Club Car 2005 Precedent Manual

2004
Precedent
IQ System Electric
Vehicles
M&S 102680401
2005
Maintenance
And
Service
Manual No. 102680401 Edition Code 0205C0306B
IQ System
Electric Vehicles
Club Car, Inc.
P.O. Box 204658
Augusta, GA 30917-4658
USA
Web www.clubcar.com
Phone [phone]
1.800.ClubCar
Int’I +1 706.863.3000
Fax [phone]

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page i
FOREWORD
Club Car vehicles are designed and built to provide the ultimate in performance efficiency; however, proper
maintenance and repair are essential for achieving maximum service life and continued safe and reliable
operation.
This manual provides detailed information for the maintenance and repair of the electric Precedent vehicles,
and should be thoroughly reviewed prior to servicing the vehicle. The procedures provided herein must be
properly implemented, and the DANGER, WARNING, and CAUTION statements must be heeded.
This manual was written for the trained technician who already possesses knowledge and skills in electrical
and mechanical repair. If the technician does not have such knowledge and skills, attempted service or
repairs to the vehicle may render the vehicle unsafe. For this reason, Club Car advises that all repairs and/or
service be performed by an authorized Club Car distributor/dealer representative or by a Club Car factory-
trained technician.
It is the policy of Club Car, Inc. to assist its distributors and dealers in continually updating their service knowl-
edge and facilities so they can provide prompt and efficient service for vehicle owners. Regional technical rep-
resentatives, vehicle service seminars, periodic service bulletins, maintenance and service manuals, and
other service publications also represent Club Car’s continuing commitment to customer support.
This manual covers all aspects of typical vehicle service; unique situations, however, do sometimes occur
when servicing a vehicle. If it appears that a service question is not answered in this manual, you may write
to us at: Club Car, Inc.; P.O. Box 204658; Augusta, Georgia 30917; Attention: Technical Services, or contact
a Club Car Technical Service Representative at [phone], ext. 3580.
Copyright © 2005 Club Car, Inc.
Club Car and PowerDrive are registered
trademarks of Club Car, Inc.
This manual effective August 2, 2004.

Page ii 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
ý WARNING
• Read Section 1 – Safety before attempting any service on the vehicle.
• Before servicing vehicle, read complete section(s) and any referenced information that may
be relevant to the service or repair to be performed.
NOTE: This manual represents the most current information at the time of publication. Club Car, Inc. is
continually working to further improve its vehicles and other products. These improvements may
affect servicing procedures. Any modification and/or significant change in specifications or proce-
dures will be forwarded to all Club Car dealers and will, when applicable, appear in future editions
of this manual.
Club Car, Inc. reserves the right to change specifications and designs at any time without notice
and without the obligation of making changes to units previously sold.
There are no warranties expressed or implied in this manual. See the limited warranty found in the
vehicle owner’s manual or write to Club Car, Inc., P.O. BOX 204658, Augusta, Georgia 30917-
4658 USA, Attention: Warranty Department.

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page iii
CONTENTS
SECTION 1 – SAFETY
General Warnings ............................................................................................................................. 1-1
SECTION 2 – VEHICLE SPECIFICATIONS
SECTION 3 – GENERAL INFORMATION
Serial Number Identification .............................................................................................................. 3-1
Safety Committee ............................................................................................................................. 3-2
Storage ............................................................................................................................................. 3-2
Preparing the Electric Vehicle for Extended Off-Season Storage ................................................ 3-3
Returning the Stored Electric Vehicle to Service .......................................................................... 3-3
SECTION 4 – BODY AND TRIM
Cleaning the Vehicle ......................................................................................................................... 4-1
Seat .............................................................................................................................................. 4-1
Front and Rear Body Repair ............................................................................................................. 4-2
Stress Lines or Streaks ................................................................................................................. 4-2
Minor Impact Damage/Deformations ............................................................................................ 4-2
Minor Scratches and Surface Blemishes ...................................................................................... 4-2
Gouges, Punctures, Tears, Large Scratches, and Abrasions ....................................................... 4-2
Front Body ........................................................................................................................................ 4-4
Front Body Removal ..................................................................................................................... 4-4
Front Body Installation .................................................................................................................. 4-4
Front Bumper .................................................................................................................................... 4-4
Instrument Panel ............................................................................................................................... 4-4
Instrument Panel Removal ........................................................................................................... 4-4
Instrument Panel Installation ........................................................................................................ 4-6
Floor Mat and Retainers ................................................................................................................... 4-6
Floor Mat Retainer Removal ......................................................................................................... 4-7
Floor Mat Retainer Installation ...................................................................................................... 4-7

