CMA Dishmachines AH User manual

MODELS AH/B/C/S
PARTS MANUAL
Rev 1.03
CMA DISHMACHINES
12700 KNOTT STREET
GARDEN GROVE, CALIFORNIA 92841
800-854-6417
FAX [phone]

TABLE OF CONTENTS
MODEL AH/B/C/S.
1. PARTS MANUAL.......................................................................................... 4
1.1. INITIAL PARTS KIT (P/N 01100.20).....................................................................................................4
1.2. EXPLODED VIEW DRAWINGS...............................................................................................................5
1.2.1. Cabinet Assembly for Model AH.................................................................................................5
1.2.2. Cabinet Assembly for Model B ...................................................................................................6
1.2.3. Cabinet Assembly for Model B Energy Saver.............................................................................7
1.2.4. Cabinet Assembly for Model CB Right Door Only.....................................................................8
1.2.5. Cabinet Assembly for Model CB Left Door Only........................................................................9
1.2.6. Cabinet Assembly For Model C..............................................................................................10
1.2.7. Control Box Assembly for Model AH, B and C.........................................................................11
1.2.8. Door Actuator Assembly...........................................................................................................12
1.2.9. Door Actuator Assembly for Model C.......................................................................................13
1.2.10. Pump Assembly AH and C........................................................................................................14
1.2.11. Pump Assembly For Model B ...................................................................................................15
1.2.12. Plumbing System Assembly for Model AH and C.....................................................................16
1.2.13. Plumbing System Assembly for Model B...................................................................................17
1.2.14. Spray System Assembly for Model AH......................................................................................18
1.2.15. Spray System Assembly for Models B/CB Left..........................................................................19
1.2.16. Spray System Assembly for Model B.........................................................................................20
1.2.17. Spray System Assembly for Model B Energy Saver..................................................................21
1.2.18. Spray System Assembly for Model C ........................................................................................22
1.2.19. Spray Base Conversion Kit.......................................................................................................23
1.2.20. Drain System Assembly for Model AH and C...........................................................................24
1.2.21. Drain System Assembly for Model B.........................................................................................25
1.2.22. Peristaltic Pump Assembly .......................................................................................................26
1.2.23. Unique Parts For Scullary AH .................................................................................................27
1.2.24. Unique Parts For Scullery B.....................................................................................................28
1.2.25. Unique Parts For Scullery C....................................................................................................29
1.2.26. Unique Parts For Pizza Machines............................................................................................30
1.3. OPTIONAL SOLID BOWL ....................................................................................................................31
1.4. OPTIONAL SANI ALARM ....................................................................................................................32
1.5. TEMP-SURE HEATER. ........................................................................................................................33

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 4
1. Parts Manual
1.1. Initial Parts Kit (P/N 01100.20)
P/N DESCRIPTION Qty
00100.00 Drain Ball Solenoid 120V 1
00120.00 Thermometer (Bi Metal) 1
00121.00 Drain Ball 1
00200.10 Pump Assy 110/220V 60Hz (Open) 1
00206.00 Pump Seal Kit 1
00304.03 Spray Arm B L1-C & L-1X 1
00304.06 Spray Arm A & C 1
00308.50 Spray Arm End Plug SS 1
00341.00 Spray Arm Bearing (Cleanable) 1
00363.00 Spray Base Lock Pin 1
00404.82 Motor Contactor 120 VAC 1
00411.00 Micro Switch 1
00415.00 Peristaltic Pump Assy 120V/60Hz 1
00418.00 Peristaltic Pump Cover 1
00421.40 Start/Fill switch 1
00433.00 Master Switch (30 Amp) 1
00435.00 Squeeze Tube 8" Silicone 1
00500.00 Timer Motor 90 Sec 110V/60Hz 1
00562.00 Roller Door Switch 1
00631.00 Ice Cube Relay 120V 1
00706.00 3/4 Water Solenoid Repair Kit JE 1
00715.00 1/2 Ball Check Valve 1
00735.00 3/4 Vac Breaker Rep Kit Watts 1
00738.10 Solenoid Coil JE 120V (3/4 &1/2) 1

