COBHAM D1702 Use and care manual

D17XX OEM Integration v0.1
1
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
1 V1.1v
Mesh D17xx OEM Integration
Document
V0.1
24/04/2015

D17XX OEM Integration v0.1
2
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Table of Contents
Table of Contents ....................................................................................................... 2
Change History .......................................................................................................... 3
Introduction............................................................................................................... 4
Hardware Overview..................................................................................................... 5
PCB Variants ............................................................................................................. 7
Mechanical Design...................................................................................................... 8
Functional Specification .............................................................................................. 9
Connector Pin outs................................................................................................... 11
J1 Aux Power Out ............................................................................................................ 11
J2 Power Input................................................................................................................. 11
J3 RS485 Serial Data Port ................................................................................................ 11
J4 Power to D550 Encoder ............................................................................................... 11
J5 1W Amplifier Power and Enable................................................................................... 12
J6 RF Output.................................................................................................................... 12
J7 RS232 Serial Control ................................................................................................... 12
J8 BDM/JTAG (Reserved)................................................................................................. 12
J9 RS232 to control D550 Encoder................................................................................... 12
J10 Talkback Audio connections...................................................................................... 12
J11 Connections to D550 Encoder ................................................................................... 13
J12 RS232 External Serial Data Ports............................................................................... 13
J13 RTC Battery connector .............................................................................................. 13
J14 External 10/100 Base-T Ethernet Port......................................................................... 13
J15 External Secondary 10/100 Base-T Ethernet Port....................................................... 13
J16 USB connector (Not currently used) .......................................................................... 14
J17 LED Drive .................................................................................................................. 14
J18 Power over Ethernet.................................................................................................. 14
J19 Antenna B (Rx 1)........................................................................................................ 14
J20 SD Card Management................................................................................................ 14
J21 (not on board)............................................................................................................ 15
J22 Antenna A (Tx Rx 0)................................................................................................... 15
J23 (not on board)............................................................................................................ 15
J24 RF Out....................................................................................................................... 15
Mounting Considerations........................................................................................... 16
Heat sinking..................................................................................................................... 16
Connector clearance........................................................................................................ 16
Turning On the System.............................................................................................. 17
1. Test Setup............................................................................................................... 17
2. Initial Setup............................................................................................................. 17
2.1 Setting unit type ............................................................................................17
2.2 Software updates...........................................................................................18
3. Verify the RF RX performance ................................................................................. 18
4. Verify the RF TX performance.................................................................................. 21
5. Spectrum Verification.............................................................................................. 22
6. Set RTC Clock......................................................................................................... 22
7. Ethernet Video Streaming........................................................................................ 23
8. Recording and Playback.......................................................................................... 23
9. Direct connection to PC........................................................................................... 24
10. Serial RS232 Control........................................................................................... 24
RS232 Control –General Principles ............................................................................24
Command Packet Structure........................................................................................24
Reply Packet Structure ...............................................................................................24
Control Commands................................................................................................... 26

D17XX OEM Integration v0.1
3
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Change History
Version
Main Changes from Previous Version
Edited By
V0.1
First Draft
CM 24/05/15

D17XX OEM Integration v0.1
4
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Introduction
This document outlines the hardware integration for the D17XX IP Mesh baseband transceiver card.
The Cobham D17XX PCB is a digital diversity IP Mesh transceiver, designed specifically as the
baseband and IP processing card for the Cobham IP Mesh phase 4 system. The system allows
wireless IP, digital video and audio transmission in mobile, urban and non-line-of-sight scenarios.
Equipped with Ethernet and serial control interfaces, the D17XX is easy to integrate into a larger
system.
The key design criteria for this solution were:
Low power consumption
Small size
Ease of integration
Features include:
2.5MHz / 3MHz / 3.5MHz / 5MHz and 6MHz operating bandwidth modes
Two-way diversity Maximum Ratio Combining for fade and multipath elimination
Internal AES 128 / 256bit encryption (optional)
Twin IP interfaces
Multiple Serial interfaces
SMP connectors for reduced size and ease of connection
Optional Encoder offering very low delay video operation for real time applications
Interfaces for optional 1W amplifier
Talk-back Audio
Micro SD card for 32GB storage
Low power—typically ?W

D17XX OEM Integration v0.1
5
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Hardware Overview
Figure 1: D17XX overview block diagram
Figure 2: D1705 hardware overview

