Clevo P150EM User manual

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 37. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 73. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 109. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 145. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).

II
Contents
About this Concise User Guide .........................................................1
Instructions for Care and Operation ..................................................2
System Startup ..................................................................................4
RAID Setup (Model C Only) ............................................................5
System Map: Front View with LCD Panel Open .............................7
LED Indicators ..................................................................................8
Keyboard & Function Keys ..............................................................9
Control Center .................................................................................11
System Map: Front, Left, Right & Rear Views (Models A & B) ...14
System Map: Front, Left, Right & Rear Views (Model C) ............15
System Map: Bottom Views ...........................................................16
Video Features ................................................................................17
Power Options .................................................................................18
Audio Features ................................................................................18
Driver Installation ...........................................................................21
PC Camera (Option) .......................................................................23
Wireless LAN Module (Option) .....................................................25
Intel® Wireless Display Application ..............................................26
Fingerprint Reader (Option) ...........................................................28
Bluetooth Module (Option) .............................................................29
Intel® Rapid Storage Technology Driver .......................................30
Intel® Rapid Start Technology Driver ............................................31
Troubleshooting ..............................................................................33
Specifications ..................................................................................34
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................37
Hinweise zu Pflege und Betrieb ......................................................38
Schnellstart ......................................................................................40
RAID Setup (Nur Modell C) ...........................................................41
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ..............................................................................43
LED-Anzeigen ................................................................................44
Tastatur & Funktionstasten .............................................................45
Control Center (Steuerzentrum) ......................................................47
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modelle A & B) .............................................................................50
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modell C) .......................................................................................51
Systemübersicht: Ansicht von unten ...............................................52
Grafikfunktionen .............................................................................53
Energieoptionen ..............................................................................54
Audiofunktionen ..............................................................................54
Installation der Treiber ....................................................................57
PC-Kamera (Option) .......................................................................59
Wireless-LAN-Modul (Option) .......................................................61
Intel® Wireless Display Application ..............................................62
Fingerabdruckleser (Option) ...........................................................64
Bluetooth-Modul (Option) ..............................................................65
Intel® Rapid Storage Technology Driver .......................................66
Intel® Rapid Start Technology Driver ............................................67
Fehlerbehebung ...............................................................................69
Technische Daten ............................................................................70

III
Sommaire
A propos de ce Guide Utilisateur Concis ........................................73
Instructions d’entretien et d’utilisation ...........................................74
Guide de démarrage rapide .............................................................76
Configuration RAID .......................................................................77
Carte du système: Vue de face avec l’écran LCD ouvert ...............79
Indicateurs LED ..............................................................................80
Clavier & touches fonction .............................................................81
Control Center (Centre de contrôle) ...............................................83
Carte du système: Vues de face, gauche, droite & arrière
(Modèles A & B) ............................................................................86
Carte du système: Vues de face, gauche, droite & arrière
(Modèle C) ......................................................................................87
Carte du système: Vues du dessous ................................................88
Caractéristiques vidéo .....................................................................89
Options d’alimentation ....................................................................90
Caractéristiques audio .....................................................................90
Installation du pilote .......................................................................93
Caméra PC ......................................................................................95
Module LAN sans fil (Option) ........................................................97
Application Intel® Wireless Display ..............................................98
Lecteur d'empreintes digitales .......................................................100
Module Bluetooth (Option) ...........................................................101
Intel® Rapid Storage Technology Driver .....................................102
Intel® Rapid Start Technology Driver ..........................................103
Dépannage .....................................................................................105
Spécifications ................................................................................106
Contenidos
Acerca de esta Guía del Usuario Concisa .....................................109
Instrucciones para el cuidado y funcionamiento ...........................110
Guía rápida para empezar ..............................................................112
Configuración RAID (sólo Modelo C) ..........................................113
Mapa del sistema: Vista frontal con panel LCD abierto ...............115
Indicadores LED ...........................................................................116
Teclado & teclas de función ............................117
Control Center (Centro de control) ...............................................119
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelos A & B) ...........................................................................122
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelo C) ....................................................................................123
Mapa del sistema: Vistas inferior ..................................................124
Parámetros de vídeo ......................................................................125
Opciones de energía ......................................................................126
Características de audio .................................................................126
Instalación de controladores ..........................................................129
Cámara PC .....................................................................................131
Módulo LAN Wireless (Opción) ...................................................133
Intel® Wireless Display Application ............................................134
Lector de huellas digitales .............................................................136
Módulo Bluetooth (Opción) ..........................................................137
Intel® Rapid Storage Technology Driver .....................................138
Intel® Rapid Start Technology Driver ..........................................139
Solución de problemas ..................................................................141
Especificaciones ............................................................................142

