CMA Dishmachines MODEL GL-C User manual

www.cmadishmachines.com
GLC/GW-100
MANUAL
INSTALLATION
SERVICE
PARTS
REV.1.01B
800-854-6417
FAX [phone]
CMA DISHMACHINES
12700 KNOTT STREET
GARDEN GROVE, CALIFORNIA 92841
Owner’s Manual
Keep with machine for reference

TABLE OF CONTENTS
MODEL GLC/GW-100
1. RECEIVING ...................................................................................................2
2. SPECIFICATIONS.........................................................................................3
2.1. GLC................................................................................................................................................ 3
2.2. GW-100.......................................................................................................................................... 4
3. INSTALLATION.............................................................................................5
3.1. ELECTRICAL.................................................................................................................................... 5
3.2. PLUMBING....................................................................................................................................... 5
4. OPERATION..................................................................................................6
4.1. FILLING OF THE WASH TANK .......................................................................................................... 6
4.2. OPERATION INSTRUCTIONS ............................................................................................................. 6
4.2.1. Proper Chemical Dosage ........................................................................................................ 6
4.3. CLEANING INSTRUCTIONS ............................................................................................................... 7
4.3.1. Highly Recommended Daily Cleaning Instructions...................................................................... 7
4.3.2. Weekly Cleaning Instructions....................................................................................................... 7
5. TROUBLESHOOTING...................................................................................8
6. PARTS MANUAL ........................................................................................10
6.1. GLC INITIAL PARTS KIT P/N 1100.47.............................................................................................10
6.2. GW-100 INITIAL PARTS KIT P/N 1100.49.......................................................................................11
6.3. EXPLODED VIEW DRAWINGS..........................................................................................................12
6.2.1. Main Assembly.............................................................................................................................12
6.2.2. Conveyor Wheel / Curtain...........................................................................................................13
6.2.3. Conveyor Shut-Off Rod Assembly................................................................................................14
6.2.4. GLC Control Box Assembly P/N 18612.49..................................................................................15
6.2.5. GW-100 Control Box Assembly P/N 18611.47............................................................................16
6.2.5. Soap Tank Assembly....................................................................................................................17
6.2.6. Water Inlet Plumbing...................................................................................................................18
6.2.7. Sanitizer Plumbing Component Hardware..................................................................................19
6.2.8. Vacuum Breaker and Hardware..................................................................................................20
6.2.9. Wash Pump Assembly..................................................................................................................21
6.2.10. Conveyor Drive Assembly..........................................................................................................22
6.2.11. Waste Collector Assy. P/N 16565.00.........................................................................................23

7. GLC ELECTRICAL DIAGRAM....................................................................24
8. GW-100 ELECTRICAL DIAGRAM ..............................................................25

Receiving
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01B Page2
1. Receiving
1. Remove all packing material from the machine.
2. Remove all tape securing components within the machine. Check that both trays are
positioned properly.
3. Check for the following component parts:
A. Check that the rinse screen is secure in the rinse drain.
B. Check the position of the GLC curtains.
C. Check that the conveyor is level and the drive gear is engaged in the conveyor’s
outer rim grooves.
D. Important: Check and remove overflow drain tube, which is secured to the front of
the scrap tank, behind the access door. Place it in position in soap tank.
E. Check that the screen in the detergent tank is in position.
F. Check that the drain screen is in position.
4. Important: Read all instructions completely.

