Clemco CPF 20 User manual

CPF 20/80
PARTICULATE AIR FILTER
O. M. 04143
© 2007 CLEMCO INDUSTRIES CORP.
One Cable Car Dr.
Washington, MO 63090
Phone [phone]
Fax [phone]
Email: [email protected]
www.clemcoindustries.com
MC FILE NUMBER: 161-0278
DATE OF ISSUE: 06/30/78
REVISION: J, 12/2007
®
Do not proceed with
these instructions until
you have READ the
orange cover of this
MANUAL and YOU
UNDERSTAND its
contents. *
These WARNINGS are
included for the health
and safety of the
operator and those in
the immediate vicinity.
*If you are using a Clemco Distributor
Maintenance and Part Guide, refer to
the orange warnings insert preceding
the Index before continuing with the
enclosed instructions.
Electronic files include a Preface
containing the same important
information as the orange cover.
WARNING

PREFACE
•Read and follow ALL instructions before using
this equipment.
•Failure to comply with ALL instructions can result
in serious injury or death.
•In the event that the user, or any assistants of the
user of this equipment cannot read or cannot
completely understand the warnings and
information contained in these instructions, the
employer of the user and his assistants must
thoroughly educate and train them on the proper
operation and safety procedures of this
equipment.
NOTICE TO PURCHASERS AND USERS OF OUR
PRODUCTS AND THIS INFORMATIONAL MATERIAL
The products described in this material, and the information
relating to those products, is intended for knowledgeable,
experienced users of abrasive blasting equipment.
No representation is intended or made as to the suitability of
the products described herein for any particular purpose or
application. No representations are intended or made as to the
efficiency, production rate, or the useful life of the products
described herein. Any estimate regarding production rates or
production finishes are the responsibility of the user and must
be derived solely from the user’s experience and expertise,
and must not be based on information in this material.
The products described in this material may be combined by
the user in a variety of ways for purposes determined solely by
the user. No representations are intended or made as to the
suitability or engineering balance of the combination of
products determined by the user in his selection, nor as to the
compliance with regulations or standard practice of such
combinations of components or products.
Abrasive Blast Equipment is only a component of the range of
equipment used in an abrasive blasting job. Other products
may include an air compressor, abrasive, scaffolding, hydraulic
work platforms or booms, paint spray equipment,
dehumidification equipment, air filters and receivers, lights,
ventilation equipment, parts handling equipment, specialized
respirators, or equipment that while offered by Clemco may
have been supplied by others. Each manufacturer and supplier
of the other products used in the abrasive blasting job must be
contacted for information, training, instruction and warnings
with regard to the proper and safe use of their equipment in the
particular application for which the equipment is being used.
The information provided by Clemco is intended to provide
instruction only on Clemco products. All operators must be
trained in the proper, safe, use of this equipment. It is the
responsibility of the users to familiarize themselves with, and
comply with, all appropriate laws, regulations, and safe
practices that apply to the use of these products. Consult with
your employer about training programs and materials that are
available.
Our company is proud to provide a variety of products to the
abrasive blasting industry, and we have confidence that the
professionals in our industry will utilize their knowledge and
expertise in the safe efficient use of these products.
GENERAL INSTRUCTIONS
Described herein are some, BUT NOT ALL, of the major
requirements for safe and productive use of blast
machines, remote control systems, operator respirator
assemblies, and related accessories. Completely read ALL
instruction manuals prior to using equipment.
The user's work environment may include certain
HAZARDS related to the abrasive blasting operation.
Proper protection for the blaster, as well as anyone else
that may be EXPOSED to the hazards generated by the
blasting process, is the responsibility of the user and/or
the employer. Operators MUST consult with their employer
about what hazards may be present in the work
environment including, but not limited to, exposure to dust
that may contain TOXIC MATERIALS due to the presence
of silica, cyanide, arsenic or other toxins in the abrasive,
or materials present in the surface to be blasted such as
lead or heavy metals in coatings. The environment may
also include fumes that may be present from adjacent
coatings application, contaminated water, engine exhaust,
chemicals, and asbestos. The work area may include
PHYSICAL HAZARDS such as an uneven work surface,
poor visibility, excess noise, and electrical hazards. The
operator MUST consult with his employer on the
identification of potential hazards, and the appropriate
measures that MUST be taken to protect the blaster and
others that might be exposed to these hazards.
ALL machines, components and accessories MUST be
installed, tested, operated and maintained only by trained,
knowledgeable, experienced users.
DO NOT modify or substitute any Clemco parts with other
types or brands of equipment. Unauthorized modification
and parts substitution on supplied air respirators is a
violation of OSHA regulations and voids the NIOSH
approval.