Page iv 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
Kick Plate and Charger Receptacle Bezel ....................................................................................... 4-7
Kick Plate and Charger Receptacle Bezel Removal .................................................................... 4-7
Kick Plate and Charger Receptacle Bezel Installation ................................................................. 4-7
Rear Body – Two-Passenger Vehicles ............................................................................................ 4-8
Universal Accessory Mounting ..................................................................................................... 4-8
Backrest and Structural Accessory Module (SAM) ...................................................................... 4-10
Rear Body Components (Two-Passenger) .................................................................................. 4-10
Rear Body – Four-Passenger Vehicles ............................................................................................4-12
Seat Backs ................................................................................................................................... 4-12
Seat Support ................................................................................................................................ 4-13
Foot Deck ..................................................................................................................................... 4-14
Rear Body Components (Four-Passenger) .................................................................................. 4-15
Canopy – Two-Passenger ................................................................................................................ 4-16
Two-Passenger Canopy Removal ................................................................................................ 4-16
Two-Passenger Canopy Installation ............................................................................................. 4-18
Canopy – Four-Passenger ............................................................................................................... 4-20
Four-Passenger Canopy Removal ............................................................................................... 4-20
Four-Passenger Canopy Installation ............................................................................................ 4-20
SECTION 5 – ACCELERATOR AND BRAKE PEDAL GROUP
Pedal Group ..................................................................................................................................... 5-1
Pedal Group Removal .................................................................................................................. 5-1
MCOR .......................................................................................................................................... 5-3
Debris Shields .............................................................................................................................. 5-3
Brake Return Spring ..................................................................................................................... 5-3
Pawl Assembly ............................................................................................................................. 5-4
Accelerator Return Spring ............................................................................................................ 5-4
Pedal Group Installation ............................................................................................................... 5-6
SECTION 6 – WHEEL BRAKE ASSEMBLIES
General Information ......................................................................................................................... 6-1
Brake Shoe Removal ....................................................................................................................... 6-1
Brake Assembly Cleaning ................................................................................................................ 6-5
Brake Shoe Installation .................................................................................................................... 6-6
Brake Cable Equalizer Adjustment .................................................................................................. 6-9
Brake Cluster Removal and Installation ........................................................................................... 6-9
Brake Cluster Installation ............................................................................................................. 6-10
Brake Cable Removal and Installation ............................................................................................. 6-11

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page v
SECTION 7 – STEERING AND FRONT SUSPENSION
General Information .......................................................................................................................... 7-1
Steering Wheel ................................................................................................................................. 7-1
Steering Wheel Removal .............................................................................................................. 7-1
Steering Wheel Installation ........................................................................................................... 7-2
Steering Column ............................................................................................................................... 7-2
Steering Column Removal ............................................................................................................ 7-2
Steering Column Installation ......................................................................................................... 7-4
Rack and Pinion ................................................................................................................................ 7-4
Rack and Pinion Removal ............................................................................................................ 7-4
Rack and Pinion Disassembly ...................................................................................................... 7-5
Rack and Pinion Assembly ........................................................................................................... 7-8
Rack and Pinion Installation ......................................................................................................... 7-9
Front Suspension .............................................................................................................................. 7-10
Lubrication .................................................................................................................................... 7-10
Wheel Alignment ........................................................................................................................... 7-10
Front Suspension Components ........................................................................................................ 7-12
Tie Rod End Removal ................................................................................................................... 7-12
Tie Rod Installation ....................................................................................................................... 7-12
Leaf Spring Removal .................................................................................................................... 7-13
Leaf Spring Installation ................................................................................................................. 7-13
Kingpin and Steering Spindle Removal ........................................................................................ 7-13
Kingpin and Steering Spindle Installation ..................................................................................... 7-13
Control Arm Removal ................................................................................................................... 7-14
Control Arm Installation ................................................................................................................ 7-14
Shock Absorber Removal ............................................................................................................. 7-14
Shock Absorber Installation .......................................................................................................... 7-14
Front Wheel Bearings and Hubs ....................................................................................................... 7-17
Front Wheel Free Play Inspection ................................................................................................ 7-17
Front Hub Removal ....................................................................................................................... 7-17
Hub Installation ............................................................................................................................. 7-17
SECTION 8 – WHEELS AND TIRES
General Information .......................................................................................................................... 8-1
Wheels .............................................................................................................................................. 8-1
Wheel Removal ............................................................................................................................ 8-1
Wheel Installation ......................................................................................................................... 8-1

