CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
©2009 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
STK# DIMENSIONS
104895 12' W x 8' 7" H x 17' 3" L
ClearSpan™
Backyard Cedar Greenhouse
Ground Level
Photo may show a model of a different length.

CLEARSPAN™CEDAR GREENHOUSES
2Revision date: 06.16.09
YOU MUST READ THIS DOCUMENT BEFORE YOU
BEGIN TO ASSEMBLE THE SHELTER.
Thank you for purchasing this ClearSpan™ greenhouse.
When properly assembled and maintained, this product will
provide years of reliable service. These instructions include
helpful hints and important information needed to safely
assemble and properly maintain the greenhouse. Please
read these instructions before you begin.
If you have any questions during the assembly, contact
Customer Service for assistance.
SAFETY PRECAUTIONS
Wear eye protection.•
Wear head protection.•
Wear gloves when handling metal and wood.•
Use a portable GFCI (Ground Fault Circuit Interrupter)• when working with power tools and cords.
Do not climb on the greenhouse during or after• construction.
Do not occupy the greenhouse during high winds,• tornadoes, or hurricanes.
Provide adequate ventilation if the structure is• enclosed.
Do not store hazardous materials in the greenhouse.•
Provide proper ingress and egress to prevent• entrapment.
ANCHORING INSTRUCTIONS
Prior to assembling this greenhouse, please read the
anchoring precautions and instructions included with the
kit. Anchoring instructions are included in the MUST READ
document. You must anchor the building after the base is
assembled and before the panels are installed.
WARNING: The anchor assembly is an integral part
of the greenhouse construction. Improper anchoring
may cause greenhouse instability and failure of the
structure. Failing to anchor the greenhouse properly
will void the manufacturer’s warranty and may cause
serious injury and damage.
LOCATION
Choosing the proper location is an important step before
you begin to assemble the structure. Always consult local
and regional building codes before you begin.
The following suggestions and precautions will help you
determine whether your selected location is the best
location.
Never erect the structure under power lines.•
Identify whether underground cables and pipes are• present before preparing the site or anchoring the
structure.
Location should be away from structures that could• cause snow to drift on or around the building.
Do not position the greenhouse where large loads• such as snow and ice, large tree branches, or other
overhead obstacles could fall.
SITE
After choosing a location, proper preparation of the site is
essential. The following site characteristics will help ensure
the integrity of the structure.
A level site is required to properly and safely erect and• anchor the frame.
Drainage: Water draining off the structure and from• areas surrounding the site should drain away from the
site to prevent damage to the site, the structure, and
contents of the structure.
WARNING: The individuals assembling this structure
are responsible for designing and furnishing all
temporary bracing, shoring and support needed during
the assembly process. For safety reasons, those who
are not familiar with recognized construction methods
and techniques must seek the help of a qualified
contractor.
SITE PREPARATION
The information regarding the preparation of the site is
presented as a general set of guidelines.
Soil conditions vary greatly among different sites. If
needed, consult the services of a qualified engineer
before you prepare the site to determine the best and
most efficient way to construct the greenhouse.
Prepare the site so drainage is away from the building
and in a direction that will not cause erosion around the
support structure.

