Osram e:cue SYMPL input Node User guide

AB444200035
e:cue SYMPL input Node
Setup Manual / Installationsanleitung
Our Brand
www.osram.com/ecue
Light is OSRAM

02
AB444200035
e:cue SYMPL input Node Setup Manual (original issue)
e:cue SYMPL input Node Installationsanleitung (Originalversion)
Edition/Ausgabe: 23.08.19 [EN_DE_SYMPL_input_Node_Setup_v2p0]
Published by / Herausgegeben von:
OSRAM GmbH
Karl-Schurz-Strasse 38
33100 Paderborn, Germany
©2019 OSRAM GmbH, BU Digital
All rights reserved / Alle Rechte vorbehalten
Read the Setup Manual
carefully before unpacking the
product. Subject to
modication without prior
notice. Typographical and other
errors do not justify any claim
for damages. All dimensions
should be veried using an
actual part.
Except for internal use,
relinquishment of the
instructions to a third party,
duplication in any type or form
- also extracts - as well as
exploitation and/or
communication of the contents
is not permitted.
Lesen Sie die
Installationsanleitung vor dem
Auspacken des Produktes
sorgfältig durch. Alle Änderungen
vorbehalten.
Rechtschreibfehler oder andere
Fehler rechtfertigen keinen
Anspruch bei Schäden. Alle
Maße sollten an einem realen
Gerät überprüft werden.
Außer für interne Verwendung ist
die Überlassung dieser Anleitung
an Dritte, die gesamte oder
auszugsweise Veröffentlichung,
Verwertung oder Mitteilung in
jeglicher Art und Form sind nicht
gestattet.

03
Table of Contents / Inhalt
Table of Contents / Inhalt
English 06
1 Security instructions 07
1.1 Symbols 07
1.2 General security instructions 07
2 General device description 08
2.1 Delivery content 08
2.2 Connectors and interfaces 09
2.3 User interface: LEDs 09
2.4 Identify button: Identication & Reset 10
3 General remarks 11
3.1 Transport 11
3.2 Unpacking 11
3.3 Warranty regulations 12
3.4 Maintenance and Repair 12
3.5 Disposal 12
3.6 Support 13
4 Installation 13
4.1 Installation conditions 13
4.2 Mounting process 14
4.3 Ethernet connection 14
4.4 Input connection 15
4.5 Power supply 15
5 Network configuration 16
5.1 Default network properties 16
5.2 Network conguration with SYMPHOLIGHT 16
5.3 Network conguration with the web interface 17
6 Firmware Update 19
7 Dismounting 19

04
Table of Contents / Inhalt
8 Product specifications 20
9 Certifications 21
Deutsch 22
10 Sicherheitshinweise 23
10.1 Symbole 23
10.2 Hinweise 23
11 Gerätebeschreibung 24
11.1 Lieferumfang 24
11.2 Anschlüsse und Schnittstellen 25
11.3 Benutzeroberäche: LEDs 26
11.4 Identify-Taster: Identikation & Reset 27
12 Allgemeine Hinweise 27
12.1 Transport 27
12.2 Entpacken 28
12.3 Garantiebestimmungen 28
12.4 Reparatur und Wartung 28
12.5 Entsorgung 28
12.6 Technischer Support 29
13 Installation 29
13.1 Installationsbedingungen 30
13.2 Montage 30
13.3 Ethernet-Verbindung 30
13.4 Eingangs-Verbindung 31
13.5 Stromversorgung 31
14 Netzwerk-Konfiguration 32
14.1 Standardeinstellungen vom Netzwerk 32
14.2 Netzwerkeinstellung über SYMPHOLIGHT 33
14.3 Netzwerkeinstellung über die Webschnittstelle 33
15 Firmware-Update 35
16 Demontage 35
17 Produktdaten 36

05
Table of Contents / Inhalt
18 Zertifizierung 37
Dimensions / Abmessungen 38
Application examples / Anwendungsbeispiele 39

06
English

07
Security instructions
1 Security instructions
Please read the safety instructions, provided in a separate manual, carefully.
Make sure that the environmental, mounting, and installation prerequisites
are met. This manual should be kept at a safe place and in reach of the
installation.
1.1 Symbols
!
The exclamation mark warns about possible damage of the
device itself or connected devices.
i
The information symbol gives general hints and informs
about handling and procedures for use of the device.
1.2 General security instructions
!
Connect cables and data only when the device is powered
down.
!
The device must be supplied by a separate certied SELV
Class 2 power supply.
!
The maximum length of each connected cable is 30 m.
i
If safety instructions are missing, please contact OSRAM to
receive a new copy.