Page vi 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
Tires ................................................................................................................................................. 8-2
Tire Removal ................................................................................................................................ 8-2
Tire Repair .................................................................................................................................... 8-2
Tire Installation ............................................................................................................................. 8-3
SECTION 9 – REAR SUSPENSION
General Information ......................................................................................................................... 9-1
Shock Absorbers .............................................................................................................................. 9-1
Shock Absorber Removal and Inspection .................................................................................... 9-1
Shock Absorber Installation .......................................................................................................... 9-1
Leaf Springs (Two-Passenger Vehicles) ..........................................................................................9-1
Leaf Spring Removal (Two-Passenger Vehicles) ......................................................................... 9-1
Leaf Spring Installation (Two-Passenger Vehicles) ...................................................................... 9-4
Leaf Springs (Four-Passenger Vehicles) .........................................................................................9-4
Leaf Spring Removal (Four-Passenger Vehicles) ........................................................................ 9-4
Leaf Spring Installation (Four-Passenger Vehicles) ..................................................................... 9-6
SECTION 10 – PERIODIC MAINTENANCE
General Information ......................................................................................................................... 10-1
Periodic Service Schedule ............................................................................................................... 10-1
Periodic Lubrication Schedule .......................................................................................................... 10-3
SECTION 11 – ELECTRICAL SYSTEM AND TESTING
General Information ......................................................................................................................... 11-1
Wiring Diagrams ............................................................................................................................... 11-2
Troubleshooting ............................................................................................................................... 11-7
Troubleshooting the Vehicle with the IQDM ................................................................................. 11-7
Troubleshooting Guide 1 .............................................................................................................. 11-8
Troubleshooting Guide 2 .............................................................................................................. 11-11
Test Procedures ............................................................................................................................... 11-13
Index of Test Procedures ............................................................................................................. 11-14
Communication Display Module (CDM) ........................................................................................... 11-38
Using the CDM to Retrieve Data from the Onboard Computer .................................................... 11-39
CDM Troubleshooting Guide ............................................................................................................ 11-40

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page vii
SECTION 12 – ELECTRICAL COMPONENTS
Key Switch ........................................................................................................................................ 12-1
Battery Warning Light ....................................................................................................................... 12-3
Forward/Reverse Rocker Switch ...................................................................................................... 12-3
Electronics Module Cover ................................................................................................................. 12-5
Tow/Run Switch ................................................................................................................................ 12-6
Motor Controller Output Regulator (MCOR) ..................................................................................... 12-7
Reverse Buzzer ................................................................................................................................ 12-8
Electronics Module ........................................................................................................................... 12-10
Solid State Speed Controller ............................................................................................................ 12-11
Solenoid ............................................................................................................................................ 12-12
Onboard Computer (OBC) ................................................................................................................ 12-13
Charger Receptacle .......................................................................................................................... 12-13
SECTION 13 – BATTERIES
General Information .......................................................................................................................... 13-1
Battery Replacement ........................................................................................................................ 13-1
Battery Care ...................................................................................................................................... 13-2
Preventive Maintenance ............................................................................................................... 13-2
Self-Discharge .............................................................................................................................. 13-3
Electrolyte Level ........................................................................................................................... 13-3
Mineral Content ............................................................................................................................ 13-4
Vibration Damage ......................................................................................................................... 13-4
Battery Charging ............................................................................................................................... 13-4
Charger Shuts Off After 16 Hours ................................................................................................. 13-5
Deep-Discharge ............................................................................................................................ 13-5
Early Excessive Discharging ........................................................................................................ 13-5
Incoming AC Service .................................................................................................................... 13-5
Fleet Rotation ............................................................................................................................... 13-5
Numbering Vehicles and Chargers ............................................................................................... 13-5
Battery Troubleshooting Chart .......................................................................................................... 13-6
Battery Testing .................................................................................................................................. 13-7
Battery Charger Test .................................................................................................................... 13-7
On-Charge Voltage Test ............................................................................................................... 13-7
Hydrometer Test ........................................................................................................................... 13-7
Discharge Test .............................................................................................................................. 13-9
Battery Troubleshooting Examples ............................................................................................... 13-11
Battery Storage ................................................................................................................................. 13-12

