Clear Comfort CCW100 Instruction manual

WW
For further assistance contact us:
303.872.4477
[e-mail]
clearcomfort.com
IMPORTANT SAFETY INSTRUCTIONS
Clear Comfort’s CCW100
Pool & Spa System
Patented Hydroxyl-Based Advanced Oxidation (AOP)
Installation, Operations & Maintenance
Manual
V.13.0.30

For the latest version, please visit:
clearcomfort.com/ccw100-manual
MADE IN USA ©2020 Clear Comfort. All Rights Reserved.

Clear Comfort’s CCW100 System
Installation, Operations & Maintenance Manual
TABLE OF CONTENTS
303.872.4477 [e-mail] clearcomfort.com
WARRANTY ...................................................................................2
GENERAL INFORMATION.............................................................3
Important Safety Instructions ....................................................3
Electrical Safety......................................................................... 4
Grounding ................................................................................4
General Safety...........................................................................4
DESCRIPTION FOR STANDARD CLEAR COMFORT SYSTEMS...... 5
Key Features .............................................................................5
Operating Ranges .....................................................................5
Light Functionality..................................................................... 6
INSTALLING THE CLEAR COMFORT SYSTEM............................... 7
Standard Clear Comfort Installation Kit ...................................7
Recommended Materials and Tools........................................... 7
System Installation ....................................................................8
Electrical Installation - General..................................................8
Electrical Installation - Directly to Pump Circuit ........................9
Electrical Installation - Wall Outlet ............................................9
Cartridge Connection................................................................10
INSTALLING THE CLEAR COMFORT MANIFOLD INJECTION...... 11
Full System Diagram: Manifold Injection ..................................11
Manifold Installation .................................................................12
Connecting Clear Comfort System to Manifold Venturi ...........14
Air Flow Meter ..........................................................................16
Operating Instructions .............................................................17
FULL SYSTEM INTEGRATION DIAGRAMS ....................................18
Full System Diagram: Inline Chlorine Feeder.............................18
Full System Diagram: Ofine Chlorine Feeder ..........................18
Full System Diagram: Salt Water Chlorine Generator ...............19
Full System Diagram: UV System ............................................. 19
SYSTEM MAINTENANCE ..............................................................20
Cartridge Replacement ............................................................20
BASIC WATER CARE .....................................................................22
FREQUENTLY ASKED QUESTIONS............................................... 23
WIRING.......................................................................................... 24

303.872.4477 [e-mail] clearcomfort.com
2
Clear Comfort warrants all Equipment
to be free from defects in material
or workmanship under normal use
and service. Clear Comfort, Inc. at
its discretion may repair or replace
the Equipment or parts thereof. The
Company’s warranty does not cover
any Equipment that has been altered
or changed in any way by any person
not authorized by Clear Comfort, Inc..
THIS CONSTITUTES THE SOLE
WARRANTY MADE BY CLEAR
COMFORT, INC. EITHER EXPRESSED
OR IMPLIED. THERE ARE NO OTHER
WARRANTIES EXPRESSED OR
IMPLIED WHICH EXTEND BEYOND
THE FACE HEREOF, INCLUDING
THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
IN NO EVENT WILL CLEAR
COMFORT, INC. BE LIABLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND CUSTOMER’S
REMEDIES ARE LIMITED TO
REPAIR OR REPLACEMENT OF
NONCONFORMING CLEAR
COMFORT SYSTEMS OR PARTS.
This equipment was inspected before
shipment from our plant. To original
purchasers of this equipment, Clear
Comfort Water Inc.(“Clear Comfort”),
warrants its Clear Comfort Systems
to be free from defects in materials
and workmanship for a period of FIVE
(5) years from the date of purchase.
Replacement Cartridges and cylinders
are warranted for a period of ONE (1)
year from the date of purchase.
Parts which fail or become defective
during the warranty period, except
as a result of freezing, negligence,
improper installation, use, or care, shall
be repaired or replaced, at our option,
without charge, within 90 days of the
receipt of defective product, barring
unforeseen delays.
To obtain warranty replacements or
repair, defective components or parts
should be returned, transportation
paid, to the place of purchase, or to
the nearest authorized Clear Comfort
service center. For further Clear
Comfort dealer or service center
information, contact Clear Comfort
customer service department.
Clear Comfort shall not be responsible
for cartridge, removal and/or re-
installation labor or any other such
costs incurred in obtaining warranty
replacements.
The Clear Comfort Products warranty
does not apply to components
manufactured by others. For such
products, the warranty established by
the respective manufacturer will apply.
This warranty shall be voided if at any
time: (i) Customer attempts to make
any internal changes to any of the
components of the Equipment; (ii)
the power supplied to any part of the
Equipment exceeds the Equipment’s
operating parameters; (iii) any external
device attached by Customer creates
conditions exceeding the Equipment’s
operating parameters; (iv) the
Equipment is tampered with; or (v) the
serial number is covered, removed or
defaced. Clear Comfort, Inc. reserves
the right to seek damages if its system
is tampered with, reverse engineered,
or if Customer takes any other actions
to interfere with the operation or
integrity of the Clear Comfort system
To activate and validate your warranty,
you must submit your warranty
card or ll out our warranty form on
clearcomfort.com/warranty within 1 year
of your ship date from Clear Comfort.
CONTACT INFORMATION:
Tel: [phone]
Operations: [email protected]
clearcomfort.com
WARRANTY

