Coaster 753447 User manual

PAGE 1 OF 3
REVISION 0 : 02/11/2022
COASTERFURNITURE.COM
753447
End Table
Fine Furniture for every stage of life
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE

PAGE 2 OF 3
ITEM: 753447
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
ASSEMBLY TIME
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
15 MINUTES
A TOP 1PC
B PEDESTAL COLUMN
C BASE
1PC
1PC
PARTS IDENTIFICATION
HARDWARE IDENTIFICATION
COASTERFURNITURE.COM
1SHORT BOLT
3SMALL LOCK WASHER
(1/4" - RBW)
6BIG FLAT WASHER
(5/16" - RBW)
7ALLEN WRENCH
(4MM - RBW)
4PCS
4PCS
2PCS
1PC
2LONG BOLT
(5/16" x 2 1/2" - RBW) 2PCS
5BIG LOCK \WASHER
(5/16" - RBW) 2PCS
4SMALL FLAT WASHER 4PCS
(1/4" - RBW)
(5/16" x 1 1/4" - RBW)

ITEM: 753447
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
STEP 3
COMPLETE
COASTERFURNITURE.COM
ITEM:
PAGE 3 OF 3
B
A

NOTE: Dimension tolerance + 5%
ITEM: 753447
COASTERFURNITURE.COM
20.04"
17.24"
22.01"
17.72"
19.69"