D17XX OEM Integration v0.1
6
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Features of the D17XX board are:
Kintex 7 FPGA and Coldfire microprocessor further reducing power consumption of the unit
and increasing the processing power
Large SDRAM and Flash
Ethernet, RS485 and RS232 capability
Recording to SD card (when optional encoder is fitted)
Talkback Audio facility

D17XX OEM Integration v0.1
7
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
PCB Variants
The frequency selection is provided by the choice of RF card and setting the unit type on the D17XX.
Table 1: D17XX variants (without screen cans)
A number of the boards are available in top-level assemblies.
Table 2: Sub-assemblies featuring D17XX parts (with screen cans)
Product No.
Frequency [MHz]
D1700
200 –300
D1702
300 –470
D1703
450 –600
D1705
1140 –1500
D1707
1980 –2550
D1710
3000 –3700
D1713
4400 –5000
D1715
5500 –6000
Cobham SA Number
Description
SA3024
D1707 OEM AGILE IP MESH, Mk4 (S Band 1.98-2.55GHz) Top Level
Assembly
SA3245
D1705 OEM AGILE IP MESH, Mk4 (L Band 1.14 - 1.5GHz) Top Level
Assembly
SA3334
D1705_D DSTAR OEM Agile IP MESH, MK4 (L Band) Top Level Assembly
SA3453
D1703 OEM Agile IP MESH, MK4, 450-600MHz (UHF Band) Top Level
Assembly
SA3457
D1741 OEM Pavement RF Board (S Band 1.98-2.55GHz) Top Level
Assembly

D17XX OEM Integration v0.1
8
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Mechanical Design
Figure 3: D17XX connectors and heat sinks
Figure 4: D17XX isometric view

D17XX OEM Integration v0.1
9
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Functional Specification
Interfaces
RF Interfaces
(Antenna 1 and 2) SMP
Power JST J2
Ethernet 1 JST J14
Ethernet 2 JST J15
Control and misc. I/O JST J3 (RS485) and JST J12 (RS232)
Camera (A/V) Optional Card –D550
Typical range
S-Band (1W) Non-LoS light urban 500-700m
LoS 40km+
RF Interfaces
Antenna 1 Switched transmit (100mW) & receive antenna
Antenna 2 Receive only antenna
Tuning step size 125kHz step
Output power +20 to -10dBm in 0.25dB steps (100mW variant)
+30 to 0dBm in 0.25dB steps (1W variant)
Bandwidth 2.5, 3.0, 3.5, 5.0, 6.0MHz
Mesh capacity Up to 8 Mb/s
Modulation COFDM 360 carrier modulation
Carrier Modulation BPSK, QPSK or 16QAM (adaptive)
FEC rate FEC 1/2
Receive diversity Maximum Ratio Combining
Receive sensitivity -98dBm for most robust mode
IP interface
Primary & secondary
Ethernet electrical 100BaseT Ethernet
IP address allocation DHCP dynamic IP addressing
Video and audio Multicast VLC compatible
streaming format UDP & RTSP Support
Open Audio comms channel (shared voice channel)
Multi-user audio
comms channel Interface microphone level/headphone o/p
Compression G726 32kbit audio
Encryption
Type AES128 or AES256 (both optional)
GPS
Dedicated GPS I/F RS232/RS485

D17XX OEM Integration v0.1
10
www.cobham.com/domo
Domo Limited doing business as Cobham Surveillance
Data interface
RS232/RS485 data 1K2 to 115K2 baud switchable
With UDP and TCP routing protocol
Control
Local control LEDs power and mesh status
Remote control Mission Commander PC application
Full control of all parameters in a map based application
Web browser control
Physical
Mass 82g
Power
DC input 12-14V
Power consumed 1W Up to 14W max
Environment
Temperature rating -10°C to +50°C
A/V input option
Video input Composite or SDI (selectable)
Video format 525 or 625 (PAL or NTSC)
Video encoding MPEG4
Quality Low/Medium/High (selectable)
Video bit-rate 2.4Mb/s to 50kb/s (variable)
Resolution 704, 576, 480 or 352
Frame rate Self-selecting 30 to 2F/s
Audio input Line level or microphone level
Audio sample freq. 48KHz
Audio encoding MPEG audio layer 1
Audio bit-rate 384 to 64kb/s
Store and forward options*
Storage format SD card interface (Secure Digital card) –optional
Record options Continuous or triggered
Files download From web browser interface (Milestone)
AV clip size 30 seconds
* asterisk means what?
