Coaster 950306 Quick start guide

C O A S T E R F IN E FU RN ITURE
A S S E M B LY IN S T RUC TION
R
2014/06/6
950306
CABINET
www.coastercompany.com
page 1 of 7

PARTS IDENTIFICATION
ASSEMBLY INSTRUCTION
ITEM :
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior to start of assembly.
3.Please follow attached instructions in the same sequence as numbered to assure fast &
easy assembly.
Warning !
1. Don't attempt to repair or modify parts that are broken or defective .Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishment.
Assembly Instruction
R
page 2 of 7
www.coastercompany.com
A
C
E
F
G
H
I
J
K
B
D
950306
L
M
LEFT SIDE FRAME 1PC
MIDDLE FRAME 1PC
RIGHT SIDE FRAME 1PC
BOTTOM PANEL 2PCS
FRONT RAIL 2PCS
BACK RAIL 2PCS
TOP PANEL 1PC
MIRROR PANEL 4PCS
UPPER & LOWER 2PCS
BACK PANEL
MIDDLE BACK PANEL 1PC
RIGHT DOOR 2PCS
LEFT DOOR 2PCS
SHELF 4PCS
N GLASS CLAMP 2PCS

R
7fo3egap
moc.ynapmocretsaoc.www
NOITCURTSNIYLBMESSA
ITEM :
HARDWARE PACKAGE
Q’TY
FIGURE
NO: DESCRIPTION
1
3 22 PCS
4 4 PCS
5 38 PCS
6 4 PCS
7 4 PCS
2 22
950306
WOOD DOWEL
CAM BOLT
CAM LOCK
LONG BOLT
ROUND HEAD SHORT SCREW
SHORT BOLT
KNOB
15 PCS
PCS
8
9
10 16 PCS
8 PCS
4 PCS
56 PCS
8 PCS
HINGE
FLAT HEAD SCREW
SHELF HOLDER
MAGNET
ROUND HEAD LONG SCREW
11
12

R
page 4 of 7
www.coastercompany.com
ASSEMBLY INSTRUCTION
ITEM : 950306
STEP 1:
Use Cam Bolt(2) & Wood Dowel(1) to
Side Panel(A&C) & Middle Panel(B),insert
Cam lock(3) into holes of Bottom(D) & Rail(E&F),
attach Side Panel(A&C) & Middle Panel(B) to
Bottom Panel(D) & Front Rail(E) & Back Rail(F)
with screwdriver,rotate Cam Lock(3) clockwise
to secure Cam Bolt(2).
STEP 2:
Use Cam Bolt(2) & Wood Dowel(1) to
Top Panel(G) ,insert Cam lock(3) into holes
of Side Panel(A&C) & Middle Panel(B),attach
Top Panel(G) to Side Panel(A&C) & Middle
Panel(B) with screwdriver,rotate Cam Lock(3)
clockwise to secure Cam Bolt(2).
Use Long Bolt(4) through Front Rail(E) to
Top Panel(G) with screwdriver,then tighten.
It need two persons and takes about thirty minutes to
assembly the item.

R
page 5 of 7
www.coastercompany.com
ASSEMBLY INSTRUCTION
ITEM : 950306
STEP 3:
Insert Mirror Panel to Glass Clamp,then
into grooves of preassembled unit from
Step 2 back.
STEP 4:
Insert Back Panel(I&J) into grooves
of preassembled unit from Step 3,
tighten Round Head Short Screw(5)
with Phillips screwdriver.
STEP 5:
Use Flat Head Screw(9) through
Hinge(8) to Door(K&L) with screwdriver,
then tighter.
Attach Short Bolt(6) through Door
(K&L) to Knob(7) with screwdriver,
then tighter.

R
page 6 of 7
www.coastercompany.com
ASSEMBLY INSTRUCTION
ITEM : 950306
STEP 6:
Use Flat Head Screw (9) to hinge (8) to
Side Panel (A&C) & Middle Panel(B), tighten
Flat Head Screw (9) with screwdriver.
Use Round Head Long Screw(12) to
Magnet(11) & Top Panel(G) together.
STEP 7:
Insert Shelf Holder(10) to the holes
of Side Panel(A&C) & Middle Panel(C),
then put Shelf Panel(M) on the
Shelf Holder(10).

R
page 7 of 7
www.coastercompany.com
ASSEMBLY INSTRUCTION
ITEM : 950306
STEP 8:
Now your new cabinet to use.
