CNC-Step T-Rex Series User manual

Status: 16.09.2015
Quick Start Guide
T-Rex Series
www.cnc-router-store.com

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 2
Support: +49 (0)2831/91021-50
15.01.2015
T-Rex Series
Short Description
This Quick Start Guide will help you with the initial start-up of the machine.
It also includes optional accessory that is connected directly to the machine or control.
For more detailed information please refer to the individual manuals.

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 3
Support: +49 (0)2831/91021-50
15.01.2015
CONTENTS
1CONNECTORS AND CABLES ON THE MACHINE.....................................................5
1.1 Connection Panel Machine......................................................................................................5
1.2 Mini XLR Jack.........................................................................................................................6
1.3 Connection Panel Z-axis..........................................................................................................7
1.4 Noga Minimum lubrication system ........................................................................................8
1.4.1 control box with solenoid valve...........................................................................................8
2CONNECTIONS TO THE ZERO-3 STEPPER MOTOR CONTROLLER......................9
2.1 Front side ..................................................................................................................................9
2.2 Back side..................................................................................................................................10
3CONNECTING THE MACHINE TO THE ZERO-3 CONTROL....................................11
4CONNECTION POSSIBILITY OF A 4TH AXIS...........................................................12
5CONNECTION OPTIONS OF OPTIONAL ACCESSORIES.......................................13
5.1 Overview Connection and power supply via Zero-3 control..............................................13
5.2 Milling motors ........................................................................................................................14
5.3 Noga spray cooling with solenoid valve................................................................................14
5.4 Inverter and HF spindles.......................................................................................................15
5.5 Granitograv and laser engraving unit..................................................................................15
6SOFTWARE INSTALLATION.....................................................................................16
6.1 WinPCNC ...............................................................................................................................16
6.1.1 Installation.........................................................................................................................17
6.1.2 Connecting the computer to the Zero-3 control.................................................................17
6.1.3 Configuration.....................................................................................................................18
6.1.4 Determination of the LPT interface (Light and Economy) ...............................................18
6.1.5 Determination of the COM interface (Professional) .........................................................20
6.1.6 Entry of the determined interface / port address in WinPCNC.........................................21
6.1.7 Entry LPT2 port (only Economy)......................................................................................21
6.1.8 check the efficiency...........................................................................................................22
6.1.9 Load and save machine parameters...................................................................................23
6.2 ConstruCam 3D......................................................................................................................24
6.2.1 Installation.........................................................................................................................24
6.2.2 Interaction with WinPCNC ...............................................................................................24

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 4
Support: +49 (0)2831/91021-50
15.01.2015
6.3 Other Software .......................................................................................................................25
7CUSTOMER SERVICE ...............................................................................................26

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 5
Support: +49 (0)2831/91021-50
15.01.2015
Connection Panel Machine
1Connectors and cables on the machine
1.1 Connection Panel Machine
D-Sub 9pol. ST
Control line ST
D-Sub 15pol. C
Tangential Tools (to Connection Panel Z-axis)
Neutrik 4pol. X
Motor connection cable X-axis
Neutrik 4pol. Y
Motor connection cable Y-axis
Neutrik 4pol. Z
Motor connection cable Z-axis
Hirschmann 7pol.
HF-Spindle (to Connection Panel Z-axis)
230V Plug
230V Socket Connection Panel Z-axis
Touchprobe
Length Sensor

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 6
Support: +49 (0)2831/91021-50
15.01.2015
1.2 Mini XLR Jack
The miniXLR jack provides the option of connecting extensions without additional hardware.
For example:
Tool length control, Security housings with door switch
3D Buttons
Note:
Concomitant use of this socket and a 4th axis, such as a rotation axis or tangential knife, the
connectivity is limited because both the miniXLR socket and the reference switch the 4th axis are
found via the PIN15 of the LPT port.
For this combination, we have a solution. To do so, please contact our customer service.
Mini-XLR-jack