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 5
1.2. Exploded View Drawings
1.2.1. Cabinet Assembly for Model AH
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 2 01506.30 Door 11 3 00725.50 1/2" Plumbing Strap
2 1 01530.02 Wrapper 12 4 01310.00 Bullet Foot
3 33 00912.00 1/4-20 Lock Nut 13 1 01558.20 Chemical Tube Support Bracket
4 50 00926.00 SS Washer 1/4" 13A 4 00427.00 Line Bracket Snap Bushing
5 16 00905.00 1/4-20 x 1/2" Truss Head Bolt 14 4 00636.10 EZ Glide Plastic Guide
6 1 01505.02 Tray Track (Set) 15 4 01572.10 SS Leg (A, AH, C, B)
7 1 01531.02 Pan 16 2 01571.00 Drain Baffle
8 17 00906.00 1/4-20 x 1/2" Hex Head Bolt 17 1 01577.10 Scrap Trap Body Molded
9 1 01532.52 Frame Stand 18 1 01577.20 Scrap Trap Drawer Molded
10 4 01554.30 EZ Glide Door Guide SS 19 1 01577.25 Scrap Trap Lid Molded

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 6
1.2.2. Cabinet Assembly for Model B
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 01530.03 Wrapper (TM-B) 12 2 01571.00 Drain Baffle
2 1 01501.03 Pan Double (B) 12A 4 00427.00 Snap Bushing 375-4
3 1 01532.53 Stand TM-B (w/o Legs) 13 1 01558.20 Chemical Tube Support Bracket
4 1 01577.10 Scrap Trap Body Molded 14 3 00725.50 1/2" Plumbing Strap
5 1 01577.20 Scrap Trap Drawer Molded 15 16 00905.00 Trusshead Bolt 1/4"-20 x 1/2"
6 1 01577.25 Scrap Trap Lid Molded 16 22 00906.00 Hex Head Bolt 1/4"-20 x 1/2"
7 1 01505.03 Tray Track B (Set of 2) 17 72 00924.00 SS Washer, 1/4"
8 4 01554.30 EZ Glide Door Guide SS 21 1/8” 18 38 00912.00 SS Nylon Lock Nut, 1/4"
9 4 00636.10 EZ Glide Door Guide (Plastic) 19 4 01572.10 SS Leg (A, AH, C, B)
10 2 01506.30 SS Door (A, B, C, M, CMA-44) 20 4 01310.00 Bullet Foot
11 2 01505.13 Support Bracket for B Tray Track 21 --- 01145.00 Leg Assembly, 10” w/Bullet Foot

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 7
1.2.3. Cabinet Assembly for Model B Energy Saver
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 01530.43 ES-B Wrapper 12 2 01571.00 Drain Baffle
2 1 01501.43 ES-B Pan 12A 4 00427.00 Snap Bushing 375-4
3 1 01532.53 Stand TM-B (w/o Legs) 13 1 01558.20 Chemical Tube Support Bracket
4 1 01577.10 Scrap Trap Body Molded 14 3 00725.50 1/2" Plumbing Strap
5 1 01577.20 Scrap Trap Drawer Molded 15 16 00905.00 Trusshead Bolt 1/4"-20 x 1/2"
6 1 01577.25 Scrap Trap Lid Molded 16 22 00906.00 Hex Head Bolt 1/4"-20 x 1/2"
7 1 01505.03 Tray Track B (Set of 2) 17 72 00924.00 SS Washer, 1/4"
8 4 01554.30 EZ Glide Door Guide SS 21 1/8” 18 38 00912.00 SS Nylon Lock Nut, 1/4"
9 4 00636.10 EZ Glide Door Guide (Plastic) 19 4 01572.10 SS Leg (A, AH, C, B)
10 2 01506.30 SS Door (A, B, C, M, CMA-44) 20 4 01310.00 Bullet Foot
11 2 01505.13 Support Bracket for B Tray Track 21 --- 01145.00 Leg Assembly, 10” w/Bullet Foot

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 8
1.2.4. Cabinet Assembly for Model CB Right Door Only
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 01530.24 Wrapper CB (For RD) 6 1 00246.24 Motor suction Tube CB (For RD)
2 1 01501.24 Pan CB (For RD) 7 1 00246.14 Motor suction Tube CB (For RD)
3 1 01506.25 Side Door CB (For RD) 8 1 01556.50 RH Door Handle Support Bracket
4 1 00613.25 Door Handle CB (Right) 9 1 01555.50 LH Door Handle Support Bracket
5 1 01505.24 Tray track CB(RD) 10 1 01553.24 Door Handle Link CB

