Co2meter TON-0007 User manual

1
Power supply 24VAC/VDC
Consumption 1.5 W Max ; 0.8 W avg
CO2 sensor Infrared Sensor with lifetime of 15 years
ABC Logic Self Calibration (default: effective)
CO2measuring range 0～2,000ppm
Accuracy@25℃(77℉),2000ppm ±40ppm + 3% of reading or ±75ppm (whichever is greater)
Response time <2 minutes for 90% step change
Warm up time for each turning-on 2 hours (first time) 2 min (operation)
6 LED lights
1st green light on as CO2 measurement≤600ppm
1st and 2nd green lights on as CO2 measurement>600ppm and≤800ppm
1st yellow light on as CO2 measurement>800ppm and≤1,200ppm
1st and 2nd yellow lights on as CO2 measurement>1,200ppm and≤1,400ppm
1st red light on as CO2 measurement>1,400ppm and≤1,600ppm
1st and 2nd red lights on as CO2 measurement>1,600ppm
On/Off output for control CO2 level <240VAC/30VDC 3A switching current (resistance load),
Operation conditions 0~50℃(32~122℉); 0~95%RH, non condensing
Storage conditions 0~50℃(32~122℉);
Dimensions 100mm×80mm×28mm (H X W X D)
Net weight 180g
Installment standard 65mm×65mm (2”×4”) wire box
Housing and protection class PC/ABS fire proof material with IP30
Standard approval CE-Approval
Version TSM-CO2-1A1R-ST02_65 (SE)
Mounting and Wire Connection
Notice the supply power voltage of the detector: 24VAC. Do not install the detector on voltages
higher than marked on the detector.
Firstly, prepare a flat head screwdriver and put it inside of the hole on the top of the detector
housing following step 1, and then open the cover from step 2 to step 4 in next page fig.1.
Mount the wall plate first, dimensions see next page fig. 2.
Connect wires to terminal strips, (see fig. 3).
Follow step 5 to step7 in fig. 4 to close the cover.
Tongdy CO2 Monitor with Relay (TON-0007)
UUsseerrMMaannuuaall
Specifications

Select CO2 level to Control the Relay
The CO2 level for control the relay turning on has been set to 1200ppm. Ifyou need tochange the CO2 level, open the
cover after switch off,you may see two jumpers (J4 and J5) on the top of the circuit board and under the CO2 module. Take
off the CO2 module, you can select the CO2 level to control the relay on /off by jumpers as below table.
CO2 level Relay turns on /turns off
800ppm CO2>900ppm,the relay on; CO2 <700ppm,the relay off
1000ppm CO2>1100ppm, the relay on; CO2 <900ppm, the relay off
J4-disconnect; J5-connect 1200ppm (default) CO2>1300ppm, the relay on; CO2 <1100ppm, the relay off
J4-connect; J5-connect 1400ppm CO2>1500ppm, the relay on; CO2 <1300ppm, the relay off
Connection
Terminal
Function Electrical Data
1 G+ Power (+) 24VAC/VDC +
2 G0 Power ground (-) 24VAC/VDC
4 Ventilator Relay output <240VAC/30VDC 3A switching
current (resistance load)
5Common
2
1
3
4
5
6
7
Fig.4 close the cover
Fig.1 open the cover
60.00
45.00
55.00
28.00
3.00
4.50
8.00
Fig.2 wall plate
Fig.3 wiring diagram
Transformer
24VAC
Line
Voltage
Common
ON
4
1 2 5
J5
J6
J6
jump selection
J5
400ppm
800ppm 1600ppm
1200ppm
J5
J6
J6J5J5 J6
Important Instructions:
1. Don’t shake or hitthe CO2 unit too much in shipment or in mounting to protect the internal infrared CO2
sensor from any damage and excursion of infrared receiver.
2. When open the cover ofthe CO2 unit, you'll see one PCB board mounted over another bigger PCB board. This upper small
PCB board is loaded with CO2 sensor.Don’t uninstall the CO2 module without instruction from our engineers, inorder not
to cause any damage to the CO2 sensor. Please note: the pins on the CO2 module which connect with the bigger PCB
board have direction. Wrong connection will cause the CO2 module and processor damage.
Jumper
J4-connect; J5-dis connect
CO2Meter, Inc.
131BusinessCenterDriveOrmond
Beach,FL32174 USA
[email protected]
[phone] ( Technical Support)
[phone] (Sales)
See CO2Meter, Inc. Terms & Conditions at,
www.CO2Meter.com/pages/terms-conditions
J4-disconnect; J5-disconnect
CONTACT US - We are here to help!