OPERATIONAL INSTRUCTIONS
OPERATOR SAFETY EQUIPMENT
•Blast operators and others working in the vicinity of
abrasive blasting must always wear properly-
maintained, NIOSH-approved, respiratory protection
appropriate for the job site hazards.
•DO NOT USE abrasives containing more than one
percent crystalline (free) silica. Ref. NIOSH Alert
#92-102
•Inhalation of toxic dust (crystalline silica, asbestos,
lead paint and other toxins) can lead to serious or
fatal disease (silicosis, asbestosis, lead or other
poisoning).
•ALWAYS wear NIOSH-approved supplied-air respirators
as required by OSHA, in the presence of any dust including,
but not limited to, handling or loading abrasive; blasting or
working in the vicinity of blast jobs; and cleanup of expended
abrasive. Prior to removing respirator, an air monitoring
WARNING
WARNING
I

PREFACE
instrument should be used to determine when surrounding
atmosphere is clear of dust and safe to breathe.
•NIOSH-approved, supplied-air respirators are to be worn
ONLY in atmospheres:
• NOT IMMEDIATELY dangerous to life or health and,
• from which a user can escape WITHOUT using the
respirator.
•Clemco supplied-air respirators DO NOT REMOVE OR
PROTECT AGAINST CARBON MONOXIDE (CO) OR ANY
OTHER TOXIC GAS. Carbon monoxide and toxic gas removal
and/or monitoring device must be used in conjunction with
respirator to insure safe breathing air.
•Air supplied to respirator MUST BE AT LEAST GRADE D
QUALITY as described in Compressed Gas Association
Commodity Specification G-7.1, and as specified by OSHA
Regulation 1910.139 (d).
•ALWAYS locate compressors to prevent contaminated air
(such as CO from engine exhaust) from entering the air intake
system. A suitable in-line air purifying sorbent bed and filter or
CO Monitor should be installed to assure breathing air quality.
•ALWAYS use a NIOSH-approved breathing air hose to
connect an appropriate air filter to the respirator. Use of a non-
approved air hose can subject the operator to illness caused
by the release of chemical agents used in the manufacture of
non-approved breathing air hose.
•ALWAYS check to make sure air filter and respirator
system hoses are NOT CONNECTED to in-plant lines that
contain nitrogen, acetylene or any other non-breathable gas.
NEVER use oxygen with air line respirators. NEVER modify air
line connections to accommodate air filter/respirator breathing
hose WITHOUT FIRST testing content of the air line. FAILURE
TO TEST THE AIR LINE MAY RESULT IN DEATH TO THE
RESPIRATOR USER.
•Respirator lenses are designed to protect against
rebounding abrasive. They do not protect against flying
objects, glare, liquids, radiation or high speed heavy materials.
Substitute lenses from sources other than the original
respirator manufacturer will void NIOSH-approval of this
respirator.
BLAST MACHINES AND REMOTE CONTROLS
•ALWAYS equip abrasive blast machines with
remote controls.
•Abrasive blast machine operators must wear NIOSH-
approved supplied-air respirators (ref: OSHA
regulations 1910.94, 1910.132, 1910.139 and
1910.244).
•NEVER modify OR substitute remote control parts. Parts
from different manufacturers are NOT compatible with Clemco
equipment. If controls are altered, involuntary activation, which
may cause serious injury, can occur.
•Inspect the air control orifice DAILY for cleanliness.
NEVER use welding hose in place of twinline control hose. The
internal diameter and rubber composition are UNSAFE for
remote control use.
•UNLESS OTHERWISE SPECIFIED, maximum working
pressure of blast machines and related components MUST
NOT exceed National Board approved 125 psig (8.5 BAR).
•NEVER weld on blast machine. Welding may affect
dimensional integrity of steel wall and WILL VOID National
Board approval.
•Point nozzle ONLY at structure being blasted. High
velocity abrasive particles WILL inflict serious injury. Keep
unprotected workers OUT of blast area.
•NEVER attempt to manually move blast machine when it
contains abrasive. EMPTY machines, up to 6 cu. ft.(270kg)
capacity, are designed to be moved:
• on flat, smooth surfaces by AT LEAST two people;
• with the Clemco "Mule"; or
• with other specially designed machine moving devices.
•Larger empty blast machines or ANY blast machine
containing abrasive MUST be transported by mechanical lifting
equipment.
AIR HOSE, BLAST HOSE, COUPLINGS, AND NOZZLE HOLDERS
•Air hose, air hose fittings and connectors at compressors
and blast machines MUST be FOUR times the size of the
nozzle orifice. Air hose lengths MUST be kept as short as
possible AND in a straight line. Inspect DAILY and repair
leakage IMMEDIATELY.
