ClearSpan Cedar 8' Wide End Frame Kit User manual

1
CLEARSPAN™END FRAME KIT
Revision date: 05.18.10
©2010 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
ClearSpan™
Cedar 8' Wide End Frame Kit
Photo may show a different but similar model.
STK # WIDTH
105363 8'

CLEARSPAN™END FRAME KIT
2Revision date: 05.18.10
YOU MUST READ THIS DOCUMENT BEFORE YOU
BEGIN TO ASSEMBLE THE SHELTER.
Thank you for purchasing this ClearSpan™ End Frame Kit.
When properly assembled and maintained, this product will
provide years of reliable service. These instructions include
helpful hints and important information needed to safely
assemble and properly maintain the end frame. Please
read these instructions before you begin.
If you have any questions during the assembly, contact
Customer Service for assistance.
SAFETY PRECAUTIONS
• Wear eye protection.
• Wear head protection.
• Wear gloves when handling the materials.
• Use a portable GFCI (Ground Fault Circuit Interrupter)
when working with power tools and cords.
• Do not climb on the shelter or framing during or after
construction.
• Do not occupy the shelter during high winds,
tornadoes, or hurricanes.
• Provide adequate ventilation if the structure is
enclosed.
• Do not store hazardous materials in the shelter.
• Provide proper ingress and egress to prevent
entrapment.
WARNING: The individuals assembling this structure
are responsible for designing and furnishing all
temporary bracing, shoring and support needed during
the assembly process. For safety reasons, those who
are not familiar with recognized construction methods
and techniques must seek the help of a qualified
contractor.
REQUIRED TOOLS
The following list identifies the main tools needed to
assemble the end frame. Additional tools and supports may
be needed depending on the structure, location, and
application.
• Tape measure or measuring device
• Variable speed drill and impact driver (cordless with
extra batteries works best)
• Wrenches and impact socket set, or an adjustable
wrench
• Scissors or utility knife
• Hammers and gloves
• Ladders, work platforms, and other machinery for lifting
designed to work safely at the height of the building
and end frame.
ASSEMBLY PROCEDURE
Following the instructions as presented will help ensure the
proper assembly of your end frame. The steps outlining the
assembly are as follows:
1. Verify that all parts are included in the shipment. Notify
Customer Service for questions or concerns.
2. Read these instructions and all additional
documentation included with the shipment before you
begin.
3. Gather the tools, bracing, ladders (and lifts), and
assistants needed for assembly.
4. Check the weather before you install the film (if
equipped). Do not install covers or panels on a windy
or stormy day.
5. Assemble the end frame.
6. Read the care and maintenance information.
7. Complete and return all warranty information (if
included) as instructed.

3
CLEARSPAN™END FRAME KIT
Revision date: 05.18.10
UNPACK AND IDENTIFY PARTS
The following steps will ensure that you have all the
necessary parts before you begin to assemble the end
frame.
1. Unpack the contents of the shipment and place where
you can easily inventory the parts. Refer to the Bill of
Materials/Spec Sheets.
2. Verify that all parts listed on the Bill of Materials/Spec
Sheets are present. If anything is missing or you have
questions, consult the Pictorial Parts Guide and all
shelter diagrams for clarification, or contact Customer
Service.
NOTE: At this time, you do not need to open the plastic
bags containing smaller parts such as fasteners and
clamps.
SHELTER CARE AND MAINTENANCE
Proper care and maintenance of your ClearSpan™ building
is important. Check the following items periodically to
properly maintain your building:
• Regularly check the main cover and end panels to see
that these remain tight and in proper repair.
• Frequently check the anchoring system and all
components. Replace worn or damaged parts
immediately.
• Check all fasteners frequently to verify that these
remain tight and in good repair.
• Do not climb or stand on the building or frame at
anytime.
• Remove debris and objects that may accumulate on
the shelter. Use tools that will not damage the cover
when removing debris.
• Remove snow to prevent excess accumulation. Use
tools that will not damage the cover when removing
snow. Never allow snow to accumulate on the main
cover or to remain against the sides or end panels after
it is removed from the main cover.
• Check the contents of the shelter to verify that
nothing is touching the cover or panels that could
cause damage.
• Replace all worn or damaged parts.
• For replacement or missing parts, call 1-800-245-9881
for assistance.
NOTE: With the exception of Truss Arch buildings,
ClearSpan™ shelters and greenhouses do not have any
tested loading criteria.