3
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
REQUIRED TOOLS
The following list identifies the main tools needed to
assemble the greenhouse. Additional tools and supports
may be needed.
Transit or laser level for site layout•
String line and tape measure•
Marker, carpenter's level, and shovel•
Variable speed drill and impact driver (cordless with• extra batteries works best)
Wrenches or ratchet and impact socket set• (recommended)
Drill and bits•
Hammers, gloves, and eye protection•
Ladders, work platforms, and other machinery for lifting• designed to work safely at the height of the greenhouse
UNPACK AND IDENTIFY PARTS
The following steps will ensure that you have all the
necessary parts before you begin to assemble the
greenhouse.
Unpack the contents of the shipment and place where1. you can easily inventory the parts. Refer to the Bill of
Materials/Spec Sheets.
Verify that all parts listed on the Bill of Materials/Spec2. Sheets are present. If anything is missing or you have
questions, consult the Pictorial Parts Guide and all
shelter diagrams throughout these instructions for
clarification, or contact Customer Service.
At this time, you do not need to open the plastic
bags containing the fasteners (if used).
ATTENTION: To prevent splitting, drill and countersink
all mounting holes in greenhouse panels and other cedar
components.
Failing to drill and countersink the holes may split the
cedar when mounting screws are tightened.
ASSEMBLE AND ANCHOR THE BASE
For concrete surfaces, anchor the frame using customer-
supplied brackets and wedge anchors. Consult the
services of a qualified contractor for additional information
and details.
Measure all lengths of plastic lumber and match them to
the lumber lengths shown in the chart found below the
base diagrams in the Quick Start section.
ASSEMBLY PROCEDURE
Following the instructions as presented will help ensure
the proper assembly of your greenhouse. Failing to follow
these steps may result in an improperly assembled and
anchored greenhouse and will void all warranty and
protection to which the owner is entitled.
The steps outlining the assembly process are as follows:
Verify that all parts are included in the shipment. Notify1. Customer Service for questions or concerns.
Read these instructions, the Must Read document, and2. all additional documentation included with the shipment
before you begin assembling the shelter.
Gather the tools, bracing, ladders (and lifts), and3. assistants needed to assemble the greenhouse.
Check the weather4. before you install any panels. Do
not install panels on a windy or stormy day.
Re-evaluate the location and site based on the5. information and precautions presented in the
documentation included with the shipment.
Lay out the site (if this has not been completed).6.
Assemble the base frame and7. anchor to the site.
NOTE: Do not assemble the greenhouse on a
base frame that has not been anchored to the site.
Consult the anchoring diagram near the back of these
instructions and the Must Read document for anchoring
comments and instructions.
Assemble the greenhouse components in the order8. they are presented
Read the care and maintenance information at the end9. of these instructions.
Complete and return all warranty information as10. instructed.

CLEARSPAN™CEDAR GREENHOUSES
4Revision date: 06.16.09
The following graphics and photos will help you identify the
different parts of the building. (Some parts are not shown.)
FAS8 & FAS13 & FAS14
Construction Screws
FAF25P & FAF28P
Phillips Head Screws
104639
Pass-thru Connector 104636
Corner Bracket
104642
A-Angle 104643
Middle Connector
LAY OUT THE BUILDING SITE
After the site is prepared, identifying the location of the
greenhouse corners helps to square the frame after it is
assembled.
Taking these steps before assembling the greenhouse
saves time and ensures that the structure is positioned as
desired. The following procedure is a suggested method.
Its use depends on the size of the greenhouse, the
footings, and the method used to anchor the shelter.
SQUARE THE SITE
Identify a corner where a building rafter will be1. positioned, drive in a stake, and string a line the exact
width of the building and stake in place.
String a line at least as long as the building from the2. first stake at 90°.
NOTE: A transit can be used to ensure an accurate 90°
angle, or the 3-4-5 rule can be used. Refer to diagram.
Using multiples of 3-4-5 such as 6-8-10 or 12-16-20
helps to maintain an accurate 90° angle.
After squaring the position of the building and placing3. a stake at all corners, string a line between the stakes
to mark the base of the building.