•Blast hose inside diameter MUST be THREE to FOUR
times the size of the nozzle orifice. AVOID sharp bends that
wear out hose rapidly. Use SHORTEST hose lengths possible
to reduce pressure loss. Check blast hose DAILY for soft
spots. Repair or replace IMMEDIATELY.
•ALWAYS cut loose hose ends square when installing hose
couplings and nozzle holders to allow uniform fit of hose to
coupling shoulder. NEVER install couplings or nozzle holders
that DO NOT provide a TIGHT fit on hose. ALWAYS use
manufacturers recommended coupling screws.
•Replace coupling gaskets FREQUENTLY to prevent
leakage. Abrasive leakage can result in dangerous coupling
failure. ALL gaskets MUST be checked SEVERAL times during
a working day for wear, distortion and softness.
•Install safety pins at EVERY coupling connection to
prevent accidental disengagement during hose movement.
•ALWAYS attach safety cables at ALL air hose AND blast
hose coupling connections. Cables relieve tension on hose and
control whipping action in the event of a coupling blow-out.
WARNING
II

PREFACE
MAINTENANCE
•ALWAYS shut off compressor and depressurize blast
machine BEFORE doing ANY maintenance.
•Always check and clean ALL filters, screens and alarm
systems when doing any maintenance.
•ALWAYS cage springs BEFORE disassembling valves IF
spring-loaded abrasive control valves are used.
•ALWAYS completely follow owner's manual instructions
and maintain equipment at RECOMMENDED intervals.
ADDITIONAL ASSISTANCE
•Training and Educational Programs.
Clemco Industries Corp. offers a booklet, Blast-Off 2,
developed to educate personnel on abrasive blast equipment
function and surface preparation techniques. Readers will learn
safe and productive use of machines, components and various
accessories, including selection of abrasive materials for
specific surface profiles and degrees of cleanliness.
•The Society for Protective Coatings (SSPC) offers a video
training series on protective coatings including one entitled
"Surface Preparation." For loan or purchase information,
contact SSPC at the address shown below.
TECHNICAL DATA AND RESEARCH COMMITTEES
•The following associations offer information, materials and
videos relating to abrasive blasting and safe operating
practices.
The Society for Protective Coatings (SSPC)
40 24th Street, Pittsburgh PA 15222-4643
Phone: [phone] • FAX [phone]
Email: [email protected] • Website: www.sspc.org
National Association of Corrosion Engineers (NACE)
1440 South Creek Drive, Houston TX 77084
Phone: [phone] • FAX [phone]
Email: [email protected] • Website: www.nace.org
American Society for Testing and Materials (ASTM)
100 Barr Harbor Dr., West Conshohocken, PA 19428
Phone [phone] • FAX [phone]
Email: [email protected] • Website: www.astm.org
NOTICE
This equipment is not intended to be used in an area that might
be considered a hazardous location as described in the
National Electric Code NFPA 70 1996, article 500.
WARRANTY
The following is in lieu of all warranties express, implied or
statutory and in no event shall seller or its agents, successors,
nominees or assignees, or either, be liable for special or
consequential damage arising out of a breach of warranty. This
warranty does not apply to any damage or defect resulting
from negligent or improper assembly or use of any item by the
buyer or its agent or from alteration or attempted repair by any
person other than an authorized agent of seller. All used,
repaired, modified or altered items are purchased “as is” and
with all faults. In no event shall seller be liable for
consequential or incidental damages. The sole and exclusive
remedy of buyer for breach of warranty by seller shall be repair
or replacement of defective parts or, at seller’s option, refund
of the purchase price, as set forth below:
1. Seller makes no warranty with respect to products used
other than in accordance hereunder.
2. On products seller manufactures, seller warrants that all
products are to be free from defects in workmanship and
materials for a period of one year from date of shipment to
buyer, but no warranty is made that the products are fit for a
particular purpose.
3. On products which seller buys and resells pursuant to this
order, seller warrants that the products shall carry the then
standard warranties of the manufacturers thereof, a copy of
which shall be made available to customer upon request.
4. The use of any sample or model in connection with this
order is for illustrative purposes only and is not to be construed
as a warranty that the product will conform to the sample or
model.
5. Seller makes no warranty that the products are delivered
free of the rightful claim of any third party by way of patent
infringement or the like.
6. This warranty is conditioned upon seller’s receipt within ten
(10) days after a buyer’s discovery of a defect, of a written
notice stating in what specific material respects the product
failed to meet this warranty. If such notice is timely given, seller
will, at its option, either modify the product or part to correct the
defect, replace the product or part with complying products or
parts, or refund the amount paid for the defective product, any
one of which will constitute the sole liability of seller and a full
settlement of all claims. No allowance will be made for
alterations or repairs made by other than those authorized by
seller without the prior written consent of seller. Buyer shall
afford seller prompt and reasonable opportunity to inspect the
products for which any claim is made as above stated.