08
General device description
2 General device description
e:cue SYMPL Nodes are a system of interfaces for e:cue SYMPHOLIGHT
only. They provide various connection types like DMX512, DALI, digital
inputs and outputs etc. SYMPL Nodes always operate in online mode, as a
device interface for SYMPHOLIGHT. All interactions are initiated and
controlled by SYMPHOLIGHT. Connections between servers, Cores and
Nodes are always made with e:net via Ethernet.
The e:cue SYMPL input Node is an eight-channel analog input interface for
use with e:cue’s lighting control solution SYMPHOLIGHT. It provides eight
independent analog 10 V inputs, four inputs also support 20 mA constant
current input, congurable with four slide switches. The e:cue
SYMPL input Node can be powered by an external power supply or via
Power-over-Ethernet. It is easily mounted on standard 35 mm DIN rails, or
with a key hole in the housing base on walls or on any stable vertical
surface. The e:cue SYMPL input Node is a simple, reliable and easy to use
interface solution for e:cue lighting control solutions with SYMPHOLIGHT.
2.1 Delivery content
Delivery content for the e:cue SYMPL input Node (AB444200035):
1. e:cue SYMPL input Node
2. Safety instructions
3. Installation guide (English only)
i
To operate SYMPL Nodes a SYMPHOLIGHT version 2.0 or
higher is mandatory. Earlier versions do not support the
SYMPL Nodes. SYMPL Nodes are not supported by the
e:cue Lighting Application Suite.
i
e:cue SYMPL input Node is not hot-pluggable.

09
General device description
2.2 Connectors and interfaces
View from top
1Common ground
2a Inputs 0 ... 10 V
(pins 1 ... 4, left to right)
2b Inputs 0 ... 10 V or 0/4 ... 20 mA
(pins 5 ... 8, left to right)
3Mode switches inputs 5 ... 8
(left: 0 ... 10 V, right: 0/4 ... 20 mA)
4Input status 1 ... 8 LEDs (left to
right)
5Error LED
6e:net LED (Ethernet, LAN activity)
7Status LED (Device status)
8Identify button
9Power supply
(Vcc+, Vcc– left to right)
10 e:net / Ethernet
2.3 User interface: LEDs
The SYMPL input Node has 11 LEDs. The 11 LEDs show the basic states
of the SYMPL Node.
LEDs
Status On: If constantly on, the device is online. Server
application is in operation.
Blinking: If blinking in one second intervals, the device is
ofine, no connection to a SYMPHOLIGHT server or
Core is available. If blinking more rapidly, the device is in
bootloader mode.

10
General device description
e:net Off: no link available.
On: link established.
Blinking: e:net trafc.
Error Off: no error detected.
On: If constantly lights in red, an error occurred. This
can be an internal error or malfunction of the device, or
an external error, e.g. a shortcut of interface
connections or alien power supply. Switch the device off
and on. If the error persists, check the wiring or contact
OSRAM Service.
Status +
Error
The Status and Error LED blink simultaneously to
identify the SYMPL Node (enabled “Identify Interface
Mode” in SYMPHOLIGHT).
Input status 1
to 8
Off: Input value is smaller than the Digital Threshold
Low.
On: Input value is bigger than the Digital Threshold
High.
(Change the Digital Thresholds in the properties of the
Node in the Setub Tab of SYMPHOLIGHT).
2.4 Identify button: Identification & Reset
The Identify button has four functions: to send an Identify message (A) and
to reset the Node (B).
(A) A short press during operation in online mode sends an Identify
message to the server. This helps to assign the Node in the Layout in
SYMPHOLIGHT.
(B) The Identify button can also be used to reset the device to factory state
or to stay in bootloader mode:
• Keep the Identify button pressed while powering up, Status and
Error light up at rst. Bootloader mode is signaled by a fast blinking