303.872.4477 [e-mail] clearcomfort.com 3
GENERAL INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ AND FOLLOW ALL
INSTRUCTIONS.
2. For cord connected/convertible
units: DANGER – Risk of injury.
A. Replace damaged cord
immediately.
B. Do not bury cord.
C. Connect to a grounding
type receptacle only.
3. For all permanently connected
units intended for use on 15 or 20
ampere, 125V or 230V, single phase
branch circuits: WARNING – Risk
of Electric Shock. Connect only to a
branch
circuit protected by a ground-fault
circuit-interrupter (GFCI). Contact a
qualied electrician if you cannot verify
that the circuit is protected by a GFCI.
4. For all cord connected units other
than storable pool pumps: WARNING
– Risk of Electric Shock. Connect
only to a grounding type receptacle
protected by a ground-fault circuit
interrupter
(GFCI). Contact a qualied electrician if
you cannot verify that the receptacle is
protected by a GFCI.
5. For all permanently connected
units: WARNING – Risk of Electric
Shock. Connect only to a branch circuit
protected by a ground-fault circuit-
interrupter (GFCI). Contact a qualied
electrician if you cannot verify that the
receptacle is protected by a GFCI.
6. For units intended for above-
ground storable swimming pools: Do
not bury cord. Locate cord to minimize
abuse from lawn mowers, hedge
trimmers, and other equipment.
7. For all cord and plug connected
units: WARNING – To reduce the risk
of electric shock, replace damaged
cord immediately.
8. For units intended for above
ground storable swimming pools:
WARNING – To reduce the risk of
electric shock, do not use extension
cord to connect unit to electric supply;
provide a properly located outlet.
9. CAUTION: At low or no ow
conditions, gas may accumulate –
ensure system is off when backwashing
or when water is not being treated
to prevent an unsafe gas buildup.
Pressure switches, ow switches and
other safety equipment to prevent
unsafe gas buildup is recommended.
10. When the modied air is
introduced into the pool or spa
water via the existing plumbing,
the biocide is produced. Some of the
remaining activated atoms either keep
minerals dissolved in the water or
remove minerals that were previously
deposited.
11. This unit is to be installed in
accordance with the installation
instructions, the applicable plumbing
and building codes, the applicable
state and local laws and regulations,
and the requirements of the Authority
Having Jurisdiction.
12. When installing and using this
equipment, basic safety precautions
should always be followed including
the following.
13. WARNING - To reduce the risk of
injury, do not permit children to use
this product unless they are closely
supervised at all times.
14. WARNING - Do not sit or stand
on unit.
15. SAVE THESE INSTRUCTIONS.

303.872.4477 [e-mail] clearcomfort.com
4
GENERAL INFORMATION
ELECTRICAL SAFETY
• Do not service the machine
when the power is ON.
• The power supply wire gauge
and insulation must meet
the temperature and power
requirements.
• To avoid personal injury never
touch exposed electrical
connections or components
while the power is ON.
• Do not install/service the Clear
Comfort system if you or the
machine is standing in water
with the power ON.
• Protect the power cord from
being walked on or pinched,
particularly at plugs and the
point where they exit from the
system.
• The device must be properly
connected to the correct power
source (either 60Hz 120V or
230V) using the supplied power
cord in accordance with the
local electrical code. If possible
the unit should be hardwired to
the pump circuit and controlled
by the pump circuit (rather than
hardwiring, an appropriate 120V
or 230V receptacle outlet and
plug may be used to connect to
the pump controlled circuit).If
the unit is being wired to
standalone AC power (i.e., not
through the pump circuit on
either 120V or 230V) it should
be installed with its own timer
circuit and plugged in through
a Ground Fault Circuit Interrupt
(GFCI) and the timer should be
set to reect the pool or tub’s
hours of operation. Regardless
if hardwired or standalone
connected, the electrical
connection must be made
in accordance with the local
electrical code.
GROUNDING
The Clear Comfort, Inc. system
must be properly grounded. An
electrical ground connection to a
reliable earth ground is essential for
safe operation. Without an electrical
ground, all accessible conductive
components (including knobs and
controls that appear insulated) can
render an electrical shock.
GENERAL SAFETY
Use personal protective equipment
(steel toe shoes, hearing protection,
eye protection) when installing the
Clear Comfort system. Follow ladder
safety requirements.

