Cochlear Osia 2 User manual

© Cochlear Limited, 2023 1
Cochlear™Osia® 2
Sound Processor Kit
User manual
EN-GB English

This guide is intended for recipients and caregivers using
the Cochlear™ Osia®2 Sound Processor as part of the
Cochlear Osia System.
Intended use
The Cochlear Osia System uses bone conduction to transmit
sounds to the cochlea (inner ear) with the purpose of
enhancing hearing. The Osia Sound Processor is intended
to be used as part of the Cochlear Osia System to pick up
surrounding sound and transfer it to the implant through a
digital inductive link.
The Cochlear Osia System is indicated for patients
with conductive, mixed hearing loss and single-sided
sensorineural deafness (SSD). Patients should have sufficient
bone quality and quantity to support successful implant
placement. The Osia System is indicated for patients with up
to 55 dB SNHL.
Cochlear Osia 2 Sound Processor Kit
CONTENTS:
• Osia 2 Sound Processor
• 5 Covers
• Tamper proof tool
• Inner case
2 Cochlear™ Osia®2 Sound Processor Kit User manual

Contraindications
Insufficient bone quality and quantity to support successful
implant placement.
NOTES
Refer to the Cautions and Warnings sections for safety
advice relating to the use of the Osia Sound Processor,
batteries and components.
Please also refer to your Important Information
document for essential advice that applies to your
implant system.
Symbols used in this guide
NOTE
Important information or advice.
TIP
Time saving hint.
CAUTION (no harm)
Special care to be taken to ensure safety and
effectiveness.
Could cause damage to equipment.
WARNING (harmful)
Potential safety hazards and serious adverse
reactions.
Could cause harm to person.
© Cochlear Limited, 2023 3

Contents
Intended use. . . . . . . . . . . . . . . . 2
Symbols used in this guide. . . . 3
Overview. . . . . . . . . . . . . . . . . . . . .5
Use. . . . . . . . . . . . . . . . . . . . . . . . . . 6
Turn on and off . . . . . . . . . . . . . . 6
Change programs . . . . . . . . . . . 6
Adjust volume . . . . . . . . . . . . . . . 7
Power . . . . . . . . . . . . . . . . . . . . . . .8
Batteries. . . . . . . . . . . . . . . . . . . . 8
Battery life . . . . . . . . . . . . . . . . . . 8
Change the battery . . . . . . . . . . 9
Lock and unlock the battery
door . . . . . . . . . . . . . . . . . . . . . . 10
Wear . . . . . . . . . . . . . . . . . . . . . . .11
Wear your sound processor. . 11
For users with two implants . . 11
Attach a Cochlear SoftWear™
Pad . . . . . . . . . . . . . . . . . . . . . . . 12
Attach a Safety Line . . . . . . . . . 14
Wireless accessories . . . . . . . . 20
Made for iPhone. . . . . . . . . . . . 21
Care . . . . . . . . . . . . . . . . . . . . . . . .22
Regular care . . . . . . . . . . . . . . . 22
Water, sand and dirt . . . . . . . . 23
Audio and visual indicators . . . .24
Audio signals. . . . . . . . . . . . . . . 24
Visual signals. . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . .27
Cautions . . . . . . . . . . . . . . . . . . . .29
Warnings . . . . . . . . . . . . . . . . . . .30
For parents and caregivers. . . 30
Processors and parts. . . . . . . . 31
Batteries. . . . . . . . . . . . . . . . . . . 33
Medical treatments . . . . . . . . . 34
Other information. . . . . . . . . . . .34
Physical configuration . . . . . . . 34
Batteries. . . . . . . . . . . . . . . . . . . 35
Materials . . . . . . . . . . . . . . . . . . 35
Implant and sound processor
compatibility . . . . . . . . . . . . . . . 35
Environmental conditions. . . . 35
Product dimensions (Typical
values) . . . . . . . . . . . . . . . . . . . . 36
Operating characteristics . . . . .37
Wireless communication link . .38
Electromagnetic compatibility
(EMC) . . . . . . . . . . . . . . . . . . . . . . .39
Environmental protection . . . . .40
Equipment classification and
compliance. . . . . . . . . . . . . . . . . .40
Certification and applied
standards . . . . . . . . . . . . . . . . . . .42
Privacy and the collection of
personal information . . . . . . . . .43
Product order overview . . . . . . .44
Key to symbols. . . . . . . . . . . . . . .48
Radio symbols . . . . . . . . . . . . . . .49
4 Cochlear™ Osia®2 Sound Processor Kit User manual