Except as expressly set forth above, all warranties, express,
implied or statutory, including implied warranty of
merchantability, are hereby disclaimed.
DAILY SET-UP CHECK LIST
•ALL piping, fittings and hoses MUST be checked
DAILY for tightness and leakage.
•ALL equipment and components MUST be thoroughly
checked for wear.
•ALL worn or suspicious parts MUST be replaced.
•ALL blast operators MUST be properly trained to
operate equipment.
•ALL blast operators MUST be properly outfitted with
abrasive resistant clothing, safety shoes, leather gloves
and ear protection.
•BEFORE blasting ALWAYS use the following check list.
□1. PROPERLY MAINTAINED AIR COMPRESSOR sized
to provide sufficient volume (cfm) for nozzle and other tools
PLUS a 50% reserve to allow for nozzle wear. Use large
compressor outlet and large air hose (4 times the nozzle orifice
size). FOLLOW MANUFACTURERS MAINTENANCE
INSTRUCTIONS.
□2. BREATHING AIR COMPRESSOR (oil-less air pump)
capable of providing Grade D Quality air located in a dust free,
contaminant free area. If oil-lubricated air compressor is used
to supply respirator, it should have high temperature monitor
and CO monitor or both. If CO monitor is not used, air MUST
be tested FREQUENTLY to ensure proper air quality.
WARNING
III

PREFACE
□3. Clean, properly maintained NIOSH-APPROVED
SUPPLIED-AIR RESPIRATOR. ALL components should
ALWAYS be present. NEVER operate without inner lens in
place. Thoroughly inspect ALL components DAILY for
cleanliness and wear. ANY substitution of parts voids NIOSH
approval i.e. cape, lenses, breathing hose, breathing air supply
hose, air control valve, cool air or climate control devices.
□4. OSHA required BREATHING AIR FILTER for removal
of moisture and particulate matter from breathing air supply.
THIS DEVICE DOES NOT REMOVE OR DETECT CARBON
MONOXIDE (CO). ALWAYS USE CO MONITOR ALARM.
□5. ASME CODED BLAST MACHINE sized to hold 1/2
hour abrasive supply. ALWAYS ground machine to eliminate
static electricity hazard. Examine pop up valve for alignment.
Blast machine MUST be fitted with a screen to keep out foreign
objects and a cover to prevent entry of moisture overnight.
□6. AIR LINE FILTER installed AS CLOSE AS POSSIBLE
to machine inlet. Sized to match inlet piping or larger air supply
line. Clean filter DAILY. Drain OFTEN.
□7. REMOTE CONTROLS MUST be in PERFECT
operating condition. ONLY use APPROVED spare parts,
including twin- line hose. DAILY: test system operation and
check button bumper and spring action of lever and lever lock.
DO NOT USE WELDING HOSE.
□8. BLAST HOSE with ID 3 to 4 times the nozzle orifice.
Lines MUST be run AS STRAIGHT AS POSSIBLE from
machine to work area with NO sharp bends. Check DAILY for
internal wear and external damage.
□9. HOSE COUPLINGS, NOZZLE HOLDERS fitted
SNUGLY to hose end and installed using PROPER coupling
screws. Coupling lugs MUST be snapped FIRMLY into locking
position. Gasket MUST form positive seal with safety pins
inserted through pin holes. Check gaskets and replace if ANY
sign of wear, softness or distortion. ALWAYS install safety
cables at every connection to prevent disengagement. Check
nozzle holder for worn threads. NEVER MIX DIFFERENT
BRANDS OF COMPONENTS. Check each of these
components DAILY.
□10. Inspect NOZZLE and GASKET DAILY for wear.
Replace nozzle when 1/16" larger than original size or if liner
appears cracked. Check nozzle threads for wear.
□11. Use abrasive that is properly sized and free of harmful
substances; such as, free silica, cyanide, arsenic or lead.
Check material data sheet for presence of toxic or harmful
substances.
□12. Test surface to be blasted for toxic substances. Take
appropriate, and NIOSH required, protective measures for
operator and bystanders which pertain to substances found on
the surface to be blasted.
3. NIOSH
Approved
Supplied-Air
Respirator
11. Silica-free Abrasive 5. ASME Coded
Blast Machine
8. Blast Hose
10. Appropriately
Sized Nozzle
2. Breathing Air Compressor
4. CPF Air-Filter
6. Air Line
Filter
9. Hose Couplings and
Safety Cables
1 Air Compressor
(or)
2. Ambient Air Pump
for low pressure
respirator
7. Remote
Controls
IV

CPF 20/80 PARTICULATE AIR FILTER Page 1
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
1.0 INTRODUCTION
1.1 Scope of Manual
1.1.1 These instructions cover setup, operation,
maintenance, replacement parts, and important warnings
to safely operate the Clemco CPF Particulate Air Filter.
