The DP Series are powerful DSP based loudspeaker processors, ideally suited for install application, where they
combine the functions of a multitude of conventional products in a compact 1U unit with extensive remote control
capabilities. To achieve this, the DP Series devices have two inputs, three inputs, and four inputs and up to eight
outputs.
Base crossover modes:
6 Outputs have 2x2 way, 2x3 way, 4+2 way, 5+1 way and 6 way.
Each output has a gain control, variable delay line, highpass and lowpass crossover filters, seven band multi-type filters,
polarity, input signal source, a limiter. The crossover filters offer slopes of up to 48dB/Octave.
Security lock-out is avaiable for each parts.
Supply external device remote controls.
Remote port is and RS485.
8 Outputs have 2x2 way, 2x3 way, 2x4 way, 4+4 way, 5+3 way and 6+2 way.
4 Outputs have 2x2 way, 3+1 way, 4 way and 2 MonoSub.
Units also offer “Source” for free assign signal, which allows completely flexible routing of any output from any
combination of inputs.
Each input has a gain control, variable delay line, multi-type filters. Filter types included parametric equalisation,
high & low shelving, notch, band-pass, all-pass, variableQ highpass & lowpass.
RS232

Front Panel
Rear Panel
12
1. LCD Sreeen: Show, the name of last recalled memory on the bottom line of the screen, and current device model
name on the top line. Also used to show all parameters as they are edited, and all menu selections.
2. BACK/ NEXT: Moves backwards or forward through list of parameters.
MENU: Activates the main menu.
BYPASS: Bypass filter.
QUIT: Quit key.
ENTER: Enter key.
3. Rotary Encoders: Three velocity encoders adjust parameters.
4. MUTE: These buttons illuminate when pressed and mute audio for that channel.
(Press and Hold 3 seconds) Access current channel parameters.
5. Meters: Input and Output meters show dB from clipping point. Red CLIP LED show signal overflow, Yellow LED
show signal near -3dB.
1. Power Switch: turns the device’s mains supply off and on.
2. RS232: RS232 standard via a 9 pin D-type connector, for connection to PC.
3. RS485: RJ45 style sockets. Used for transmission of remote control data over long distance or multiply device
applications.
4. Audio Inputs: 3 pin XLR sockets are provided for each channel. All are fully balanced, pin 2 hot, 3 cold, 1 screen.
5. Audio Outputs: 3 pin XLR sockets are provided for each channel. All are fully balanced, pin 2 hot, 3 cold, 1 screen.
354
3
12
5
4
~

IN PUT
A
GA IN PEQ DELAY MU TE Graphic EQ
OUTPU T
1
HP F LPF LIMITER
PEQ DELAY GAIN MUTE
Diagram of input channels
Diagram of output channels

Input Gain
The range of the control over the input gain is -40dB to +6dB in 0.1dB steps.
InputA Gain
Gain = + 0 0dB.
Gain
Input Delay
InputA Delay
Delay = 0 000mS.
x10uS
4mm
The maximum avaiable delay depend on different devices.
Input Graphic EQ
The Graphic EQ only avaiable some devices.
The equaliser can be 1/3 or 2/3 Octave, and a gain range of -12dB ~ +12dB in 0.1dB steps.
Frequency Gain
InputA GEQ 1
1k00Hz ----- +0 0dB
:
.
InputA GEQ 1
1k00Hz ----- +0 0dB
:
.
Pressing BYPASS will bypass the entire Graphic EQ.
Input Link
Set link value for channel, while modify parameters, the channel of have same link value will modify together.
InputA Link
Link = None
Link
Bypass
x10mS
3.43 m
x1mS
343mm