5
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
Ground Level
1
FRONT
BACK
SIDE
SIDE
1
SIDE BOARD
BACK BOARD
ATTENTION: Verify that the
front and back boards are seated
against the corner bracket.
2
3Outside
Inside
Align the
centers of the
connectors with
the measured
marks.
ASSEMBLE BASE FRAME
Consult the Assembled Base and Exploded Base Views at the back of these instructions to assemble the
base frame.
NOTE: All screws in this step are installed in the sides of the baseboards. DO NOT install screws into the
top of the baseboards.
Gather the correct board lengths and assemble each baseboard using two (2) middle connectors; one1. placed over the top edge and one placed over the bottom edge at the joint between the boards. Use
3/4" Phillips head screws (FAF25P) to secure middle connectors.
With the baseboards assembled, attach the corner brackets as shown below using 3/4" Phillips head2. screws (FAF25P) to secure. Repeat at the remaining corners. Consult diagrams to properly install the
corner brackets and to assemble the frame.
On each3. side, attach pass-thru connectors (#104639) in the locations shown below. Consult the
Assembled Base View diagrams near the back of these instructions for the correct measurements and
locations. Use 3/4" Phillips head screws (FAF25P) to secure pass-thru connectors.
Consult the diagrams near the back of these instructions4. to square and anchor the assembled frame.

CLEARSPAN™CEDAR GREENHOUSES
6Revision date: 06.16.09
Frame length of your
building may differ
from what is shown.
2
Seat the corner panels into the corner brackets as
shown and secure using 3/4" Phillips head screws.
Corner Panel
3/4" Phillips
head screws
1
Brackets come pre-
installed. Secure using
3/4" Philips head screws.
Verify the ridge
bracket is to
the inside.
3
2
CG12123
View as seen
from the inside
BACK BOARD
INSTALL BACK PANELS
WARNING: To prevent damage to the
panels and to prevent serious personal
injury, do not attempt to install the panels
on windy days.
Secure corner panels (#CG12100 &1. #CG12101) to the base frame using 3/4"
Phillips head screws (FAF25P). Attach to
the base frame using the corner brackets
and the pre-installed brackets on the
corner panels as shown.
NOTE: If needed, brace panels in place or
have an assistant hold the panels steady
until side panels can be attached to the
end panels.
Install the back center panel (#CG12123). Secure panel using the pre-installed 3" x 3" flat brackets and2. 3/4" Phillips head screws (FAF25P) as shown.
Install the back peak panel (#CG12114). Secure panel using the pre-installed brackets on the corner3. panels as shown and the FAF25P screws.

7
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
3
NOTE: Brace panels during
assembly, if needed.
INSTALL SIDE PANELS
WARNING: To prevent damage to the
panels and to prevent serious personal
injury, do not attempt to install the panels
on windy days.
Beginning at the corner, attach a side panel1. to the back end panel using three 2-1/2"
construction screws (#FAS13).
NOTE: Drill and countersink all mounting
holes for panel installation. Install
construction screws through the end panel
and into the side panel as shown below.
Secure side panels (#CG96113) to the2. base frame using 3/4" Phillips head screws
(FAF25P). Attach to the base frame using the pass-thru connectors as shown. Align the centers of the
pass-thru connectors with the edge of the side panels as shown to the right, and secure using 3/4"
Phillips head screws.
Repeat steps to install panels for the remaining side.3.
View as seen
from the outside.
2
ATTENTION: Verify that
all pre-installed brackets
are to the inside of the
greenhouse.
1
FAS13 Construction
screw locations Frame length of your
building may differ
from what is shown.

CLEARSPAN™CEDAR GREENHOUSES
8Revision date: 06.16.09
4INSTALL FRONT PANELS
WARNING: To prevent damage to the panels and to prevent serious personal injury, do not attempt to
install the panels on windy days.
Secure front panels (#CG12100 & #CG12101) to the base frame as previously described in Section 2.1.
Attach front panels to the side panels using three 2-1/2" construction screws (#FAS13) as described in2. Section 3. Drill and countersink all mounting holes.
Attach the front peak panel (#CG12114) as described in Section 2.3.
NOTE: Verify that the ridge bracket is to the inside of the greenhouse.
CG12101
CG12114
CG12100
Frame length of your
building may differ
from what is shown.