Page viii 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
Charging a Battery Pack that has Low Voltage ................................................................................ 13-12
SECTION 14 – BATTERY CHARGER
SECTION 15A – MOTOR (MODEL 5BC59JBS6365)
General Information ......................................................................................................................... 15a-1
Motor Identification ........................................................................................................................... 15a-1
External Motor Testing ..................................................................................................................... 15a-1
Motor ................................................................................................................................................ 15a-3
Motor Component Testing and Inspection ....................................................................................... 15a-5
Armature ...................................................................................................................................... 15a-5
Field Windings Inspection ............................................................................................................ 15a-6
Motor Components ....................................................................................................................... 15a-7
Bearing Inspection ....................................................................................................................... 15a-7
Bearing Removal .......................................................................................................................... 15a-9
Bearing Installation ....................................................................................................................... 15a-9
Speed Sensor Magnet Inspection ................................................................................................ 15a-9
Speed Sensor Magnet Removal .................................................................................................. 15a-9
Speed Sensor Magnet Installation ...............................................................................................15a-9
Reconditioning the Motor ................................................................................................................. 15a-9
Motor Assembly ............................................................................................................................... 15a-10
Motor Installation .............................................................................................................................. 15a-12
Motor Speed Sensor ........................................................................................................................ 15a-15
SECTION 15B – MOTOR (MODEL EJ4-4001)
General Information ......................................................................................................................... 15b-1
Motor Identification ........................................................................................................................... 15b-1
External Motor Testing ..................................................................................................................... 15b-1
Motor ................................................................................................................................................ 15b-2
Motor Removal ............................................................................................................................. 15b-2
Motor Disassembly ....................................................................................................................... 15b-4
Motor Component Testing and Inspection ....................................................................................... 15b-6
Armature Inspection and Testing ................................................................................................. 15b-6
Motor Frame and Field Windings Inspection ................................................................................ 15b-8
Motor Brush, Spring, and Terminal Insulator Inspection .............................................................. 15b-8
Reconditioning the Motor ................................................................................................................. 15b-11
Motor Assembly ............................................................................................................................... 15b-11

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page ix
Motor Installation .............................................................................................................................. 15b-13
SECTION 16 – TRANSAXLE (TYPE G)
Lubrication ........................................................................................................................................ 16-1
Axle Bearing and Shaft ..................................................................................................................... 16-1
Axle Shaft ..................................................................................................................................... 16-1
Axle Bearing ................................................................................................................................. 16-4
Transaxle .......................................................................................................................................... 16-5
Transaxle Removal ....................................................................................................................... 16-5
Transaxle Disassembly, Inspection, and Assembly .......................................................................... 16-7
Transaxle Disassembly and Inspection ........................................................................................ 16-7
Transaxle Assembly ..................................................................................................................... 16-9
Transaxle Installation ........................................................................................................................ 16-10
SECTION i – INDEX