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 7
Support: +49 (0)2831/91021-50
15.01.2015
Panel Z-axis
1.3 Connection Panel Z-axis
At the Z-axis various connectivity options for optional accessories are available.
Note socket:
This socket can be connected to an external power supply, or alternative directly to the machine
control Zero-3.
Then there is the possibility to turn off the power by software. (see chapter 2.2)
EOT-2
Milling Motor 230V
HF-Spindle
TCM-3
TCT-1
Tangential tools
230V / max. 8A
Connect to Zero-3
Controller !
(see chapter 2.2)

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 8
Support: +49 (0)2831/91021-50
15.01.2015
Noga-Minimalmengenschmierung
1.4 Noga Minimum lubrication system
The Noga minimal lubrication system allows the processing of materials which make cooling
necessary. For the operation of a compressor is required with min. 2.5 bar.
1 – Coolant container 2 – control valve
3 – Air connection Z axis 4 – adjustable nozzle
5 – Manual On / Off (with the hex screw you can adjust the amount of air)
1.4.1 control box with solenoid valve
The control box for the Noga system is located on the back of the machine. The system is
automatically switched on and off via software, when connected to the Zero-3 Control.
1 – 230V power supply (at Rel.2 of Zero-3)
2 – Air output to Z axis
3 - silencer
4 – Air connection (min. 2.5 bar)

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 9
Support: +49 (0)2831/91021-50
15.01.2015
2Connections to the Zero-3 stepper motor controlle r
2.1 Front side
7 8
1 2 3 4 5 6 9
Front side Overview
1Connector D-Sub 9pol. for motor X1
2Connector D-Sub 9pol. for motor X2 (not use for T-Rex)
3Connector D-Sub 9pol. for motor Y
4Connector D-Sub 9pol. for motor Z
5Connector D-Sub 15pol. for 4th axis (Rotary axis / tangential knife)
6Connector D-Sub 9pol. for Control line ST
7Emergency-stop-button
8Power-button
9Status-LEDs
Zero-3 Front Side

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 10
Support: +49 (0)2831/91021-50
15.01.2015
2.2 Back side
5 6
1 2 3 4 7*
Overview back side
1 power supply (115-240V input voltage)
2 LPT1 input
3 LPT2 input
4 LPT2 output (0-10Volt Edition)
5 Socket 1 (115-240V depending on input voltage - switchable via relay 1)
6 Socket 2 (115-240V depending on input voltage - switched via relay 2)
7 Ground (* only High-Z series > 03/2015)
Note on the sockets 1 + 2:
The two sockets are with two relays switchable. Thus, the consumer connected to it can be switched
on and off via software.
This guarantees also that the power supply is interrupted at faults and in emergency case.
The maximum power consumption per outlet may not exceed 8A.
The current consumption of the two sockets together may not exceed 13.5A.
Zero-3 Back Side

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 11
Support: +49 (0)2831/91021-50
15.01.2015
3Connecting the machine to the Zero-3 control
- Make sure that the control is turned off.
- Connect all 5 cables with the Zero-3 controller.
- Make sure that you back up all connections with the knurled screws from loosening.
Zero-3 Front Side
Connection cable of the machine

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 12
Support: +49 (0)2831/91021-50
15.01.2015
4Connection possibility of a 4th axis
On the C-terminal of the zero-3 control another step motor can be operated as the fourth axis. In
addition to this port, a 12-24V supply for an oscillation motor and the connection for a further
reference switch are supplied.
- Make sure that the control is turned off.
- Connect the supplied power cable to the C-socket of the controller.
- Make sure that you back up all connections with the knurled screws from loosening.
Zero-3 Front Side
Rotation Axis
TCM-3
EOT-2
TCT-1

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 13
Support: +49 (0)2831/91021-50
15.01.2015
Compressor
5Connection options of optional accessories
The accessories at this point we just cover briefly the connection to the machine to the controller
and if necessary to the additional hardware interface (depending on the software).
For more detailed information please refer to the individual manuals.
5.1 Overview Connection and power supply via Zero-3 control
Milling motors
Noga spray cooling
Control signals
Zero-3 Back Side
Granitograv
Laser engraving unit
Converter / HF-spindle