9
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
5ATTACH AND MARK TOP PLATES
Gather the parts:
96" top plate (#10513696)•
12" top plate (#10513612)•
2-1/2" construction screws (#FAS13)•
Using FAS13 construction screws spaced at1. 12" intervals, attach two (2) 96" and one (1)
12" top plate to the top of the side panels on
one side. Repeat for the remaining side. Drill
and countersink holes.
Measure and mark 25-1/2" from the end of2. the installed top plate. Continue measuring
and marking in 25-1/2" increments for the
on-center middle rafter locations.
NOTE: Mark the outside of the top plates
and not the top. This allows the mark to be
visible when the rafter assemblies are set
into position.
ATTENTION: Drill and countersink all mounting holes
before you install and tighten the mounting screws.
FAS13
construction
screws
1Drill and countersink
all mounting holes.
2
25-1/2"
Top Plate Locations
Top Plate
Frame length of your
building may differ
from what is shown.

CLEARSPAN™CEDAR GREENHOUSES
10 Revision date: 06.16.09
4
View as seen
from the inside
FAF25P
Phillips head
screw
104642
A-Angle bracket
NOTE: Attach rafters
with the angled brackets
facing the back panels.
Pre-drill
fastener hole.
Verify rafter
is over the
edge when
drilling so as to
not drill into the
top plate.
2
3
Align the
center of the
rafter leg with
the previously
measured
mark.
FAS13
construction
screw
Frame length of your
building may differ
from what is shown.
6ASSEMBLE AND ATTACH MIDDLE RAFTERS
Rafters are shipped in two sections and must
be assembled before they are attached to the
greenhouse.
Assistance may be required to attach rafters.
Align the pre-drilled holes in the rafter leg1. with the holes of the angle brackets. Using
the screws that shipped with the rafter
sections, assemble the rafter. See diagrams
to the right.
NOTE: When properly assembled, a space is present between the top ends of each rafter leg for the
ridge assembly, which is installed later.
Locate an assembled rafter and position it on the previously installed top plates. Align the center of the2. rafter legs with the first set of marks. Allowing the end of the rafter leg to hang over the edge, drill and
countersink a hole for the rafter fastener using a 1/8" drill bit.
NOTE: You must pre-drill and countersink the hole for the rafter fastener to prevent the rafter leg from
splitting. DO NOT drill into the top of the top plate.
Verify the centers of the rafter legs are aligned with the previously measured marks. Using the pre-drilled3. holes in the previous step and 2-1/2" FAS13 construction screws, secure the rafter legs to the top plate.
Select two (2) A-angle brackets (#104642) and attach one to the underside of each rafter leg on the4. inside as shown below. Secure using 3/4" FAF25P Phillips head screws.
Repeat steps for all remaining rafters.5.
1Diagram shows
rafter sections as
they are shipped.

11
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
NOTE: If needed, remove
rafter bracket, adjust to fit
the rafter assemblies, and
reattach.
3Secure using
FAF25P Phillips
head screws.
4
Secure using
FAF25P Phillips
head screws.
Frame length of your building may differ
from what is shown.
7
CG12135
CG12137
104643
FAF25P
1
CG12135 CG12137 10513612
NOTE: Verify ridge
assembly is connected
as shown or the rafter
brackets will not align with
the rafters. Consult Ridge
Assembly page near the
back of this manual.
ASSEMBLE AND INSTALL RIDGE ASSEMBLY
IMPORTANT: Consult the Ridge Assembly diagram in
the back of these instructions to properly connect the
ridge assembly.
Ridge sections are shipped with brackets and
connectors already attached. If the sections are not
connected, assemble the ridge sections as shown,
attach assembled ridge beam to frame, then attach the
4-way connectors using the rafters as guides.
Assemble the ridge beam using a middle1. connector placed over the bottom edge at the joint
between the boards. Use 3/4" Phillips head screws
(FAF25P) to secure middle connector.
ATTENTION: When assembled, verify that the
on-center distance between each rafter bracket is
25-1/2".
With the ridge beam assembled, position it2. between the peaks of the end walls and align the
rafter brackets with the middle rafter assemblies.
Once the ridge assembly is aligned with the middle3. rafters, seat the assembly into the ridge brackets
attached to the end rafter assemblies. Secure
using 3/4" Phillips head screws (FAF25P).
Secure each rafter bracket to the rafter assemblies4. using 3/4" Phillips head screws (FAF25P).

