Climax TSP-3 User manual

TSP-3
Touchscreen Keypad
User Manual
June, 2020

Table of Contents
INTRODUCTION _____________________________________________________________________- 1 -
1. SYSTEM OVERVIEW_______________________________________________________________ 2
1.1. PARTS IDENTIFICATION ___________________________________________________________ 2
1.2. POWER SUPPLY ________________________________________________________________ 3
2. GETTING STARTED _______________________________________________________________ 3
2.1. EQUIPMENT REQUIRED____________________________________________________________ 3
2.2. SETUP _______________________________________________________________________ 3
2.3. HARDWARE INSTALLATION_________________________________________________________ 6
2.4. LOW BATTERY NOTIFICATION ______________________________________________________ 9
3. OPERATION_____________________________________________________________________ 10
3.1. HOME _______________________________________________________________________ 10
3.2. SECURITY ____________________________________________________________________ 13
3.3. HOME AUTOMATION DEVICES _____________________________________________________ 18
3.4. EVENTS______________________________________________________________________ 21
3.5. SETTINGS ____________________________________________________________________ 22

2
Introduction
The Touchscreen Keypad provides easy-to-use, on-premises security system control for
enhanced flexibility and convenience.
When connected to the system Control Panel via Wi-Fi network, the Touchscreen Keypad
enables quick access to the Control Panel, allowing users to easily arm, disarm, or home arm
their security system and control home devices.
1.System Overview
1.1. Parts Identification
1. Camera
Slide up or down the switch to reveal or hide the camera.
2. Power Button
3. Micro USB Port
4. Micro SD Card Slot
5. Earphone Jack
6. Cable Managing Space
7. Notch
8. Desktop Deployment Bracket
9. Wall Mounting Bracket
1.2. Power Supply
The Touchscreen Keypad is powered by rechargeable battery. To
charge the battery, press the latch to open the compartment and
plug in a 5V/1.5A adapter to the Micro USB port of the device and
connect the other end to mains power.

3
2. Getting Started
2.1. Equipment required
The following equipment is required to use your Touchscreen Keypad:
Arouter supporting 2.4 GHz Wi-Fi network. The hub should be connected to this router with
access to internet.
2.2. Setup
To set up your Touchscreen Keypad for accessing hub:
Step 1. Power on the Touchscreen Keypad.
Step 2. Select the WiFi SSID of the router that hub is connected to. Enter the WiFi network
password if required, and click “OK”.

4
Step 3. Put your Hub into learning mode (refer to Hub’s user manual for details). Please note
that Learning process is only required for first time setup.
Step 4. Your Touchscreen Keypad will automatically search for available hubs. Select the hub
you’d like to access to.
<NOTE>
The Touchscreen Keypad is compatible with Climax Video Door Phone and IP
Camera. Up to 6 IP Cameras and VDPs are supported. Ensure to update
device and panel firmware to the latest version for compatibility.
Ensure your Control Panel, VDP, and Touchscreen Keypad are in the
same Local Area Network (LAN). Moreover, both of the VDP and
Touchscreen Keypad should be added into the same Control Panel, or the
devices will not be identified.
Step 5. You will enter the dashboard that displays the current date and time. Now you can
access and control your Hub and smart devices directly on your Touchscreen Keypad.

5
2.3. Hardware Installation
2.3.1 Installation Instructions
There are two mounting options available for installing the Touchscreen Keypad. Users can
choose to install their device anywhere in their home or office to suit their needs. Moreover, a
wall mounting bracket is also provided to enhance installation flexibility for uses to install the
Touchscreen Keypad at a particular place.
Desktop Deployment
A desktop deployment bracket is provided for users to place their Touchscreen Keypad at a
desired place. Please follow steps below:
Step 1. Attach the desktop deployment bracket to the rear side of the Touchscreen .Keypad .in
the direction of the arrows as shown below until you hear a “click” .sound. If you .wish to
remove the bracket, simply press the notches at both sides .and gently lift upward.

6
Step 2. Place the Touchscreen Keypad at desired location.
Wall Mounting
A wall mounting bracket is also included for users to place their Touchscreen Keypad at a fixed
place when not in use. Please follow steps below:
Step 1. Use the three mounting holes on the bracket as template to drill holes.
Step 2. Insert the wall plugs if fixing into plaster or brick.
Step 3. Screw the bracket into the wall with the 3 screws provided.
Step 4. Attach the Touchscreen Keypad onto the bracket.

7
Step 5. Hold the Touchscreen Keypad and gently push downwards until you hear a “click”
sound.

8
2.4. Low Battery Notification
When battery is running low, a low battery notification will be displayed to inform you to recharge
the battery. Please refer to Power Supply to recharge the Touchscreen Keypad.

