ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
REVISION 0: 04/03/2019
650356P
Power Recliner
REVISION 1: 12/30/2019 PAGE 1 OF 3 COASTERFURNITURE.COM
REVISION 2: 09/07/2020

ITEM : 650356P
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior to start of assembly.
3.Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
A BACK 1PC C LEFT EAR 1PC
B BASE 1PC
COASTERFURNITURE .COM
ASSEMBLY TIME 10 MINUTES
PAGE 2 OF 3
D RIGHT EAR 1PC
E POWER CABLE 1PC

ITEM : 650356P
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
STEP 3
COASTERFURNITURE.COM
PAGE 3 OF 3
STEP 4
1066.8mm(42'')
1041.4mm(41'')
1016mm(40")
508mm(20'')
558.8mm(22'')
558.8mm(22'')
673.1mm(26.5'')
635mm(25'')
Note : Dimension tolerance ±5%
1702mm(67'')
1041mm(41'')
(508mm(20'')
737mm(29'')
