Canvas DASHLEY 088-1792-0 User manual

DASHLEY COLLECTION
SWIVEL CHAIR
MODEL N0. 088-1792-0
ASSEMBLY INSTRUCTIONS
Toll-free: 1-866-578-6569
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
Production Number: xxxxxxxx

IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8
MADE IN CHINA

3
TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONS
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembly and using the chair.
~This product is intended for domestic outdoor use only.
~The product should be placed on flat, horizontal ground.
~Any assembly or maintenance of the product must be carried out by adults only.
~Some parts may contain sharp edges. Wear protective gloves if necessary.
~Keep children and pets away while setting up the chair.
~Check all nuts and bolts periodically for tightness. When required, tighten them again.
~Keep the original packaging to store the chair.
3
3
4
5
6-8
9
9
Table of Contents
Important Safety Instructions
Parts List
General Requirements
Assembly
Cleaning and Maintenance
Technical Data
Warranty
10

4MODEL NO. 088-1792-0
PARTS LIST
A
Upper Seat - 1
P31106A06117
Bolt (M8*40) - 4
AA
B
T Seat - 1
P30405A06117
C
Rotating Base - 1
P31207A06117
D
Cushion - 1
P00413H02114
Mat (Ø16*10) - 8 Pre Assemble
BB
Flat Washer (M8) - 4 + 4 Pre Assemble
m
b
l
e
CC
Spring Washer (M8) - 4 + 4 Pre Assemble
DD
Nut (M8) - 4+ 4Pre Assemble
EE
Big Washer (50*25*3) - 4 + 2 Pre Assemble
FF
Bolt (M8*35) - 4Pre Assemble
GG
Wrench (M8) - 2
HH
H01040D11
P91003A07001
H12001D11
H13001D11
H14001D11
P31601A01100
H01035D11
H00001D12

5
IMPORTANT: Please read and understand this manual before any assembly. Before beginning the assembly of
the product, make sure all parts are available. Compare parts with package contents list. If any part is missing,
or if you have any questions,contact the service center at 1-866-578-6569 (toll-free).
Take all parts from the box and position them on a clean floor. Remove all packing materials and place them
backinto the box. Do not dispose of the packing materials until assembly is complete. Read each step carefully
before beginning any assembly and make sure you understand each step.
1 people
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-866-578-6569
If you have questions regarding your product, require warranty assistance,
or have damaged or missing parts, please call our customer service toll-free
helpline.
Contact us for assistance; we’re here to help.
GENERAL REQUIREMENTS

MODEL NO. 088-1792-0
6
STEP 1 : Connecting the Upper
Seat
and the T Seat
A
4x
1x
1x
B
FF
FF
4x
4x
4x
FF
4x
ASSEMBLY

7
STEP 2 : Assembly of the Rotating Base
C
1x
ASSEMBLY

MODEL NO. 088-1792-0
8
STEP 3 : Assembly of the Cushion
DD
1x
ASSEMBLY

CLEANING AND MAINTENANCE
Dimensions (L x W x H)
25.20'' x 23.23'' x 36.81''
64 x 59 x 93.5 cm
Product weight 39 lbs
17.8 Kg
9
Caution!
~Check all screws and nuts periodically for tightness, tightening them again as required.
~Clean the chair with mild soap and water. Rinse thoroughly, and wait until the product
is dry before reassembling it.
~Do not use bleach, acid, or other abrasive cleaners on the chair or frame parts.
TECHNICAL DATA

This CANVAS product carries a five (5) year warranty against defects in
workmanship and materials. Trileaf Distribution agrees to replace a defective
product free of charge within the stated warranty period, when returned by
the original purchaser with proof of purchase. This product is not guaranteed
against wear or breakage due to misuse and/or abuse.
MODEL NO. 088-1792-0
10
WARRANTY