InputA All-EQ
Bypass = Off
Input Parametric EQ
Pressing BYPASS will bypass the All bands EQ.
Frequency ‘Q’ Gain
InputA PEQ 01
1k00Hz Q=3 0 +0 0dB
:
. .
The range of frequency is 20Hz to 20kHz in 1/36 Octave. The range of Q is 0.4 to 128. The range of gain is -30dB to
+15dB in 0.1dB steps.
InputA LSF 01
1k00Hz Q= 71 +0 0dB
:
. .
InputA HSF 01
1k00Hz Q= 71 +0 0dB
:
. .
InputA PEQ 01
1k00Hz Q=3 0 +0 0dB
:
. .
Pressing BYPASS will bypass the current band EQ.
While filter was in BYPASS ON, Changing the filter type is achieved by pressing ENTER.
Frequency ‘Q’ Gain
Frequency ‘Q’ Gain
Bypass
Bypass
Frequency ‘Q’
Frequency ‘Q’
Frequency ‘Q’
InputA APF 01
1k00Hz Q= 71
:
. -----
InputA BPS 01
1k00Hz Q= 71
:
. -----
InputA NOT 01
1k00Hz Q= 71
:
. -----
Frequency ‘Q’
Frequency ‘Q’
InputA LPF 01
1k00Hz Q= 71
:
. -----
InputA HPF 01
1k00Hz Q= 71
:
. -----
( )LoShelf
( )HiShelf
( )Allpass
( )Bandpass
( )Notch
( )Lowpass
( )Highpass

Output Polarity
Output Gain
The range of the control over the input gain is -40dB to +15dB in 0.1dB steps.
The polarity (or phase) of each output may be switched individually.
Out1 Output1 Polarity
Polarity = [+]
Out1 Output1 Gain
Output Gain = + 0 0dB.
Gain
- or +
Output Delay
Out1 Output1 Delay
Delay = 0 000mS.
The maximum avaiable delay depend on different devices.
Output Highpass/Lowpass Filter
The highpass/lowpass filter on each output has a frequency range of 20Hz to 20kHz in 1/36 Octave steps.
Crossover slope can be 6dB, 12dB, 18dB, 24dB, 36dB and 48dB/Octave.
Filter type can be Butterworth, Linkwitz-Riley, Bessel.
Frequency Slope
Frequency Slope
Out1 Output1 HPF
20 5Hz Butwrth 24dB.
Out1 Output1 LPF
20k2Hz Lnk/Ril 48dB
x10uS
4mm
x10mS
3.43 m
x1mS
343mm

Output Parametric EQ
The range of frequency is 20Hz to 20kHz in 1/36 Octave. The range of Q is 0.4 to 128. The range of gain is
-30dB to +15dB in 0.1dB steps.
Pressing BYPASS will bypass the All bands EQ.
While filter was in BYPASS ON, Changing the filter type is achieved by pressing ENTER.
Pressing BYPASS will bypass the current band EQ.
Out1 Output1 APF 01
1k00Hz Q= 71
:
. -----
Out1 Output1 BPS 01
1k00Hz Q= 71
:
. -----
Out1 Output1 NOT 01
1k00Hz Q= 71
:
. -----
Out1 Output1 LPF 01
1k00Hz Q= 71
:
. -----
Out1 Output1 HPF 01
1k00Hz Q= 71
:
. -----
Frequency
Frequency
Frequency
Frequency
Frequency
Bypass
Bypass
‘Q’
‘Q’
‘Q’
‘Q’
‘Q’
Out1 Output1 All-EQ
Bypass = Off
Out1 Output1 PEQ 01
1k00Hz Q=3 0 +0 0dB
:
. .
Out1 Output1 PEQ 01
1k00Hz Q=3 0 +0 0dB
:
. .
Out1 Output1 LSF 01
1k00Hz Q= 71 +0 0dB
:
. .
Out1 Output1 HSF 01
1k00Hz Q= 71 +0 0dB
:
. .
( )LoShelf
( )HiShelf
( )Allpass
( )Bandpass
( )Notch
( )Lowpass
( )Highpass
Frequency ‘Q’ Gain
Frequency ‘Q’ Gain
Frequency ‘Q’ Gain