IV
Sommario
Informazioni sulla Guida Rapida per l'Utente ..............................145
Istruzioni per la custodia e il funzionamento ................................146
Guida di avvio rapido ....................................................................148
Configuración RAID (sólo Modelo C) .........................................149
Descrizione del sistema: Vista anteriore con pannello LCD
aperto .............................................................................................151
Indicatori LED ..............................................................................152
Tastiera & tasti funzione ...............................................................153
Control Center (Centro di controllo) .............................................155
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modelli A & B) ............................................................................158
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modello C) ...................................................................................159
Descrizione del sistema: Vista inferiore .......................................160
Funzioni video ..............................................................................161
Opzioni risparmio energia .............................................................162
Funzionalità audio .........................................................................162
Installazione driver ........................................................................165
Camera PC ....................................................................................167
Modulo LAN Wireless (Opzione) ................................................169
Intel® Wireless Display Application ............................................170
Lettore d’impronte digitali ............................................................172
Modulo Bluetooth (Opzione) ........................................................173
Intel® Rapid Storage Technology Driver .....................................174
Intel® Rapid Start Technology Driver ..........................................175
Risoluzione dei problemi ..............................................................177
Specifiche tecniche .......................................................................178

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’sManual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information
contained in the expanded User’s Manual on the Device Drivers & Utilities + Us-
er’s Manual disc.
© February 2012
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Oper-
ation
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the case
and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and power
supply away from any kind of heating element. This is an electrical
appliance. If water or any other liquid gets into it, the computer
could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
• Note that in computer’s featuring a raised LCD electro-plated logo,
the logo is covered by a protective adhesive. Due to general wear
and tear, this adhesive may deteriorate over time and the exposed
logo may develop sharp edges. Be careful when handling the com-
puter in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may
rub against the top of the computer during transport. If any such
wear and tear develops contact your service center.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel but it
still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service rep-
resentative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible
outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it
by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or
replacement to your service representative or qualified service personnel.
• Keep children away from, and promptly dispose of a damaged bat-
tery. Always dispose of batteries carefully. Batteries may explode
or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check with
local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal objects.

3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries. Do
not use polymer batteries in high ambient temperature environ-
ments, and do not store unused batteries for extended periods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners on
any part of the computer.
• Before cleaning the computer remove the battery and make sure the
computer is disconnected from any external power supplies,
peripherals and cables (including telephone lines).
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the oper-
ating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.

Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end ofits use-
ful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discard used battery according to the
manufacturer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and tighten the screws.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack at the rear of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the lid/LCD to a comfortable viewing
angle (do not to exceed 135 degrees);
use the other hand (as
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
Model Differences
This notebook series includes three different model types
that mainly differ as indicated in the table below.
Table 1 - Model Differences
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 7.
135 ﾟ
Figure 1
Opening the Lid/LCD/
Computer with AC/DC
Adapter Plugged-In
Feature Model A Model B Model C
Video Adapt-
ers Supported See Specifications on page 34 for a full list of
video adapters supported by each model.
Display Type 15.6" (39.62cm) FHD (1920 *
1080)
17.3"
(43.94cm)
FHD (1920 *
1080)
Illuminated
Keyboard Yes No Yes
RAID Not Supported RAID Level 0/
1/Recovery
Supported
AC/DC
Adapter 19V, 9.47A
(180W)19V, 6.3A (120W)19V, 11.57A (220W)