CLEARSPAN™END FRAME KIT
4Revision date: 05.18.10
The following graphics and photos will help you identify the
different parts of the end frame. Consult the diagrams for
additional details. (Some parts are not shown.)
105107
1.05" Fabric Clip
CC6212
1.315" Fabric Clip
102197
Aluminum U-Channel
102198
U-Channel Spring
FA4482B
Tek Screw
100441
Nut Setter
FAF25PB
Phillips Head Screws
FAS8
Square Head Screws
104638
Tee Connector

5
CLEARSPAN™END FRAME KIT
Revision date: 05.18.10
OVERVIEW
This section describes assembling your end frame kit. See
illustration below to identify main parts of end frame kit.
1. Locate the required parts for each assembly procedure.
2. Assemble and attach all end wall framing.
3. Prepare and attach end panel film.
ClearSpan™
Cedar 8' Wide End Frame Kit
Photo may show a different but similar model.
Ground Level
Ground Level
Drawing may show a different but similar model.
Exploded drawings do not
show the film end panel.
Ground Level
View as seen
from the inside
of the shelter.
View as seen from the outside of the shelter.

CLEARSPAN™END FRAME KIT
6Revision date: 05.18.10
1INSTALL ANGLE ANCHORS
Ground Level
Drawing may show a different but similar model.
Gather the parts:
• #105232 Angle Anchors
View the diagrams to measure and determine the location
of the two (2) angle anchors for the two door jambs.
1. Mark the center of the shelter's end rafter by
measuring the distance between the two ground
posts and dividing in half.
2. Measure 13-7/16" in both directions from the center
mark and push the two (2) angle anchors into the
ground leaving at least 3" exposed. Anchors must
be straight and evenly spaced. Refer to the diagram
below.
NOTE: Place the anchors so the door jamb sits
directly in line with the ground posts.
3. Continue with the information on the following page to
assemble and install the door jambs.
Diagram shows position of angle anchors measured from the center mark.
Center
13-7/16" 13-7/16"
Ground
Post
Ground
Post
105232
Angle
Anchor
105232
Angle
Anchor
Outside of Shelter
D
oor
J
amb
D
oor
J
amb
TOP VIEW
* DIAGRAM NOT TO SCALE.

7
CLEARSPAN™END FRAME KIT
Revision date: 05.18.10
2INSTALL DOOR JAMBS
Gather the parts:
• Door jambs (#EG08W1200)
• Square head screws (#FAS8)
• 1.05" Fabric clips (#105107)
• Tek screws (#FA4482)
Consult the diagrams to assemble and attach the two (2)
door jambs.
1. Gather the two (2) door jambs and the two (2) 105107
fabric clips. Attach the fabric clips to the angled ends
of the jambs using a FAS8 square head screw. Drill a
hole through the fabric clip if needed. Center the clip
on the angled cut.
2. Set assembled door jambs into position by seating the lower end of the door jambs into the angled anchors and
clipping the top of the door jambs with the fabric clips onto the rafter. Verify the jambs are straight and evenly
spaced.
3. Once in position, secure clips by installing a Tek screw through the clip and into the rafter from the inside of the
shelter.
4. Secure lower ends of the door jambs by installing two square head construction screws through each angle anchor
and into the door jamb from the outside of the shelter. Pre-drill the holes through the anchor stake for each FAS8
screw.
Ground Level
Step 1 & 3
Step 4
Step 1
FAS8
105107
EG08W1200
Inside of
shelter
Outside of
shelter
FAS8
Ground
Level
Step 4
Tek screw
Step 3
Views above are seen from the
inside of the shelter.
Ground
Level
EG08W1200 EG08W1200
Angled Anchors
Drawings may show a different but similar model.
Outside View
Outside View