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 9
1.2.5. Cabinet Assembly for Model CB Left Door Only
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 01530.25 Wrapper CB (For LD) 7 1 00246.25 Motor suction Tube CB (For LD)
2 1 01501.25 Pan CB (For LD) 8 1 00246.15 Motor suction Tube CB (For LD)
3 1 01506.24 Side Door CB (For LD) 9 1 01555.50 LH Door Handle Support Bracket
4 1 00613.24 Door Handle CB (Left) 10 1 01556.50 RH Door Handle Support Bracket
5 1 01505.25 Tray Track CB (LD) 11 1 01553.24 Door Handle Link CB
6 1 00111.00 Drain Sump Casting CB (LD)

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 10
1.2.6. Cabinet Assembly For Model C
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 01500.14 Wrapper Corner (C) 14 1 01558.20 Chemical Tube Support Bracket
2 1 01501.04 Frame Pan (C) 14A 4 00427.00 Line Bracket Snap Bushing
3 1 01532.54 Frame Stand 15 1 00101.10 Solenoid Bracket CRH
4 4 01572.10 Stand Legs (A, AH, C, B) 16 16 00905.00 Trusshead Bolt 1/4"-20 x 1/2"
5 2 01506.30 Door A, B, C, M, CMA-44 17 1 00101.20 Solenoid Bracket CLH
6 4 01554.30 Door Guide SS 21 1/8” 18 34 00912.00 Nylon Lock Nut, 1/4"-20
7 4 00636.10 EZ Glide Door Guide (Plastic) 19 12 00914.10 Hexhead Bolt ¼-20 x 5/ 8 "
8 1 01505.04 Tray Track Corner 20 12 01906.00 Hexhead Bolt ¼-20 x ½ "
9 1 01577.10 Scrap Trap Body Molded 21 68 00924.00 1/4’’ SS Washer
10 1 01577.20 Scrap Trap Drawer Molded 22 1 01570.24 Pan Support Bracket C
11 1 01577.25 Scrap Trap Lid Molded 23 1 01577.50 Molded Scrap Trap Mount Bracket
12 4 01310.00 Bullet Feet 24 1 00924.00 1/4" SS Washer
13 2 01571.00 Drain Baffle 25 1 00912.00 ¼ x20 Nylon Lock Nut
26 1 00911.00 8-32x1/2 ‘’Pan Head Screw

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 11
1.2.7. Control Box Assembly for Model AH, B and C
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 01503.14 Control Box Body AH-B-C 22 3 00918.00 8-32 X 1 ½” Fillister Bolt
2 1 01504.14 Control Box Lid AH-B-C 23 12 00911.00 8-32 X ½” Panhead screw
3 1 00407.80 Timer 90 Sec 8 Cam 120V 24 1 00464.07 3/8” SS Tubing (For Solenoid Wire
4 1(2) 00404.82 Motor Contactor 120V AH/C (B) 25 1 00436.00 3/8” 90Deg Elbow Comp X Mip
5 1 00433.10 Master Switch (20Amp) 26 1 00712.00 3/8” jamb Nut (Plated)
6 1 00631.00 Ice Cube relay 120V 27 1 00712.30 3/8” jamb Nut (standard)
7 1 00454.10 3 Pole Socket Terminal Block 28 1 03408.50 Counter (Panel Mount) 120V
8 1 13825.00 8-32 X 1” Pan Head Screw 29 3 03470.00 Primer Switch (Momentary)
9 1 00450.00 Key Only 30 1 00475.00 Delimer Switch (DPDT 15Amp)
10 1 00449.00 Lock and Key 31 1 00562.60 Roller Switch Connector
11 8 00411.00 Microswitch 32 1 00421.40 Start/Fill Switch (With light)
12 1 00500.00 Timer Motor 120V (For 90Sec Timer) 33 3FT 00546.00 Switch Cord
13 4 00911.50 8-32 X 3/8” Pan Head Screw 34 4 00914.00 ¼ “ –20 X ¾” Hex Head Bolt
14 AR 00400.00 Conduit 3/8” Sealtite 35 4 00922.00 ¼” Lock Star Washer
15 2 00401.00 St. Straight 3/8” Connector 36 4 00912.00 ¼”-20 Nylon Lock Nut
16 4 00402.00 St. 90Deg 3/8” Connector 37 1 00535.00 Control Box Lid Handle
17 4 00438.00 Snap Bushing 875-11 38 1 01514.00 Timer Support Bar
18 3 00416.00 Peristaltic Pump Motor 120V 39 4 00470.10 Toggle Switch Rubber Boot
19 3 00417.00 Peristaltic Pump Block 40 1 00562.00 Roller Switch
20 3 00419.00 Peristaltic Pump Rotor 41 1 00927.00 8-32 Nylon Lock Nut
21 6 00919.00 8-32 X 1 ½” Panhead Bolt 42 3 00418.00 Peristaltic Pump Cover

