CSH-2400W(B)
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
TOTAL NETWORK SOLUTIONS
CSH-2400W – 24 Ports Smart Access Web Management Switch
www.cnetusa.com
The CNet 24port web managed switch is any network administrator’s dream come through. Using this switch along
with the CNet management utility , the whole network of CSH-2400 or any of the CNet web switches are at the finger
tip of the network administrator. Using the browser, all web managed CNet switches are now available for view,
reconfiguration or troubleshooting all at the same time and from a central location.
KEY FEATURES
Up to 24 Port based VLAN groups
Support ToS priority setting
Support QoS priority ratio setting
Independent bandwidth for each port
Store-and-Forward switching technology
Auto MDI/MDIX function supported
IEEE 802.3x Flow-Control supports for Full-Duplex
operation
Back-Pressure function supports for Half-Duplex
operation
PRODUCT SPECIFICATIONS
Model CSH-2400W
Standards 10BASE-T IEEE 802.3
100BASE-TX IEEE 802.3u
IEEE 802.3x Flow Control for Full-Duplex operation
Ports 24x 100BASE-TX/10BASE-T
Media Support
10BASE-T Category 3, 4 or 5 TP
100BASE-TX Category 5 TP
Bandwidth
100BASE-TX - 200/100Mbps
10BASE-T - 20/10Mbps
Forwarding/Filtering
Rate 148,800 packets/second per port @ 100Mbps, max.
14,880 packets/second per port @ 10Mbps, max.
Configuration
Interface
IE Web browser
Auto-MDIX All TP ports support Auto-MDI/MDIX function
LED Indicators One (1) for Power
One (1) per port for Link/ACT
One (1) per port for Full-Duplex or Collision
Power Supply Internal full range switching power supply
Input voltage: 100 ~ 240 +/-10%V AC, 50/60 Hz
Power Consumption 15 watt max.
Environment Operating Temp: 0°~ 45°C (32°~ 113°F)
Storage Temp: -20°~ 70°C (-4°~ 158°F)
Humidity: 10% ~ 90% non-condensing
Dimensions 442 x 185 x 44 mm (17.40 x 7.28 x 1.73 inches)
Ordering Information
Model Description
CSH-2400W (B) 24 Ports Smart Access Web Management Switch