11
General remarks
Status LED. Release the button now. The device stays in bootloader
mode to download a new rmware.
To exit the bootloader mode, short press the Identify button again.
• Press the Identify button until Status and Error LEDs blink
alternating, then blink together. Releasing the button now resets the
device to its factory settings. The password and other settings are reset
to their default values.
• Keeping the button pressed further on, the device proceeds to
normal operation. No changes apply.
3 General remarks
3.1 Transport
Only transport the device in its original packaging. This protects the device
from damage.
3.2 Unpacking
Only unpack the e:cue SYMPL input Node at its installation location. To
protect the device against condensation water, unpack it and wait until all
moisture remaining in the device has evaporated. Condensation can occur
when the device is moved from a cold to a warm location. Keep the
packaging for use in case of further transport. Inspect all parts for
completeness regarding chapter „2.1 Delivery content“ on page 08. If
there is apparent damage to the device or parts are missing from the
delivery scope, please contact the OSRAM Support service.

12
General remarks
3.3 Warranty regulations
Depending on the product, guaranty regulations are of different duration.
The warranty time is usually noted in the quote and in the order
conrmation. See “Services”  “OSRAM Guarantee” at www.osram.com
for details. Legal warranty regulations apply in any case.
3.4 Maintenance and Repair
This device requires no maintenance.
3.5 Disposal
The proper disposal of packing materials and of the device is the
responsibility of the respective user and for his account; in all other matters,
the retrieval obligation for packing materials and the device is subject to the
statutory regulations.
!
Before dismounting, appropriate measures must be taken to
protect the respective components against damage caused
by electrostatic discharge (ESD protection).
!
Do not try to repair the device. Return it to your OSRAM
distributor for replacement or repair.
Batteries and technical appliances must not be disposed of
with domestic waste, but should be handed in at the
appropriate collection and disposal points.

13
Installation
3.6 Support
In case of technical problems or questions regarding installation and repair
please contact:
OSRAM GmbH
Customer Service
Karl-Schurz-Str. 38
33100 Paderborn, Germany
[phone]
[email protected]
4 Installation
The installation of the SYMPL input Node consists of mounting the device,
connections to analog inputs, to e:net, and to power supply.
The sequence of cabling is not dened. Supply the SYMPL input Node with
power after all cabling is completed; it starts booting.
4.1 Installation conditions
Installation position: Terminals on top and bottom
Horizontal spacing: No spacing necessary
Minimum vertical rail grid spacing: 115 mm (90 + 25 mm)
(excluding conduit)
Recommended vertical rail grid spacing: 160 mm (with 40 mm conduit)
Installation location Indoor
!
Connect cables and data only when the device is powered
down.
!
Each cable should not exceed a length of 30 m.

14
Installation
4.2 Mounting process
The e:cue SYMPL Node is designed to mount onto a 35 mm DIN rail
(EN 60715) in a vertical position.
1. Clip the device to the rail from
top.
2. Gentle pressure is then
applied to the top front to snap it
in place. The SYMPL input Node
has been mounted successfully.
You can also mount the e:cue
SYMPL Node on any at vertical surface. Use a 3 to 3.5 mm screw for the
hanger hole.
For mechanical stability, mounting on a rail is recommended.
4.3 Ethernet connection
The pin-assignment of the Ethernet port corresponds to RJ45 standards.
You can use every common Ethernet component, like cable, splitters, and
switches. Connect the SYMPL input Node at the designated Ethernet
interface with a patch cable (RJ45, CAT5).
i
Never connect more than one SYMPL Node in factory state
to a network. The identical IP addresses will conict and
disturb proper communication.
i
The Ethernet port of the SYMPL Node is not designed for
inter-building connections with power and lighting transients.
Use only intra-building networks to connect the SYMPL
Nodes and Cores.