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page 1-1
1
SECTION 1 – SAFETY
To ensure the safety of those servicing Club Car vehicles, and to protect the vehicles from possible damage
resulting from improper service or maintenance, the procedures in this manual must be followed.
It is important to note that throughout this manual there are statements labeled DANGER, WARNING, or CAU-
TION. These special statements relate to specific safety issues, and must be read, understood, and heeded
before proceeding with procedures. There are statements labeled NOTE, which provide other essential ser-
vice or maintenance information.
ý DANGER
• A DANGER indicates an immediate hazard that will result in severe personal injury or death.
ý WARNING
• A WARNING indicates an immediate hazard that could result in severe personal injury or death.
ý CAUTION
• A CAUTION with the safety alert symbol indicates a hazard or unsafe practice that could
result in minor personal injury.
CAUTION
• A CAUTION without the safety alert symbol indicates a potentially hazardous situation that
could result in property damage.
GENERAL WARNINGS
The following safety statements must be heeded whenever the vehicle is being operated, repaired, or ser-
viced. Other specific safety statements appear throughout this manual and on the vehicle.
ý DANGER
• Battery – Explosive gases! Do not smoke. Keep sparks and flames away from the vehicle and
service area. Ventilate when charging or operating vehicle in an enclosed area. Wear a full
face shield and rubber gloves when working on or near batteries.
• Battery – Poison! Contains acid! Causes severe burns. Avoid contact with skin, eyes, or
clothing. Antidotes:
- External: Flush with water. Call a physician immediately.
- Internal: Drink large quantities of milk or water. Follow with milk of magnesia or vegetable
oil. Call a physician immediately.
- Eyes: Flush with water for 15 minutes. Call a physician immediately.

SAFETY General Warnings
Page 1-2 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
1
ý WARNING
• Only trained technicians should service or repair the vehicle or battery charger. Anyone doing
even simple repairs or service should have knowledge and experience in electrical and
mechanical repair. The appropriate instructions must be used when performing maintenance,
service, or accessory installation.
• Follow the procedures exactly as stated in this manual, and heed all DANGER, WARNING, and
CAUTION statements in this manual as well as those on the vehicle and battery charger.
• Lift only one end of the vehicle at a time. Use a suitable lifting device (chain hoist or hydraulic
floor jack) with 1000 lb. (454 kg) minimum lifting capacity. Do not use lifting device to hold
vehicle in raised position. Use approved jack stands of proper weight capacity to support the
vehicle and chock the wheels that remain on the floor. When not performing a test or service
procedure that requires movement of the wheels, lock the brakes.
• Improper use of the vehicle or failure to properly maintain it could result in decreased vehicle
performance, severe personal injury, or death.
• Any modification or change to the vehicle that affects the stability or handling of the vehicle,
or increases maximum vehicle speed beyond factory specifications, could result in severe
personal injury or death.
• Check the vehicle for proper location of all vehicle safety and operation decals and make sure
they are in place and are easy to read.
• Wear safety glasses or approved eye protection when servicing the vehicle or battery charger.
Wear a full face shield and rubber gloves when working on or near batteries.
• Do not wear loose clothing or jewelry such as rings, watches, chains, etc., when servicing the
vehicle or battery charger.
• Use insulated tools when working near batteries or electrical connections. Use extreme
caution to avoid shorting of components or wiring.
• Prior to leaving the vehicle unattended or servicing the vehicle, turn the key switch OFF,
remove the key, and place the Forward/Reverse switch in the NEUTRAL position. Chock the
wheels when servicing the vehicle.
• Place Tow/Run switch in the TOW position before disconnecting or connecting the batteries.
Failure to heed this warning could result in a battery explosion or severe personal injury.
• To avoid unintentionally starting the vehicle, disconnect the batteries as shown (Figure 1-1).
• After disconnecting the batteries, wait 90 seconds for the controller capacitors to discharge.
• Do not leave children unattended on vehicle.
Figure 1-1 Battery Disconnection
CCI102519501
RUN
TOW
Place Tow/Run
switch in TOW.
Remove negative (–)
cable first.
Place TOW/RUN Switch in the TOW
position before disconnecting or
connecting battery cables. 12
3
4
FRONT
OF VEHICLE
CCI 102519501
RUN
TOW