Overview
Indicator light
Control button
Microphone
ports
Cover
Front
Battery
door
THIS WAY UP
Back
Attachment
holes for
Safety line
© Cochlear Limited, 2023 5

Use
Turn on and off
Turn on your sound processor by completely closing the
battery door. (A)
Turn off your sound processor by gently opening the battery
door until you feel the first “click.” (B)
A B
Change programs
You can choose between programs to change the way your
sound processor deals with sound. You and your hearing care
professional will have selected up to four preset programs for
your sound processor.
Program 1 . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
Program 2 . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
Program 3 . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
Program 4 . .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..
6 Cochlear™ Osia®2 Sound Processor Kit User manual

These programs are suitable for different listening situations.
Ask your hearing care professional to fill in your specific
programs on the lines provided above.
To change programs, press and release the button on your
sound processor.
If enabled, audio and visual signals will let you know
which program you are using.
Program 1: 1 beep, 1 orange flash
Program 2: 2 beeps, 2 orange flashes
Program 3: 3 beeps, 3 orange flashes
Program 4: 4 beeps, 4 orange flashes
NOTE
You will only hear the audio signal if you are wearing your
sound processor.
Adjust volume
Your hearing care professorial has set the volume level for
your sound processor.
You can adjust the volume level with a compatible Cochlear
remote control, Cochlear Wireless Phone Clip, iPhone, iPad or
iPod touch (See the “Made for iPhone” section on page 21).
© Cochlear Limited, 2023 7

Power
Batteries
The Osia 2 Sound Processor uses a high power 675 (PR44)
zinc air disposable battery designed for hearing implant use.
CAUTION
If a standard 675 battery is used the device will not
function.
Battery life
Batteries should be replaced as needed, just as you would
with any other electronic device. Battery life varies according
to your implant type, the thickness of skin covering your
implant, and which programs you use each day.
Your sound processor has been designed to provide the
majority of users with a full day of battery life when using zinc
air batteries. It will automatically go into sleep mode after you
remove it from your head (~30 seconds). When it is attached
again, it will automatically turn on again within a few seconds.
As sleep mode will still consume some power, the device
should be turned off when not in use.
8 Cochlear™ Osia®2 Sound Processor Kit User manual

Change the battery
1. Hold the sound processor with the front facing you.
2. Open the battery door until it is completely open. (A)
3. Remove the old battery. Dispose of the battery according
to local regulations. (B)
4. Remove the sticker on the + side of the new battery and
let it stand for a few seconds.
5. Insert the new battery with the + sign facing upwards in
the battery door. (C)
6. Gently close the battery door. (D)
A B
CD
© Cochlear Limited, 2023 9

Lock and unlock the battery door
You can lock the battery door to prevent it from opening
accidentally (tamper-proof). This is recommended when the
sound processor is being used by a child.
To lock the battery door, close the battery door and place the
Tamperproof tool into the battery door slot. Slide the locking
pin up into place.
To unlock the battery door, place the Tamperproof tool into
the battery door slot. Slide the locking pin down into place.
WARNING
Batteries can be harmful if swallowed. Be sure to keep
your batteries out of reach of small children and other
recipients in need of supervision. In the event of a battery
being swallowed, seek immediate medical attention at
the nearest emergency centre.
10 Cochlear™ Osia®2 Sound Processor Kit User manual

Wear
Wear your sound processor
Place the processor on your implant with the button/light
facing up and battery door facing down.
CAUTION
It is important to position your processor correctly.
Correct positioning enables its best performance.
For users with two implants
Ask your hearing care professional to mark your sound
processors with coloured stickers (red for right, blue for left)
to make identifying left and right processors easier.
R
L
CAUTION
If you have two implants, you must use the correct sound
processor for each implant.
© Cochlear Limited, 2023 11

NOTE
Your sound processor will be programmed to recognise
the implant’s ID, so it will not work on the wrong implant.
Attach a Cochlear SoftWear™ Pad
The Cochlear SoftWear™ Pad is optional. If you experience
discomfort when wearing your processor, you can attach this
adhesive pad to the back of your processor.
NOTE
You may need a stronger magnet and new feedback
calibration measurement after attaching the Cochlear
SoftWear Pad.
Please contact your hearing care professional if you
experience poor sound or magnet retention.
12 Cochlear™ Osia®2 Sound Processor Kit User manual

