Introduction
Thank you for purchasing the Cobra 19 DX IV EU CB Radio
Transceiver. Properly used, this Cobra product will give
you many years of reliable service.
NOTICE!
Before using this transceiver, please check that the radio has been programmed on the
frequency band specications and operating modes allowed by the regulations valid in the
country where the product is used. If not, please proceed to modify the frequency band
programming, as described in this owners manual page 5. This transceiver is programmed
at the factory on the EU frequency band (40 CH AM 4W/40 CH FM 4W).
Customer Assistance
Should you encounter any problems with this product, or not understand
its many features, please refer to this owner’s manual. If you require further assistance after
reading this manual, please contact your local dealer.
This equipment is intended for use in:
For warranty and customer service
information, please go to:
www.cobraeurope.eu
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Caution Warning
Installation Customer
Assistance
Customer Assistance
©2015 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
MOBILE RADIO
19 DX IV EU Printed in China
Part No. 480-526-P
Version L
Owner’s Manual
Nothing Comes Close to a Cobra® English
Nothing Comes Close to a Cobra® English
For more information or to
order any of our products,
please visit our website:
www.cobraeurope.eu
CB Radios
microTALK®Radios
Radar/Laser Detectors
HighGear®Accessories
CobraMarine®VHF Radios
Power Inverters
Accessories
The Cobra line of quality products includes:
AT
BA
BE
BG
CH
CZ
DE
This equipment is intended for use in:
Countries of use
EE
ES
FI
FR
GB
GR
HR
HU
AT Austria
BE Belgium
CY Cyprus
CZ Czech Republic
DE Germany
DK Denmark
EE Estonia
ES Spain
FI Finland
FR France
GB United Kingdom
GR Greece
HU Hungary
IE Ireland
IS Iceland
IT Italy
LT Lithuania
LV Latvia
LI Liechtenstein
LU Luxembourg
MT Malta
NL Netherlands
NO Norway
PL Poland
PT Portugal
SE Sweden
CH Switzerland
SI Slovenia
SK Slovakia
TR Turkey
IE
IS
IT NL
NO
PT
RO
RS
SE
SI
SK
TR
Bulgaria - BG
Bosnia and Herzegovina - BA
Croatia - HR
Macedonia - MK
Romania - RO
Sebia and Montenegro - CS
LT
LV
LU
DK
MK
MT
CY UA
Russia Fed - RU
RU
PL
19DXIVEU_MANL_ENG_vL.indd 17-1 9/24/15 12:14 PM