CLEARSPAN™END FRAME KIT
8Revision date: 05.18.10
3ASSEMBLE AND ATTACH FRAME BRACES
Gather the parts:
• Outer frame braces (#EG08W1202)
• Middle frame brace (#EG00W1201)
• Square head screws (#FAS8)
• 1.315" Fabric clips (#CC6212)
• Tee Connectors (#104638)
• Phillips head screws (#FAF25P)
• Tek screws (#FA4482)
View the diagrams to assemble and attach the two (2)
frame braces.
1. Gather the two (2) outer frame braces and the two (2) CC6212 fabric clips. Attach each fabric clip to the end of a
frame brace using a FAS8 square head screw. Center the clip on the brace end as shown below.
2. Set assembled frame braces into position by seating the plain end against the door jambs and clipping the fabric
clip to the ground post. Verify the braces are straight and level. (Push fabric clips into the ground if needed.)
3. Once in position, secure fabric clips by installing a Tek screw through the clip and into the ground post from the
inside of the shelter. Drill a hole through the fabric clip if needed.
4. Place the EG00W1201 middle frame between the door jambs. Verify the brace is straight and level.
5. Secure the braces to the door jamb from the inside of the shelter by attaching a 104638 tee connector using
FAF25P Phillips head screws. Position tee so it does not contact the anchor stake.
Frame is seen from the inside of the shelter.
Ground Level
EG08W1202 EG08W1202
Drawing may show a different but similar model.
EG00W1201
Ground Level
EG08W1202
EG00W1201
EG08W1202
Step 1 & 3 Step 4
Views as seen from the
inside of the shelter.
EG08W1202CC6212FAS8
Step 1
FA4482B
Ground Level
Ground Post
Step 3
FAF25P
Step 4
104638
EG08W1202
Ground Level
Inside View

9
CLEARSPAN™END FRAME KIT
Revision date: 05.18.10
4INSTALL FILM END PANELS
Ground Level
End panel installed. View as seen from outside the building.
Gather the parts:
• End panel film
• Poly latch U-channel (#102197)
• Spring for U-channel (#102198)
• Tek screws (#FA4482)
View the diagrams to install the poly latch U-channel and
attach the end panel film.
1. Using Tek screws, attach sections of the poly latch
U-channel along the outside of the frame base as
shown in the diagrams.
NOTE: If main cover is installed, detach the main cover
from the end rafter. Reinstall main cover after end film
has been installed.
2. Unfold and position the end film over the end rafter. Drape some of the material over the top rafter leaving enough
to reach the ground plus 6" - 12". Center the film so equal excess material is on each side of the shelter. Tape can
be used to temporarily hold material in place if needed.
3. Once end film is in position, attach the film to the end rafter starting at the top of the end rafter. If U-channel is
present, work your way down each side and wiggle the wire spring back and forth to seat the spring into the
previously installed U-channel. Holding the film in place and pull it tight while working down the end rafter.
4. Install the remaining springs into the
U-channel attached along the frame base.
Pull the cover snug while installing the
spring.
View as seen from outside the building.
Step 1
Step 4
Drawing may show a different but similar model.
Space Tek screws evenly about 24" apart.
102197
FA4482B
Ground
Level
Step 1
Always wear eye protection when
installing the 102198 spring!
CAUTION: Risk of Injury
DO NOT REMOVE TOO MUCH OF THE
EXCESS FILM MATERIAL. Some excess
end film material–the material that extends
beyond the U-channel–should remain
in place. If the film needs stretched in
the future, remove the spring from the
U-channel, grasp the excess material, pull
the film tight, and reinstall the spring.