Specifications
MODEL GL-C/GW-100 SERVICE & PARTS MANUAL Rev. 1.01BPage3
2. Specifications
2.1. GLC
WATER CONSUMPTION
HOT WATER INITIAL FILL 3 GAL. 11.35 L.
HOT WATER PER HOUR (max) 12 GAL. 45.42 L.
COLD WATER PER HOUR 168 GAL. 636 L.
OPERATING CAPACITY
(2-1/2”) GLASSES PER HOUR 1000 -
WATER REQUIREMENTS
COLD WATER INLET 1/2” -
HOT WATER INLET 1/2” -
DRAIN CONNECTION 1-1/2” -
TEMPERATURES
INLET COLD WATER 75
°
F 24
°
C
INLET HOT WATER (recommended) 140
°
F 60
°
C
FRAME DIMENSIONS
DEPTH 25-1/8” 63.8CM
WIDTH 25-1/4” 64CM
HEIGHT 39”-40-1/2” 99.1-102.8CM
MAX CLEARANCE FOR GLASSES 11-3/4” 29.8CM
ELECTRICAL 208 - 240 VAC
20 AMPS
TANK HEATER
(Not Booster Heater) 3KW
WASH PUMP MOTOR .1HP
SHIPPING WEIGHT
GL-C (Approximate)
156#
71 kg

Specifications
MODEL GL-C/GW-100 SERVICE & PARTS MANUAL Rev. 1.01BPage4
2.2. GW-100
WATER CONSUMPTION
HOT WATER INITIAL FILL 3 GAL. 11.35 L.
HOT WATER PER HOUR (max) 12 GAL. 45.42 L.
COLD WATER PER HOUR 168 GAL. 636 L.
OPERATING CAPACITY
(2-1/2”) GLASSES PER HOUR 1000 -
WATER REQUIREMENTS
COLD WATER INLET 1/2” -
HOT WATER INLET 1/2” -
DRAIN CONNECTION 1-1/2” -
TEMPERATURES
INLET COLD WATER 75
°
F 24
°
C
INLET HOT WATER (recommended) 140
°
F 60
°
C
FRAME DIMENSIONS
DEPTH 25-1/8” 63.8CM
WIDTH 25-1/4” 64CM
HEIGHT 39”- 40-1/2” 99 -102.8CM
MAX CLEARANCE FOR GLASSES 11-3/4” 29.9CM
ELECTRICAL 120 VAC
11 AMPS
TANK HEATER
(Not Booster Heater) 1.25KW
WASH PUMP MOTOR .1HP
SHIPPING WEIGHT
GW-100 (Approximate)
156#
71 kg

Operation
MODEL GL-C/GW-100 SERVICE & PARTS MANUAL Rev. 1.01BPage5
3. Installation
3.1. Electrical*
GLC - a 20 Amp, 208-240 Volt, 60 Hz dedicated circuit should be used to supply electrical power to the GL-C machine
(see specification sheet page 3). The power connection with the leads L-1, L-2 and Ground must be such that there is
sufficient length of flexible conduit to permit the machine to be moved for cleaning. This machine operates from 208 to
240 Volts.
GW-100 - a 15 Amp, 120 Volt, 60 Hz dedicated circuit should be used to supply electrical power to the GW-100
machine (see specification sheet page 3). The power connection with the leads L-1, L-2 (N) and Ground must be such
that there is sufficient length of flexible conduit to permit the machine to be moved for cleaning.
3.2. Plumbing*
Making Cold Water Connection
1. Connect a cold 1/2” water line to the cold water solenoid valve and inspect for leaks. Water flow pressure
should be between 20-100 PSI.
2. Cold water usage is approximately 2.8 U.S. gpm.
3. Machine is equipped with a mixing valve located between hot and cold solenoid valves. Open until
temperature reaches 75°F for areas with very cold rinse water to heat the rinse water which will prevent
glasses from cracking.
Making Hot Water Connection
1. Connect a hot 1/2” water line to the hot water solenoid valve. The temperature must be minimum 140°F/60°C
with flow pressure between 20-100 PSI.
2. Hot water usage is approximately 12 U.S. gph.
Making Drain Connection
1. Connect a 1-1/2” PVC drain line to the bottom of the scrap tank (note: machine is gravity drain)
*Electrical and plumbing connections must be made by a qualified person who
will comply with all available Federal, State, and Local Health, Electrical,
Plumbing and Safety codes.