1.1.2 These instructions also contain important
information required for safe operation of the filter. All
respirator users and maintenance personnel must be
trained to safely operate and maintain the filter and
respirators. The respirator users and all personnel
involved with the breathing air process must be able to
identify potential hazards associated with breathing
compressed air. Before using the filter, all personnel
involved with the operation must read this entire manual,
including the orange cover, plus the respirator manuals
and all accessory manuals.
1.2 Safety Alerts
1.2.1 Clemco uses safety alert signal words, based on
ANSI Z535.4-1998, to alert the user of a potentially
hazardous situation that may be encountered while
operating this equipment. ANSI’s definitions of the signal
words are as follows:
This is the safety alert symbol. It is used
to alert the user of this equipment of
potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
CAUTION
Caution used without the safety alert symbol
indicates a potentially hazardous situation
which, if not avoided, may result in property
damage.
CAUTION
Caution indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
WARNING
Warning indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
DANGER
Danger indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
1.3 OSHA Compliance
1.3.1 When CPF Filters are used with a NIOSH-
approved supplied-air respirator, meets OSHA regulations
1910.94(a)(6)and 1910.134 (i)(5)(iii), requiring air for
abrasive blasting respirators shall be free of harmful
quantities of dust, mists, and noxious odors. CPF filters
provide a pressure-reducing valve to lower the pressure to
meet the pressure requirements of the respirator,
providing that the filter’s inlet pressure does not exceed
150 psi.
1.3.2 Important information concerning the quality of
compressed air, the use of respirators, and exposure to
hazardous dust is found in OSHA regulations 29 CFR
1910.94, 29 CFR 1910.134 and 29 CFR 1910.1000.
Note regulations 29 CFR 1910.94 and 29CFR1910.134
require that abrasive blasting respirators meet the
requirements for supplied-air quality. For total
compliance, the system must also include a NIOSH-
approved supplied-air respirator.
1.3.3 All supplied-air respirators using non-oil-
lubricated or oil-lubricated compressors shall have a
carbon monoxide monitor to meet the requirements of
CFR 1910.134 (i)(6) and (i)(7).
1.3.4 OSHA regulations 29 CFR1910 and
29CFR1926 require that respirator air line couplers be
incompatible with air lines for non-respirable use. This
prevents inadvertent servicing of respirators with non-
respirable gases or oxygen. It is the employer's or facility
owner's responsibility to comply with the regulation.
1.3.5 The CPF filter is to be used with NIOSH-
approved supplied-air respirators in atmospheres not
immediately dangerous to life or health (IDLH), with as
least 19.5% oxygen, and from which a user can escape
without the use of the respirator.
1.3.6 Breathing air used to supply the filter must be
respirable breathing air and contain no less than 19.5
volume-percent of oxygen. Breathing air shall also meet
the requirements for Grade D or higher quality, as
described in Compressed Gas Association Commodity
Specification pamphlet G-7.1., titled Commodity
Specification For Air, published by Compressed Gas
Association Inc., Chantilly, VA. CGA Website is
cganet.com

CPF 20/80 PARTICULATE AIR FILTER Page 2
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
WARNING
Respirator(s) must be supplied with at least
Grade "D" quality respirable air, containing no
less than 19.5 volume-percent of oxygen.
Breathing air requirements are described in
Compressed Gas Association, G-7.1.,
Commodity Specification For Air, published by
Compressed Gas Association Inc., Chantilly,
VA. CGA Website is cganet.com. If air quality is
unknown, consult a safety professional and/or
industrial hygienist. Poor quality air will cause
serious respiratory injury or death to the user.
1.4 General Description
1.4.1 The CPF is a particulate filter, which removes
mists (including oil mist), water vapor and particulate
matter, down to 0.5 micron in size from breathing air
supplied by a breathing-air compressor. The CPF Filter
does not detect or remove carbon monoxide (CO) or
any other toxic gases. Filter effectiveness and cartridge
life will be reduced considerably if the supplied air is
heavily contaminated with particulate matter or moisture.
1.4.2 The main components of the filters are shown in
Figure 1. The CPF-20 is equipped with an outlet that
supplies filtered air to one or two supplied-air respirators.
The CPF-80 has four outlets, and will accommodate up
to four supplied-air respirators with total air requirement
not to exceed 100 cfm.