15
Installation
4.4 Input connection
The SYMPL input Node provides eight independent analog 10 V inputs,
four inputs also support 20 mA constant current input, congurable with
four slide switches. Connect inputs to the SYMPL Node using the input
pins and the common ground. Set the mode switch for the pins 5 to 8 to
according to your inputs. See „Application example / Anwendungsbeispiel“
on page 39 for examples.
4.5 Power supply
Connect the SYMPL input Node to a certied NEC Class 2 24 V DC power
supply unit. Present power supply equates to the status “On” or running of
the SYMPL Node.
To connect the device to a power supply unit, use the provided 2-pole
terminal and lay the wires as stated on the front label. The voltage
assignment is left V+ and right V-.
Turn the power on when all cables are connected to the
SYMPL input Node. The device starts booting. The device has nished
booting and is in operation when the LED Status is ashing.
i
When replacing a SYMPL input Node in an installation, set
the new Node to the same mode settings as the old one.
Otherwise the communicationwith SYMPHOLIGHT does not
work.
!
The SYMPL input Node is not suited for powering over a DC
power supply network. Use a separate certied SELV Class 2
power supply unit in the control cabinet for supplying 24 V
DC to the SYMPL input Node.

16
Network conguration
5 Network conguration
The conguration of the e:cue SYMPL input Node is done via e:cue
SYMPHOLIGHT. See the SYMPHOLIGHT System Manual for details on
conguration, available at www.ecue.com.
The network properties of the SYMPL input Node are precongured. The
successful installation of the power supply is required for changing the
network conguration. You can either adjust the network settings with
SYMPHOLIGHT or using the web interface of the SYMPL input Node.
5.1 Default network properties
The SYMPL input Node has as factory setting the default IP address
192.168.123.1.
DHCP is enabled by default.
To change the network conguration use either SYMPHOLIGHT or the web
interface of the SYMPL input Node:
5.2 Network configuration with SYMPHOLIGHT
1. Open the context menu of the SYMPL input Node in the Setup tab
of SYMPHOLIGHT by a right-click on the device.
2. Select “Congure Network”:

17
Network conguration
3. Dene the IP address, the subnet mask and the DHCP settings to
your needs:
4. Click “Apply” to submit the changes.
The network conguration of the SYMPL input Node is completed.
5.3 Network configuration with the web interface
1. Open a common web browser on a connected PC. Enter the
SYMPL input Node's IP address into the address bar:
e.g. http://192.168.123.1
The web interface of the SYMPL input Node is displayed:

18
Network conguration
2. Click “Congure” to access the network conguration page:
3. Dene the network settings at “Device Basics” to your needs. You
can also change the password for entry to the web interfaces of the
SYMPL input Node here.
4. Click “Submit” to apply the settings.
The network conguration of the SYMPL input Node is completed.
i
The employment of a discrete network is recommended.
i
Note down all employed and, if applicable, reserved IP
addresses. Keep the information for future network
congurations.
i
You can change the login password to the
SYMPL input Node's conguration page and the device
name of the SYMPL input Node at “Settings” page. Do not
forget the new password.

19
Firmware Update
6 Firmware Update
To update the SYMPL input Node, a connection of the SYMPL input Node
to SYMPHOLIGHT is required.
Updating with SYMPHOLIGHT
Use the usual update options in the Device Tree of the Setup tab in
SYMPHOLIGHT: select “Update rmware” in the context menu of the
SYMPL input Node or click the Update button in the head toolbar.
7 Dismounting
Disconnect all attached cables. Dismount the e:cue SYMPL input Node
from the rail by pulling the black DIN rail handle and unhitching the SYMPL
Node. The dismounting is completed.
!
Before dismounting, appropriate measures must be taken to
protect the respective components against damage caused
by electrostatic discharge (ESD protection).

20
Product specications
8 Product specications
Product number AB444200035
Dimensions (W x H x D) 53.5 x 90.5 x 62 mm
0.76 x 0.30 x 0.20 in
(without fastening clip)
Weight 110 g
Power supply input 24 V DC on screw terminal
wire gauge: 0.25 ... 2.5 sqmm
(0.5 sqmm for exible wires with
ferrules)
or Power over Ethernet (PoE), IEEE
802.3af
Power consumption max. 1.2 W
Operating temperature 0 … 50 °C / 32 … 122 °F
Storage temperature -10 ... 70 °C / 14 ... 158 °F
Operating / storage humidity 0 … 80%, non-condensing
Protection class IP20
Electrical safety SELV
Housing Self extinguishing blend PC / ABS
UL document E140692
Mounting on 35 mm DIN rails
EN 60715, width: 3 units
or wall mount with 1 x 3 ... 3.5 mm screw
Interface specications
User interface 11 LED indicators (8 x input status, Error, Ethernet,
Device status)
1 push button