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 12
1.2.8. Door Actuator Assembly
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
00613.32 Door Handle, 1” (Model AH) 11 4 00906.00 1/4-20 x 1/2" Hex Head Screw1 1
00613.33 Door Handle, 1” (Model B) 12 6 00924.00 1/4" SS Washer
2 1 01556.50 Door Handle Support, 1” (Right) 13 8 00912.00 1/4-20 Nylon Locknut
3 2 00603.07 Door Spring Extension Rod 14 4 00610.00 Door Handle Spacer, Small
4 2 00602.00 Door Spring 15 4 00611.00 Door Handle Spacer, Large
5 2 01506.30 Door (Cut Away) 16 2 00910.00 1/4-20 x 1-1/2” Hex Bolt
6 2 01553.00 Door Handle Link 17 1 01555.50 Door Handle Support, 1” (Left)
7 2 00606.00 5/16-18 x 7” Eyebolt 18 2 00903.00 1/4-20 x 1-3/4” Hex Head Bolt
8 2 00913.00 5/16-18 Nut 19 2 00607.04 Door Handle Cap, 1”
9 2 00926.00 5/16” SS Washer 20 2 01552.00 Door Stop
10 2 00900.00 Cotter Pin

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 13
1.2.9. Door Actuator Assembly for Model C
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 00613.04 Door Handle 11 2 01552.00 Door Stop
2 1 00619.34 Door Handle Mounting Plate, Long 12 6 00924.00 1/4" SS Washer
2A 1 00619.44 Door Handle Mounting Plate, Short 13 4 00912.00 1/4-20 Nylon Lock Nut
3 1 00603.04 Extension Rod 14 4 00610.00 Door Handle Spacer, Small
4 2 00602.00 Door Spring 15 4 00611.00 Door Spacer, Large
5 2 01506.30 Door (Cut Away) 16 2 00903.00 1/4-20 x 1-3/4” Hex Head Bolt
6 2 01553.00 Door Handle Link 17 8 00926.00 5/16” SS Washer
7 1 00606.00 5/16-18 x10” Eyebolt 18 2 00910.00 1/4-20 x 1-1/2” Hex Head Screw
8 9 00913.00 5/16-18 Nut 19 2 00607.04 Door Handle Cap
9 9 00926.00 5/16 SS Washer 20 8 00920.00 5/16-18 x 3/4" Hex Head Bolt
10 1 13805.00 5/16-18 Nylon Lock Nut 21 1 00563.20 Limit Switch Door Bracket

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 14
1.2.10. Pump Assembly AH and C
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 00201.00 Pump Motor, 1 HP 12 1 00246.01 Motor Suction Tube (A/AH)
2 2 00975.00 3/8”-16 x 1 ½” SS Stud 12A 1 00246.04 Motor Suction Tube (C)
3 1 00206.00 Pump Seal Kit 13 1 13916.00 Motor Support Bracket
4 2 00207.00 1 ½” x 1 ¼” Slip Joint Nut 14 1 00906.00 1/4”-20 x ½” Hex Head Bolt
5 3 00208.00 Slip Joint Nut Gasket 15 1 00924.00 ¼” SS Washer
6 1 00768.20 Pump Inlet Elbow SS Casting 16 1 00912.00 1/4"-20 Nylon Lock Nut
7 1 03224.00 Pump Base Small 17* 1 00200.10 Pump Assy.
8 1 03226.00 Pump O-Ring 18 1 00214.50 1/2 Comp x 3/8” M.I.P. F.T.G.
9 1 03222.05 Open Impeller 19 6 00921.00 3/8”-16 x ¾” SS Head Bolt
10 1 04206.00 Pump Cover, Small 20 3 00208.20 Slip Joint Nut Friction Ring
11 1 04204.00 Compression Nut (2.5”) *P/N 00200.10 includes items 1, 3, 7, 8, and 9 already assembled.

