Climax BB4500 User manual

BB4500-
BB5000
BORING MACHINE
OPERATING MANUAL
ORIGINAL INSTRUCTIONS
P/N 92974
June 2019
Revision 1
BB4500
BB5000

P/N 92974, Rev. 1 Page A
©2019 CLIMAX or its subsidiaries.
All rights reserved.
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, dissem-
inated, downloaded, or stored in any storage medium, without the express prior written consent of CLIMAX.
CLIMAX hereby grants permission to download a single copy of this manual and of any revision hereto onto
an electronic storage medium to be viewed and to print one copy of this manual or any revision hereto, pro-
vided that such electronic or printed copy of this manual or revision must contain the complete text of this
copyright notice and provided further that any unauthorized commercial distribution of this manual or any
revision hereto is prohibited.
At CLIMAX, we value your opinion.
For comments or questions about this manual or other CLIMAX documentation, please e-mail
[e-mail].
For comments or questions about CLIMAX products or services, please call CLIMAX or e-mail
[email protected]. For quick and accurate service, please provide your representative with the following:
• Your name
• Shipping address
• Telephone number
• Machine model
• Serial number (if applicable)
• Date of purchase
CLIMAX World Headquarters
2712 East 2nd Street
Newberg, Oregon 97132 USA
Telephone (worldwide): [phone]
Toll-free (North America): 1-800-333-8311
Fax: [phone]
H&S Tool World Headquarters
715 Weber Dr.
Wadsworth, OH 44281 USA
Telephone: [phone]
Fax: [phone]
hstool.com
CLIMAX | H&S Tool (UK Headquarters)
Unit 7 Castlehill Industrial Estate
Bredbury Industrial Park
Horsfield Way
Stockport SK6 2SU, UK
Telephone: [phone]
CLIMAX | H&S Tool (European Headquarters)
Am Langen Graben 8
52353 Düren, Germany
Telephone: [phone]
E-mail: [e-mail]
CLIMAX | H&S Tool (Asia Pacific Head-
quarters)
316 Tanglin Road #02-01
Singapore 247978
Telephone: [phone]
Fax: [phone]
CLIMAX | H&S Tool (Middle East Headquarters)
Warehouse #5, Plot: 369 272
Um Sequim Road
Al Quoz 4
PO Box 414 084
Dubai, UAE
Telephone: [phone]

Page B BB4500-BB5000 Operating Manual
CLIMAX GLOBAL LOCATIONS

P/N 92974, Rev. 1 Page C
CE DOCUMENTATION

Page D BB4500-BB5000 Operating Manual
LIMITED WARRANTY
CLIMAX Portable Machine Tools, Inc. (hereafter referred to as “CLIMAX”) warrants that all new machines
are free from defects in materials and workmanship. This warranty is available to the original purchaser for a
period of one year after delivery. If the original purchaser finds any defect in materials or workmanship
within the warranty period, the original purchaser should contact its factory representative and return the
entire machine, shipping prepaid, to the factory. CLIMAX will, at its option, either repair or replace the
defective machine at no charge and will return the machine with shipping prepaid.
CLIMAX warrants that all parts are free from defects in materials and workmanship, and that all labor has
been performed properly. This warranty is available to the customer purchasing parts or labor for a period of
90 days after delivery of the part or repaired machine or 180 days on used machines and components. If the
customer purchasing parts or labor finds any defect in materials or workmanship within the warranty period,
the purchaser should contact its factory representative and return the part or repaired machine, shipping pre-
paid, to the factory. CLIMAX will, at its option, either repair or replace the defective part and/ or correct any
defect in the labor performed, both at no charge, and return the part or repaired machine shipping prepaid.
These warranties do not apply to the following:
• Damage after the date of shipment not caused by defects in materials or workmanship
• Damage caused by improper or inadequate machine maintenance
• Damage caused by unauthorized machine modification or repair
• Damage caused by machine abuse
• Damage caused by using the machine beyond its rated capacity
All other warranties, express or implied, including without limitation the warranties of merchantability and
fitness for a particular purpose are disclaimed and excluded.
Terms of sale
Be sure to review the terms of sale which appear on the reverse side of your invoice. These terms control and
limit your rights with respect to the goods purchased from CLIMAX.
About this manual
CLIMAX provides the contents of this manual in good faith as a guideline to the operator. CLIMAX cannot
guarantee that the information contained in this manual is correct for applications other than the application
described in this manual. Product specifications are subject to change without notice.