Operation
MODEL GL-C/GW-100 SERVICE & PARTS MANUAL Rev. 1.01BPage6
4. Operation
4.1. Filling of the Wash Tank
•With overflow drain tube in place in the detergent tank proceed to following.
•Turn power on-off/flush switch to the “ON” position. The water solenoid will activate and fill soap
tank until the proper level is reached, also activating heating element.
•Set the thermostat for minimum 140°F/60°C. The wash tank temperature is regulated by heater
and thermostat.
4.2. Operation Instructions
•Open the door; place on-off/flush switch to the “ON” position. The wash tank will begin its
automatic fill cycle.
•Verify product containers have chemicals.
•Detergent is fed from the supply container into the detergent tank in controlled amounts by the
detergent pump. Use detergent at strength recommended by your chemical supplier.
•Place glasses on the conveyor wheel. Push conveyor rocker switch located on front right side of
machine. The conveyor wheel will stop and start with conveyor shut-off rod.
4.2.1. Proper Chemical Dosage
The amount of chemical delivered, whether it is detergent, sanitizer or rinse aid, is controlled using the
setscrew located on the circuit board attached to the control box.
•For detergent, contact your chemical supplier for proper type and detergent concentration.
Note: Detergent pump only operates when hot water tank is filling or when prime switches are
activated.
•Circuit board basic settings are: arrow facing 9:00 for sani and rinse, 12:00 for detergent.
Adjustments To Detergent Pump:
•When replacement container is installed, push the prime switch in and hold until the detergent feed line is full.
•Securely place overflow drain tube into soap tank and switch power on-off/flush switch to the “ON” position.
The detergent dispenser will automatically dispense soap as the soap tank fills with water.
•The quantity of product can be regulated at the circuit board using the setscrew.
Adjustments To Sanitizer Pump:
•Follow same procedures as detergent for priming chemical.
•Push conveyor rocker switch located on the front of the machine. Place sanitizer test strip under the final rinse
and read for proper level.
•The quantity of product can be controlled at the sani circuit board set screw.
Note: Use chlorine test papers to verify and monitor the 50ppm chlorine level

Operation
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01B Page7
Adjustments To Rinse Agent Pump:
•Follow same procedures as detergent for priming chemical.
•Cycle glasses through machine and verify rinse agent is feeding properly. Increase rinse aid as
necessary by turning up or down circuit set screw.
•Basic circuit board setting is 9:00.
Note: To meet standards set by NSF, chlorine at 50ppm must be used in the final rinse.
4.3. Cleaning Instructions
4.3.1. Highly Recommended Daily Cleaning Instructions
Remove optional GLC drain tray & waste collector from the front of your glasswasher and clean
thoroughly.
Turn power switch off behind front service door.
Remove all trays, screens and curtains. Wash, rinse them thoroughly and allow to dry.
Move shut-off rod to side and remove conveyor hub and wheel from machine.
Remove and clean wash and rinse arms. Wash tube brush and jet reamer supplied for cleaning of
arms.
Install wash and rinse arms (Wash and rinse arms are different .The receiver arm sockets are molded
differently to prevent placing arms in wrong location).
CAUTION: Do not twist spray arms, pull straight out or they will break
Use reverse procedures for placing conveyor wheel and hub back into position.
Note: conveyor motor can be pulled to the side as your placing wheel into position. Open
front access door and pull conveyor motor toward you as seat the conveyor wheel into
position.
Place conveyor hub in center of conveyor, align shut-off rod to normal position. Install left and right
trays, making sure shut-off rod is positioned between guide brackets. Install curtains into their
holders.
Upper and lower wash tank screens should be removed and cleaned thoroughly.
Pull the drain tube from the soap tank and clean the tank.
Insert overflow drain tube and wash tank screens back to appropriate placement.
Reattach optional GLC waste collection assembly.
Check product levels and close front service door.
4.3.2. Weekly Cleaning Instructions
Remove upper and lower wash and rinse arms from their spray bases, remove end plugs, and clean
spray tubes with Cleaning Drill p/n 00899.01, Cleaning Brush p/n 00899.02 provided.