303.872.4477 [e-mail] clearcomfort.com 5
KEY FEATURES
This manual describes how to install, operate and maintain the standard
Clear Comfort system. The Clear Comfort system can be installed in
a few hours with little or no disruption to the recirculation or electrical
systems. After the Clear Comfort system is installed, it is ready to start
treating the water immediately. The Clear Comfort system protects pool
or spa water (biocide, scale control and corrosion control) without the
harsh effects of salt chlorine, high cyanuric acid or high chlorine levels.
The pool or spa water still needs to be tested, as would be done with a
traditional treatment system.
OPERATING RANGES
Power: 120V or 230V receptacle with approximately 10 watts.
Ballast: 120V or 230V
Electrical Requirements: 120V, 60Hz
Electrical Rating: 120V, 60Hz, 1.0Amp or 230V, 60Hz, 0.5Amp
NOTE: CLEAR COMFORT SHOULD ONLY RUN WHEN THE PUMP IS
OPERATING
DESCRIPTION FOR STANDARD
CLEAR COMFORT SYSTEMS

303.872.4477 [e-mail] clearcomfort.com
6
DESCRIPTION FOR STANDARD
CLEAR COMFORT SYSTEMS
LIGHT FUNCTIONALITY
Green Light: System is on and operating properly.
Yellow Light: Cartridge Unit has reached 80 percent of its life expectancy
(8,000 hours) and it’s time to purchase a replacement cartridge.
To exchange your Cartridge Unit, please visit: clearcomfort.com/cartridge
Red Light: Cartridge Unit has reached its life expectancy and needs to be
replaced.
Blue Light: Operation light that should always be illuminated.
FRONT VIEW
Red LED
Yellow LED
Green LED
System Power
Switch
Control Unit Cartridge Unit
Figure 1: System Functions
Blue LED

303.872.4477 [e-mail] clearcomfort.com 7
Prior to installation, a site survey should be performed to validate that
the correct system parameters are in place and ready for installation. We
recommend that you maintain compliance within the following operating
ranges for well constructed and circulated pools.
• Pool volume: Up to 40,000 gallons.
• Type of pool/spa lter: Any ANSI 50 approved ltration.
• Type of pump: Variable speed pump is highly recommended.
• Voltage of power supply: 120V or 230V AC.
• Maximum distance from injection point: Air Tubing length
should be as short as possible with no more than 10 feet from the
system to the Manifold/Venturi injection location.
• Indoors or outdoors: Either is suitable. It is recommended to
install away from upward facing sprinklers.
• Water quality at installation: The water quality should be
balanced prior to installing the Clear Comfort system.
STANDARD CLEAR COMFORT INSTALLATION KIT
• Option 1: Manifold
• Option 2: Venturi
• Air Check Valve
• 10’ Air Tubing
• Flow Meter and Barbed Connector
• Conduit Connector
• Conduit Box and Lid
• 12” Conduit Tubing
RECOMMENDED MATERIALS AND TOOLS
• A power drill and proper hardware for mounting the Clear
Comfort system.
• Proper plumbing materials and tools for Manifold injection
installation.
INSTALLING THE CLEAR COMFORT SYSTEM