WARNING
Respirators are NIOSH-approved to operate
within specific pressure ranges. When
connecting multiple respirators, make sure that
all respirators are approved to operate within
the same pressure range. Operating the
respirator outside of the approved pressure
range will increase or restrict airflow beyond
permissible limits.
1.4.3 Compressed air enters the filter through either of
the two side inlet ports. Moisture condensing inside the
filter is drained through the petcock at the bottom of the
filter body. Air is forced through a replaceable filter
cartridge, which contains several filtering materials,
which traps particulates.
1.4.4 Outlet pressure is adjusted by the knob on the
pressure regulator. Both filters are equipped with a
pressure relief valve. The relief valve is an audible signal
that pressure is exceedingly high.
Figure 1
Respirator Hose Fitting
Respirator Hose Fitting
Plug: Connect an approved
respirator hose fitting here when
connecting a second respirator.
Plug: Connect an approved
respirator hose fitting here
when connecting additional
respirator(s).
Pressure Regulator
Pressure Regulator
Filter Cartridge
Breathing-Air
Supply Inlet
Relief Valve
Strap Handle
Drain
CPF-80
Shown with mounting bracket
configured for wall-mounting
CPF-20
Shown with mounting bracket
configured for freestanding use

CPF 20/80 PARTICULATE AIR FILTER Page 3
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
2.0 ASSEMBLY
2.1 Mounting Bracket
2.1.1 Refer to Figure 2 and attach the mounting
bracket to the four bottom lugs for freestanding, floor
use, or to the four side lugs for wall mounting.
Figure 2
2.2 Regulator Assembly, Ref. Figure 3
NOTE: To ensure air tight seals, use Teflon tape on
all male pipe threads. It is easiest to assemble the
CPF regulator assembly, wrench tight in a vice, and
then screw the assembly onto the cap.
2.2.1 Attach the male end of the 3/8" NPT tee, (cross
manifold on CPF-80) to the pressure regulator outlet port
(see direction of air-flow arrow on the regulator, the inlet
is from the back of the arrow).
Figure 3
2.2.2 Attach a respirator hose fitting that is approved
for use with the respirator (the fitting is supplied with the
respirator hose), to one of the ports on the 3/8" branch
tee (cross manifold on CPF-80). Plug the other port(s)
when connecting a single respirator.
2.2.3 Multiple outlets: When supplying air to additional
respirators, remove as many plugs as required and
replace them with approved hose fittings, up to two on
the CPF-20, up to four on the CPF-80. When multiple
respirators are used with the CPF, they must all be
approved to operate within the same pressure range.
3/8-NC Cap-Screw
3/8-NC Cap-Screw
3/8-NC Nut
3/8-NC Nut
Lockwasher
Flatwasher
Lockwasher
Flatwasher
Hose Fitting
For second
hose
Hose Fitting
3/8"NPT Tee
3/8"NPT Plug
Relief Valve
3/8"NPT Nipple
Pressure Regulator
Gauge
CPF-20
CPF-80
Gauge
Pressure Regulator
Relief Valve
Hose Fitting Hose Fitting
For second
hose
3/8"NPT Plug
3/8"NPT Cross Manifold
3/8"NPT Hex Nipple

CPF 20/80 PARTICULATE AIR FILTER Page 4
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
WARNING
Outlet fittings (the point of attachment) and
respirator hose must be NIOSH-approved for
use with the respirator. Use of non-approved
fittings and hose will void the NIOSH approval
of the respirator, and could restrict air flow. Do
not use any bushings or reducers that reduce
the internal diameter of the plumbing. Reduced
air flow may result in ingress of hazardous
dust, fumes or gases, exposing the user to
immediate health risk and subsequent
respiratory disease and possible death.
2.2.4 Attach the 3/8" x 2" nipple (3/8" hex nipple on
CPF-80) to the regulator inlet port, and tighten the
regulator assembly into the 3/8" port on the filter cap.
Arrange the assembly so the outlet ports of the tee are
accessible, and the regulator control knob is convenient
to adjust.
2.2.5 Screw the pressure gauge into one of the
regulator side ports, and position it so the pressure can
be easily monitored.
2.2.6 Screw the relief valve into the remaining port on
the cap.
3.0 AIR SUPPLY
WARNING
Air supply to this filter is critical to the safety of
the user. Read this section and the respirator
manuals carefully. Poor quality air will cause
serious respiratory injury or death to the user.
(See Toxic Dust Poisoning Warning on page 1.)
3.1 Air Quality
3.1.2 Air supplied to the filter’s inlet must be at least
Grade "D" quality. Special care must also be taken to
avoid accidental connection to any other gas lines, such
as, oxygen, acetylene, or nitrogen.