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page 2-1
2
SECTION 2 – VEHICLE SPECIFICATIONS
SPECIFICATIONS Two-
Passenger
Electric
Vehicle
Four-
Passenger
Electric
Vehicle
POWER SOURCE
Drive motor: Direct drive, 48 volts DC, shunt-wound, 3.2 hp • •
Transaxle: Double reduction helical gear with 12.3:1 direct drive axle • •
Electrical system: 48 volts DC, reduced speed reverse • •
Batteries: High capacity, deep cycle, 12 volt ••
Charger: Automatic, 48-volt; UL and CSA listed ••
Engine: 4-cycle OHV, 286 cc, 9.0 hp rated, single-cylinder, air-cooled, with pressure lubrication system
Fuel system: Side-draft carburetor with float bowl, fixed jets, fuel filters, and impulse fuel pump
Governor: Automatic ground-speed sensing, internally geared in unitized transaxle
Ignition: Transistor electronic ignition with electronic RPM limiter
Unitized transaxle: Fully synchronized forward and reverse with neutral and reduced speed reverse (11.8:1 for-
ward, 17.1:1 reverse)
Torque converter: Automatic, variable-speed, dry type
Electrical system: 12 volt, 500 cca at 0 °F (-17.8 °C), 650 at 32 °F (0 °C). 105-minute reserve capacity and 35-amp
charging capacity
STEERING/SUSPENSION/BRAKES
Steering: Self-adjusting rack and pinion ••
Suspension: Front and rear tapered mono-leaf springs with dual hydraulic shocks • •
Brakes: Dual rear wheel self-adjusting brakes with cast iron drums and single brake pedal with automatic-release
park brake ••
BODY/CHASSIS
Frame/Chassis: Aluminum and composite ••
Front and rear body: Dupont Surlyn© Reflections ••
Body finish: High-gloss molded-in color ••
Tires: 18 x 8.5 – 8 tubeless, 4 ply rated ••
DIMENSIONS/WEIGHT
Overall length 91.5 in.
(232 cm) 104 in. (264 cm)
Overall width 47.25 in.
(120 cm) 47.25 in. (120 cm)
Overall height (with canopy) 68.5 in.
(174 cm) 71 in. (180 cm)
Overall height (at steering wheel) 48.0 in.
(122 cm) 48.0 in. (122 cm)
Wheelbase 65.5 in.
(166 cm) 65.5 in. (166 cm)
Ground clearance 4.5 in.
(11 cm) 4.5 in. (11 cm)
Front wheel tread 34.5 in.
(88 cm) 34.5 in. (88 cm)
Vehicle Specifications continued on next page...

2
Rear wheel tread 38.6 in.
(98 cm) 38.6 in. (98 cm)
Weight (standard electric vehicle with canopy, with batteries) 855 lb.
(388 kg) 970 lb. (440 kg)
Weight (standard gasoline vehicle with canopy, with battery, without fuel)
Forward speed 12-15 mph (19-24 km/h)
Curb clearance circle (diameter) 17 ft - 4in.
(528 cm) 17 ft - 4 in. (528 cm)
Standard seating capacity 24
LIQUID CAPACITIES
Transaxle 22 oz.
(.67 liters) 22 oz. (.67 liters)
Engine crankcase (without filter)
Engine crankcase (with filter)
Unitized transaxle
Fuel tank
TIRE PRESSURE
Front and rear 18-20 psi (1.24-1.38
bars)
18-20 psi
(1.24-1.38
bars)
SPECIFICATIONS Two-
Passenger
Electric
Vehicle
Four-
Passenger
Electric
Vehicle

2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page 3-1
3
SECTION 3 – GENERAL INFORMATION
ý DANGER
• See General Warnings, Section 1, Page 1-1.
ý WARNING
• See General Warnings, Section 1, Page 1-1.
Important features unique to the different models covered in this manual are highlighted. Club Car, Inc. rec-
ommends the owner/operator read and understand this manual and pay special attention to features specific
to their vehicle(s).
Refer to the owner’s manual provided with the vehicle for information on the following topics:
•Pre-Operation and Daily Safety Checklist
•Controls and Indicators
•Driving Instructions
•Towing
•Transporting on a Trailer
•Subsequent Owner Registration
•Warranties
SERIAL NUMBER IDENTIFICATION
The serial number of the vehicle is printed on a bar code decal mounted on the passenger side inner dash
(Figure 3-1).
NOTE: Always have the vehicle serial number available when ordering parts or making inquiries.
Figure 3-1 Serial Number Decal
SERIAL NUMBER
PQ0501-123456

