ClearSounds Quattro 4.0 User manual

QUATTRO 4.0
AMPLIFIED BLUETOOTH NECKLOOP
USER GUIDE
Moving Beyond the Sound Barrier

Thank you for purchasing the ClearSounds Quattro 4.0 Amplified Bluetooth
Communication System. You are either really smart for purchasing the Quattro 4.0 or
someone really likes you and bought this for you. Or maybe you are both smart AND lucky
to have someone who gave you the Quattro 4.0. Either way, nicely done.
The Quattro 4.0 is an innovative Bluetooth Communication System. Bluetooth is a
technology that uses radio transmissions to exchange data between devices over short
distances. It offers an array of features that will connect you to your mobile phone so you
can actually hear the conversations clearly, connect you to your music & TV; bringing
the joy of entertainment back. It will allow you stress-free meetings & one-on-one
conversations by bringing sound directly to your ears, significantly reducing
background noise.
With all this awesomeness comes some new technology that may require a learning
curve. Have no fear; our remarkably patient & passionate team of Customer Solutions
Consultants are here to help. In addition, we have created a pictorial Quick Start Guide
to get you up & running quickly. And that’s not all! We have developed a series of
instructional videos for those of you who really don’t like manuals.
Welcome
1

The following precautions are the kind of boring but important information you
should read to ensure maximum performance and safety when using the Quattro
4.0. Although it may seem fairly obvious that standing outside in a lightning storm
wearing an electronic device is not wise, we do have to officially advise you that it’s
not a good idea to do that-- along with these other nuggets of wisdom.
Warnings
Warnings must be observed to prevent bodily injury.
WARNING: Use the equipment only in the described manner to avoid bodily injury or
damage to the equipment.
WARNING: Locate and use the Quattro 4.0 away from water and damp areas, such
as swimming pools, bathtubs, sinks and damp basements, and do not use the
Quattro 4.0 when you are wet, to avoid electrical shock.
WARNING: Do not overload extension cords or power strips. This can result in
electric shock.
WARNING: Avoid using the Quattro 4.0 during an electrical storm. There is a slight
risk of electrical shock from lightning during a storm.
Contact Information
Please contact us with any questions that you might have. We are happy to assist you!
ClearSounds Communications, Inc.
1743 Quincy Avenue, Suite 155
Naperville, IL 60540 USA
800-965-9043 (toll-free)
Information Online
To view & print additional
copies of this manual,
quick-start guide or
spec sheet or to view
instructional videos,
please visit the Support
section on our website.
www.clearsounds.com
Welcome
2
Safety Precautions
3

Cautions
Cautions indicate practices that could harm the Quattro 4.0 or other objects.
CAUTION: Some electronic devices that are not properly shielded will generate
electromagnetic interference (EMI) that may cause buzzing or odd sounds in the
Quattro 4.0 (or any headset for that matter). Examples include PCs, automobiles
and large screen TVs.
CAUTION: Turn off the Quattro 4.0 in any facility where posted notices instruct
you to do so. Hospitals or health care facilities might include equipment that is
sensitive to external radio frequency (RF) energy that can cause electromagnetic
interference (EMI).
CAUTION: While onboard aircraft, turn off the Quattro 4.0 in accordance with
airline regulations and crew instructions.
CAUTION: If you use any personal medical device, consult the manufacturer
of the device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
CAUTION: Avoid dropping the Quattro 4.0.
WARNING: Use the Quattro 4.0 only with the supplied AC power adapter assembly.
Other types of power adapter assemblies can damage the Quattro 4.0 and cause
personal injury.
WARNING: The Quattro 4.0 can amplify volume which can cause hearing loss. Instruct
each user of proper usage, adjust the volume to each user’s personal preference and
adjust the volume to low when not in use.
WARNING: Do not spill liquid on the Quattro 4.0 or clean it while it is plugged in to AC
power. This can cause a short circuit, a fire or electric shock.
WARNING: Do not push any type of object into the Quattro 4.0. Contact with
dangerous voltage points can occur, resulting in fire, electric shock or parts damage.
WARNING: Do not disassemble the Quattro 4.0. Dangerous voltage or other risks can
occur. Use after incorrect reassembly can lead to electric shock.
WARNING: Keep the Quattro 4.0 out of reach of small children.
WARNING: The Quattro 4.0 contains a magnet in the body of the unit. This may affect
pacemakers. If you wear a pacemaker, please check with your instrument provider to
verify if the Quattro 4.0 will affect your pacemaker.
Safety Precautions
4
Safety Precautions
5