DANGER
CPF Filters are particulate filters. They do not
remove carbon monoxide or other toxic gases.
Air supplied to the filter inlet must be at least
Grade "D" quality. Never connect the CPF Filter
or any breathing-air line to an air source that has
not been tested for gas contamination. The
presence of unacceptable levels of carbon
monoxide (CO) or other gases, or oxygen
deficiency in the breathing air will cause death to
the user.
WARNING
OSHA regulations 29 CFR 1910 and 29 CFR
1926 require that respirator air line couplers be
incompatible with air lines for non-respirable
use. This incompatibility prevents inadvertent
supply of respirators with potentially
hazardous, non-respirable gases, or oxygen. It
is the employer's or facility owner's
responsibility to comply with the regulations.
3.1.3 Prior to using the filter and respirator, read the
owner's manual and all instructions, labels, and warnings
related to the compressed air source. Take special care to
abide by all warnings from the compressor manufacturer
regarding compressor use.
3.1.4 A breathing-air-type-compressor must be used.
The compressor must be equipped with necessary safety
and monitoring devices, plus suitable in-line air filters and
purifying equipment to assure breathing-air quality.
[Reference OSHA Regulation 1910.134 (d)].
3.1.5 If an oil-lubricated compressor is used, it must be
equipped with a high-temperature alarm or carbon
monoxide (CO) alarm, or both. If only a high-temperature
alarm is used, the air from the compressor must be tested
frequently for the presence of carbon monoxide.
[Reference OSHA Regulation 1910.134 (d)].
3.1.6 Regardless of the air compressor type,
precautions must be taken to prevent contaminants from
entering through the compressor intake. The compressor
inlet must be located away from all sources of toxic
contaminants including carbon monoxide, which is found
in engine exhaust, and in any form of combustion. No
vehicles should be allowed near the compressor intake.
Contaminants can enter respiratory equipment through the
compressor air inlet. This inlet must not be located near
any exhaust system outlet, ventilation flue, or source of
fumes or particles of any kind.

CPF 20/80 PARTICULATE AIR FILTER Page 5
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
3.1.7 The preceding precautions also apply to portable
compressors. In addition, in the case of engine-driven
compressors, precautions must be taken to prevent
engine exhaust gases from entering the air intake of the
compressor. Compressor engine exhaust should be piped
to a location safely downwind from the compressor air
intake. Compressors vary in design and operation;
therefore, it is important that users carefully read the
manufacturer's operation and maintenance instructions
before making modifications.
3.1.8 It is the owner's and user's responsibility to make
sure the air supply is safe to breathe. The air supply
includes the compressor, carbon monoxide alarms, and
shutdown devices. An overheated compressor, or one that
is in poor mechanical condition, may produce carbon
monoxide. A carbon monoxide removal or conversion
system may also be used to ensure breathing-air quality.
The maximum allowable level of carbon monoxide in
Grade D breathing air is 10 ppm (parts per million).
3.2 Air Pressure (Outlet Pressure)
3.2.1 Outlet pressure must be set to the pressure for
which the respirator(s) is designed. Refer to the
respirator owner’s manual to find the approved pressure
setting. All respirators connected to the filter must be
approved to operate within the same pressure range.
WARNING
Failure to maintain the minimum pressure at the
CPF filter outlet (point of attachment) may
reduce air flow below the minimum flow
required by OSHA. Reduced air flow may result
in ingress of hazardous toxic dust, subjecting
the user to immediate health and life
threatening poisoning and subsequent
respiratory disease.
4.0 SETUP
NOTE: The filter must be setup and placed in an area
that permits monitoring of the outlet pressure,
access to the drain, and removal of the cap for filter
cartridge replacement.
4.1 Breathing-Air Connections
4.1.1 Filters can be configured for either left or right
hand inlet. If it is more convenient to have the air inlet on
the opposite side, swap the plug and inlet connector.
This is usually required only with fixed installations.
4.1.2 The following instructions explain air
connections using hose as the air supply line; hard
piping may be used in place of hose. If the filter is hard-
piped, place an isolation valve in the piping to enable
depressurization for service.
4.1.3 Connect an air fitting that is compatible with the
air supply hose, from an air source that meets OSHA
requirements for respirable air, to either of the inlet ports
on the side of the filter. The port’s thread size is 1" NPT.
4.1.4 Connect a 3/4" ID or larger air hose, from a
respirable air source to the inlet fitting. Maximum inlet
pressure is 150 psi.
DANGER
Do not connect the CPF Filter to bottled air or
any other air source that does not have a
pressure-reducing valve that lowers pressure to
maximum of 150 psi. Failure to comply with this
warning will cause the CPF filter to explode
under the high pressure of bottled air, and
could cause severe injury or death.