Output Channel Name
For edit channel name by pressing ENTER. Cursor will blink on first character position.
Turn rotary encoder and modify character, move cursor position by pressing BACK or NEXT.
Pressing ENTER again for confirm and store channel name.
Output Link
Set link value for channel, while modify parameters, the channel of have same link value will modify together.
Out1 Output1 Name
Name = Output1
Out1 Output1 Link
Link = None
Source
The source on each output, can assign signal rounting from input channel, create free Xover combination.
Out1 Output1 Source
Source = A
Out1 Output1 InputA
Mix Gain = +0 0dB.
Output Limiter
The limiter on each output has adjustable attack time, release time and threshold.
The range of attack time 0.3 to 90mS, the range of release time 0.1 to 2.0 second, the range of threshold -10dB to
+15dB in 0.1dB steps.
Out1 Output1 Limiter
A:1 4mS R:2 0S +15dB. .
Attack Release Threshold
Char
Source
MixGain
Pressing ENTER will switch each input channel mix gain.
Link

Menu System
Program Sub-menu
Load Factory Program.
Load User Program.
Design a Xover.
Save User Program.
Delete User Program.
Pressing ENTER will enter Load User Program sub-menu.
Turn rotary encoder to change program index,
Pressing ENTER
Pressing ENTER for confirm and load program.
Pressing ENTER will enter Design a Xover sub-menu.
MAIN MENU
Program Sub Menu
:......
-
MAIN MENU
System Sub Menu
:......
-
MAIN MENU
CopyTools Sub Menu
:......
-
MAIN MENU
Interface Sub Menu
:......
-
PROGRAM MENU
Load User Program
:...
Load User Program
01 2x3 Way Xover:
[ ] .
:
ENTER for Recall
01 2x3 Way Xover
Loading New Program
01 2x3 Way Xover:
PROGRAM MENU
Design a Xover
:...
MAIN MENU
Security Sub Menu
:......
-
Pressing MENU will enter menu system. Pressing ENTER will enter sub-menu.
Turn rotary encoder to change Xover mode,
Pressing ENTER
Pressing ENTER for confirm and change Xover mode.
About Xover mode details, see Appendix I.
Design a Xover
Type 2x2 WAY XOVER:
New Xover
ENTER to Confirm[ ]

PROGRAM MENU
Save User Program
:... Pressing ENTER will enter Save User Program sub-menu.
Save User Program
01 2x3 Way Xover: ?
Turn rotary encoder to change program index,
Pressing ENTER.
[ ]
: ?
ENTER to Overwrite
01 2x3 Way Xover
Pressing ENTER for confirm and overwrite program.
Pressing QUIT for exit.
Program name length is 16 character.
Turn rotary encoder and modify character, move cursor position
by pressing BACK or NEXT.
Pressing ENTER again for confirm and store program name.
Pressing QUIT for exit.
Pressing ENTER for confirm and Save program.
Pressing ENTER will enter Delete User Program sub-menu.
Turn rotary encoder to change program index,
Pressing ENTER.
Pressing ENTER for confirm and delete program.
Set Program Name
01 2x3 Way Xover: ?
[ ]
: ?
ENTER to Save
01 2x3 Way Xover
Saving to Memory
01 2x3 Way Xover: ?
PROGRAM MENU
Delete User Program
:...
Delete User Program
01 2x3 Way Xover:
[ ] .
:
ENTER to Delete
01 2x3 Way Xover
Deleting Memory
01 2x3 Way Xover
...
:

CopyTools Sub-menu
Copy Input Section
Copy Output Section
COPYTOOLS MENU
Copy Input Section
:...
On Copy Input Section screen, Turn rotary “FREQ”encoder change source channel,
Turn rotary “Q” encoder change target channel.
Pressing ENTER to confirm and copy intput channel parameters.
On Copy Output Section screen, Turn rotary “FREQ”encoder change source channel,
Turn rotary “Q” encoder changetarget channel.
Pressing ENTER to confirm and copy output channel parameters.
COPYTOOLS MENU
Copy Output Section
:... Copy Output Section
Source 1 Target 2: :
System Sub-menu
Device startup wake up time.
Mute Hold, set to keep mutes on when powered up.
0 secs......60 secs, set wait time before the audio fades in.
Turn rotary encoder to change parameter,
Pressing ENTER to confirm and save.
Select filter Q or Bandwidth display unit.
Turn rotary encoder to change parameter,
Pressing ENTER to confirm and save.
SYSTEM MENU
Wake up Time
:......
-
SYSTEM MENU
Filter Q or BW
:......
Turn rotary encoder to change LED brightness,
Pressing ENTER to confirm and save.
SYSTEM MENU
LED Brightness
:......
Turn rotary encoder to change LCD contrast,
Pressing ENTER to confirm and save.
SYSTEM MENU
LCD Contrast
:......
Copy Input Section
Source A Target B: :

Change device title name on LCD screen top line.
Pressing ENTER to edit.
SYSTEM MENU
Device Name Title
:......
Device name length is 16 character.
Turn encoder and modify character.
move cursor position by pressing BACK or NEXT.
[ ]
:
ENTER to Editing
Tit Speaker Processor
Set Device NameTitle
Tit Speaker Processor:
Pressing ENTER for confirm.
Pressing QUIT for exit.
[ ]
:
ENTER to Store
Tit Speaker Processor
Pressing ENTER again for confirm and store.
Select delay time or distance.
Turn rotary encoder to change parameter,
Pressing ENTER to confirm and save.
Select load program option.
AutoMute: Force all output mute on after loading program.
LoadMute: Load output MUTE status in program stored.
Turn rotary encoder to change parameter,
Pressing ENTER to confirm and save.
SYSTEM MENU
DelayTime Distance
:......
/
SYSTEM MENU
Load Program Option
:......
Select output meter indicate style.
output Level or attenute on limiter.
Turn rotary encoder to change parameter,
Pressing ENTER to confirm and save.
SYSTEM MENU
Output LED Meter
:......

Interface Sub-menu
Select communication port: RS232 or RS485.
INTERFACE MENU
Interface Setup
:....
INTERFACE MENU
Protocol Setup
:....
Interface Setup
Master Source: RS232
Interface Setup
Master Source: RS485
Interface Setup
Remote ID Num: 1
Protocol Setup
Select: PCsw Ctrl
While select RS485.
Need assign a remote ID number(1-32).
Select control protocol.
PCsw: select PC control.
ESRP: select external simple control device.
Protocol Setup
Select: ESRP Ctrl

Pressing ENTER will enter Security sub-menu.
Security Sub-menu
Lock status setting:
No Lock: without lock out.
Control: cannot change.
Display: cannot view.
Pressing ENTER will enter password.
Turn rotary encoder and modify character, move cursor position by pressing BACK or NEXT.
Pressing ENTER for enter password again.
while twice time password match, system will lock unit.
Enter Password
[******]
Confirm Password
[******]
Locking Unit
[******]
Enter Password
[******]
UnLocking Unit
[******]
Speaker Processor
2 X 3 Way Xover
Input Gain
Xover Only Xover + Trim Xover + Trim
+ Mute
Changes Only Changes + MutesChanges + View EVERYTHING
Input Delay
Input PEQs
In GraphEQ
Input Links
Output Gain
Output Delay
Output PEQs
HPFs & LPFs
Output Links
Output Phase
Limiters
Matrix Gains
Input Mutes
Output Mutes
Output Name
Menu System
Memory Store
Memory Load
No Lock
No Lock
No Lock
No Lock
No Lock
No Lock
Display
Display
Display
Display
Display
Display
Display
No Lock
No Lock
Control
No Lock
No Lock
No Lock
In “User Specific” setting, you can free set up lock status depend on each function part.
File Operation No Lock
No Lock
No Lock
No Lock
No Lock
No Lock
Display
Display
Display
Display
Display
Display
Display
No Lock
No Lock
Control
No Lock
No Lock
No Lock
No Lock
Display
No Lock
No Lock
No Lock
No Lock
No Lock
Display
Display
Display
Display
Display
Display
Display
Display
No Lock
Control
Control
No Lock
No Lock
No Lock
No Lock
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
No Lock
No Lock
Control
No Lock
No Lock
No Lock
No Lock
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
No Lock
No Lock
Control
No Lock
No Lock
No Lock
No Lock
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
Control
No Lock
No Lock
No Lock
No Lock
Control
Control
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Display
Control
Control
Control
Control
Control
Control
Control