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 15
1.2.11. Pump Assembly For Model B
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 00201.00 Pump Motor, 1 HP 11 1 04204.00 Compression Nut (2.5”)
2 2 00975.00 3/8”-16 x 1 ½” SS Stud 12 1 00246.23 Motor Suction Tube
3 1 00206.00 Pump Seal Kit 13 1 13916.10 Motor Support Bracket
4 2 00207.00 1 ½” x 1 ¼” Slip Joint Nut 14 3 00906.00 1/4”-20 x ½” Hex Head Bolt
5 3 00208.00 Slip Joint Nut Gasket 15 3 00924.00 ¼” SS Washer
6 1 00768.20 Pump Inlet Elbow SS Casting 16 3 00912.00 1/4"-20 Nylon Lock Nut
7 1 03224.00 Pump Base Small 17* 1 00200.10 Pump Assy.
8 1 03226.00 Pump O-Ring 18 1 00214.50 1/2 Comp x 3/8” M.I.P. F.T.G.
9 1 03222.05 Open Impeller 19 6 00921.00 3/8”-16 x ¾” SS Head Bolt
10 1 04206.00 Pump Cover, Small 20 3 00208.20 Slip Joint Nut Friction Ring
21 1 00238.00 3/8” Mail Plug
*P/N 00200.10 includes items 1, 3, 7, 8, and 9 already assembled.

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 16
1.2.12. Plumbing System Assembly for Model AH and C
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 13029.00 3/4"Strainer Ball Valve 15 1 00735.60 Vacuum Breaker Bonnet, Brass
2 1 00798.00 SS Braided Hose 16 1 00739.50 Vacuum Breaker Cap SS
3 1 00715.00 Ball Check Valve 17 1 00738.10 Solenoid Coil, J/E
4 1 00760.00 5/8” Comp x 1/2” MIP Fitting 18 1 00705.20 Water Solenoid Valve Bonnet
5 1 00214.50 1/2" Comp x 3/8” MIP Fitting 19 1 00710.50 3/4" Vacuum Breaker
6 1 00795.00 Flush Tube 20 1 00786.00 Water Solenoid Plunger, G Style ¾” x ½”
7 1 00770.10 5/8 Compression Ftg. Nut 21 1 00706.00 Repair Kit (Water Solenoid)
8 1 00770.20 5/8 Compression Ftg. Ring 22 1 00706.10 3/4" Solenoid Plunger, Spring Only
9 1 00770.00 Water Inlet Elbow Assy 23 1 00705.00 3/4" Water Solenoid
10 2 00721.00 1/2" Jamb Nut 24 1 00781.00 3/4" x 3-½” Nipple, Brass
11 1 00748.00 Sprinkler Head 25 1 01525.06 Plumbing Support Bracket
12 2 00701.00 3/4" x 1-½” Nipple 26 1 00704.00 3/4" Street Elbow
13 2 00704.00 3/4" Street Elbow 25 1 00912.00 1/4"-20 Nylon Lock Nut
14 1 00735.00 Repair Kit (Vacuum Breaker) 27 1 00706.10 3/4" Solenoid Plunger, Spring Only
27A 1 00926.00 1/4" SS Washer

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 17
1.2.13. Plumbing System Assembly for Model B
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 13029.00 3/4"Strainer Ball Valve 16 1 00739.50 Vacuum Breaker Cap SS
2 1 00798.00 SS Braided Hose 17 1 00738.10 Solenoid Coil, J/E
3 1 00715.00 Ball Check Valve 18 1 00705.20 Water Solenoid Valve Bonnet
4 1 00760.00 5/8” Comp x 1/2” MIP Fitting 19 1 00710.50 3/4" Vacuum Breaker
5 1 00214.50 1/2" Comp x 3/8” MIP Fitting 20 1 00786.00 Water Solenoid Plunger, G Style ¾” x ½”
6 1 00795.00 Flush Tube 21 1 00706.00 Repair Kit (Water Solenoid)
7 1 00770.10 5/8 Compression Ftg. Nut 22 1 00706.10 3/4" Solenoid Plunger, Spring Only
8 1 00770.20 5/8 Compression Ftg. Ring 23 1 00705.00 3/4" Water Solenoid
9 1 00770.00 Water Inlet Elbow Assy 24 1 00781.00 3/4" x 3-½” Nipple, Brass
10 2 00721.00 1/2" Jamb Nut 25 1 01525.06 Plumbing Support Bracket
11 1 00748.00 Sprinkler Head 26 1 00704.00 3/4" Street Elbow
12 2 00701.00 3/4" x 1-½” Nipple 25 1 00912.00 1/4"-20 Nylon Lock Nut
13 2 00704.00 3/4" Street Elbow 27 1 00706.10 3/4" Solenoid Plunger, Spring Only
14 1 00735.00 Repair Kit (Vacuum Breaker) 27A 1 00926.00 1/4" SS Washer
15 1 00735.60 Vacuum Breaker Bonnet, Brass 28 1 00743.10 ½” Tee FxFxF Brass