Maintenance
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage8
5. Troubleshooting
PROBLEM LIKELY CAUSE SOLUTION
The soap tank water
temperature low Thermostat malfunction
Replace
Thermostat set too low
Turn thermostat up
Bad heater Replace
Float switch malfunction
Remove and replace
Water supplied to machine low Must provide 140°F
Low or no pressure in
rinse spray arms
Rinse spray arms dirty Clean spray arms with cleaning
drill and brush provided
Shut-off valve on supply line may
be closed Open valve
Spray arm pressure low Minimum 20-100PSI flow pressure
required
No rinse arm water Rinse solenoid valve non-
operational Check coil
Check and install rebuild kit
Replace if necessary
Solenoid valve strainer or
restrictor disc plugged Remove screen and clean- replace or clean flow restrictor
Product containers filling
with water Plugged rinse arms Clean
Worn flow restrictor in solenoid
valve Replace
No chemical being
dispensed Empty product in containers Refill containers
Chemical lines plugged
Flush lines with hot water and
condition of chemical
Strainer on pick-up tube plugged
Clean with hot water
Circuit board setting too low Increase by turning clockwise
while machine is running/filling
No power to pump
Check LED signal, all electrical
connections
Pump motor or circuit board
defective Replace pump motor or circuit
board
Soap tank continues to fill
with water with power off Leaking solenoid valve diaphragm. Inspect and clean seat
Replace diaphragm kit
Install new valve

Maintenance
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage9
PROBLEM LIKELY CAUSE SOLUTION
Moisture, condensation,
wet areas behind service
door
Pump seal leaking Replace
Detergent tank drain screen
plugged Clean
Primary drain plugged Clean
Rinse water drain line backing up Clear obstruction, clean machine
Return screen in soap detergent
tank plugged Clean
Covers on detergent tank are not
installed properly causing
condensation
Position all top covers to
completely cover top of tank
Wheel not turning Power off at circuit breaker Reset circuit breaker
Drive motor defective Replace
Micro switch on switch support
bracket faulty or not making
contact
Replace or make adjustment to
switch
Conveyor not engaged with drive
gear
Position properly.
Low or no pressure
coming from wash arms No or low water in soap tank
Check water supply
Check tank stand pipe position
Check that fill switch is in On-Fill
position and that tank fills with
water
Check float switch operation
Check hot fill solenoid is
operational
Obstruction in wash arm
Clear obstruction
Wash Pump not running Check power supply
Check pump capacitor
Replace pump
Pump running but no pressure to
wash arms. Inspect the impeller
Replace if needed
Water spraying out
conveyor entrance Spray arms not locked in place Spray arms must be pushed firmly
on to hub connection on spray
base
Spray arms plugged Clear and clean with cleaning drill,
scraper, and brush
Splash curtain not in position Install or adjust
Machine in operation without any
glasses on conveyor Operate machine with a full load of glasses