CLEARSPAN™CEDAR GREENHOUSES
12 Revision date: 06.16.09
8INSTALL RAKE BOARDS (2 FRONT)
Locate one (1) rake board (#CG72133) and attach it to the top of the1. front end wall as shown below.
Secure using three (3) evenly spaced 2-1/2" construction screws (#FAS13).
NOTE: Drill and countersink mounting holes in rake boards to prevent splitting.
Locate another rake board (#CG72133) and attach to the remaining side of the2. front end wall as
described in the previous step.
NOTE: Verify that the angled edges of the rake board align with the peak of the end wall.
1FAS13
construction
screw
CG72133
View as
seen from
the inside.
2FAS13
construction
screw
CG72133
View as
seen from
the inside.
Step 2
Step 1
Frame length of your
building may differ
from what is shown.

13
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
CG72138
Roof Panel
1
CG72138
Roof Panel
Top edge aligns
with the center
of end wall.
View as
seen from
the inside.
Rake Board
2
FAS13
construction
screws
CG72138
roof panel
SIDE
VIEW
3
FAS13
screw
locations
Frame length of your
building may differ
from what is shown.
9INSTALL ROOF PANELS
WARNING: To prevent damage to the panels and to
prevent serious personal injury, do not attempt to install
the panels on windy days.
Roof panels can be installed in different locations depending
on desired result. For the purpose of these instructions, the
roof panels are installed with the vented panels on the left
side of the greenhouse as seen from the front.
IMPORTANT: Consider the direction of the prevailing winds when installing the vented roof panels. These
panels should be positioned (if possible) so that the prevailing winds cannot catch and damage the vents
when open. See diagram in upper-right corner.
NOTE: Drill and countersink all mounting holes to prevent splitting.
Locate a double roof panel (#CG72138) and set it in position as shown below.1.
NOTE: The roof panel will be flush with the top of the adjacent rake board. Additionally, the top edge will
not extend past the center of the ridge assembly.
Verify the top edge is aligned with the center as shown and secure to the rake board using three (3)2. 2-1/2" construction screws (#FAS13). Install screws through the rake board and into the roof panel.
NOTE: When installed correctly, the open edge of the double roof panel will align with the center of the
second inside rafter. Panel should be tight against and secured to the rake board at this time.
Secure the panel by installing 2-1/2" construction screws through the double roof panel frame and into3. the rafters beneath in the locations shown in the bottom right diagram.
Prevailing Winds

CLEARSPAN™CEDAR GREENHOUSES
14 Revision date: 06.16.09
CG72141
CG72138
CG72138
CG72138
Rake Board
CG72138
roof panel
6
FAS13
construction
screws
7 & 8
CG72133
Rake Boards
FAS13
construction
screws
9
Attach the roof panels for the remaining side as desired. For the purpose of these instructions, the6. diagrams show the two (2) vented panels attached in the middle of the roof side.
NOTE: Remember to attach the first panel to the front rake board as described in Step 2 before
fastening to the rafters. See diagram below.
With all roof panel in position and secure, attach the two (2) back rake boards (#CG72133) as described7. in Section 8.
With the back rake boards secured into position, secure the back roof panels to the rake boards by8. installing three (3) 2-1/2" construction screws (#FAS13) through the side of each rake board and into the
roof panel.
FAS13 screw
locations
4
INSTALL ROOF PANELS (continued)
Locate another double roof panel (#CG72138),4. set it into position and attach to the rafters using
2-1/2" construction screws (#FAS13). Screws are
installed through the three (3) roof panel frame
columns and into the underlying rafters.
Continue attaching CG72138 roof panels as5. previously described until the side of the roof is
complete.

