CMA Dishmachines EVA-C Manual

Connect hard wire power supply from
dishmachine to power box.
MODEL EVA REAR VIEW
DRAIN HOSE
HARD WIRE
FOUR WIRE
POWER SUPPLY
1
2
3
4
Connect dishmachine to hot water source
recommended 140°temperature (120°
minimum temperature required).
Insert tube stiffener with chemical tubing
into each corresponding chemical
dispensers.
BLUE
RED WHITE
4
STEP
TUBE
STIFFENER
TUBE
STIFFENER
AUTO START
SWITCH
2" DRAIN
OUTLET
POWER SWITCH
CHEMICAL
TUBING
CHEMICAL
TUBING
3/4" WATER
INLET 3
HARD WIRE
POWER SUPPLY 2
HARD WIRE
POWER SUPPLY
NORMAL-OFF DELIMER
SWITCH
DRAIN/RINSE
SWITCH
SANI/DETERGENT
SWITCH
4
4
4
1/2" WATER
INLET
1
2
3
4
Models EVA
EVA-C, EVA-T
& EVA-C-T
Quick Setup
Instructions
800-854-6417
WARN ING: Electrical and plumbing connections
need to be made by a licensed service person
and comply with all Federal, State and Local
Health, Electrical, Plumbing and Safety codes.
WARN ING: Electrical and
plumbing connections
need to be made by a
licensed service person
and comply with all
Federal, State and Local
Health, Electrical,
Plumbing and Safety
codes.
5-2007
3
STEP
WALL
DRAIN
8"
FLOOR DRAIN
Connect a 2" drain pipe (not
supplied) from scrap accumulator
to floor or wall drain.
2
STEP
1
STEP
1
STEP
ON/OFF
POWER SWITCH

000000
FILL
START
MODEL EVA FRONT VIEW
DRAIN HOSE
HARD WIRE
FOUR WIRE
POWER SUPPLY
1
2
3
4
TUBE
STIFFENER
DOOR
HANDLE
AUTO START
SWITCH
LEVELING
LEGS
POWER SWITCH
CHEMICAL
TUBING
3/4" WATER
INLET 3
HARD WIRE
POWER SUPPLY 2
4
4
7
FILL/START
SWITCH 6
5
Models EVA
Quick Setup
Instructions
800-854-6417
WARN ING: Electrical and plumbing connections
need to be made by a licensed service person
and comply with all Federal, State and Local
Health, Electrical, Plumbing and Safety codes.
5-2007
7
STEP
Level dishmachine by adjusting leveling legs.
Dishmachine must be level front and back to
ensure proper performance.
5
STEP
000000
START
6
STEP
Open dishmachine doors completely. Closing
the doors will automatically activate the
machine.
Press the "FILL/START" switch. Hold in the
"FILL" position until the water overflows into
the scrap accumulator.
00000
FILL
START
FILL
POLY PRO
TM
SCRAP
ACCUMULATOR
THERMOMETER
WARN ING: Electrical and
plumbing connections
need to be made by a
licensed service person
and comply with all
Federal, State and Local
Health, Electrical,
Plumbing and Safety
codes.
Models EVA
EVA-C, EVA-T
& EVA-C-T
Quick Setup
Instructions