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01B Page10
6. Parts Manual
6.1. GLC Initial Parts Kit p/n 1100.47
P/N DESCRIPTION Qty
*00120.00 Thermometer (Bi Metal) 1
00201.47 Wash Pump 1
00308.47 Spray Arm End Plug 3
00421.47 Conveyor Rocker Switch 1
00472.47 Conveyor Shut Off Switch 1
00490.47 Wash Pump Capacitor 1
*00631.05 Ice Cube Relay 220V, 12A 1
00631.47 Ice Cube Relay 220V, 20A 1
00715.47 3/8” Check Valve 1
00810.47 Drive Motor 208-240V 1
00811.47 Drive Motor Spring 1
00815.00 Peri Pump Complete 1
00820.00 Peri Pump Circuit Board 1
00821.30 Transformer 220 V 1
00839.00 Squeeze Tube w/conn. 3
00899.01 Cleaning Drill 1
00899.02 Cleaning Brush 1
03470.47 Power on-off/ Flush Switch 1
*03475.00 Primer Switch - Push Button 1
*03623.00 1/2 Vac Breaker Repair Kit Watts 1
13415.47 Heater 3kW 1
*13417.92 Heater Thermostat (EGO) 1
13418.47 Auto-Fill Timer 220V 1
*13605.00 Pressure Gauge 1
13703.47 Curtain – Full Size 1
13703.57 Curtain – Half Size 1
41015.70 Solenoid Valve 3/8" 220V 1
NOTE: Important! CMA recommends that the initial parts kit be purchased immediately and kept on
hand as a back up supply of critical parts in the event your machine should require
emergency service.
All the parts included in this kit are unique to the GL-C glasswasher (except those with *).

Maintenance
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage11
6.2. GW-100 Initial Parts Kit p/n 1100.49
P/N DESCRIPTION Qty
*00120.00 Thermometer (Bi Metal) 1
00201.49 Wash Pump 1
00308.47 Spray Arm End Plug 3
00421.47 Conveyor Rocker Switch 1
00472.47 Conveyor Shut Off Switch 1
*00631.00 Ice Cube Relay 120V, 12A 1
00631.49 Ice Cube Relay 120V, 20A 1
00715.47 3/8” Check Valve 1
00810.49 Drive Motor 120V 1
00811.47 Drive Motor Spring 1
00815.00 Peri Pump Complete 1
00820.00 Peri Pump Circuit Board 1
00821.30 Transformer 120V 1
00839.00 Squeeze Tube w/conn. 3
00899.01 Cleaning Drill 1
00899.02 Cleaning Brush 1
03470.47 Power on-off/ Flush Switch 1
*03475.00 Primer Switch - Push Button 1
*03623.00 1/2 Vac Breaker Repair Kit Watts 1
15417.30 Heater 1250 Watt 1
*13417.89 Heater Thermostat (EGO) 1
13418.49 Auto-Fill Timer 120V 1
*13605.00 Pressure Gauge 1
13703.47 Curtain – Full Size 1
13703.57 Curtain – Half Size 1
41015.49 Solenoid Valve 3/8" 120V 1
NOTE: Important! CMA recommends that the initial parts kit be purchased immediately and kept on
hand as a back up supply of critical parts in the event your machine should require
emergency service.
All the parts included in this kit are unique to the GW-100 glasswasher (except those with *).

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01B Page12
6.3. Exploded View Drawings
6.2.1. Main Assembly
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 2 05004.00 Upper Spray Base Inlet Tube 21 1 16306.50 Right Door
2 2 14754.10 Grommet 22 2 00940.50 Screw, 10-32 x 3/8”
3 4 03101.47 Clamp #6 23 1 00941.00 10-32 X 5/8 Panhead Screw
4 1 03106.47 Braided Hose 3/8” 24 1 00421.45 Switch Bumper
5 1 14755.00 Wash Arm 25 1 16402.60 Front Pillar (Right Hand) 2” taller
6 1 14752.00 Upper Spray Base 26 4 01146.00 Leg 6-1/2”- Thread
7 1 00924.00 Washer,1/4” 27 1 16331.00 Base
8 1 00910.00 Bolt, 1/4-20 x 1 1/2" 28 1 00421.47 Conveyor Rocker Switch
9 4 00940.60 Screw, 10-32 x 3/8” 29 1 16514.50 Conveyor Switch Box
10 1 14756.00 Lower Spray Base Inlet Tube 30 4 00438.00 Snap Bushing Universal 875-11
11 4 14752.10 Spray Base “O” Ring 31 1 16302.00 Side Panel Wrap
12 1 14755.00 Wash Arm 32 1 16330.00 Wash Tank Assy.
13 2 14754.00 Rinse Arm 33 4 00940.60 Screw, 10-32 x 3/8”
14 6 00308.47 Spray Arm End Plug 34 1 16510.50 Vacuum Breaker Access Cover
15 1 14753.00 Lower Spray Base 35 1 16513.00 Top Panel
16 2 00940.50 Screw, 10-32 x 3/8” 36 1 16571.20 Deflector Screen (Rinse)
17 1 16302.50 Face Trim 37 1 16571.00 Drain Deflector (Wash)
18 2 00812.47 Magnetic Door Catch 38 1 16530.50 Tank Support Bracket *
19 1 16302.65 Front Pillar (Left Hand) 39 1 00860.01 Moisture Pad 10 x 23 *
20 1 16306.00 Left Door 40 1 00860.02 Moisture Pad 3 x 23 *
*Not shown. 41 1 00860.03 Moisture Pad 10 x 12 *