WARNING
If you experience numbness, tightness or pain at the
implant site, or develop significant skin irritation, or
experience vertigo, stop using your sound processor
and contact your hearing care professional.
1. Remove any old pad from the processor
2. Peel off the single backing strip on the adhesive side of
the pad. (A)
3. Attach the pad to the back of the processor – press down
firmly. (B, C)
4. Peel off the two semicircle backing covers on the cushion
side of the pad. (D)
5. Wear your processor as usual.
D
AC
B
© Cochlear Limited, 2023 13

Attach a Safety Line
To reduce the risk of losing your processor, you can attach a
Safety Line that clips onto your clothing or hair:
AB
1. Pinch the loop on the end of the line between
your finger and thumb. (A)
2. Pass the loop through the attachment hole
in the sound processor from front to back. (B)
3. Pass the clip through the loop and pull the line tight. (B)
4. Attach the clip to your clothing or hair depending
on the Safety Line design.
NOTE
If you have trouble attaching the safety line, you can
remove the sound processor cover (page 18).
14 Cochlear™ Osia®2 Sound Processor Kit User manual

To attach the Safety Line to your clothes,
use the clip shown below.
1. Lift the tab to open the clip. (A)
2. Place the clip on your clothing and press down to close. (B)
3. Place the sound processor on your implant.
A B
© Cochlear Limited, 2023 15

To attach the Safety Line to your
hair use the below clip.
1. Press up on the ends to open the clip. (A)
2. With the teeth facing up and against your hair, push the
clip up into your hair. (B)
3. Press down on the ends to close the clip. (C)
4. Place your processor on your implant.
ABC
Wear the headband
The Cochlear Headband is an optional accessory that holds
the processor in place on your implant. This accessory is
useful for children or when performing physical activities.
TO FIT THE HEADBAND:
Choose an appropriate size.
Size Circumference Size Circumference
XXS 41–47 cm M 52–58 cm
XS 47–53 cm L 54–62 cm
S 49–55 cm
NOTE
The headband may affect your sound processor’s
performance.
If you notice any change, contact your
hearing care professional.
16 Cochlear™ Osia®2 Sound Processor Kit User manual

LEFT
PROCESSOR
POCKET
RIGHT
PROCESSOR
POCKET
ANTI-SLIP
(for forehead)
VELCRO VELCRO
1. Open the headband and lay it flat on a table with the anti-
slip facing up and the pockets facing away from you.
2. Pull the pocket lining out. (A)
3. Insert your processor in the correct pocket. (B)
- Place the left processor in the left-side pocket, the
right processor in the right-side pocket.
- Ensure the top of the processor is at the top of the
pocket.
- Ensure the side of the processor that fits onto your
implant is facing up towards you.
4. Fold the pocket lining back over the processor.
5. Pick up the ends of the headband and place the anti-slip
section against your forehead.
6. Join the ends behind your head. Adjust so the headband
fits firmly, with your processor over your implant. (C)
7. Press firmly on the ends to ensure they join together.
ACB
© Cochlear Limited, 2023 17

Change the cover
TO REMOVE THE COVER:
1. Open the battery door. (A)
2. Press and lift to remove the cover. (B)
AB
TO ATTACH THE COVER:
1. Place the cover over the front part of the sound processor
base unit. The button should be aligned with the cover
opening.
2. Press down on the cover around the button until you feel
a “click” on both sides of the button. (A)
3. Press down on the cover between microphone ports until
you feel a “click”. (B)
4. Close the battery door. (C)
AC
B
18 Cochlear™ Osia®2 Sound Processor Kit User manual

Change the battery door
1. Open the battery door. (A)
2. Pull the door out of its hinge. (B)
3. Replace the door. Be sure to align the hinge clip
to the metal pin on the processor. (C)
4. Close the battery door. (D)
A
D
C
B
© Cochlear Limited, 2023 19

Flight mode
When boarding a flight, wireless functionality must be
deactivated because radio signals must not be transmitted
during flights.
TO ACTIVATE FLIGHT MODE:
1. Turn off your sound processor by opening the battery door.
2. Press the button and close the battery door at the same
time.
3. If enabled, audio and visual signals will confirm that flight
mode is activated (See the “Audio and visual indicators”
section on page 24).
TO DEACTIVATE FLIGHT MODE:
Turn the sound processor off and then on again (by opening
and closing the battery door).
Wireless accessories
You can use Cochlear wireless accessories to enhance
your listening experience. To learn more about the options
available, ask your hearing care professional or visit
www.cochlear.com.
20 Cochlear™ Osia®2 Sound Processor Kit User manual
