CNET CSH-2402G Installation instructions

CWR-854(D) April 2005
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
TOTAL NETWORK SOLUTIONS
CSH-2402G – 24 PORT 10/100 + 2 PORT 1000MBPS SMART SWITCH
www.cnetusa.com
This backbone switch provides 24 fixed 10/100Mbps copper ports plus two fixed 1000 Mbps copper giga ports. Each Gigabit port
is equipped with 2000Mbps Bandwidth, Full-duplex, and Collision Free. This model provides perfect bandwidth versatility for
enterprise and high quality networks.
KEY FEATURES
Auto-negotiation, Half-/Full-duplex and Flow-control
for Flexible and Reliable Control on Packet Transaction
Provide Console Port for Easy Configuration
Support Broadcast Storm Filtering Control and
Trunking Function (8 groups) Enhanced Network-wide
Reliability and Efficiency
Support up to 30 VLAN Groups for Port-based VLAN
and 17 for 802.1Q VLAN Tag
Support Per-port Bandwidth Control and Priority Tag
Insert and Remove Function
PRODUCT SPECIFICATIONS
Model CSH-2402G
Standards IEEE802.3: 10 BASE-T
IEEE802.3u: 100 BASE-TX
IEEE802.3ab: 1000 BASE-T
IEEE802.3x: Flow-control
Ports 24 100 Mbps Copper Ports
Two 1000Mbps Copper Ports
Media support 10 Mbps: Category 3, 4 or 5 TP
100/1000Mbps: Category 5 TP
Bandwidth 1000 BASE-T: 20/200/2000Mbps
100 BASE-TX: 10/20/100/200Mbps
Forwarding/Filtering
Rate 1488100 packets/second per port@1000Mbps maximum
148810 packets/second per port@100Mbps maximum
14881 packets/second per port@10Mbps maximum
Duplex Modes Support Auto-negotiation and Auto-MDI/MDI-X functions
LED Indicators One LED displays PWR status
For port 1 to 24 (10/100Mbps ports):
One Yellow/Green LED per port displays
10/100Mbps LINK/ACT status
One LED per port displays FDX/COL status
For port 25, 26 (Copper ports):
One LED per port displays 1000Mbps LINK/ACT status
One Yellow/Green LED per port displays 10/100Mbps LINK/ACT
status
One LED per port displays FDX/COL status
Power Supply Full range Auto-switching
Input voltage: 100~240 +/-10%V AC/50~60Hz
Power Consumption 36.4 Watt maximum
Environment Operating Temperature: -20°~ 70°C (-4°~ 158°F)
Storage Temperature: -40°~ 80°C (-40°~ 176°F)
Humidity: 10% ~ 90% Non-condensing
Certifications CE, FCC
Dimensions 442 x 44 x 185mm (17.4 x 1.73 x 7.28inches)
ORDERING INFORMATION
Model Description
CSH-2402G (F) 24-Port 10/100Mbps Switch with 2 Fixed 1000Mbps Copper Ports