303.872.4477 [e-mail] clearcomfort.com
8
INSTALLING THE CLEAR COMFORT SYSTEM
SYSTEM INSTALLATION
1. Determine the best location to mount the Clear Comfort system.
Screw in the top mounting bracket rst, and then the bottom
mounting bracket of the Control Unit (orange unit). Mount the
Cartridge Unit (blue unit) by securely fastening the Cartridge Unit
to the Control Unit using side keyed brackets, and screw in the top
mounting bracket rst, and then the bottom mounting bracket.
2. System must be installed no more than 10 feet from injection
location.
3. Where possible, ensure system location is at least one (1) foot above
the water line of pool/spa and Manifold/Venturi injection site.
ELECTRICAL INSTALLATION - GENERAL
1. Follow all local and national electric codes.
2. Determine if the Clear Comfort system will be powered by 120V or
230V. NOTE: All units are factory set to 230V. If your system will be
powered by 230V, skip to Step 4.
3. Set the switch on the ballast
on the orange Control Unit:
Remove plug in the left side of
the Control Unit. With a small
screwdriver, slide the switch
in the appropriate direction
according to the label on the
Control Unit. Re-install the
plug. See Figure 2.
4. The Clear Comfort system
comes with a 12 inch section
of 1/2 inch exible conduit,
a water-tight conduit tting, and a conduit body that may be easily
converted into the shape preferred for the particular installation.
5. If 12 inches is too long, cut to the desired length. Slide the wires from
the Clear Comfort system through the conduit, insert the conduit into
the water tight connector on the Clear Comfort system, and tighten
down.
6. Congure the conduit body as needed for the installation into the
desired shape (LL, LB, LR, or C), and attach the water-tight conduit
tting to the body.
7. Slide the conduit and wire into the conduit body and tighten down
the water-tight connection.
Figure 2: Ballast Electrical Switch

303.872.4477 [e-mail] clearcomfort.com 9
8. Run wire (and conduit, if required by local code) from the pump
circuit to the conduit body using water-tight ttings.
9. Using appropriately sized wire nuts inside the conduit body, connect
the switched power to the Clear Comfort system.
NOTE: CLEAR COMFORT SHOULD ONLY RUN WHEN THE PUMP IS
OPERATING
ELECTRICAL INSTALLATION - DIRECTLY TO PUMP CIRCUIT
(RECOMMENDED)
1. Direct pump circuit connection is recommended. Unit should be
hardwired to the pump circuit and controlled by the pump circuit.
2. The device must be properly connected to the correct power source
(either 60Hz, 120V or 230V) using the supplied power cord, in
accordance with the local electrical code.
3. Remove protective ballast switch cover. Toggle ballast switch
between 120V and 230V to match required voltage. See Figure 2.
Ensure white marked saddle switch matches correct voltage.
4. If hard wired, cord supplied must be hard wired in accordance to the
National Electrical Code and in accordance with local regulations.
5. Test for proper grounding and secure connections.
NOTE: WIRE THE SYSTEM TO RUN ONLY WHEN THE PUMP IS
RUNNING
ELECTRICAL INSTALLATION - WALL OUTLET
1. If the unit is being wired to standalone 120V AC power (i.e., not
through the pump circuit), connect Clear Comfort system to the pool
timing clock so that the system operates simultaneously with pool
pump through a Ground Fault Circuit Interrupt (GFCI). In either case,
the electrical connection must be made in accordance with the local
electrical code.
2. Remove protective ballast switch cover. Toggle the ballast switch
between 120V and 230V to match required voltage. See Figure 2.
3. Test for proper grounding and secure connections.
On page 11, Figure 4 shows the preferred installation that uses a
Manifold injection.
INSTALLING THE CLEAR COMFORT SYSTEM

303.872.4477 [e-mail] clearcomfort.com
10
CARTRIDGE CONNECTION
Gently align the notched outdent on the front of the Cable Connector
with the keyed indent of the front of Cartridge Connector, as shown with
the arrow in Figure 3. Seat the Cable Connector down onto the Cartridge
Connector and turn the Cable Connector’s Collar a quarter-turn clockwise
to lock the Cable and Cartridge Connector together. If a strange light
pattern occurs, disconnect cable assembly and reconnect.
INSTALLING THE CLEAR COMFORT SYSTEM
9-Holed
Cable Connector
9-Pinned
Cartridge Connector
Cartridge Unit
Figure 3: Cartridge Connection
Collar

303.872.4477 [e-mail] clearcomfort.com 11
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION
Figure 4: Full System Diagram With Manifold Injection
NOTE: For full system diagrams that include additional sanitation
systems integrated with the Clear Comfort system,
see pages 18 and 19.
FULL SYSTEM DIAGRAM: MANIFOLD INJECTION
NOTE: The Manifold injection is the preferred CCW100 installation
method. For other U-bypass diagrams and instructions, please visit:
clearcomfort.com/residential-manual

303.872.4477 [e-mail] clearcomfort.com
12
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION
MANIFOLD INSTALLATION
(PREFERRED METHOD)
PLEASE NOTE: TURN MAIN POOL PUMP OFF AND SWITCH OFF
MAIN CIRCUIT BREAKER.
1. Pick a Location:
• Select a location to install Manifold, see Step 2 for proper water
ow conguration position.
• If retrotting, cut a 11” section of the main
2. Select Orientation
The 3-way valve unions allow you to install the Manifold either left-to-
right or right-to-left to match your water ow congurations.
• If the water ow is going in the direction of the arrow on the
Manifold, skip to Step 4.
• If the water ow is not going in the direction of the arrow on the
Manifold, proceed to Step 3.
Figure 5: Manifold Location
Figure 6: Manifold Orientation

