Cobi Rehab XXL-Rehab Rollator King User manual

XXL-Rehab Rollator King
Strong and functional rollator designed for the bariatric user.
The Rollator King is intended for users weighing up to 325 kg.
The rollator can be used outdoors and indoors in institutions, care centers
and in private homes.
Cobi Rehab and Cobi Rehab’s suppliers comply with UN conventions
on child and forced labor and ILO 029, C132 and C182.
USER MANUAL
Scan or click on the qr code and find
the product on the Danish AssistData.

| 10-2020 User manual XXL-Rehab Rollator King
2
Table of content
1. Safety...............................................................................................................................................................................3
2. General ...........................................................................................................................................................................4
3. Specifications ...............................................................................................................................................................5
4. Using the Rollator King..............................................................................................................................................6
5. Assembling the rollator .............................................................................................................................................6
6. Adjustment ....................................................................................................................................................................7
7. Cleaning and maintenance........................................................................................................................................8
8. Disposal ..........................................................................................................................................................................8
9. Warranty ........................................................................................................................................................................8

| 10-2020 User manual XXL-Rehab Rollator King
3
CAUTION
Do not use the Rollator King without prior thorough instruction by
trained staff or by persons who have received instructions in the use of
the rollator. Improper operation may cause injury to the user.
If the Rollator King is used for persons weighing more than the
maximum user weight, the risk of damaging the Rollator King
increases.
Carefully study these instructions before using the Rollator
King. Pay attention to Safety Instructions indicated by a warning
triangle .
Cobi Rehab accepts no responsibility for damage caused to the
product nor for personal injury caused by improper installation,
assembly or use of the Rollator King.
Contact Cobi Rehab immediately in the case of damaged or missing
parts. Never use your own spare parts.
SAFETY INSTRUCTIONS
Never sit on the rollator and push off with the feet.
Always lock the rollator before sitting down.
Never use the rollator on stairs and escalators.
Never use the rollator as a wheelchair.
Never use the rollator to transport large items. Only items that fit in
the basket.
Never use the rollator on surfaces that slope by more than 3,5 degrees.
Never use the rollator on soft and uneven surfaces.
Always remember to tighten the hand nuts for height adjustment.
Keep both feet on the ground while using the rollator as resting chair.
This prevents the rollator from tipping backwards if the user leans
against the backrest.
1. Safety

| 10-2020 User manual XXL-Rehab Rollator King
4
The following symbols are used in this user manual and/or
on the product label.
Caution!
Declaration of conformity, Medical Device
Regulation, EU 2017/745
IP31
Ingrees Protection Ratings Guide.
Cobi Catalogue number
Serial number
Date of manufacture
Manufacturer
Medical device
Body weight
Consult instructions for use
TBA
To Be Announced
Label on the product is located on the bottom frame.
2. General
The Rollator King should only be used by the
independent user, who are physically and
mentally able to use the rollator safely (e.g. to
walk, steer, brake).
The rollator should only be used on level ground
and accessible terrain, indoors as well as
outdoors.
2.1 Intended use
This user manual contains important information
about using the rollator King. Visually impaired
readers can view the user manual as a PDF file
on
cobirehab.com and enlarge it on-screen as
required.
Information about the product, e.g. safety
instructions or changes to the user manual can be
found on the product page at
cobirehab.com.
2.2 Thank you for choosing a Cobi Rehab® rollator.

| 10-2020 User manual XXL-Rehab Rollator King
5
General
Maximum user weight
325 kg
Total length
850 mm
Total width
710 mm
Width between handles
610 mm
Height adjustable in 2.5 cm intervals
770.5 –990 mm
Seat width
510 mm
Seat depth
350.5 mm
Seat opening
580 mm
Seat height
500 mm
Weight
15.7 kg
Weight capacity in basket
5 kg
Foldable
Yes
Massive wheels
Yes
Frame
Powder-lacquered aluminium
Frame
Flame retardant
Seat and back
Polyurethane
Wheels
8” massive
Expected product life
7 years
ISO classification
ISO 12 06 06 –
11
Risk class
I
UDI-DI
5740000102490
Basic UDI
5740000100007N8
User manuals and product sheets are available on the website and can be scaled up to
large font size for the visually impaired.
The surface temperature of the Rollator King can increase or decrease when exposed to
external sources of heat or cold.
Model
Seat width
Seat opening
Item number
XXL-Rehab Rollator King, including
basket
510 mm
580 mm
0172-050-000
3. Specifications