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage13
6.2.2. Conveyor Wheel / Curtain
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 16505.00 Curtain Support 6 1 16451.00 Conveyor Hub 2” taller
2 1 13703.47 Curtain 7 1 14750.00 Conveyor Turntable
3 1 16505.10 Curtain Clamp 8 1 16350.50 Tray- Left
4 8 00927.00 Nut, 8-32 9 1 16350.00 Tray- Right
5 8 00911.50 Screw, 8-32 x 3/8” 10 4 14750.10 Turntable Glide Block

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage14
6.2.3. Conveyor Shut-Off Rod Assembly
16 2 00940.50 Truss Head Screw 10-32 x 3/8”
17 1 16320.00 Shut-off Rod
18 1 16521.00 Activator
19 1 00935.00 Socket Set Screw, 1/4-20 x 1/4”
20 1 16514.30 Nut Plate
21 1 00472.47 Conveyor Shut Off Switch
22 1 00438.00 Snap Bushing Universal 875-11
23 2 04806.00 #10 Brass Washer
24 2 01001.00 Pan Head Screw 6-32 x 1"
25 1 16514.00 Conveyor Shut Off Switch Brack.
26 2 03814.10 10-32 Lock Star Washer

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage15
6.2.4. GLC Control Box Assembly P/N 18612.49
Not shown 820.10 Circuit Board Spacer Large, and 821.11 Circuit Board Spacer Small
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 16403.00 GLC/GW-100 Control Box 12 1 00821.30 Transformer 220V
2 1 00470.10 Toggle Switch Rubber Boot 13 1 00815.00 Peri Pump Complete
3 3 13417.92 Heater Thermostat (EGO) 14 1 00818.00 Peri Pump Cover
4 1 13418.47 Auto- Fill Timer 220V 15 1 16515.00 Peri Pump Panel
5 1 00454.06 Power Block 6 Position 16 1 00816.00 Peri Pump Gear Motor
6 3 03475.00 Primer Switch - Push Button 17 1 03470.47 Power on-off/ Flush Switch
7 3 00820.00 Peri Pump Circuit Board 18 4 00438.00 Snap Bushing Universal 875-11
8 1 16504.00 Control Box Lid 19 3 00839.00 GLC Squeeze Tube w/ conn.
9 1 00631.47 Ice Cube Relay 220V, 20A 20 3 03826.47 4-40x3/16 Pan Head Screw
10 2 00631.05 Ice Cube Relay 220V,12A 21 3 00820.06 Circuit Board Stand off
11 3 00820.20 Circuit Board Connector 22 3 00820.07 Circuit Board Stand -off Cap