303.872.4477 [e-mail] clearcomfort.com 13
3. Reverse 3-Way Valve (If Needed)
• Arrange 3-way valve by removing all three unions, as seen below.
• Once you have the 3-way valve facing the correct direction,
connect the it to the Manifold by attaching all three unions.
4. Connect to Pool Plumbing
Put the Manifold into the 11” cut section of the pool plumbing.
5. Position 3-Way Valve
• Position the 3-way valve handle in between
the Venturi & water out ow, as highlighted
in Figure 9.
• Make adjustments, as necessary to set
Venturi air suction to draw between
5 - 7 LPM using a Flow Meter. See
page 16 for detailed instructions.
NOTE: Failure to properly position the 3-way
valve can result in an unwanted back-ow of
water into the Clear Comfort system and other
negative effects.
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION
Figure 7: Manifold Reverse
Figure 8: Connecting Manifold
Figure 9: 3-Way Valve

303.872.4477 [e-mail] clearcomfort.com
14
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION
CONNECTING CLEAR COMFORT SYSTEM TO MANIFOLD VENTURI
Figure 10: Venturi Connection
Water
Flow
Figure 11: One-Way Air Check Valve
From CCW100 System To Venturi

303.872.4477 [e-mail] clearcomfort.com 15
1. Run provided 1⁄4-inch tubing from the Manifold injection port to
the straight barb tting. Length of tube should be less than 10 feet.
Shorten and cut tubing as possible. See Figure 10.
2. If the unit is installed below the water line, install a loop in the 1⁄4-
inch line known as a Hartford loop. Loop the Air Tubing so that at
some point, tubing is above water level.
3. Install 1⁄4-inch one-way Air Check Valve (supplied) to eliminate any
potential water back ow. See Figure 10 and 11 for details.
4. Gas exiting the Clear Comfort system to the Venturi connector port
should ow easily.
5. Measure air suction using an Air Flow Meter and set Venturi air
suction to draw between 5 - 7 LPM. See page 16 for detailed
instructions.
CONNECTING CLEAR COMFORT SYSTEM TO MANIFOLD VENTURI
Figure 12: Hartford Loop Figure 13: Manifold’s 3-Way Valve
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION

303.872.4477 [e-mail] clearcomfort.com
16
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION
AIR FLOW METER
1. Determine your variable speed setting and run your pump (2,400
RPM or higher).
2. Disconnect the blue Air Tubing from the Check Valve (between the
Manifold and Check Valve)
3. Connect blue Air Tubing to the Flow Meter.
4. Adjust the Manifold’s 3-way valve to increase/decrease pressure until
the Flow Meter reads 5 - 7 LPM. Note: If RPM on variable speed
pump is altered, readjust air suction.
5. When adjusted to 5 - 7 LPM, disconnect the ow meter and
reconnect Air Tubing to the Check Valve. .
Figure 15: Adjusting 3-Way Valve
Water Out Water In
5 - 7
LPM
From CCW100 System To Venturi
From CCW100 System To Venturi
Figure 14: Air Flow Meter

303.872.4477 [e-mail] clearcomfort.com 17
OPERATING INSTRUCTIONS
1. Install plumbing according to Figure 4.
2. Ensure the Manifold’s 3-way valve is OPEN before turning pumps ON.
3. Turn pool/spa pump and ltration systems on.
4. Position the Manifold’s 3- Way Valve
• Position the 3-way valve handle in between the Venturi & water out
ow, as highlighted in Figure 9.
• Make adjustments, as necessary to set Venturi air suction to draw
between 5 - 7 LPM using a Flow Meter. See page 16 for
detailed instructions.
5. Toggle Clear Comfort system switch to the ON position.
6. Water entering the pool/spa should have bubbles exiting from at least
one of the returns on to the body of water.
INSTALLING THE CLEAR COMFORT
MANIFOLD INJECTION

303.872.4477 [e-mail] clearcomfort.com
18
FULL SYSTEM INTEGRATION DIAGRAMS
FULL SYSTEM DIAGRAM: INLINE CHLORINE FEEDER
Figure 16: Inline Chlorine Feeder
FULL SYSTEM DIAGRAM: OFFLINE CHLORINE FEEDER
Figure 17: Ofine Chlorine Feeder