P/N 92974, Rev. 1 Page i
TABLE OF CONTENTS
CHAPTER/SECTION PAGE
1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 HOW TO USE THIS MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 SAFETY ALERTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 GENERAL SAFETY PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4 MACHINE-SPECIFIC SAFETY PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 RISK ASSESSMENT AND HAZARD MITIGATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.6 RISK ASSESSMENT CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.7 LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.1 Label identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.7.2 BB4500-BB5000 label locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 BB4500 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 BB5000 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.1 Rotational drive unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3.2 Axial feed unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.3 Leadscrew. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.4 BB4500 tool heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.5 BB5000 tool heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3.6 BB4500 boring bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3.7 BB5000 boring bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3.8 Spherical bearing mounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 CONTROLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4.1 Hydraulic power unit and hydraulic motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4.2 BB5000 servo motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.4.3 Electric motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.4.4 Air motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.4.5 Pneumatic conditioning unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.5 DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.6 SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.6.1 Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.7 ITEMS REQUIRED BUT NOT SUPPLIED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3 SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.1 RECEIPT AND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2 LIFTING AND RIGGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3 MACHINE ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Page ii BB4500-BB5000 Operating Manual
TABLE OF CONTENTS (CONTINUED)
CHAPTER/SECTION PAGE
3.3.1 Bar and mounting bracket assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.3.2 Tooling and tool head assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.3.3 RDU and AFU assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.4 AXIAL FEED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.4.1 Selecting the feed direction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.4.2 Setting the feed rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.4.3 Automatic feed stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3.5 POWER CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.5.1 Hydraulic machines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.5.2 BB5000 servo drive machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3.5.3 Electrical machines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3.5.4 Pneumatic machines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3.6 BB4500-BB5000 WITH SMALL DIAMETER BARS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4 OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
4.1 PRE-OPERATION CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.2 TOOL BIT SELECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.3 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.3.1 Starting the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.4 SHUTDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.5 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
5.1 MAINTENANCE CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5.2 APPROVED LUBRICANTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.3 MAINTENANCE TASKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.3.1 AFU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.3.2 Boring bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.3.3 Hydraulic power system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.3.4 Electric motor assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.3.5 Air motor assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.3.6 BB5000 servo motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.3.7 4:1 RDU gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.3.8 Cutting fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.4 QUALITY CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6 STORAGE AND SHIPPING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
6.1 STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

P/N 92974, Rev. 1 Page iii
TABLE OF CONTENTS (CONTINUED)
CHAPTER/SECTION PAGE
6.1.1 Short-term storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.1.2 Long-term storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.2 SHIPPING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.3 DECOMMISSIONING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
APPENDIX A BB4500 ASSEMBLY DRAWINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
APPENDIX B BB5000 ASSEMBLY DRAWINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
APPENDIX C SCHEMATICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
APPENDIX D SERVO CONTROLS ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
APPENDIX E SDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Page iv BB4500-BB5000 Operating Manual
This page intentionally left blank

