Storm AXS Code Master User manual

Fixing instructions
(Please read carefully before attempting installation.)
Rear Casing
1. Select a suitable location with a sound flat surface. Using the case as a template, mark the position
of the four fixing holes (A) on the surface.
2. Drill and plug the fixing holes to suit fixing screws (E) as supplied.
3. Locate the thicker 6mm thick sealing gasket (B) on the rear face of the case before positioning the
case over the fixing holes (A).
4. Secure the case to the surface using suitable fixing screws (E) (as supplied).
Keypad to Casing
5. When making the electrical connections to the connector block care should be taken not to damage
the thin sealing gasket (C) fixed to the front face of the rear case. [For connection details see section iii)
of this manual].
6. Fix the keypad to the case using the thread forming security screws
(D) as supplied. (Please ensure the nylon sealing washers are located
beneath the head of the security screws (D). Please note a special key
is provided for tightening these screws.
7. Check the installation to ensure gaskets are in place
and compressed evenly around the perimeter of the case.
Note: On rough or uneven surfaces it may be
necessary to apply a bead of silicone
sealant around the inner face of the case
at the point where it meets the
mounting surface. Where
this method of sealing is
necessary the thicker
sealing gasket (B)
must not be fitted.
13
2
6
5
4
79
8
0
ii) INSTALLATION INSTRUCTIONS
Storm AXS Code Master keypads convert codes entered via the keypad into industry standard 26 bit or
32 bit (Weigand) data. They are suitable for use as a replacement for, or in conjunction with, most
standard card readers that form part of an integrated access control / security system. All keypads in the
range will accept either a +5V or +12V DC supply. Door / system status is indicated by a high intensity
LED light source and an audible sounder. The sounder can be deselected for installations where audible
signals would be disruptive or considered an annoyance. StormAXS Code Master keypads are specified
to survive in different service environments ranging form exposed, unsupervised public locations to
general service outdoor / indoor installations.All StormAXS Code Master keypads are dimensionally and
electrically interchangeable. This allows users, entering codes at all outdoor or indoor access points, to
establish and maintain familiarity with the keypad features.
t m r o
Secure Keypads
for access control
®
i) INTRODUCTION
Code Master
A
B
C
D
E
• Two protection levels
– anti vandal keypad for unsupervised
public, outdoor locations
– robust keypad for general
outdoor / indoor locations
• 26 bit or 32 bit data output
• Selectable ‘keypress’ audible tone
• Selectable ‘code accepted’ audible tone
• LED and audible tone status indication
• Requires +5V or +12V DC supply
• All weather resistant
WES-MAN ISS.2

Table 1
Configuration 32 bit 26 bit Key press Code accept Audible Tone
Codes Communication Communication Audible Tone Audible Tone Disabled
0✔ ✔
1✔✔
2✔✔
3✔✔✔
4✔✔
5✔✔
6✔✔
7✔✔✔
Default settings
Site Code.....................................................00000 (Unless site code is allocated at time of sale.)
Setting the site code
In everyday operation the keypad is in code entry mode. To configure the keypad or set / reset the site code,
the keypad must be in programming mode. To enter programming mode, power up the keypad and within
one minute enter the code ‘725’. The LED on the keypad should start to flash. Now enter the 5 digit site code
that the keypad is to use, including any leading zeros. If the unit is to be configured to provide 32 bit
communication then the site code must be less than or equal to ‘65535’. For 26 bit communication the site
code must be less than or equal to ‘00255’. After the site code has been entered the configuration code (0-
7, as detailed in table 1) can be entered. After a valid configuration code has been entered the unit will give
a (rising tone) OK bleep and the LED will stop flashing and return to code entry mode.
If the site code entered is invalid (for 32 bit comms) the unit will give a (decreasing tone) error bleep and the
LED will continue flashing. If this happens try entering the site code again. (Please note that if an invalid site
code for 26 bit comms has been entered no audible or visual warning can be given.)
The Storm keypad will store the site code and configuration code even if the unit is powered down.
Note:
In use, the site code will be transmitted automatically each time a valid entry code is keyed
in to the keypad.
iv) CONFIGURING THE KEYPAD
System
5. Indicator input (LED audible sounder)
4.Weigand data 1
3.Weigand data 0
2. Supply
Range +5V to +12V DC
1. Retun Zero volts
Note: To achieve maximum protection against EMC, RFI, or damage from Electro-static Discharge it is recommended that the keypad casing is
earthed (grounded) via the screw terminal attached to the metal shield on the rear face of the keypad. This terminal is identified by a symbol.
It is recommended that a regulated, fully isolated power supply is used to power the StrikeMaster keypad. (Keymat Technology part no.
DEPS0101 or DEPS0201 or equivalent). Bifular wound supplies are not recommended.
To operate the keypad whilst in code entry mode simply enter a 5 digit entry code (<=65535). The access
control or security system will respond as though a card with that number had been swiped through a
weigand card reader. If an entry code of less than 5 digits is entered and then the ‘# enter’key is pressed
the keypad will transmit the digits entered prefixed by zeros to achieve a 5 digit entry code. For example,
if the code ‘321’ is entered and then the ‘# enter’ key is pressed, the entry code ‘00321’ will be
transmitted.
If a 5 digit entry code greater than ‘65535’ is entered, or if there was a pause between digits of more
than 15 seconds than the keypad will give an error bleep and the code will have to be re-entered.
v) ENTRY CODES
iii) ELECTRICAL AND DATA CONNECTIONS
2
Note: The keypad’s buzzer will sound and its LED
will illuminate (green) whenever the indicator input
on the keypad is connected to zero volts (return).
Connect to access
control / security system
(refer to manufacturer’s
instructions for
connection details).
WES-MAN ISS.2
For 32 bit communication, valid codes comprise 16 bit (site code) and 16 bit (entry code). For 26 bit communication valid codes
comprise 8 bit (site code) and 16 bit (entry code), with a leading and trailing parity bit.
Whilst every effort is made to ensure that information given in this document is correct at time of print, Keymat Technology Ltd. can not
be held responsible for any errors contained within.
STORM , AXS, STRIKE MASTER & CODE MASTER are trademarks of Keymat Technology Ltd, England.