GENERAL INFORMATION Safety Committee
Page 3-2 2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual
3
SAFETY COMMITTEE
If the golf car is to be rented or is part of a fleet, we strongly recommend that a safety committee be appointed.
One of the main concerns of this committee should be the safe operation of the golf cars.
This should include at a minimum:
•Where golf cars should be driven.
•Ensuring that proper warnings of driving hazards are displayed and visible. See below for list of signs
available from Club Car Service Parts Department.
•Who should and who should not drive golf cars.
•Instructing first time drivers.
•Maintaining golf cars in a safe driving condition
•How various rules are to be enforced.
The safety committee should include all these items and such others as the committee feels necessary or
appropriate. Warning signs available from Club Car are listed below.
STORAGE
See General Warnings, Section 1, Page 1-1.
ý WARNING
• Turn the key switch OFF, remove the key, and leave the Forward/Reverse switch in the
NEUTRAL position during storage. This is to prevent unintentionally starting the vehicle or a
fire hazard.
• Do not attempt to charge frozen batteries or batteries with bulged cases. Discard the battery.
Frozen batteries can explode.
ý CAUTION
• Batteries in low state of charge will freeze at low temperatures.
• To avoid exposing electrical components to moisture and subsequent damages, do not use
any type of pressure washing or steam cleaning equipment to wash the vehicle.
• Place Tow/Run switch in the TOW position.
WARNING SIGN CCI P/N
Sharp Left S9911211
Sharp Right S9921211
Steep Hill S9931211

GENERAL INFORMATION Storage
2005 Precedent IQ System Electric Golf Car Maintenance and Service Manual Page 3-3
3
PREPARING THE ELECTRIC VEHICLE FOR EXTENDED OFF-SEASON STORAGE
1. Fully charge batteries. See Section 13 – Batteries.
2. Batteries should be clean and free of corrosion. Wash tops and terminals of batteries with a solution of
baking soda and water (1 cup (237 mL) baking soda per 1 gallon (3.8 L) of water). Rinse solution off bat-
teries. Do not allow this solution to enter the batteries. Be sure terminals are tight. Let the terminals dry
and then coat them with Battery Terminal Protector Spray (CCI P/N 1014305).
3. Store vehicle in a cool, dry place. This will minimize battery self-discharge.
4. Adjust tires to recommended tire pressure. See Section 2 – Vehicle Specifications.
5. Perform all semiannual periodic lubrication. See Periodic Lubrication Schedule, Section 10, Page 10-3..
6. Thoroughly clean front body, rear body, seats, battery compartment, and underside of vehicle.
7. Do not engage the park brake. Chock the wheels to prevent the vehicle from rolling.
8. Keep batteries fully charged during storage.
•Leave chargers plugged in during storage. The onboard computer will automatically activate the
charger when necessary. If the battery charger is left plugged in during extended storage, the electro-
lyte should be checked monthly to ensure that proper level is maintained. AC power should also be
checked periodically.
•If charger cannot remain plugged in, or AC power will not be available during extended storage, discon-
nect the batteries for storage. See WARNING “To avoid unintentionally starting...” in
General Warnings,
Section 1, Page 1-1
.
CAUTION
• Check the vehicle monthly to ensure the charger is operating correctly during storage.
RETURNING THE STORED ELECTRIC VEHICLE TO SERVICE
1. If necessary, connect batteries.
2. Fully charge batteries.
ý WARNING
• Do not attempt to charge frozen batteries or batteries with bulged cases. Discard the battery.
Frozen batteries can explode.
3. Adjust tire to recommended pressure. See Section 2 – Vehicle Specifications.
4. Perform the Pre-Operation and Daily Safety Checklist. See Section 10 – Periodic Maintenance.

3