P/N 92974, Rev. 1 Page v
LIST OF FIGURES
FIGURE PAGE
1-1 AFU label locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1-2 RDU label locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2-1 BB4500-BB5000 components with Eibenstock motor (BB5000 shown) . . . . . . . . . . . . . . . . . . . . . . . . 12
2-2 RDU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2-3 AFU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-4 BB4500 tool heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-5 BB5000 tool heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2-6 Single-arm spherical bearing mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-7 Double-arm spherical bearing mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-8 Universal spherical bearing mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-9 BB5000 servo drive dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2-10 RDU and Eibenstock motor dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2-11 Air motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2-12 Pneumatic conditioning unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2-13 BB4500 dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2-14 BB5000 dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3-1 Setup cones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3-2 Boring bar insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3-3 Setup cone installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3-4 Centering the spherical bearings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3-5 Positioning the spherical bearings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3-6 Aligning the bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3-7 Inserting the tool bit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3-8 Tool head setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3-9 Positioning the RDU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3-10 Positioning the AFU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3-11 Clamp collars on the AFU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3-12 AFU components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3-13 Feed box arrows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3-14 Automatic feed stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3-15 Servo motor main control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3-16 Servo motor pendant controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3-17 Air control valve handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3-18 Collets (BB5000 version shown) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3-19 BB5000 RDU collet keyway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3-20 Snap ring removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3-21 Small bore kit adapter insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3-22 Snap ring replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4-1 Disengaging the axial feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4-2 AFU disassembly components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5-1 Electric motor with handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
A-1 Axial feed unit assembly (P/N 43378) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
A-2 Axial feed unit assembly parts list (P/N 43378). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
A-3 Boring heads set assembly (P/N 43576). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Page vi BB4500-BB5000 Operating Manual
LIST OF FIGURES (CONTINUED)
FIGURE PAGE
A-4 Boring heads set 4–10 metric diameter assembly (P/N 43576) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
A-5 Boring heads set 4–10" diameter assembly (P/N 43575) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
A-6 RDU 2nd gen assembly (P/N 53912) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
A-7 RDU 2nd gen assembly (P/N 53912) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
A-8 Hydraulic motor assembly (P/N 39848) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
A-9 Single-arm mount assembly (P/N 43262) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
A-10 Universal mount assembly (P/N 43267) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
A-11 Double-arm bearing mount assembly (P/N 43279). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
A-12 Large and small set cones assembly (P/N 49060) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
A-13 Eibenstock motor assembly (P/N 88012) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
A-14 Eibenstock motor assembly -- gen. 2 only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
A-15 Eibenstock motor assembly parts list -- gen. 2 only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
B-1 Axial feed unit assembly (P/N 28636). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
B-2 Axial feed unit assembly parts list (P/N 28636). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
B-3 HD axial feed unit assembly (P/N 91518) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
B-4 HD axial feed unit assembly parts list (P/N 91518). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
B-5 Air motor CE assembly (P/N 28697). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
B-6 Air motor CE assembly (P/N 28614). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
B-7 Pneumatic connection assembly (P/N 15088) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
B-8 Hydraulic motor assembly (P/N 39848) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
B-9 Setup cone assembly (P/N 26383) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
B-10 Single-arm mount assembly (P/N 37472) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
B-11 Double-arm mount assembly (P/N 37473) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
B-12 Air motor CE assembly (P/N 36959) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
B-13 ID bearing mount assembly (P/N 46293) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
B-14 Set cones setup assembly (P/N 49060) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
B-15 Servo drive 460 CE assembly (P/N 52876) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
B-16 Servo drive 460 CE assembly parts list (P/N 52876) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
B-17 RDU 12:1 assembly (P/N 53165) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
B-18 RDU 12:1 assembly parts list (P/N 53165) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
B-19 RDU no mount modified assembly (P/N 93090) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
B-20 RDU no mount modified assembly parts list (P/N 93090). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
B-21 Servo drive 230V CE assembly (P/N 54321) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
B-22 Servo drive 230V CE assembly (P/N 54321) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
B-23 Servo motor RDU adapter assembly (P/N 51536) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
B-24 Servo motor guard assembly (P/N 52937) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
B-25 Servo shroud fan assembly (P/N 56773) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
B-26 Servo drive motor 230V non-CE assembly (P/N 71071). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
B-27 Servo drive motor 460V non-CE assembly (P/N 71072). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
B-28 Eibenstock motor assembly -- gen. 2 only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
B-29 Eibenstock motor assembly parts list -- gen. 2 only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
B-30 Leadscrew assembly (P/N 28654) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
C-1 BB4500-BB5000 Eibenstock controller 2nd gen 230V 50-60 hz CE schematic (P/N 88035 C00467) 120
C-2 BB4500-BB5000 Eibenstock controller 2nd gen 230V 50-60 hz domestic assembly (P/N 88036 C00468)
121

P/N 92974, Rev. 1 Page vii
LIST OF FIGURES (CONTINUED)
FIGURE PAGE
C-3 BB4500-BB5000 Eibenstock controller 2nd gen 120V domestic assembly (P/N 88037 C00465) . . . 122
C-4 BB4500-BB5000 Eibenstock controller 2nd gen 120V CE assembly (P/N 88038 C00466) . . . . . . . . 123
C-5 BB5000 motor 230V and 460V fan assembly (P/N 91811 E00034) . . . . . . . . . . . . . . . . . . . . . . . . . . 124
C-6 BB5000 servo motor 230VAC and 460VAC power cable assembly (P/N 91811 E00048) . . . . . . . . . 125
C-7 BB5000 Eibenstock motor cable assembly 2nd gen 120V 12AWG schematic (P/N 88649 E00170). 126
C-8 BB5000 Eibenstock motor cable assembly 2nd gen 230V 14AWG schematic (P/N 88650 E00171). 127
C-9 BB5000 Eibenstock power cable assembly 2nd gen 120V domestic L5-30P plug (P/N 88652 E00172) .
128
C-10 BB5000 Eibenstock power cable assembly 2nd gen 120V CE 332P4W pin/sleeve plug (P/N 88653
E00173) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
C-11 BB5000 Eibenstock power cable assembly 2nd gen 230V CE CEE7/7 Schuko plug (P/N 88654 E00174)
130
C-12 BB5000 Eibenstock power cable assembly 2nd gen 230V domestic L6-15P plug (P/N 88655 E00175)
131
C-13 Pneumatic conditioning unit schematic (P/N 59248) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
C-14 BB4500-BB5000 Eibenstock controller 2nd gen 230V 50-60 hz CE assembly (P/N 88035 B00367) 133
C-15 BB4500-BB5000 Eibenstock controller 2nd gen 230V 50-60 hz domestic assembly (P/N 88036 B00368)
134
C-16 BB4500-BB5000 Eibenstock controller 2nd gen 120V domestic assembly (P/N 88037 B00365) . . 135
C-17 BB4500-BB5000 Eibenstock controller 2nd gen 120V CE assembly (P/N 88038 B00366) . . . . . . . 136
C-18 BB5000 servo controller 3rd gen 460VAC CE assembly (P/N A00099) . . . . . . . . . . . . . . . . . . . . . . 137
C-19 BB5000 Eibenstock controller 2nd gen 120V domestic assembly (P/N A00100) . . . . . . . . . . . . . . . 138
C-20 BB5000 servo pendant assembly (P/N B00024) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
D-1 Servo amp function keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Page viii BB4500-BB5000 Operating Manual
This page intentionally left blank

