CMA Dishmachines EST-Front Loader Manual

Insert tube stiffener with chemical tubing
into each corresponding chemical
dispenser.
3
STEP
RED
WHITE
BLUE
Model EST-Front Loader
Quick Setup
Instructions
WARNING: Electrical and
plumbing connections
need to be made by a
licensed service person
and comply with all
Federal, State and Local
Health, Electrical,
Plumbing and Safety
codes.
11-2016
2
STEP
WALL
DRAIN
8"
FLOOR DRAIN
Connect a 2" drain pipe (not supplied)
from scrap accumulator to floor or wall
drain.
Connect dishmachine to hot water source
recommended 140 temperature (120
minimum temperature required).
2" DRAIN
OUTLET
HARD WIRE
POWER SUPPLY
TUBE
STIFFENER
CHEMICAL
TUBING
1
STEP
3
3
1/2" WATER
INLET
1
MODEL EST FRONT LOADER
REAR VIEW
2
PN: 10130.19

CMA ENERGY SAVER
CMA ENERGY SAVER
MODEL EST FRONT LOADER
FRONT VIEW
11-2016
6
STEP
Level dishmachine by adjusting leveling legs.
Dishmachine must be level front and back to
ensure proper performance.
4
STEP
Open dishmachine doors completely. Closing
the door will automatically activate the
machine.
Press the "FILL/START" switch. Hold in the
"FILL" position until the water overflows into
the scrap accumulator.
WARNING: Electrical and
plumbing connections
need to be made by a
licensed service person
and comply with all
Federal, State and Local
Health, Electrical,
Plumbing and Safety
codes.
THERMOMETER NEEDS TO
BE INSTALLED:
The Model EST FRONT LOADER
is Shipped from CMA without
thermometer being installed. To
prevent leaking, the installation
Team will need to install it on the
dishwasher using TEFLON TAPE.
So the thermometer for this unit
is not misplaced during shipment,
please find thermometer shipped
inside the dishwasher, zip-tied
to the dishrack.
Model EST-Front Loader
Quick Setup
Instructions
5
STEP
CMA ENERGY SAVER
CMA ENERGY SAVER
LEVELING
LEGS 4
PERISTALTIC
PUMP
DETERGENT
SWITCH
FILL/START
SWITCH 5
CYCLE LIGHT
DRAIN
SWITCH
RINSE
SWITCH
SANI
SWITCH
DOOR
HANDLE 6
POLY PRO
TM
SCRAP
ACCUMULATOR