| 10-2020 User manual XXL-Rehab Rollator King
6
The Rollator King is a strong and functional
rollator intended for bariatric users weighing up
to 325 kg.
Rollator King is used at institutions, care centers
and in private homes.
Always consult a therapist before assigning the
Rollator King to a user.
Any serious incident that has occurred in
connection with the use of the XXL-Rehab
Rollator King should be reported to Cobi Rehab.
4.1 Accidental incident
5. Assembling the rollator
In addition to the rollator, the shipped box also
contains two handles (connected to the rollator
by cables), a basket and a safety backrest.
1. Unfold the rollator.
2. Remove the screws for height adjustment from
the handlebar.
3. Attach the bars to the rollator.
4. Mount the back on the front of the rollator by
pulling upwards on the knobs on the left and
right sides, respectively.
Notice that the knob can be locked to make it
easier to mount the back. This is done by pulling
the knob upwards and turning it a quarter turn.
Remember to loosen the knob again to fasten the
safety back rest.
5. Mount the basket in the front by placing the
two hooks on the upper tube below the seat.
Place the notch on the bottom of the basket on
top of the bottom tube.
6. Adjust the height of the handles to suit the
user.
7. Adjust the brakes.
Do not use the rollator without the safety
backrest.
The safety backrest ensure that the weight is not
positioned too far forward. If the weight it
positioned too far forward, the rollator may tip.
Do not lay or put extra cushions on the
upholstered seat when in use.
4. Using the Rollator King

| 10-2020 User manual XXL-Rehab Rollator King
7
Adjusting the height of the handle
Remove the screw and the height-adjustment
knob from both handles to enable the handles to
move freely up and down.
2. Push the handle up or down until the required
height has been found. Reinsert the screw and
the knob again. Place the bolt on the back side,
so it fits in the hole.
3. Tighten.
Ensure left and right handles are level to avoid
instability problems.
How to fold the rollator
1. Grab the front of the seat (the side closest to
user) with one hand. Hold one of the handles
with the other hand.
2. Lift the seat.
3. The rollator now folds.
To minimize the size of an already folded
rollator, remove the back and basket
Adjustment of the brakes
The rollator can brake in two ways:
1.
Brief stops:
Squeeze each brake handles upwards.
2.
Longer stops:
Push both brake-handles downwards, so they
lock in a “down” position. The handles stay in
this position until they are actively released.
Brake inspection
The brakes are properly set on delivery.
Brake operation, and parking brake should be
checked before every use.
If the parking brake cannot lock or if the brakes
are not working correctly, contact Cobi Rehab
immediately.
Service the brakes every three months.
6. Adjustment
The Rollator King can be transported from one
place to another. Fold the rollator as described
above.
Rollator King cannot be used as a seat in a
motor vehicle.
Rollator King withstands being lifted in the frame,
handles or back rest, but not in the basket.
Contact Cobi Rehab for more information on
transportation or disassembly.
6.1 Transportation
The Rollator King should be stored in the dark
and covered with a sheet or other cover.
The Rollator King should be stored at
temperatures between -10 ° - 50 ° C.
Check regularly that the rollator has not become
wet or damaged during storage.
6.2 Storage

| 10-2020 User manual XXL-Rehab Rollator King
8
The frame, seat handles, and safety backrest is
cleaned with water and a household detergent.
Contact Cobi Rehab for further guidelines on
cleaning and maintenance.
Disinfection
The frame, seat handles, and safety backrest can
be disinfected with ethanol 70-85% or a chlorine
product 1000-1200 ppm.
The upholstered seat and the back rest must be
replaced or thoroughly disinfected when Rollator
King is transferred to a new user. This is done to
avoid cross-contamination and infections.
Local cleaning and disinfection procedures must
always be followed.
7.1 Cleaning and disinfection
Check bolts and nuts every three months.
Retighten them if needed.
Non-compliance with the bolt inspection
guidelines can lead to malfunction.
7.2 Maintenance
Products that can no longer be used are to be
disposed of in a sustainable way. Please contact
the relevant authorities for information on proper
disposal.
Recycling
Parts of the rollator can be reused. Contact Cobi
Rehab for more information.
When delivered, the Rehab Rollator King is free
from defects. Should, contrary to all inspections,
there be any defects or damage to the Rollator
King, please contact Cobi Rehab immediately.
The Rollator King is covered by a 1-year warranty
from the date of purchase. The invoice serves as
warranty certificate.
The warranty does not apply to:
- products whose serial number, batch number
etc. have been removed or considerably
damaged
- products that have been repaired by
unauthorized staff
- normal wear and tear, for example cleaning,
adjustment, lubrication and update of equipment
or parts.
The warranty is void if Cobi Rehab assesses that
the Rollator King has been used for purposes
other than its intended use, for example, if its
weight capacity is exceeded.
In case of incorrect use, both service and spare
parts will be invoiced.
The warranty described above is the only valid
warranty.
Cobi Rehab may not be held liable for damages
of any kind.
Lack of maintenance can damage the product,
shorten the life or affect the performance of the
Rollator King.
9. Warranty
8. Disposal
7. Cleaning and maintenance

| 10-2020 User manual XXL-Rehab Rollator King
9
MANUFACTURER AND DEALER
Cobi Rehab
Fuglebækvej 1D
DK-2770 Kastrup
Danmark
[phone]
cobirehab.com
