/2-13 16
52 C500115 WASHER, 5/16 LOCK 4
( FOR 5.5HP MODELS)
C500130 WASHER, 3/8 LOCK
(FOR 8HP MODELS
53 C500101 NUT-5/16-18 4
(FOR 5.5HP MODELS)
C500129 NUT, 3/8-16
(FOR 8HP MODELS)
54 C100027 SPRING, THROTTLE 1
55 C100492 SPRING, 3/8" PLUNGER 1
56 64163-67 WSHR-.516X1X12GA 8
57 C500274 SCREW, M5 X.8x1-1/8 PAN HEAD 2
58 C400322 GUARD, MUFFLER 5.5HP 1
(USED ON 5.5 HP MODELS)
C400323 GUARD, MUFFLER 8 HP
(USED ON 8HP MODELS)
59 C500036 KEY, 7MM SQUARE 1
*NOT ILLUSTRATED

16
HYDRO
SOD CUTTER
KITS
OPTIONAL KITS
(NOT SHOWN ON PARTS ILLUSTRATIONS)
KIT P/N DESCRIPTION
C100076 ELECTRICAL SHUT-OFF SWITCH & HARDWARE
C400037 SET OF 2 SIDE BUMPERS & HARDWARE

17
HYDRO
SOD CUTTER
NOTES

BOB-CAT BUNTON RYAN STEINER LITTLE WONDER
SCHILLER GROUNDS CARE, INC.
1028 Street Rd.
Southampton, PA 18966
1-800-366-6268
www.classenturfcare.com
Schiller Grounds Care, Inc.
1028 Street Road • Southampton, PA 18966
Telephone: [phone]
TWO YEAR LIMITED WARRANTY
EffectiveApril 1, 2007
For the period of two years from the date of purchase, SCHILLER GROUNDS CARE, INC. will repair or
replace for the original purchaser free of charge, any part or parts found upon the examination of our factory
authorized service station, or by the factory in Norfolk, Nebraska, to be defective in material or workmanship. All
transportation charges on parts submitted for repair or replacement under this warranty shall be borne by the
purchaser.
This warranty does not include engines or engine parts, tires, batteries, or gearboxes that are covered under
separate warranties furnished by their manufacturer or supplier, nor does it include normal maintenance parts,
including but not limited to, spark plugs, points, lters, blades, and lubricants.
All service under this warranty will be furnished or performed by our factory authorized service stations.
There is no other expressed warranty. Implied warranties, including those of merchantability and tness for a
particular purpose, are limited to two years from the date of purchase and to the extent permitted by law, any
and all implied warranties are excluded. The above remedy of repair and replacement of defective parts is
the purchaser’s exclusive remedy for any defect, malfunction or breach of warranty. Liability for incidental or
consequential damages under any and all warranties is excluded to the extent permitted by law.
NORMAL RESPONSIBILITIES OF THE SELLER AND THE USER
1. The Distributor or Dealer is responsible for the proper assembly and preparation of the product for
delivery to the end user.
2. The User is responsible for reading the Manual and Instructions.
3. The User is responsible for proper operation and maintenance as described in the manual.
4. The User is responsible for the replacement of wear items such as blades, belts, tires, batteries, etc.
5. The User is responsible for damage due to improper operation and maintenance, as well as abuse.
All claims must be received by the factory 30 days after the end of the warranty period to receive warranty consideration.
© 2010 Schiller Grounds Care, Inc. All Rights Reserved. 09/2012