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage16
6.2.5. GW-100 Control Box Assembly P/N 18611.47
*Not shown
*Not shown
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 16403.00 GLC/GW-100 Control Box 14 1 00818.00 Peri Pump Cover
2 1 00470.10 Toggle Switch Rubber Boot 15 1 16515.00 Peri Pump Panel
3 3 13417.89 Heater Thermostat (EGO) 16 1 00816.00 Peri Pump Gear Motor
4 1 13418.49 Auto- Fill Timer 120V 17 1 03470.47 Power on-off/ Flush Switch
5 1 00454.06 Power Block 6 Position 18 4 00438.00 Snap Bushing Universal 875-11
6 3 03475.00 Primer Switch - Push Button 19 3 00839.00 GLC Squeeze Tube w/ conn.
7 3 00820.00 Peri Pump Circuit Board 20 3 03826.47 4-40x3/16 Pan Head Screw
8 1 16504.00 Control Box Lid 21 3 00820.06 Circuit Board Stand off
9 1 00631.49 Ice Cube Relay 120V, 20A 22 3 00820.07 Circuit Board Stand off Cap
10 2 00631.00 Ice Cube Relay 120V,12A 23 9 00820.10 Circuit Board Spacer Large *
11 3 00821.21 Circuit Board Connector 24 3 00820.20 Circuit Board Connector *
12 1 00821.10 Transformer 120 V 25 9 00821.11 Circuit Board Spacer Small *
13 1 00815.00 Peri Pump Complete

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage17
6.2.5. Soap Tank Assembly
*12A used in the machines built prior to March 2010.Both 12 and 12A must be pointed down
(normally closed position) in order to function properly.
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 03101.49 Hose Clamp #24 13 1 16545.50 Overflow Drain Tube
2 1 03106.40 Ribbed Drain Hose 1 1/2" ID 14 1 00120.00 Thermometer Bi Metal
3 1 03101.00 Hose Clamp # 16 - 1" 15 1 13415.47 GLC Screw Plug Heater 3KW
4 1 03108.60 Transfer Hose 1" Reinforced 15417.30 GW-100 Heater 1250 W, 120V
5 1 03106.45 Braided Hose 1/2" 16 1 13417.92 Heater Thermostat (EGO)
6 1 03101.47 Hose Clamp #6 17 2 00940.50 10-32 X 3/8” Truss Head Screw
7 1 05012.00 1/2 Cu Ref Tubing (Per Foot) 18 1 16522.00 Heater Cover
8 1 16541.00 Detergent tank 19 1 16579.20 Drain Screen
9 1 16544.00 Detergent Tank Screen 20 1 16579.00 Drain Pan
10 1 16543.00 Detergent Tank Rear Cover 21 2 00906.00 1/4-20 X 1/2" Hexhead Bolt
11 1 16542.00 Detergent Tank Lid 22 1 16530.50 Tank Support
12 1 13465.50 Float Switch 23 1 40116.00 1/4 Comp X 1/4 MIP Ftg (not shown)
12A 1 13463.10 S/S Liquid Level Switch *

Parts Manual
MODEL GLC/GW-100 SERVICE & PARTS MANUAL Rev. 1.01 BPage18
6.2.6. Water Inlet Plumbing
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 2 41015.70 Solenoid Valve 3/8” 220V 4 1 00715.47 3/8" Check Valve
41015.49 Solenoid Valve 3/8” 115V 5 1 41014.49 3/8" Ball Valve
1A 2 41015.77 Flow Washer 6 2 40012.10 1/2 Barb x 3/8” MIP Elbow
1B 2 N/A 3/8" Solenoid Valve Repair Kit 7 2 03101.47 Hose Clamp #6
1C 2 N/A 3/8" Solenoid Valve Cover 8 1 03106.45 Braided Hose 1/2"
1D 2 41015.60 3/8" Solenoid Valve Coil 9 1 40019.00 Nipple Brass 3/8 x 2 1/2
2 2 40010.00 3/8” MPT Tee 10 3 40012.47 Adapter 3/8"FPT X 3/8" MIP
3 2 40017.00 1/2 x 3/8” FPT Reducer