CAUTION: Do not expose the Quattro 4.0 to excessive moisture, including sweat,
humidity or steam.
CAUTION: Store the Quattro 4.0 in a dry place, and if you do not use it for an extended
length of time, remove the batteries.
CAUTION: Connect the supplied AC power adapter assembly into a surge protector.
Power surges can damage the equipment.
CAUTION: Use only a cloth slightly dampened in a mild soap and water solution to
clean the unit. Do not use harsh chemical or solvent cleaners or abrasive detergents.
CAUTION: In these circumstances, refer to our customer service department:
• Liquid spills in the Quattro 4.0, or it is exposed to rain or precipitation.
• The Quattro 4.0 does not operate according to descriptions in this manual,
or performance distinctly changes.
• The Quattro 4.0 is dropped or the casing is damaged.
Safety Precautions
6
Unpack ...................................................................................................................9
Getting Familiar ...................................................................................................10
Getting Started .....................................................................................................14
Engage the Battery ...........................................................................................15
Charge the Battery ...........................................................................................16
Pairing & Connecting........................................................................................17
Breaking the Bluetooth Connection..................................................................20
Operating the Quattro 4.0.....................................................................................22
Hearing through the Quattro 4.0.......................................................................22
Voice Control.....................................................................................................23
Calling...............................................................................................................24
Call Waiting.......................................................................................................28
Caller ID List.....................................................................................................30
QT4 Mic.................................................................................................................32
Breaking Mic Connection..................................................................................35
Reconnecting Mic Connection...........................................................................36
Listen to Audio ..................................................................................................40
Contents
7

Loop and loop
adjustment toggle
QT4 Mic
USB charging
cable
AC adapter Lanyard
SmartSound
Ear buds (RS065T)
Intercom Feature ..............................................................................................41
Resetting the Quattro 4.0 ..................................................................................43
Troubleshooting ...................................................................................................44
Power and Connection......................................................................................44
Sound................................................................................................................46
Warranty ..........................................................................................................48
Additional Products ..........................................................................................50
Bluetooth Terms...................................................................................................51
Contents
8
Unpack
Ensure that your packing box includes all of these parts. If any parts are missing
or damaged, please contact your vendor or ClearSounds.
IMPORTANT: YOUR RECEIPT IS REQUIRED FOR WARRANTY. PLEASE RETAIN
YOUR RECEIPT.
Contents
9
Quattro 4.0
neckloop
Mic Clip
Cord Clips

Earbud Jack: This jack accepts any
3.5mm audio-only headsets. We
package the Quattro 4.0 with our
patented SmartSound Ear buds.
MFB Base Multi-Function Button: This
button is used to initiate & answer calls, turn
the Quattro on & off, activate the LCD screen,
pair the Quattro 4.0 to Bluetooth devices (e.g.
mobile phone), switch between calls and
initiate Siri or S-Voice for voice activation.
Charge indicator:
The screen will read
“charging” while the
Quattro 4.0 charges.
Charging port: This is where you
plug the micro USB charging cable
into the Quattro 4.0.
Getting Familiar
10
Getting Familiar
11
8-wire Neckloop: This
cord hangs the Quattro
4.0 around your neck like
a necklace. This is an
8-wire loop that connects
to hearing aids with t-coils,
delivering sound directly
through the hearing aids
when they are in t-mode.
MMFB Microphone Multi-Function
Button: This button is used to pair and
connect the QT4 Mic to the Quattro 4.0
unit and adjust the sensitivity level of
the QT4 Mic.
Charging Pegs: These
pegs fit into the charging
contacts (dimples) on the
QT4 Mic clip.
QT4 Mic: This entire disc is the powerful Bluetooth
microphone. It magnetically connects to the mic clip,
which is also used to charge the QT4 mic.