P/N 92974, Rev. 1 Page ix
LIST OF TABLES
TABLE PAGE
1-1 Sound levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-2 Risk assessment checklist before set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1-3 Risk assessment checklist after set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1-4 BB4500-BB5000 labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2-1 BB5000 component identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2-2 Power options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2-3 Test data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2-4 Setup cones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2-5 Available HPU specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2-6 Hydraulic motor specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2-7 BB5000 servo motor specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2-8 Control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2-10 Speed range and torque per gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2-11 Recommended wire gauge for extension cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2-9 Power rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2-12 120V service parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2-13 230V service parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2-14 Control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2-15 Bar RPM and torque at maximum hp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2-16 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2-17 BB4500-BB5000 boring bar dimension identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2-18 Sub-component mass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2-19 Boring specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2-20 Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3-1 Setup cone identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3-2 Setup cone installation identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3-3 Spherical bearing identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3-4 Tool head setup identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3-5 Clamp collars installation identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3-6 AFU component identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3-7 Feed box arrow identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3-8 Automatic feed stop identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3-9 Servo motor control functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3-10 Collet identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3-11 RDU collet keyway identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3-12 Snap ring removal identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3-13 Small bore kit adapter identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3-14 Snap ring replacement identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4-1 Axial feed disengagement identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4-2 AFU disassembly identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5-1 Maintenance intervals and tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5-2 Approved lubricants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5-3 Quality checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5-4 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Page x BB4500-BB5000 Operating Manual
LIST OF TABLES (CONTINUED)
TABLE PAGE
A-1 BB4500 recommended spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
A-2 Tool kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
B-1 BB5000 recommended spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
B-2 Leadscrew spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
B-3 Hydraulic metric spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
B-4 BB5000 tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

P/N 92974, Rev. 1 Page 1
1 INTRODUCTION
IN THIS CHAPTER:
1.1 HOW TO USE THIS MANUAL - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1
1.2 SAFETY ALERTS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1
1.3 GENERAL SAFETY PRECAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
1.4 MACHINE-SPECIFIC SAFETY PRECAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
1.5 RISK ASSESSMENT AND HAZARD MITIGATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
1.6 RISK ASSESSMENT CHECKLIST - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
1.7 LABELS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6
1.7.1 LABEL IDENTIFICATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6
1.7.2 BB4500-BB5000 LABEL LOCATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7
1.1 HOW TO USE THIS MANUAL
This manual describes information necessary for the setup, operation, mainte-
nance, storage, shipping, and decommissioning of the BB4500-BB5000.
The first page of each chapter includes a summary of the chapter contents to help
you locate specific information. The appendices contain supplemental product
information to aid in setup, operation, and maintenance tasks.
Read this entire manual to familiarize yourself with the BB4500-BB5000 before
attempting to set it up or operate it.
1.2 SAFETY ALERTS
Pay careful attention to the safety alerts printed throughout this manual. Safety
alerts will call your attention to specific hazardous situations that may be encoun-
tered when operating this machine.
Examples of safety alerts used in this manual are defined here1:
DANGER
indicates a hazardous situation which, if not avoided, WILL result in
death or severe injury.
WARNING
indicates a hazardous situation which, if not avoided, COULD result in
death or severe injury.
1. For more information on safety alerts, refer to ANSI/NEMA Z535.6-2011, Product
safety Information in Product Manuals, Instructions, and Other Collateral Materials.