Specifications
Inputs: 2/3/4 electronically balanced.
Impedance: > 10k ohms.
CMRR: > 75dB 50Hz ~ 10kHz.
Outputs: 4/6/8 electronically balanced.
Source Imp: < 60ohms
Min. Load: 600ohm
Max. Level: +15dBm
Digital Audio Sample Rate: 96kHz
Frequency Response: +/- 0.5dB, 20Hz ~ 20kHz
Distortion: < 0.006% @1kHz, +15dBm
ADC Dynamic Range: > 110dB, 20Hz ~ 20kHz (A-Weight)
DAC Dynamic Range: > 110dB, 20Hz ~ 20kHz (A-Weight)
Propagation Delay: 0.41mS (DP240 / DP260 / DP440)
0.34mS (DP280AL / DP360)
Delay: 1000mS(Input), 1000mS(Output)
Min Step Size: 0.010mS(4mm)
Input Gain: -40dB to +6dB in 0.1dB steps
Output Gain: -40dB to +15dB in 0.1dB steps
Multi-Type Filters
10 per Input, 7 per Output.
Freq. Range: 20Hz ~ 20kHz, 1/36 Octave steps.
Filter Q/BW: 0.4 to 128.
Filter Type: Parametric Equaliser
HiShelf, LoShelf
Variable Q Highpass, Lowpass
Bandpass, Notch, Allpass.
High and Lowpass Filters
Freq. Range: 20Hz ~ 20kHz, 1/36 Octave steps.
Slope: 6/12/18/24/36/48 dB/Octave.
Type: Butterworth, Linkwitz-Riley, Bessel.
Limiters
Threshold: -10 ~ +15dB, 1dB steps.
Attack time: 0.3 ~ 90mS.
Release time: 0.1 ~ 2.0 second.
Display: 2x20 Character LCD
Connectors
Inputs: 3 pin female XLR
Output: 3 pin male XLR
RS232: 9 pin DEE connector
RS485: RJ45 style connector
Power: 3 pin IEC
Power Voltage: ~220V @50/60Hz
Power Consumption: < 17 watts
Weight: 2.7kg. Net (4.0kg. Shipping)
Size: 1.75”(1U) x 19” x 8.0” (44 x 482 x 205 mm)

2x2 Way DP280( ) 2x3 Way DP280( )
2x4 Way DP280( ) 4+4 Way DP280( )
5+3 Way DP280( )
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
6+2 Way DP280( )
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
7
OUTPU T
8
Appendix I - Crossover Configurations

2x2 Way /DP260( )DP360 2x3 Way /DP260( )DP360
3x2 Way DP360( )
5+1 Way /DP260( )DP360 6 Way /DP260( )DP360
4+2 Way /DP260( )DP360
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
OUTPU T
1
IN PUT
A
IN PUT
B
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
IN PUT
A
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
IN PUT
A
IN PUT
B
IN PUT
C
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
IN PUT
A
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
IN PUT
A
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
OUTPU T
5
OUTPU T
6
IN PUT
A
OUTPU T
1

2 Mono Sub DP240( )
2x2 Way DP440/DP240( ) 3+1 Way DP440/DP240( )
4 Way DP440/DP240( ) 4x1 Way DP440( )
OUTPU T
2
OUTPU T
3
OUTPU T
4
IN PUT
A
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
IN PUT
A
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
IN PUT
A
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
IN PUT
A
IN PUT
C
IN PUT
D
IN PUT
B
OUTPU T
1
OUTPU T
2
OUTPU T
3
OUTPU T
4
IN PUT
A
IN PUT
B
OUTPU T
1