Battery Engage Switches: There is a battery engage switch on both the QT4 Mic
and the Quattro 4.0 unit, which MUST be in the +position on both for it to function.
By switching to the – position, the battery is disengaged from the circuit. This
switch does NOT need to be put in the –position; its purpose was only to protect
the integrity of the battery during storage.
Home Screen: The screen
displays the following
information and more:
a) Devices connected to
the Quattro 4.0
b) Headphones plugged
into the Quattro 4.0
c) Battery charge level
The Home Screen display re-
mains active for approximately
8 seconds, then goes dark.
To re-activate the screen,
simply tap the Touch
Function Key (TFK).
Main Base Unit TFK Touch Function
Key: This touch sensor
is used to answer & end
phone calls. It activates
the LCD screen to view,
and pauses & plays mu-
sic. Tap twice to active
the voice control for the
second device. -- See
page 23, Step 1 of Voice
control.
Volume & Scroll Touch
Keys: These keys are
used to turn the volume
up & down, scroll
through the menu, or
skip forward & backward
when listening to music.
Battery Engagement + / -
Getting Familiar
12 13

Before using your Quattro 4.0 for the first time, there are four key steps you
need to take to get started.
1. Engage the Battery on both the Quattro 4.0 unit and the QT4 Mic.
2. Charge the Quattro 4.0 and the QT4 Mic.
3. Pair the Quattro 4.0 with your Bluetooth devices.
4. Connect the Quattro 4.0 to your devices paired.
(max. 2 at a time).
In the following pages, we will walk you through each step in this order. At the
back of the manual, you will find a glossary of key terms we use.
It would be a good idea to get familiar with these terms as it will make setting
up and using your Quattro 4.0 much easier. Plus, throwing out some of these
words will make you sound really smart at your next party.
Getting Started
14
Engage the Battery +/-
On the back of both the Quattro 4.0 unit and the QT4 Mic,
there is a small switch labeled +/- . Using a paperclip or pen tip,
move the switch to the + position. This is the only time you
will ever need to touch this switch.
In order to preserve the integrity of the battery while the Quattro 4.0 travels from
the production line to our warehouses and the warehouse of retailers across the
country, we protect it by keeping the battery disengaged.
Similar to the battery pull tab you might see on a new toy or hearing aid
batteries in their packaging, once you remove the tab, the battery becomes
engaged. You will only need to do this once; this is NOT an on/off switch.
Getting Started
15

Charging will display on the screen and the indicator
light will be red on the QT4 Mic.
The Quattro 4.0 is fully charged when the indicator light
turns blue and 100% Charged displays on the
screen. The battery icon will show full.
Charge your Quattro 4.0 every night for
maximum performance.
To protect your Quattro 4.0 from power
surges while charging, plug into a surge
protector.
Pairing & Connecting
About Pairing: Now that you have the Quattro 4.0 fully charged, it’s time to pair
it to your Bluetooth devices. The first time you use a Bluetooth device with the
Quattro 4.0, you must pair the device with the Quattro 4.0. Pairing is the process
of creating a constant link between the Quattro 4.0 and the Bluetooth device.
Think of it like square dancing in junior high school gym class; The teacher first
“pairs” you with a dance partner, you’re not dancing yet; you’re just standing
there “paired” together.
Charge the Battery
1. Connect the small
USB connector end of
the charging cable to
the Quattro 4.0. Connect
the large USB connector
end to the AC adapter.**
2. Connect the QT4 Mic to
the mic clip. Connect the
small USB connector end
of the charging cable to
the mic clip.***
3. Plug the AC adapter
into a wall outlet or
surge protector.
** You can also charge the Quattro 4.0 by plugging the large USB connector end into the USB port on
your desktop or laptop computer. Make sure the computer is plugged into a power source.
*** If you would like to charge your QT4 Mic and Quattro 4.0 at the same time, connect the QT4 Mic to the
back of the Quattro 4.0 by lining up the pegs and dimples.
Getting Started
16
Getting Started
17
Æ