Page 2 BB4500-BB5000 Operating Manual
CAUTION
indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTICE
indicates a hazardous situation which, if not avoided, could result in
property damage, equipment failure, or undesired work results.
1.3 GENERAL SAFETY PRECAUTIONS
CLIMAX leads the way in promoting the safe use of portable machine tools and
valve testers. Safety is a joint effort. You, the end user, must do your part by being
aware of your work environment and closely following the operating procedures
and safety precautions contained in this manual, as well as your employer’s safety
guidelines.
Observe the following safety precautions when operating or working around the
machine.
Training – Before operating this or any machine tool, you should receive
instruction from a qualified trainer. Contact CLIMAX for machine-specific
training information.
Risk assessment – Working with and around this machine poses risks to
your safety. You, the end user, are responsible for conducting a risk assess-
ment of each job site before setting up and operating this machine.
Intended use – Use this machine in accordance with the instructions and
precautions in this manual. Do not use this machine for any purpose other
than its intended use as described in this manual.
Personal protective equipment – Always wear appropriate personal pro-
tective gear when operating this or any other machine tool. Flame-resistant
clothing with long sleeves and legs is recommended when operating the
machine. Hot chips from the workpiece may burn or cut bare skin.
Work area – Keep the work area around the machine clear of clutter. Restrain
cords and hoses connected to the machine. Keep other cords and hoses
away from the work area.
Lifting – Many CLIMAX machine components are very heavy. Whenever
possible, lift the machine or its components using proper hoisting equip-
ment and rigging. Always use designated lifting points on the machine.
Follow lifting instructions in the setup procedures of this manual.
Lock-out/tag-out – Lock-out and tag-out the machine before performing
maintenance.
Moving parts – CLIMAX machines have numerous exposed moving parts

P/N 92974, Rev. 1 Page 3
and interfaces that can cause severe impact, pinching, cutting, and other
injuries. Except for stationary operating controls, avoid contact with mov-
ing parts by hands or tools during machine operation. Remove gloves and
secure hair, clothing, jewelry, and pocket items to prevent them from
becoming entangled in moving parts.
Sharp edges – Cutting tools and workpieces have sharp edges that can eas-
ily cut skin. Wear protective gloves and exercise caution when handling a
cutting tool or workpiece.
Hot surfaces – During operation, motors, pumps, HPUs, and cutting tools
can generate enough heat to cause severe burns. Pay attention to hot sur-
face labels, and avoid contact with bare skin until the machine has cooled.
1.4 MACHINE-SPECIFIC SAFETY PRECAUTIONS
Eye hazard – This machine produces metal chips during operation. Always
wear eye protection when operating the machine.
Sound level – This machine produces potentially harmful sound levels.
Hearing protection is required when operating this machine or working
around it. During testing, the machine produced the sound levels1 listed in
Table 1-1.
Hazardous environments – Do not operate the machine in environments
where potentially explosive materials, toxic chemicals, or radiation may be
present.
Machine mounting – Do not operate the machine unless mounted to a
workpiece in accordance with this manual. If mounting the machine in an
overhead or vertical position, do not remove hoist rigging until the machine
is mounted to the workpiece in accordance with this manual.
1. Machine sound testing was conducted in accordance with European Harmonized
Standards EN ISO 3744:2010 and EN 11201:2010.
TABLE 1-1. SOUND LEVELS
SBB4500 motor BB5000 motor
Sound power 90.0 dBA 94.0 dBA
Operator sound pressure 91.4 dBA 91.4 dBA
Bystander sound pressure 89.6 dBA 89.6 dBA

Page 4 BB4500-BB5000 Operating Manual
1.5 RISK ASSESSMENT AND HAZARD MITIGATION
Machine Tools are specifically designed to perform precise material-removal oper-
ations.
Stationary Machine Tools include lathes and milling machines and are typically
found in a machine shop. They are mounted in a fixed location during operation
and are considered to be a complete, self-contained machine. Stationary Machine
Tools achieve the rigidity needed to accomplish material-removal operations from
the structure that is an integral part of the machine tool.
In contrast, Portable Machine Tools are designed for on-site machining applica-
tions. They typically attach directly to the workpiece itself, or to an adjacent struc-
ture, and achieve their rigidity from the structure to which it is attached. The
design intent is that the Portable Machine Tool and the structure to which it is
attached become one complete machine during the material-removal process.
To achieve the intended results and to promote safety, the operator must under-
stand and follow the design intent, set-up, and operation practices that are unique
to Portable Machine Tools.
The operator must perform an overall review and on-site risk assessment of the
intended application. Due to the unique nature of portable machining applications,
identifying one or more hazards that must be addressed is typical.
When performing the on-site risk assessment, it is important to consider the Porta-
ble Machine Tool and the workpiece as a whole.