5
English
RAID Setup (Model C Only)
You may use your hard disks in combination with Striping
(RAID 0), Mirroring (RAID 1), or Recovery for either
fault tolerance or performance.
Table 2 - RAID Description
Prepare the following before setting up your serial ATA
hard disks in RAID mode:
•TheMicrosoft Windows OS disc.
•TheDevice Drivers & Utilities + User’s Manual disc.
Note: All hard disks in a RAID should be identical (the
same size and brand) in order to prevent unexpected sys-
tem behavior.
RAID Setup Procedure
Part I: BIOS
1. Start-up your computer and press F2 to enter the BIOS.
2. Go to the Advanced menu, select SATA Mode and press
Enter.
3. Select RAID Mode.
4. Press Esc and go to the Boot menu.
5. Set the CD/DVD-ROM Drive (make sure the Microsoft
Windows OS disc is inserted) as the first device in the boot
order from the Boot menu.
6. Select Save Changes and Reset from the Exit menu (or press
F4) and press Enter to exit the BIOS and reboot the computer.
RAID Level Description
RAID 0
(at lease two
hard disks
needed)
Identical drives reading and writing data in paral-
lel to increase performance. RAID 0 imple-
ments a striped disk array and the data is broken
into blocks and each block is written to a sepa-
rate disk drive.
RAID 0 (a striped array) is not fault-tolerant. The
failure of one drive will result in the loss of all
data in the array.
RAID 1
(at lease two
hard disks
needed)
Identical drives in a mirrored configuration used
to protect data. Should a drive that is part of a
mirrored array fail, the mirrored drive (which
contains identical data) will handle all the data.
When a new replacement drive is installed, data
to the new drive is rebuilt from the mirrored drive
to restore fault tolerance.
RAID 1 (mirrored array) provides full data pro-
tection, as data can simply be copied from a
healthy disk to a replacement for any failed disk.
Recovery
(at lease two
hard disks
needed)
Two identical drives copying data between a
master and a recovery disk. This provides more
control over how data is copied between the
master and recovery drives, fast volume
updates and the ability to view the data in Win-
dows Explorer.

6
English
Part II: Intel Matrix
1. Press Ctrl + i to enter RAID configuration menu.
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to
advance to the next field.
4. Specify (use the up and down arrow keys) the RAID level
(RAID 0 or RAID 1 or Recovery - see Table 2) and then press
Tab or Enter to advance to the next field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to
default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by
pressing Y.
10. This will now return to the main menu.
11. Select 6.Exit and press Enter, then press Y to exit the RAID
configuration menu.
12. Make sure the Windows 7 OS DVD is in the DVD drive and as
the computer starts up it will automatically boot from the
Windows 7 OS DVD (you will be prompted to press a key to
boot from the DVD).
13. Press Enter to continue installing the operating system as
normal (see your Windows documentation if you need help on
installing the Windows OS).
Figure 2
RAID
Created

7
English
System Map: Front View with LCD Panel Open
2
1
89
7
3
6
5
45
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
8
Figure 3
Front View with LCD
Panel Open
1. PC Camera (Optional)
2. LCD
3. LED Indicators
4. Power Button
5. Speakers
6. Keyboard
7. Built-In Microphone
8. Touchpad and Buttons
9. Fingerprint Reader
(Optional)
3
2
1
8
9
7
6
54
5
3
Models A & B
15.6” (39.62cm)
17.3” (43.94cm)
Model C

Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission devices (e.g. WLAN or Bluetooth) aboard air-
craft is usually prohibited. Make sure any wireless modules are OFF if you are using the com-
puter aboard aircraft.
Use the appropriate function key combination to toggle power to any wireless modules, and
check the indicators to see if any modules are powered on or not (see Table 3 on page 8).