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 14
Support: +49 (0)2831/91021-50
15.01.2015
5.2 Milling motors
Milling motors by Kress:
Art. 211105 Kress 1050FME-1 / 1050 W / 5.000 - 25.000 R/min
Art. 211110 Kress 1050FME / 1050 W / 10.000 - 29.000 R/min
Art. 211100 Kress 800FME / 800W / 10.000 - 29.000 R/min - 110Volt (for USA)
Our recommended milling motors Kress; can be attached directly to the Z-axis in the designated
tool holder (Ø43mm).
The milling motor itself contains an on and off switch and setting wheel for the speed. A speed
control via software is not possible here.
However, the milling motor can be turned on/off via the relay socket 1 (Rel.1) Zero-3 control via
software or program.
- Make sure that the control is turned off.
- Connect the power cord to the socket 1 (Rel.1) Zero-3 controller.
Of course, milling motors by other manufacturers can be connected in this way.
You should also read the notes from chapter 2.2 for max. current consumption.
5.3 Noga spray cooling with solenoid valve
Art. 350100 Noga spray cooling - without solenoid valve for manual operation
Art. 350110 Noga spray cooling - automatic control via solenoid valve
Art. 310250 Vacuum pump / compressor -0.7 bar / 2.5-3.0 bar
The Noga spray cooling requires an air pressure of min. 2.5 bar. from a compressor. This should be
designed for continuous operation. For this application we have a small, handy pump in the
program (see above).
Via solenoid valve, the air supply from the compressor can be automated by software or program.
This is recommended by us. This has the advantage that lubrication is only done when it is
necessary.
-Make sure that the control is turned off.
-Connect the power adapter to the socket 2 (Rel.2) Zero-3 controller.

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 15
Support: +49 (0)2831/91021-50
15.01.2015
5.4 Inverter and HF spindles
The output from the software WinPCNC PWM signal for the spindle speed is converted by the
zero-3 into an analogue control signal and outputted to the 0-10Volt LPT2 output.
Thus you can connect an inverter to operate a HF spindle directly to the Zero-3 controller.
-Make sure that the control is turned off.
-Connect the power cable of the inverter to the power outlet 1 (Rel.1) Zero-3 controller.
-Connect the "control cable" of the inverter with the LPT2 output of the controller.
-Make sure that you back up all connections with the knurled screws from loosening.
-Observe the notes from page 6 for max. Power consumption.
Caution:
Inverter and HF spindles that have higher performance, can also be used, but require an external
power supply!
Please feel free to contact our Customer Service.
5.5 Granitograv and laser engraving unit
Art. 230100 Granitograv CNC-Module
Art. 220500 Laser engraving unit
With this accessory, there is an additional control box that needs to be powered. For this purpose,
each power supply can be connected to the Zero-3 controller. As a result, the accessory is
disconnected from the power in emergency case!
-Make sure that the control is turned off.
-Connect the power supply of the respective control box with the socket 1 (Rel.1) of the
Zero-3 controller.
Please note for operation the associated manuals with more detailed information!

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 16
Support: +49 (0)2831/91021-50
15.01.2015
USB Dongle
6Software installation
6.1 WinPCNC
WinPCNC is a convenient and comprehensive 3/4-axis NC control under Windows for milling,
drilling, engraving, dosing, and more.
Different variants with graded functions and prices provide the right solution for beginners and
model makers, as well as semi-professional use or for demanding industrial plants.
Here is an overview of all WinPCNC versions:
Zero-3 control
Available
interface
Additional
Hardware-
Interface
Needed PC-
interface
Windows- XP/Vista/7 XP/Vista/7 XP/Vista/7/8 XP/Vista/7/8 XP/Vista/7/8 XP/Vista/7/8
Operating 32-bit 32-bit 32- / 64-bit 32- / 64-bit 32- / 64-bit 32- / 64-bit
System
WinPCNC
Variant Light Economy USB Profi Profi E/A Profi LPT2
Zero-3 Back Side

