Coaster 223521KW User manual

ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
223521KW(B1-B3)
REVISION 0 : 11/06/2020
PAGE 1 OF 6 COASTERFURNITURE.COM
California King Bed

ITEM:
223521KW (B1-B3)
ASSEMBLY TIME
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
COASTERFURNITURE.COM
35 MINUTES
PARTS IDENTIFICATION
PAGE 2 OF6
2. This product is for home use only and not intended for commercial establishments.
1. Don't attempt to repair or modify parts that are broken or defective.Please contact the store
immediately.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
2. Please check to see that all hardware and parts are present prior to start of assembly.
1. Remove hardware from box and sort by size.
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS :
WARNING !
B1 (BOX 1)
A HEADBOARD PANEL 1PC
BHEADBOARD TOP DECORATION 1PC
C HEADBOARD SUPPORT 2PCS
D LEFT HEADBOARD LEG 1PC
E RIGHT HEADBOARD LEG 1PC
FEAR PANEL SUPPORT 2PCS
GHEADBOARD SUPPORT PANEL 1 PC
B2 (BOX 2)
H FOOTBOARD PANEL 1PC
B3 (BOX 3)
I BED SLAT 5PCS
J BED SLAT SUPPORT 10PCS
K LEFT BED RAIL 1PC
L RIGHT BED RAIL 1PC
M FOOTBOARD LEG 2PCS

HARDWARE IDENTIFICATION
Z-B3 (BOX 3) - HARDWARE PACK IS LOCATED IN 223521KW (B3)
1ALLEN WRENCH
(Φ6 - BLK) 1PC
2SHORT BOLT
(Φ6 X 30mm - RBW) 4PCS
3MEDIUM BOLT
(Φ6 X 45mm - RBW) 20PCS
4LONG BOLT
(Φ6 X 60mm - RBW) 6PCS
5SHORT FLAT HEAD SCREW
(Φ4 X 16mm - RBW) 4PCS
6MEDIUM FLAT HEAD SCREW
(Φ4 X 32mm - RBW) 10PCS
7LONG FLAT HEAD SCREW
(Φ4 X 45mm - RBW) 4PCS
8LOCK WASHER
(Φ6 - RBW) 20PCS
9SMALL FLAT WASHER
(Φ7 X 19mm X 2.0 - RBW) 20PCS
10 BIG FLAT WASHER
(3/8 x 25 x 1.0 - RBW) 14PCS
11 LEVELER
(M6 x 23mm - RBW) 10PCS
12 WOOL DOWEL
(M8 X 45MM) 4PCS
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
COASTERFURNITURE.COM
PAGE 3 OF 6
ITEM:
2. This product is for home use only and not intended for commercial establishments.
1. Don't attempt to repair or modify parts that are broken or defective.Please contact the store
immediately.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
2. Please check to see that all hardware and parts are present prior to start of assembly.
1. Remove hardware from box and sort by size.
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS :
WARNING !
223521KW (B1-B3)

ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
STEP 3
COASTERFURNITURE.COM
PAGE 4 OF 6
ITEM:
223521KW (B1-B3)

ITEM:
ASSEMBLY INSTRUCTIONS
STEP 4
STEP 5
STEP 6
COASTERFURNITURE.COM
PAGE 5 OF 6
223521KW (B1-B3)

STEP 7
STEP 8
STEP 9
COASTERFURNITURE.COM
PAGE 6 OF 6
ITEM:
ASSEMBLY INSTRUCTIONS
COMPLETE
223521KW (B1-B3)

COASTERFURNITURE.COM
Note : Dimension tolerance ±5%
ITEM:
223521KW (B1-B3)