9
3.Operation
3.1. Home
Date & Time: The Home page displays current Date & Time.
Home Widget : The Home Widget list is for you to control or check currents status of
the HVAC sensors or devices which have been learned into the system.
To set the list:
Step 1. Tap the Home Widget icon. Check the devices that you are going to display on the
list. Up to six devices can be displayed here.

10
Step 2. When finishing selecting the devices, tap OK to confirm.
Step 3. The devices that you selected are displayed on the widget list.
Step 4. Tap the widget that you want to check. When there is a fault or supervision failure,
an orange exclamation mark icon will be displayed on the widget. The color of the
widget will also fade.

11
3.2. Security
The current system status is displayed on top of the screen.
System Mode: The system mode is indicated by the 3 icons at top. The current system
mode will light up. When a user disarms the system, the Touchscreen Keypad will take a
photo and the image can be viewed in the Event page.
Sensors: Sensors that report burglar alarm will be displayed on the list below. By tapping
the icon of video recording / photographing, you can control the device to record a video or
take a picture.
Previous & Next :: Tap these two icons to view the system status and the sensors of
Area 1 and 2.
Fault list : Tap the icon to view the fault list of the system. The number of the faults will
be also indicated via the number badge.

12
3.2.1. Change System Mode
Tap the desired mode icon and enter the PIN code. You will be required to enter one of the
Control Panel User PIN Code to confirm the action.
If incorrect PIN Code is entered, the Touchscreen Keypad will display error message and
arming will be aborted.

13
If the system has existing fault events when arming, the Touchscreen Keypad will display
fault message. Tap OK to view the fault list.
By checking all faults and tapping “Bypass”, the faults are bypassed and the system is
armed now.

14
3.2.2. Alarm Dashboard
When there is an alarm, the Alarm dashboard will be displayed:
Area: It will be indicated that the alarm is occurred in area 1 and/or area 2. When there are
alarms in both areas, you can tap the icon to view the alarm list for each area respectively.
Alarm list: The devices have been triggered will be displayed here.
Disarm: Tap the icon and then enter the PIN code to disarm the system.

15
After disarming the system, you can view these events again through the list. Tap the Close
icon to close the alarm dashboard and go back to Security page.
3.3. Home Automation Devices
Home Automation devices are displayed under different tabs according to following
categories: All, Switch, Lock, and HVAC. The device list under the category tab displays all
available devices according to each different category. Tap the device category tab to view the
devices.

16
All: All devices are displayed.
Switch: Power Switch and Relay Switch.
Lock: Door Lock.
HVAC: Temperature control related devices, such as Thermostat, and Thermostatic
Radiator Valve.
The device list displays device information:
Device Status will be displayed in each device column.
Switch type device will display current on/off condition.
Lock will display Locked/Unlocked status.
Dimmer will display current power output level.
Temperature and Humidity sensor will display temperature and humidity reading.
Tap some device columns to control the device:
For Switch or Locks, click the ON/OFF or LOCK/UNLOCK icon to toggle its status.
For Dimmer, either click the ON/OFF icon to toggle or click the bar to adjust the output
percentage.
For some devices with more detailed control options, click the icon to enter the
device’s own control page.

17
For Thermostat, click the icon to access configuration page:
The current temperature is displayed on the center. The mode set points are
displayed on the bar at the bottom. Toggle the bar to increase or decrease the mode
set point.
On/Off button: Turn on/off of the Thermostat.
Away button: Toggle the button to put the TMST into Away mode.
Schedule button: Enable/Disable the Schedule operation:
Enable: The Thermostat will operate according to schedule configuration.
Disable: The Thermostat will ignore all programmed schedule setting.
Fan switch button: Turn on the Fan manually, or set Fan to Auto.
Heat/Cool/Auto mode button: Press and hold the button to change the mode.

18
For Thermostatic Radiator Valve, click the icon to access its configuration page:
The current temperature is displayed on the center. The mode set points are
displayed on the bar at the bottom. Toggle the bar to increase or decrease the
mode set point.
On/Off button: Turn on/off of the Thermostatic Radiator Valve.
Schedule button: Enable/Disable the Schedule operation:
Enable: The Thermostatic Radiator Valve will operate according to schedule
configuration.
Disable: The Thermostatic Radiator Valve will ignore all programmed schedule
setting.

19
3.4. Events
The Event page records all alarm/status event, pictures and video transmitted by the Control
Panel. You can view the image or video by tapping the icons.