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 17
Support: +49 (0)2831/91021-50
15.01.2015
The additional hardware ncUSB (WinPCNC USB) and the USB dongle (WinPCNC
Economy) should be connected only after installing the software to the PC. The
required drivers are installed and the hardware can be detected correctly afterwards.
6.1.1 Installation
Now, let us start the initial installation of the software WinPCNC .
Install the software from the supplied CD into the directory specified for it. After installation, you
may have to restart the PC.
.
6.1.2 Connecting the computer to the Zero-3 control
The connection of the computer to the Zero-3 controller depends on the software and the associated
additional hardware. (see page 12)
-Make sure that the control is turned off.
-Depending on the software, connect the supplied connection cable to the PC and the
controller. Secure all cables against loosening!
-For WinPCNC variants Light and Economy there is no additional hardware interface, the
LPT cable is connected directly to the controller.
-In the other variants of the PC is connected to the additional hardware interface. This is then
connected via LPT cable to the controller.
-In all variants, the LPT2 port is only used for optional accessories, and some machines
extensions.
The additional hardware (ncUSB, USB dongle) is now recognized and installed by Windows.

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 18
Support: +49 (0)2831/91021-50
15.01.2015
6.1.3 Configuration
Start the software WinPCNC.
From the Start menu choose language and machine type.
The specification of the correct type of machine is very important because the software
automatically loads all important parameters for the selected type of machine.
The communication between PC and Zero-3 is controlled depending on the software version on the
LPT, USB or serial interface.
In WinPCNC USB installation and configuration is complete. In this version WinPCNC determines
the interface automatically.
With other versions yet the interface or port address of the PC must be determined on which the
communication runs.
6.1.4 Determination of the LPT interface (Light and Economy)
With the variants "Light" and "Economy" the LPT port or the port address must be entered in
WinPCNC (see page 17).
Some computers have multiple LPT ports, so that the right one first has to be found out. If the
interfaces are not marked on the PC, you need to find out which interface you have connected to the
control.

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 19
Support: +49 (0)2831/91021-50
15.01.2015
How do you find out the correct port address of the LPT port?
In the Device Manager of the PC all available interfaces are listed.
Standard interfaces, see Ports
(COM & LPT)
Use interfaces on expansion
cards (interface cards), it may be
that this is a multifunction
adapter or similar in the Device
Manager!
Select the interface to which you have connected to the machine. Go to the properties of the
interface (eg with double-click) and look under Resources after the port address (I / O area).
This is the first entry (4-digit hexadecimal) as seen in the screenshots.
When using 2 LPT ports (only Economy) please repeat with both connected interfaces !
This port address (es) you must now enter in WinPCNC (see 6.1.6).

Quick Start Guide
T-Rex Series
CNC-STEP e.K. ▪Siemensstrasse 13-15 ▪ 47608 Geldern ▪ Germany
Page 20
Support: +49 (0)2831/91021-50
15.01.2015
6.1.5 Determination of the COM interface (Professional)
For all "professional" versions the COM interface must be entered in WinPCNC (s. Page 17).
Some computers have multiple COM interfaces so that the right one first has to be found out. If the
interfaces are not marked on the PC, you need to find out which interface you have connected to the
control.
If the PC has no COM port, it is possible to work with a USB / Serial converter . This adapter then
emulates a COM interface. (see below COM4)
Art. 400305 Digitus DA-70156-VPR2.0 USB to Serial Converter
In the Device Manager of the PC all available interfaces are listed.
Standard interfaces, see Connections
(COM & LPT)
Here you can see, for example, a PC with three COM ports
(COM1, COM2, COM4).
The machine is connected in this case to COM4.
In WinPCNC you must then select COM4 (see 6.1.6).
The COM4 interface is provided via the USB / Serial
converter. This is indicated by the entry USB Serial Port
(COM4).