8
English
LED Indicators
The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Table 3 - LED Status Indicators
Table 4 - LED Power Indicators
*The powered USB 3.0 port may be toggled on /off by
means of the Fn + Power Button key combination. When
the powered USB port is on it will supply power when the
system is off but still powered by the AC/DC adapter
plugged into a working outlet (this may not work with cer-
tain devices - see
page 33).
Icon Color (Models A
& B)
Color
(Model C) Description
Blue White Number Lock (Numeric
Keypad) Activated
Blue White Caps Lock Activated
Blue White Scroll Lock Activated
Blue White Hard Disk Activity
Blue White Wireless LAN Module
Power Toggle
Blue Orange Bluetooth Module Power
Toggle
Models A & B Model C
Icon Color Description
Orange The AC/DC Adapter is Plugged In
Blinking
Orange* The AC/DC adapter is plugged in and the powered USB Port is on*
Green The Computer is On
Blinking
Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange The Battery Has Reached Critically Low Power Status

9
English
Keyboard & Function Keys
The keyboard includes a numeric keypad for easy numeric data input. Pressing Fn + NumLk turns on/off the numeric
keypad. It also features function keys to allow you to change operational features instantly. The function keys (F1 -
F12 etc.) will act as hot keys when pressed while Fn is held down. In addition to the basic function key combinations,
visual indicators are available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F11 WLAN Module Power
Toggle
Fn + F1 Touchpad Toggle Fn + F12 Bluetooth Module
Power Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Fn + NumLk Number Lock Toggle
Fn + F3 Mute Toggle Fn + ScrLk Scroll Lock Toggle
Fn + F4 Sleep Toggle Caps Lock Caps Lock Toggle
Fn + F5/F6 Volume Decrease/
Increase Fn + Power Button Powered USB Port Power Toggle (see page 14)
Fn + F7 Display Toggle Fn + Esc Control Center Toggle (see page 11)
Fn + F8/F9 Brightness Decrease/
Increase Fn + Keyboard LED Toggle (see page 10)
Fn + F10 PC Camera Power
Toggle Table 5 - Function Keys & Visual Indicators
Function Keys
Numeric
Keypad
Fn Key
ScrLk &
NumLk
Figure 4 - Keyboard
Models A & C Model B
Function Keys
Numeric
Keypad
Fn Key
ScrLk &
NumLk

10
English
Keyboard LED (Models A & C Only)
Press Fn plus the key to toggle the keyboard LED on/
off. The keyboard LED may be configured using the Fn +
key combination outlined in the table below. In addition
press Fnplus the key to launch the keyboard backlight
application to configure the settings.
Table 6 - Keyboard LEDs
Keyboard Backlight Application
The Keyboard Backlight application can be accessed by
pressing the Fn plus key. Click the Help button in
the application to display the configuration keys.
• Click the Custom button to display the three sections
of the keyboard which may be configured.
• Click a section of the keyboard and the color buttons will
be displayed.
• Click a color swatch to apply the color to the selected sec-
tion when not overidden by any effect applied.
• Click on any of the effect buttons to apply random colors,
wave or flashing effects etc.
Figure 5 - Keyboard Backlight Application
Effects Buttons & Help
Table 7 - LED Effects Buttons
Keyboard LED Function key Combinations
Fn + Toggle the
Keyboard LED
On/Off
Fn + *KeyboardLED
Illumination
Decrease
Fn + *KeyboardLED
Illumination
Increase
Fn + Keyboard LED
Color Toggle

*Illumination Keys
Note that the keyboard il-
lumination (increase/de-
crease) keys may be
used to configure the key-
board LED in Custom
Mode only.
LED Effects Buttons
Random Color Up/Down Wave
Dancing Effect Breathing (All Colors)
Tempo Beat Cycle (Colors as Selected in
RGB)
Flashing Custom - Display & Configure
Keyboard Sections & Colors
Help Button
Keyboard Sections
Effects Buttons
Color Swatches

11
English
Control Center
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the
Control Center on/off. The Control Center gives quick access to frequently used controls, and enables you to quickly
turn modules on/off.
Figure 6 - Control Center
Click on any button to turn any of the modules (e.g. Touchpad, Camera) on/off. Click on Power Conservation Modes
to switch between Performance, Balanced or Energy Star modes. To remove the Power Conservation Modes screen
just click in a blank area of the icon or press a key on the keyboard. Click on the buttons (or just click and hold the mouse
button) to adjust the slider for Brightness/Volume. Click on Display Switch/Time Zone/ Desktop Background
to bring up the appropriate Windows control panel. Click on the Sleep button to put the computer into Hibernate
or Sleep modes.