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 18
1.2.14. Spray System Assembly for Model AH
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 00361.10 Upper Spray Base, SS* 9 16 00924.00 1/4" SS Washer
2 1 00360.10 Lower Spay Base, SS* 10 2 00302.51 O-Ring Spray Base
3 2 00304.06 Spray Arm A/C Series 11 4 00914.10 1/4"-20 x 5/8” Hexhead Bolt
4 1 00303.32 Manifold, AH 12 2 00341.00 Spray Arm Bearing
5 4 00363.00 Spray Base Lock Pin** 13 4 00929.00 1/4"-20 x 3/4" Trusshead Bolt
6 4 00308.50 Spray Arm End Plug 14 1 00363.10 Lock Arm Spring
7 1 00302.00 Spray Base Gasket 15 2 00966.10 10-32 x 1/4" Hexhead Bolt
8 8 00912.00 1/4 Nylon Lock Nut * Includes item 5, P/N 00363.00
** Includes item 14, P/N 00363.10

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 19
1.2.15. Spray System Assembly for Models B/CB Left
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 1 00361.40 Upper Spray Base, SS* 9 16 00924.00 1/4" SS Washer
2 1 00360.40 Lower Spay Base, SS* 10 2 00302.51 O-Ring Spray Base
3 2 00304.03 Spray Arm B Series 11 4 00914.10 1/4"-20 x 5/8” Hex Head Bolt
4 1 00303.33 Manifold B 12 2 00341.00 Spray Arm Bearing
5 4 00363.00 Spray Base Lock Pin** 13 4 00929.00 1/4"-20 x 3/4" Truss Head Bolt
6 4 00308.50 Spray Arm End Plug 14 1 00363.10 Lock Arm Spring
7 1 00302.00 Spray Base Gasket 15 2 00966.10 10-32 x 1/4" Hex Head Bolt
8 8 00912.00 1/4 Nylon Lock Nut * Includes item 5, P/N 00363.00
** Includes item 14, P/N 00363.10

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 20
1.2.16. Spray System Assembly for Model B
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM
NO. NO. REQ’D P/N DESCRIPTION
1 1 00361.10 Upper Spray Base, SS* 9 16 00924.00 1/4" SS Washer
2 1 00360.10 Lower Spay Base, SS* 10 2 00302.51 O-Ring Spray Base
3 2 00304.03 Spray Arm B Series 11 4 00914.10 1/4"-20 x 5/8” Hex Head Bolt
4 1 00303.33 Manifold B 12 2 00341.00 Spray Arm Bearing
5 4 00363.00 Spray Base Lock Pin** 13 4 00929.00 1/4"-20 x 3/4" Truss Head Bolt
6 4 00308.50 Spray Arm End Plug 14 1 00363.10 Lock Arm Spring
7 1 00302.00 Spray Base Gasket 15 2 00966.10 10-32 x 1/4" Hex Head Bolt
8 8 00912.00 1/4 Nylon Lock Nut * Includes item 5, P/N 00363.00
** Includes item 14, P/N 00363.10

Parts Manual
MODEL AH, B & C PARTS MANUAL Rev. 1.03 Page 21
1.2.17. Spray System Assembly for Model B Energy Saver
ITEM
NO. NO. REQ’D P/N DESCRIPTION ITEM NO. NO. REQ’D P/N DESCRIPTION
1 4 00914.00 1/4-20 X 3/4 Hexhead Bolt 9 1 04306.00 Square Manifold Gasket
2 9 00924.00 1/4 SS Washer 10 1 00905.82 1/4-20 X 3/8 Truss Head Bolt
3 4 00912.00 1/4-20 Nylon Lock Nut 11 2 00357.43 ES-B Lower Spray Base
4 1 00966.10 10-32 X 1/4 Hexhead SS Bolt 12 4 00363.00 Spray Base Lock Pin*
5 4 00342.00 ES Spray Arm Bearing 13 4 00302.51 O-Ring Spray Base
6 4 00310.50 ES Spray Arm Short (6 Jets) 14 1 00363.10 Lock Arm Spring
7 4 00308.50 Spray Arm End Plug SS 15
8 1 00305.43 ES-B Manifold w/ Upper Spray
* Includes item 14, P/N 00363.10