15
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
10 INSTALL RIDGE CAP ASSEMBLY
The ridge cap assembly is shipped in
sections. When installed properly, one
section overlaps another until the last
section is attached.
NOTE: Each section of the ridge cap
assembly is secured to the greenhouse
using 3" construction screws (#FAS14)
installed from the inside of the greenhouse.
Using a 1/8" drill bit, drill a hole from1. the underside of the ridge assembly
up through the ridge assembly in the
locations described to the right.
Once the holes are drilled through the ridge assembly, countersink each hole approximately 1-1/2" from2. the bottom. Use a bit that is as wide or slightly wider than the head of a 3" construction screw (#FAS14).
Place the first section of ridge cap (#CG12132) in position as shown below. Verify that the wood of3. the ridge cap section is flush against the rake boards. Ridge cap will extend beyond the end of the
greenhouse.
Insert FAS14 construction screws through the first pre-drilled holes into the wood of the ridge cap and4. tighten. See diagram below.
Place the next ridge cap section into position, overlapping the first section, and secure as described in5. the previous step.
Continue to secure sections of ridge cap in place until all sections are attached to the greenhouse.6.
Roof panels and
rafters removed
for clarity.
1
NOTE: Drill holes in similar locations the entire length of
the ridge assembly. Position holes to avoid drilling through
any rafter brackets and middle connectors.
CUTAWAY
VIEW
Countersunk
hole
2
CG12132
Ridge Cap
FAS14
construction
screw
4
3
Verify the edge of the ridge
cap wood is against the
rake boards. Approximately
1/4"-1/2" of the ridge cap
metal will extend beyond
the greenhouse.
Frame length of your
building may differ
from what is shown.

CLEARSPAN™CEDAR GREENHOUSES
16 Revision date: 06.16.09
11 INSTALL DOOR PANELS
Gather the parts:
Door panels (#CG12119A & #CG12119B)•
All door accessories•
1-1/8" construction screws (#FAS8)•
1-1/2" Phillips head screws (#FAF28P)•
Use the diagrams to install the door panels.
Locate the lower door panel and position it in1. the door opening of the frame. Verify that the
side with the 90° connectors is to the inside
of the shelter.
NOTE: The door panels can be positioned to swing open from the left or the right. Remove and reattach
hinges as needed.
With the panel in the opening, attach the hinges to the doorjamb using FAS8 square head screws.2.
Locate the remaining upper door panel, position the panel in the door opening, and attach the hinges as3. described in the previous step.
ATTENTION: To ensure proper door operation, maintain a 1/4" gap between the upper and lower panels.
With both door panels secured in place, close each panel and attach door handles, door lock, and 2"4. turn button in the desired location using FAF28P Phillips head screws.
ATTENTION: Attach the locking hardware and turn button to the bottom panel.
Upper Door Panel
CG12119A
Lower Door Panel
CG12119B
NOTE: Door handles can be
attached as desired.
NOTE: Maintain an even gap of
approximately 1/4" across the
bottom of the door and between
door panels.
FAS8
screws
2
FAF28P
screws
4
Frame length of your
building may differ
from what is shown.

17
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
12 INSTALL SOLAR VENT OPENER ASSEMBLY
The solar vent opener assemblies are attached to the vented roof and end panels of the greenhouse.
When properly installed, these assemblies automatically open the vent panels of the greenhouse when the
temperature in the greenhouse increases.
NOTE: The solar vent opener requires assembly. Follow the instructions included with the solar vent opener
to assemble the vent before attaching it to the greenhouse. After the vent opener is assembled, continue
with the these instructions.
Verify that the vent panel on the greenhouse opens easily and is not obstructed.1.
Choose one of the assembled solar vent openers and attach it to the greenhouse frame and the vent2. panel as shown in the diagram. Secure using 1-1/8" FAS8 construction screws.
NOTE: Attach the opener near the middle of the vent panel. Verify that nothing interferes with the
operation of the solar vent opener.
Repeat for each vent.3.
Check the operation of the panels and the installed openers and consult the documentation4. included
with the opener for opener maintenance and winter storage.
View as
seen from
the inside.
Vent
Panel
Actual greenhouse may differ from what is shown above.