12
English
Power Modes
You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will
affect the power status of modules (e.g. WLAN or Camera), screen brightness, Touchpad power and Silent Mode. You
can click a Control Center icon to set an overall power mode and then click individual icons in the Control Center to
power on/off any modules etc.
Table 8 illustrates the basic settings for each power mode. If you choose User Defined the settings will correspond to
your selected system settings.
Table 8 - Power Modes
Modes Power Saving Flight Entertainment Quiet Performance User Defined
Icon
Power Plan Power Saver Balanced Power Saver Power Saver High Perfor-
mance
User Defined
Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance
Brightness 14 42 100 42 100
WLAN OFF OFF ON ON ON
PC Camera OFF OFF OFF ON ON
Touchpad ON ON OFF ON ON

13
English
Power Status
The Power Status icon will show
whether you are currently powered by
the battery, or by the AC/DC adapter
plugged in to a working power outlet.
The power status bar will show the
current battery charge state.
Brightness
The Brightness icon will show the
current screen brightness level. You
can use the slider to adjust the screen
brightness or the Fn+ F8/F9key com-
binations, or use the Fn + F2 key com-
bination to turn off the LED backlight
(press any key to turn it on again).
Note that screen brightness is also ef-
fected by the Power Mode selected.
Volume
The Volume icon will show the cur-
rent volume level. You can use the
slider to adjust the Volume or the Fn +
F5/F6 key combinations, or use the
Fn + F4 key combination to mute the
volume.
Power Conservation
This system supports Energy Star
power management features that place
computers (CPU, hard drive, etc.) into
a low-power sleep modes after a des-
ignated period of inactivity. Click ei-
ther the Performance, Balanced or
Energy Star button. Click in a blank
area of the icon or press a key on the
keyboard to exit Power Conservation
Mode without making any changes.
Sleep
Click the Sleep button to bring up the
Hibernate or Sleep buttons,
and click either button to have the
computer enter the appropriate power-
saving mode. Click in a blank area of
the icon or press a key onthe keyboard
to exit Power Conservation Mode
without making any changes.
Display Switch
Click the Display Switch button to ac-
cess the menu (or use the + P key
combination) and select the appropri-
ate attached display mode.
Time Zone
Clicking the Time Zone button will
access the Date and Time Windows
control panel.
Desktop Background
Clicking the Desktop Background
button will allow you to change the
desktop background picture.
K/B LED
Click to access the keyboard setting
control to configure the keyboard
LED.
TouchPad/PC Camera/Wireless
LAN Module /Bluetooth Module
Click any of these buttons to toggle
the TouchPad or module’s power sta-
tus. A crossed out icon will appear
over the top left of the icon when
it is off. Note that the power status of a
module, and TouchPad power, is also
effected by the Power Mode selected.

14
English
System Map: Front, Left, Right & Rear Views (Models A & B)
4
7
56
1
23
Front
Left
Right
10 11 13
12

USB
The USB 3.0 ports are colored blue. USB 3.0 will transfer data much faster than USB 2.0,
and is backwards-compatible with USB 2.0. When the powered USB 3.0 port is on it will
supply power (for charging devices only, not for operating devices) when the system is
off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the
battery with a capacity level above 20% (this may not work with certain devices - see page
33). Toggle power to this port by using Fn + power button.
4
5
8
4
15 17
14
16 15
Rear
18 19
Figure 7
Front, Left, Right & Rear
Views (Models A & B)
1. LED Power Indicators
2. Mini-IEEE 1394a Port
3. RJ-45 LAN Jack
4. USB 3.0 Ports
5. Combined eSATA/Powered
USB 3.0 Port (See Below)
6. Multi-in-1 Card Reader
7. Optical Device Drive Bay
8. Emergency Eject Hole
9. Headphone Jack
10. Microphone Jack
11. S/PDIF-Out Jack
12. Line-In Jack
13. USB 2.0 Port
14. Security Lock Slot
15. Vent
16. Display Port
17. HDMI-Out Port
18. DVI-Out Port
19. DC-In Jack
9