5.0 ADJUSTMENTS
5.1 Outlet Pressure
5.1.1 Outlet pressure must be set to the pressure for
which the respirator(s) is approved. The respirator’s
approved pressure may be found in the respirator’s
owner’s manual. All respirators connected to a filter must
be approved to operate within the same pressure range.
5.1.2 Adjust pressure with respirators attached and
prior to donning the respirator.
5.1.3 To adjust pressure: pull the regulator knob out,
and turn clockwise to increase pressure or counter-
clockwise to decrease. Pressure will register on the
gauge. Once operating pressure is set, push the knob in
to lock.
6.0 MAINTENANCE
6.1 Draining
6.1.1 Drain moisture from the filter every four hours.
More frequent draining may be required in humid
environments. The drain petcock is located on the
bottom of the filter body.

CPF 20/80 PARTICULATE AIR FILTER Page 6
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
6.2 Filter Cartridge Replacement
6.2.1 Never attempt to clean the filter cartridge.
Replace the filter cartridge at least every three months.
Replace it sooner if:
•Users detect any objectionable odors.
•The filter begins to pass moisture through the
outlets.
•The outlet pressure nears the lowest pressure for
which the respirators are approved.
6.2.2 Before replacing the cartridge, always drain the
filter through the petcock and leave the drain open. Shut
off the compressed air supply to the filter. Make sure
petcock no longer exhausts air and that the pressure
gauge reads zero.
6.2.3 Remove the four nuts that hold cap in place and
lift the cap. Install the new cartridge with the arrow
pointing up. Inspect the cap gasket and o-ring and
replace them as needed.
6.3 Cartridge Replacement Record
6.3.1 Use the chart in Figure 4 to maintain an
accurate record of filter cartridge replacement dates.
Replace the filter cartridge at least every three months
with a genuine Clemco replacement filter cartridge.
Filter Cartridge Replacement Record
Date originally Installed:
Replacement Due Date Date of Replacement
Figure 4
7.0 REPLACEMENT PARTS
Item Description Stock No.
(-) CPF-80 air filter assembly .........................03527
(-) CPF-20 air filter assembly .........................03578
7.1 Common Parts, Figure 5
Item Description Stock No.
1. Cartridge, CPF filter ...................................03547
2. Cap screw, 3/8-NC x 1" hex head .............03252
3. Washer, 1-1/4″OD ....................................03310
4. Nut, 3/8-NC ...............................................03311
5. Petcock, 1/4" .............................................01993
6. Mounting bracket .......................................03557
7. Plug, 1" NPT...............................................03532
8. Washer, 1/2" SAE flat ................................03515
9. Nut, 1/2-NC ...............................................03511
10. Gasket, filter top ........................................03559
11. Washer, 3/8" lock ......................................03318
12. Stud, 1/2-NC x 2" .......................................03545
13. Handle strap ..............................................03623
14. O-ring, cap .................................................03561
Figure 5
10
14
91
8
7
5
2
3
11
4
6
12
13

CPF 20/80 PARTICULATE AIR FILTER Page 7
© 2007 CLEMCO INDUSTRIES CORP •www.clemcoindustries.com •Manual No. 04143
7.2 CPF-20 Cap, Figure 6
Item Description Stock No.
1. Pressure gauge ........................................ 00024
* 2. Tee, 3/8" NPT male branch ...................... 22843
* 3. Nipple, 3/8" NPT x 2" brass ...................... 03720
4. Relief valve, 1/4" NPT ............................... 01909
* 5. Pressure regulator, less gauge
3/8" NPT small body............................... 03594
6. Cap, CPF filter .......................................... 03584
* 7. Plug, 3/8" NPT brass................................. 03536
(-) Regulator kit, converts old style regulator
to new style, includes items marked * ... 03582
Figure 6
7.3 CPF-80 Cap, Figure 7
Item Description Stock No.
1. Pressure gauge ........................................ 00024
* 2. Cross manifold, 3/8" NPT .........................22941
* 3. Nipple, 3/8" NPT hex ................................ 03596
4. Relief valve, 1/4" NPT ...............................01909
* 5. Pressure regulator, less gauge
3/8" NPT large body............................... 22939
6. Cap, CPF filter ..........................................03584
* 7. Plug, 3/8" NPT brass.................................03536
(-) Regulator kit, converts CPF-20 to CPF-80
includes items marked *......................... 22937
(-) Conversion kit, converts old style CPF-80
to new style. Includes items marked*, plus
cap, cap o-ring, and handle strap.
The kit does not include the relief valve
item (4)or gauge item (1)
Order separately if needed..................... 23477
Figure 7
2
5
7
1
3
4
6 1
2 7
5
3
4
6