CLEARSPAN™CEDAR GREENHOUSES
18 Revision date: 06.16.09
13
Frame length of your
building may differ
from what is shown.
Dashed line and arrows show where to
install the white vent tape. Repeat for
remaining side. Do not install tape in any
other location on any other panels.
SHELTER CARE AND MAINTENANCE
Proper care and maintenance of your shelter is important. Check the following items periodically to
properly maintain your shelter:
Seal the open cells on the bottom edges of the roof panels with white vent tape. (See below)•
Frequently and regularly check the panels to see that these remain tight and in proper repair.•
Repair any damage to the panels immediately to prevent further complications and damage.•
Check connections and all fasteners to verify that they remain tight.•
Do not climb or stand on the shelter at anytime.•
Remove debris and objects that may accumulate on the shelter. Use tools that will not damage the• panels when removing debris.
Remove snow to prevent excess accumulation. Use tools that will not damage the shelter when• removing snow. Never allow snow to accumulate on the roof or against the lower panels!
Check the contents of the shelter to verify that nothing is touching the panels that could cause damage.•
Check the anchoring system (if equipped) to ensure that all components are tight and in good repair.•
Consult the instructions included with the solar vent openers for proper care and maintenance of these• openers.
Check the solar vent opener mounting brackets and screws to see if they remain secure.•
Repair or replace all customer-supplied materials as needed to prevent injury or damage.•
Replace all worn or damaged parts promptly.•
NOTE: With the exception of Truss Arch buildings and unless otherwise noted, ClearSpan™ shelters and
greenhouses do not have any tested loading criteria.
Apply Vent Tape

19
CLEARSPAN™CEDAR GREENHOUSES
Revision date: 06.16.09
ITEM # PART # DESCRIPTION QUANTITY
1 104577 96" Plastic Lumber 6
2 10457712 12" Plastic Lumber 2
3 10457748 48" Plastic Lumber 2
4 104636 Corner Bracket 4
5 104639 Pass-thru Connector 6
6 104643 Middle Connector 12
NOTE: All base brackets are secured with FAF25P 3/4" screws.
ASSEMBLED BASE VIEW
2
1
3
2
1
1
3
6
1
1
1
6
4
5
5
5
4
6
6
6
6
4
5
5
5
4
6
6
6
6
NOTE: Mark lines on the side
baseboards at the 51" measurements
for the on-center pass-thru connector
locations.
IMPORTANT: Measure
51" from the end of the
side board, NOT the
outside edge.
51"
51"
51"
51"
12'-0" Width
(outside-to-outside)
17'-3" Length
(outside-to-outside)
ATTENTION: Measure all lengths of plastic lumber
and match them to the lumber lengths shown in the
chart below to verify that you have the correct parts.
ATTENTION: For concrete surfaces, anchor the frame using customer-supplied
brackets and wedge anchors. Consult the services of a qualified contractor for additional
information and details.

CLEARSPAN™CEDAR GREENHOUSES
20 Revision date: 06.16.09
EXPLODED BASE VIEW
2
1
3
2
1
1
3
6
1
1
1
6
4
5
5
5
4
6
6
6
6
6
4
5
5
5
4
6
6
6
6
ITEM # PART # DESCRIPTION QUANTITY
1 104577 96" Plastic Lumber 6
2 10457712 12" Plastic Lumber 2
3 10457748 48" Plastic Lumber 2
4 104636 Corner Bracket 4
5 104639 Pass-thru Connector 6
6 104643 Middle Connector 12
ATTENTION: Measure all lengths of plastic lumber
and match them to the lumber lengths shown in the
chart below to verify that you have the correct parts.
